Rev 2.0 – April 2011 – CPU-1474/84_UserMan_En_2.0
USER MANUAL
CPU-1474/84
Rugged Pentium M/Celeron M PC/104-
Plus CPU Module
with Gigabit Ethernet and 4 USB 2.0 ports
www.eurotech.com

CPU-1474/84 User Manual
© 2011 Eurotech
Trademarks
All trademarks both marked and unmarked appearing in this document are the property of their
respective owners.
Revision history
Revision
Description
Date
1.0 First release February 2008
1.1 •Updated layout
•Updated J20 pinout
•Inserted warning & note on page 27
November 2008
2.0 Complete manual review April 2011

Table of contents
3
Table of contents
Trademarks.................................................................................................................................................... 1
Revision history.............................................................................................................................................. 2
Table of contents............................................................................................................................................. 3
Important user information............................................................................................................................. 5
Alerts that can be found throughout this manual ........................................................................................... 5
Safety notices and warnings.......................................................................................................................... 6
Life support policy.......................................................................................................................................... 8
Warranty......................................................................................................................................................... 8
CE notice........................................................................................................................................................ 8
WEEE............................................................................................................................................................. 8
RoHS.............................................................................................................................................................. 8
Technical assistance...................................................................................................................................... 9
Product overview........................................................................................................................................... 10
Product definition ......................................................................................................................................... 11
Related products available:.......................................................................................................................... 11
Product Layout .............................................................................................................................................. 12
Processor module connectors ..................................................................................................................... 12
Carrier module connectors, jumpers and LED indicators............................................................................ 12
Processor module connectors..................................................................................................................... 13
J5’: LVDS video output for TFT-LCD displays............................................................................................. 13
J6’: LVDS Clock/Data................................................................................................................................... 13
Carrier module connectors........................................................................................................................... 14
J1, J2 and J3: Buses for PC/104-Plus connectivity..................................................................................... 14
J4: Multifunction and VGA............................................................................................................................ 16
J5: IDE.......................................................................................................................................................... 18
J21: IDE LED ............................................................................................................................................... 19
J7: USB 2.0 ports 2 and 3............................................................................................................................ 20
J9: Auxiliary power....................................................................................................................................... 21
J14: USB 2.0 Ports 0 and 1, and Audio-CODEC......................................................................................... 22
J16: Gigabit Ethernet ................................................................................................................................... 23
J17: Serial ports 1 and 2.............................................................................................................................. 24
J20: Fast Ethernet........................................................................................................................................ 25
Install the CPU-1474/84................................................................................................................................. 27
Stacking the CPU-1474/84 with other PC/104 and PC/104-Plus devices................................................... 27
Configure the CPU-1474/84: the Setup Utility............................................................................................. 29
The Main menu ............................................................................................................................................ 29
The Advanced menu.................................................................................................................................... 31
The Security menu....................................................................................................................................... 36
The Boot menu............................................................................................................................................. 37
The Exit menu.............................................................................................................................................. 38
Configure the Watchdog timer..................................................................................................................... 41

CPU-1474/84 User Manual
4
CPU-1474/84_UserMan_En_2.0
Physical characteristics................................................................................................................................ 43
Operating characteristics ............................................................................................................................. 43
Environmental specifications........................................................................................................................ 43
MTBF (Mean Time Between Failures)......................................................................................................... 43
Mechanical characteristics........................................................................................................................... 44
Appendix: Note about memory and I/O maps............................................................................................. 46
Eurotech worldwide presence...................................................................................................................... 47

Important user information
5
Important user information
Please carefully read and understand the instructions in this manual before using the
CPU-1474/84.
Whenever you have any doubt regarding the operation of this device, consult this manual or contact
the Eurotech Technical Support Team.
Keep this manual for future reference.
In order to lower the risk of personal injury, electric shock, fire or damage to equipment, you
must observe the following precautions, as well as using good technical judgment, whenever
installing or using the device.
Eurotech Spa. (Eurotech) has made every effort to ensure the accuracy of this document; however,
Eurotech assumes no liability resulting from any error/omission in this document, or from the use of the
information contained herein.
Eurotech reserves the right to revise this document or to make changes to its content at any time
without any obligation to notify any person of such revision or changes.
Alerts that can be found throughout this manual
The following alerts indicate potentially dangerous situations:
SYMBOL MEANING
DANGER!
Information highlighting potential electrical shock hazards:
•Personal injury or death could occur.
•Damage to the system, connected peripheral devices, or software could occur.
Appropriate safety precautions should always be used; these should meet the requirements set out for the
environment that the equipment will be deployed in.
WARNING!
Information highlighting potential hazards:
•Personal injury or death could occur.
•Damage to the system, connected peripheral devices, or software could occur.
Appropriate safety precautions should always be used; these should meet the requirements set out for the
environment that the equipment will be deployed in.
NOTE
These will highlight important features or instructions.

CPU-1474/84 User Manual
6
CPU-1474/84_UserMan_En_2.0
Safety notices and warnings
Observe the following safety precautions during all phases of operation, service, and repair of the
device. Failure to comply with these precautions or with specific warnings elsewhere in this manual
violates safety standards of design, manufacture, and intended use of the device.
Eurotech assumes no liability for the customer’s failure to comply with these requirements.
The safety precautions listed below represent warnings of certain dangers of which Eurotech is aware.
You, as the user of the device, should follow these warnings and all other safety precautions
necessary for the safe operation of the device in your operating environment.
Do not operate in an explosive atmosphere
WARNING!
Do not operate the equipment in the presence of flammable gases or fumes. Operation of any
electrical equipment in such an environment constitutes a definite safety hazard.
Antistatic precautions
WARNING!
To avoid ESD (Electro Static Discharge) damage, always use appropriate antistatic precautions
when handing any electronic equipment.
Connection to power supply or other devices
DANGER!
Before applying power to the system, thoroughly review all installation, operation, and safety
instructions.
Failure to install the system power supply correctly or to follow all operating instructions correctly
may create an electrical shock hazard, which can result in personal injury or loss of life, and/or
damage to equipment or other property
•To avoid injuries, always disconnect power and discharge circuits before touching them.
•Only start the device with a power supply that meets the requirements stated on the voltage
label. In case of uncertainties about the required power supply, please contact the Eurotech
Technical Support Team or the electricity authority
•Before connecting other equipment carefully read any supplied instructions
•Always disconnect the power before connecting or disconnecting cables
•Do not perform connections with wet hands
•Check any power cords for damage before use
•Use certified power cables. The power cable must meet the requirements (voltage and
current) of the device.
•Position cables with care. Avoid positioning cables in places where they may be trampled on
or compressed by objects placed on them. Take particular care of the plug, power-point and
outlet of power cable
•Avoid overcharging any power outlets
•Only apply power to the device or connected equipment after checking that all the above
conditions have been met

Important user information
7
Installation
WARNING!
•Verify that the mounting location can withstand the added loads caused by the addition of the device, it
should be firmly secured so that it will not cause any potentially hazardous situations (e.g. falling down
due to vibration or shock)
•Do not operate the device near heat sources or flames.
NOTE:
If the device must be moved from one place to another with different ambient temperatures, ensure sufficient
time for the temperature of the device to stabilize before repowering.
Ventilation
WARNING!
Ensure adequate ventilation to avoid overheating, Eurotech suggests the following steps:
•When installing the device within a cabinet, rack or other enclosed space, be sure to leave sufficient
space to allow adequate air circulation
•Do not block any ventilation openings
Maintenance
DANGER!
•Never open, dismantle or repair the device!
•For your maintenance or repair requirement please contact a qualified Eurotech engineer.
If the device does not function correctly and you are unable to find a solution, feel free to contact
the Eurotech Technical Support Team.
If the equipment does not work properly, especially if smells unusual, unplug it immediately and
contact Technical Support Eurotech (see third and fourth cover of this manual for details).
Cleaning
WARNING!
When cleaning the device, remember to:
•Ensure sufficient ESD protection during the cleaning process.
•Remove any power from the device.
•When cleaning an enclosed system or peripheral use a dry cloth on the external casing.
•With single boards, use only a low power air brush or soft bristled paintbrush.
•Do not use detergents, aerosol sprays, solvents or abrasive sponges.

CPU-1474/84 User Manual
8
CPU-1474/84_UserMan_En_2.0
Life support policy
WARNING!
Do not use Eurotech products as critical components of life support devices or systems without the
express written approval of Eurotech Spa.
Warranty
Please contact your local Eurotech Sales Office for detailed warranty terms and conditions.
Refer to the back covers of this manual for full contact details.
CE notice
This product has the CE labelling in accordance with the 1999/5/EC regulations.
Eurotech shall not be liable for use of its products with equipment (i.e. power supplies,
personal computers, etc.) that are not CE marked.
WEEE
The information below complies with the regulations set out in the 2002/96/EC directive, subsequently
superseded by 2003/108/EC. It refers electrical and electronic equipment and the waste management
of such products.
When disposing of a device, including all of its components, subassemblies and materials that are an
integral part of the product, you should consider the WEEE directive.
The use of the following symbol, attached to the equipment, packaging, instruction
literature, or the guarantee sheet, states that the device has been marketed after August
13th 2005, and implies that you must separate all of its components when possible, and
dispose of them in accordance withal waste disposal legislations:
•Because of the substances present in the equipment, improper use or disposal of the refuse can
cause damage to human health and the environment.
•With reference to WEEE, it is compulsory not to dispose of the equipment with normal urban refuse;
an arrangement for separate collection and disposal is essential.
•To avoid any possible legal implications contact the local waste collection body for full recycling
information.
RoHS
This device, including all the components, subassemblies and the consumable materials that are an
integral part of the product, have been manufactured in compliance with the European directive
2002/95/EC known as the RoHS directive (Restrictions of the use of certain Hazardous Substances).
This directive targets the reduction of certain hazardous substances previously used in electrical and
electronic equipment (EEE).

Important user information
9
Technical assistance
For any technical questions, or if you cannot isolate a problem with your device, or for any enquiry
about repair and returns policies, feel free to contact your local Eurotech Technical Support Team.
See the back cover for full contact details.
Transportation
When transporting any module or system, for any reason, it should be packed using anti-static material
and placed in a sturdy box with enough packing material to adequately cushion it.
Warning:
Any product returned to Eurotech that is damaged due to inappropriate packaging will not be
covered by the warranty!
Product labelling
Product serial number
On the external side of the PCI Bus connector you
will find a label displaying the device serial number
(i.e.: 148400223; this example refers to the entire
CPU device: CPU-1484).
Carrier module serial number
On the inner side of the PCI Bus connector you will
find a label displaying the carrier module serial
number (i.e.: 370600878; this example refers to the
carrier section, Gigabit or USB).
Processor module serial number
On the top of the thermal interface you will find a
label displaying the processor module serial number
(i.e.: 890600037; this example refers to the
processor module section).
Figure 1. Labels location

CPU-1474/84 User Manual
10
CPU-1474/84_UserMan_En_2.0
Product overview
The CPU-1474 and CPU-1484 are two embedded RoHS compliant boards based on a processor
module combined with a PC/104-Plus form factor carrier module.
In the CPU-1474 the processor module features the Intel® Celeron® M 1 GHz processor
In the CPU-1484 the processor module features the Intel® Pentium® M 1.4 GHz processor.
Both the CPU-1474 and CPU-1484 feature an Intel® i855GME chipset and come with 512 MB DDR,
266 MHz (PC2100), soldered on-board.
The carrier module implements all the connections to the external world (including Gigabit Ethernet
and 4 USB 2.0 ports), except for the LCD connection that is available on the processor module.
Processor Module
Carrier Module
Thermal interface

Product overview
11
Product definition
Feature Description
Processor
CPU-1474:
Intel® Celeron® M 1 GHz, 512 KB L2 cache, 400 MHz FSB
CPU-1484:
Intel® Pentium® M 1.4 GHz, 2MB L2 cache, 400 MHz FSB
Chipset Intel® i855GME
Memory
512MB DDR, 266 MHz (PC2100), soldered on-board
BIOS Flash 1MB Flash EPROM
Interfaces •IDE Controller Ultra DMA
•Serial ports:
o1x RS-232
o1x RS-232/422/485 (Selectable in BIOS)
•4x USB 2.0 ports
•Gigabit Ethernet (1000 Mbps)
•Ethernet (10/100 Mbps)
•Video Controllers:
oAnalog VGA output
oDigital LVDS output
•Auxiliary Power Input
•AC97 audio
•
Keyboard and Mouse
Architecture PC/104-Plus compliant
Bus •PC/104-Plus (PCI)
•PC/104 (ISA)
Supported flat panel modes Several flat panel display modes are supported up to a resolution of:
1024x768 at 60 Hz, 24 bits per pixel
Watchdog 2 to 255 seconds / minutes
Power Supply Nominal: 5.00 V (with tolerance +/-5%)
Power Consumption
CPU-1474:
•Typical: 9.5 W
•Maximum: 13.5 W
CPU-1484:
•Typical: 14.5 W
•
Maximum: 18.5 W
Supported Operating
Systems: •Windows CE®
•Windows XP Embedded®
•
Linux®
Options •Custom BIOS with embedded features
•Extended operating temperature range (- 40 to +85 °C)
•Custom carrier
•Conformal coating
•Custom connectors
RoHS Fully RoHS (2002/95/CE) Compliant
Related products available:
Product
Reference document
ACS-9092-00: Two 2-Port USB Adaptors
Technical Datasheet Td0001
ACS-9095-05: 10/100 Ethernet Adaptor
Technical Datasheet Td0004
CBL-1454-00: Cable-Set for the CPU-1454, CPU-1464, CPU-1474 & CPU-1484
Technical Datasheet Td0026
ACS-9096-00: Gigabit Ethernet Adaptor
Technical Datasheet Td0027
ACS-9093-01: AC97 Audio CODEC
Technical Datasheet Td0028
ACS-9031-00: Digital LCD/TFT LVDS Adapter Kit
Technical Datasheet Td0036

CPU-1474/84 User Manual
12
CPU-1474/84_UserMan_En_2.0
Product Layout
Processor module connectors
Conn #
Usage
Type
Pins
Format
Pitch (mm)
Manufacturer
Part Number
J5’ LVDS SIL 20 20x1 1.00 Hirose DF19G-20P-1H(56)
J6’ LVDS Clock / Data SIL 3 3x1 1.25 Molex 53261-0371
J7’ Reserved SIL 3 3x1 1.25 Molex 53261-0371
Carrier module connectors, jumpers and LED indicators
Conn # Usage Type Pins Format Pitch (mm) Manufacturer Part Number
J1 ISA Bus (bottom side only) Strip 64 32x2 2.54 Ept 972-32011-21
J2 ISA Bus (bottom side only) Strip 40 20x2 2.54 Ept 972-20011-21
J3 PCI Bus (bottom side only) Strip 120 30x4 2.00 Ept 272-30000-31
J3 PCI Bus (bottom side only) Shroud - - - Ept 264-17302
J4 Multifunction and VGA Minitek 18 9x2 2.00 Fci 98464-F61-18ULF
J5 IDE Strip 44 22x2 2.00 Adimpex IR002644-R
J7
USB 2.0 ports 2 and 3 SIL 8 8x1 2.00 JST S8B-PH-K-S(LF)(SN)
J9 Auxiliary power Strip 12 6x2 2.54 Adimpex ISO08880-R
J14 USB 2.0 ports 0 and 1;
Audio-CODEC Minitek 20 10x2 2.00 Fci 98464-F61-20ULF
J16 Gigabit Ethernet Minitek 16 8x2 2.00 Fci 98464-F61-16ULF
J17
Serial Ports 1 and 2 Minitek 18 9x2 2.00 Fci 98464-F61-18ULF
J20 Fast Ethernet SIL 8 8x1 2.00 JST S8B-PH-K-S(LF)(SN)
J21 IDE LED Strip 2 2x1 2.00 Adimpex IR002540-R
Jumper #
Usage
LED #
Usage
Type
JP2 Reserved. Default: open D10 Vcc +3.3 V present Green LED

Processor module connectors
13
Processor module connectors
The processor module features the J5’ and J6’ connectors for interfacing TFT-LCD displays.
J5’ and J6’ are located on the bottom side of the processor module
J5’: LVDS video output for TFT-LCD displays
Pin # Signal Function
1
Vcc +3.3V
Power supply to LCD
2
Vcc +3.3V
Power supply to LCD
3 GND Ground
4
GND
Ground
5
LVDS_A0M
Negative LVDS differential data output 0
6
LVDS_A0P
Positive LVDS differential data output 0
7
GND
Ground
8
LVDS_A1M
Negative LVDS differential data output 1
9
LVDS_A1P
Positive LVDS differential data output 1
10
GND
Ground
11
LVDS_A2M
Negative LVDS differential data output 2
12 LVDS_A2P Positive LVDS differential data output 2
13
GND
Ground
14 LVDS_CLK1M Negative LVDS differential clock output
15
LVDS_CLK1P
Positive LVDS differential clock output
16
GND
Ground
17
LVDS_A3M
Negative LVDS differential data output 3
18
LVDS_A3P
Positive LVDS differential data output 3
19
DDCPCLK
Panel DDC Clock
20
DDCPDATA
Panel DDC Data
J6’: LVDS Clock/Data
Pin #
Signal
Function
1
DDCPCLK
Panel DDC Clock
2 DDCPDATA Panel DDC Data
3
GND
Ground
PCI BUS

CPU-1474/84 User Manual
14
CPU-1474/84_UserMan_En_2.0
Carrier module connectors
J1, J2 and J3: Buses for PC/104-Plus connectivity
The ISA Bus (J1 and J2) and the PCI Bus (J3) connectors are located on the bottom side of the carrier
module only. They are designed to allow the connection of the product on the top position of the stack.
ISA BUS
Figure 2. J1 and J2 connector layout (bottom side)
J1
Pin # Signal Pin # Signal
B1 GND A1 IOCHK#
B2 RSTDRV A2 SD7
B3 VDD A3 SD6
B4 IRQ9 A4 SD5
B5 -5V A5 SD4
B6 DRQ2 A6 SD3
B7 -12V A7 SD2 J2
B8 ZEROWS# A8 SD1 Pin # Signal Pin # Signal
B9 +12V A9 SD0 C1 GND D1 GND
B10 GND/KEY A10 IOCHRDY C2 SBHE# D2 MEMCS16#
B11 SMEMW# A11 AEN C3 LA23 D3 IOCS16#
B12 SMEMR# A12 SA19 C4 LA22 D4 IRQ10
B13 IOW# A13 SA18 C5 LA21 D5 IRQ11
B14 IOR# A14 SA17 C6 LA20 D6 IRQ12
B15 DACK3# A15 SA16 C7 LA19 D7 IRQ15
B16 DRQ3 A16 SA15 C8 LA18 D8 IRQ14/ROMCS#
B17 DACK1# A17 SA14 C9 LA17 D9 DACK0#
B18 DRQ1 A18 SA13 C10 MEMR# D10 DRQ0
B19 REFRESH# A19 SA12 C11 MEMW# D11 DACK5#
B20 SYSCLK A20 SA11 C12 SD8 D12 DRQ5
B21 IRQ7 A21 SA10 C13 SD9 D13 DACK6#
B22 IRQ6 A22 SA9 C14 SD10 D14 DRQ6
B23 IRQ5 A23 SA8 C15 SD11 D15 DACK7#
B24 IRQ4 A24 SA7 C16 SD12 D16 DRQ7
B25 IRQ3 A25 SA6 C17 SD13 D17 VDD
B26 DACK2# A26 SA5 C18 SD14 D18 MASTER#
B27 TC A27 SA4 C19 SD15 D19 GND
B28 BALE A28 SA3 C20 GND/KEY D20 GND
B29 VDD A29 SA2
B30 OSC A30 SA1
B31 GND A31 SA0
B32 GND A32 GND
Table 1. J1 and J2 connector pinout (bottom side)

Carrier module connectors
15
PCI BUS
Figure 3. J3 connector layout (bottom side)
Pin # Signal Pin # Signal Pin # Signal Pin # Signal
D1 AD0 C1 VDD B1 NC A1 GND
D2 VDD C2 AD1 B2 AD2 A2 VDD (JPR1)
D3 AD3 C3 AD4 B3 GND A3 AD5
D4 AD6 C4 GND B4 AD7 A4 C/BEO#
D5 GND C5 AD8 B5 AD9 A5 GND
D6 M66EN C6 AD10 B6 VDD(JPR1) A6 AD11
D7 AD12 C7 GND B7 AD13 A7 AD14
D8 NC (JPR1) C8 AD15 B8 C/BE1# A8 NC (JPR1)
D9 PAR C9 NC B9 GND A9 SERR#
D10 NC C10 NC (JPR1) B10 PERR# A10 GND
D11 GND C11 PLOCK# B11 NC (JPR1) A11 STOP#
D12 DEVSEL# C12 GND B12 TRDY# A12 NC (JPR1)
D13 NC (JPR1) C13 IRDY# B13 GND A13 FRAME#
D14 C/BE2# C14 NC (JPR1) B14 AD16 A14 GND
D15 GND C15 AD17 B15 NC (JPR1) A15 AD18
D16 AD19 C16 GND B16 AD20 A16 AD21
D17 NC (JPR1) C17 AD22 B17 AD23 A17 NC (JPR1)
D18 IDSEL2 (AD18) C18 IDSEL1 (AD17) B18 GND A18 IDSEL0 (AD16)
D19 IDSEL3 (AD19) C19 VDD (JPR1) B19 C/BE3# A19 AD24
D20 GND C20 AD25 B20 AD26 A20 GND
D21 AD27 C21 AD28 B21 VDD A21 AD29
D22 AD31 C22 GND B22 AD30 A22 VDD
D23 VDD(JPR1) C23 REQ1# B23 GND A23 REQ0#
D24 GNT0# C24 VDD B24 REQ2# A24 GND
D25 GND C25 GNT2# B25 VDD(JPR1) A25 GNT1#
D26 CLK1 C26 GND B26 CLK0 A26 VDD
D27 GND C27 CLK3 B27 VDD A27 CLK2
D28 RST# C28 VDD B28 INTD# A28 GND
D29 INTC# C29 INTB# B29 INTA# A29 +12V
D30 GND C30 GNT3# B30 REQ3# A30 -12V
Table 2. J3 connector pinout (bottom side)

CPU-1474/84 User Manual
16
CPU-1474/84_UserMan_En_2.0
J4: Multifunction and VGA
The VGA output can drive a progressive scan analog monitor with pixel resolution up to 1600x1200 at
85-Hz refresh and up to 2048x1536 at 75-Hz refresh.
Figure 4. J4 connector layout
Pin # Signal Function Pin # Signal Function
1 GND_SRV
Multifunction
2 VDD_SRV (+5V)
Multifunction
3 KBDAT 4 KBCLK
5 MSDAT 6 MSCLK
7 BAT_IN 8 SPKR
9 RES_PB_IN 10 GND_VGA
VGA
11 HSYNC
VGA
12 VSYNC
13 RED_VGA 14 GREEN_VGA
15 DDC1_SCL 16 DDC0_SDA
17 GNDA_VGA 18 BLUE_VGA
Table 3. J4 connector pinout
J4: Multifunction section
This section of the J4 connector implements the following functions:
Keyboard section: connection interface for an AT compatible keyboard
Pin #
Signal
Function
1 GND Ground signal
2 +5V Power supply
3 KBDAT Keyboard data
4
KBCLK Keyboard clock
Mouse section: connection interface for a Ps/2 compatible mouse
Pin #
Signal
Function
1 GND Ground signal
2
+5V Power supply
5 MSDAT Mouse data
6 MSCLK Mouse clock

Carrier module connectors
17
System reset
Connecting pin #9 to ground will perform a hardware reset of the CPU-1474/84.
You can use an external push-button (normally open) to manually reset the system.
The reset signal is “de-bounced” on-board.
External battery
An external (backup) battery is required to preserve Real Time Clock data when the CPU-1474/84 is
powered down.
Pin #7 allows the connection of an external battery.
The battery voltage must be between 3.0 V and 3.9 V.
Typical power consumption with the module off is 7 uA.
Speaker
A transistor that supplies 0.1W to an external speaker controls the signal output available on Pin #8.
A transistor amplifier buffers the speaker signal. Use a small general-purpose 2” or 3” permanent
magnet speaker with an 8-Ohm voice coil. The audio output is based on two signals: one come from
the output of Timer 2, and the other come from I/O port 61h compliant with the AT Standard.
The Eurotech multifunction adaptor
The Eurotech multifunction adaptor simplifies the connection of keyboard and mouse to the CPU-
1474/84
Furthermore it includes the following features:
•backup battery
•speaker
•reset button.
Please refer to the Technical Datasheet Td0026 (http://www.eurotech.com/DLA/AN/Td0026.pdf) for
further information.

CPU-1474/84 User Manual
18
CPU-1474/84_UserMan_En_2.0
J5: IDE
J5 provides an interface for up to two Integrated Device Electronics (IDE) hard disk drives.
Figure 5. J5 connector layout
Pin #
Signal
Pin #
Signal
1
RESET #
2
GND
3 DD7 4 DD8
5
DD6
6
DD9
7 DD5 8 DD10
9
DD4
10
DD11
11 DD3 12 DD12
13
DD2
14
DD13
15
DD1
16
DD14
17
DD0
18
DD15
19
GND
20
[KEY]
21 DMARQ 22 GND
23
DIOW #
24
GND
25 DIOR # 26 GND
27
IORDY
28
CSEL
29 DMACK # 30 GND
31
INTRQ
32
IOCS16 #
33 DA1 34 PDIAG #
35
DA0
36
DA2
37
CS1#
38
CS3#
39
DASP #
40
GND
41
VDD (+5V)
42
VDD (+5V)
43 GND 44 NC
Table 4. J5 Connector pinout
To install the hard disk, perform the following operations:
1. Install the hardware
Connect the hard disk to the module using a data cable, and then connect the hard disk to the
power supply according to the device’s specifications. Make sure that pin 1 of connector J5 and
pin 1 of the drive or drives are correctly connected. Pin 1 of the interface cable is usually indicated
by a stripe along the edge of the cable. If two hard disks need to be connected, they must be
configured for common operation (i.e. master/slave or cable select connection)
2. Configure the IDE BIOS setup
Hard disk parameters can be configured using the Setup program. If the hard disk is connected to
the module without the correct setup configuration (BIOS or Hardware), a time-out of a few
minutes may occur
3. Perform a software initialization (for specific operating systems)
Refer to the OS documentation

Carrier module connectors
19
The Eurotech CBL-1454-00 cable set
The Eurotech CBL-1454-00 cable set contains the right IDE cable that allows you to connect up to 2
IDE devices to a Eurotech CPU module.
Please refer to the Technical Datasheet Td0026 (http://www.eurotech.com/DLA/AN/Td0026.pdf) for
further information.
J21: IDE LED
J21 allows you to connect a LED for signalling activity on the IDE BUS.
Figure 6. J21 connector layout
Pin Signal
1
IDE LED anode
2 IDE LED cathode
Table 5. J21 Connector pinout
