Eurotops Versand EP614 User manual

1
EP614
PORTABLE RADIO WITH MOTION DETECTOR
INSTRUCTIONS FOR USE
Please read this manual carefully before using the device for the
first time and keep it for future reference if necessary.
GENERAL SAFE Y INS RUC IONS
•his device can be used by children aged 8 years or
older and by persons with reduced physical,
sensory, or mental abilities or lacking experience or
knowledge, provided they are supervised or have
received instructions for using the device safely and
understand the hazards involved.
•Children must not use the device as a toy.
- For indoor use only.
- The device must not be exposed to splashes or no objects filled with liquids, such as
vases, must be placed on the device.
SAFETY INSTRUCTIONS
•Do not use the radio for a use other than that intended.
•Before connecting the radio to the power supply, check that the voltage indicated on the rating
plate corresponds to the mains supply.
•Always connect your device to a power outlet that is easily accessible.

2
•When you disconnect the power cable, always pull it by the plug. Do not pull on the cable
itself.
•Do not wrap the cord around the device and do not twist it.
•Never immerse the device, power cable or plug in water or any other liquid.
•Do not handle the device or cable with wet hands.
•It is recommended to regularly examine the device. Do not use the device:
- If the plug or power cable is damaged,
- If the device has been damaged in any way,
- If it has dropped.
•Always disconnect the power cord of the device in the following cases:
- At the end of each use
- Before any maintenance
- In case of failure or malfunction
- In case of prolonged non-use
•Never attempt to repair the device yourself. If it is damaged, it must be repaired by a qualified
technician or a specialised workshop in order to avoid any danger.
•Use only the accessories supplied with the device.
•Keep away from heat sources, direct sunlight, moisture, high temperatures, water or other
liquids.
•Do not expose the radio to shocks or violent falls.
•Do not modify, disassemble or puncture.
•Do not attempt to repair the radio. All repairs must be performed by a qualified technician.
PRODUCT DESCRIPTION
Top view
Front view
1. Telescopic antenna
2. Volume button
3. Frequency selection button
4. Tuning knob
5. AUX plug
6. 5V DC plug (not supplied - See
specifications in section below:
“Technical Specifications”)
7. MODE button (radio only or AUX -
Off - radio with motion detector)
8. Plug for the power adapter (back
of the device)
9. Power indicator
TECHNICAL SPECIFICATIONS
The radio can be switched on by 2power sources of choice:
1) By plugging the mains power cable (included) into the "AC IN” power socket (8), on the
back of the radio. Notes:
- The cable is located inside the battery compartment.

3
- The power indicator (9) only lights up when the power adapter is plugged in. It does not light up when
the radio is powered by batteries.
2) After you have inserted 2 D/ LR20 batteries (not included), 1.5V each.
Technical specification details
•230V 50Hz 1.5W
•Or 2 D/ LR20 batteries, 3V
•Frequency bands:
- FM: 88-108 MHz
- AM: 530-1600 KHz
- SW: 8 -18 MHz
Technical specifications for 5V mains power adapter
•Input: 220-240V 50Hz 0.15A
•Output: 5V 500 mA
•Tip type: female
•Tip diameter: 6.3mm
RADIO OPERATION
USE OF RADIO ONLY
•Position the Mode button (7) on the “RADIO/ AUX" position to use the radio only without the
motion detector function.
•Adjust the Volume knob (2) to set to the desired volume.
•Place the Selection knob (3) on the desired frequency: FM, AM or SW.
•Turn the Tuning knob (4) to choose your station.
Note:
During FM or SW reception, pull the telescopic antenna (1) to its entire length and adjust the
angle if necessary.
During AM reception, position your radio so that the built-in antenna can obtain an optimum
reception quality.
•Place the MODE button (7) in the "OFF" position when you have finished.
USING THE RADIO WITH THE MOTION DETECTOR FUNCTION
Motion detector details:
- Type of sensor: PIR
- Detection distance: 6 meters
- Detection angle: 90° (adjustable)
1. Turn on the radio and choose your station so that the radio switches itself on as soon as it
detects a movement.
2. Place the Mode button (7) on the "AUTO" position to activate the motion detector.
3. The radio will automatically turn on to your previously chosen station when you enter the room.
4. It will turn off after 3 minutes if no more movement is detected.
5. If you want to disable the motion detector and turn off the radio, place the Mode button in the
"OFF" position.

4
AUX AUDIO (AUXILIARY) INTERFACE
1. Place the Mode button in the RADIO/ AUX-IN
position.
2. Connect the radio to a computer, MP3 player, etc.
through a dual 3.5mm male cable jack (not included
- see photo beside).
3. After this connection has been made, the MP3
audio files contained on your computer may be
heard on the radio. Actually, it serves as an external
speaker.
WARNING REGARDING BATTERIES
•If the radio is powered by batteries and the sound becomes low, replace the old batteries with
new ones.
•If you do not plan to use the radio for a long period, please remove the batteries.
•Do not mix alkaline, ordinary (zinc carbon) and rechargeable batteries (nickel hydride).
•Do not mix old and new batteries.
•Do not try to recharge non-rechargeable batteries.
•Remove the rechargeable batteries from the device (if possible) before charging them.
•Rechargeable batteries must always be recharged under the supervision of an adult.
•Remove the old batteries.
•Do not short circuit the power terminals.
•Always use the recommended batteries or an equivalent type.
•Make sure that the batteries are correctly inserted according to polarity.
WARNING: You should not dispose of this device with your household waste. A selective
collection system for this type of product is implemented by your local authorities. Please
contact your local authorities to find out how and where collection takes place.
These restrictions apply because electrical and electronic devices contain dangerous
substances that have harmful effects on the environment or on human health and must be
recycled.
This symbol indicates that electrical and electronic devices are collected selectively. The
symbol shows a waste container crossed out with an X symbol.
Imported by Prodis SAS 1 rue de Rome 93110 ROSNY SOUS
BOIS-France/ Made in PRC
Marketed by EUROTOPS VERSAND GMBH D-40764
LANGENFELD
