EUTECH INSTRUMENTS 2-WIRE CONDUCTIVITY TRANSMITTER User manual

68X256902 Rev 1 10/99
EUTECH INSTRUMENTS
2-Wire Conductivity Transmitter
Operating Instructions
1Preface
Thank you for purchasing the Eutech 2-wire Conductivity Transmitter.
This manual serves to explain the correct installation and operations of
the XTR Transmitters. Other Transmitters available individually are: pH,
ORP (REDOX), Conductivity, Dissolved Oxygen and Temperature.
•EC-PH-XTR;
•EC-ORP-XTR;
•EC-CON-XTR;
•EC-DO-XTR; and
•EC-TEMP-XTR.
The information presented in this manual is subject to change without
prior notice, as improvements are made to the product. While Eutech will
endeavor to try its best to inform the market, this does not represent a
commitment on the part of Eutech Instruments Pte Ltd.
Eutech Instruments does not accept any responsibility for damage or
malfunction of the unit due to improper installation or operation of the
Transmitter.
Copyright 1999 Eutech Instruments Pte Ltd. Version 1.0. All rights
reserved.
Eutech Instruments Pte Ltd. Blk 55 Ayer Rajah Crescent #04-14/24,
Singapore 139 949. Tel: [phone]; Fax: [phone]; e-mail:
[email protected]; Home page: http://www.eutechinst.com
2Introduction
The Transmitter is used for the continuous measurement of pH, ORP
(REDOX), Conductivity, Dissolved Oxygen or Temperature, in conjunction
with an appropriate sensor. Data output is via 4-20 mA current output.
The Transmitter is housed in a IP65 enclosure, with openings for input
and 4-20mA output.
3Diagram and Dimensions (in mm)
4Installation
Operating with one or several Transmitters:
Figure 1- Operating with 1 Transmitter
Figure 2- Operating with several transmitters
5Electrical Connections

68X256902 Rev 1 10/99
6Before Calibration
Remove cover of Transmitter and ensure that electrode is correctly
connected as above. Connect Amp meter to the 4/20mA output of
Transmitter (Appendix 1).
7Conductivity Transmitter Calibration
Prepare fresh Calibrating solutions.
1) Hold electrode in air (electrode MUST be dry) and Amp meter should
read 4mA; if not, calibration is necessary;
2) Locate “Zero adjustment” trimmer; Using a fine screwdriver,
slowly turn trimmer till Amp meter reads 4mA;
3) For greater accuracy, adjust the slope with Standard calibrating
solutions;
4) Rinse probe in de-ionised water and immerse in standard solution;
5) In 1413 µµS solution, the output is 5.1304 mA;
6) In 2764 µµS solution, the output is 6.2112 mA;
7) In 12.88 mS solution, the output is 14.304 mA;
8) Using a fine screwdriver, slowly turn trimmer, marked ‘FSMS’, till
Amp meter reads correct mA value with respective Standard
solutions.
9) Remember to disconnect Amp meter and close cover.
NB: For other Standard values, expected current output is based on:
mA = {(16/20) x Conductivity value of Standard soln} + 4mA
8Specifications
Model ECCONXTR
Range 0.00 TO 20.00 mS
Accuracy 2% Full Scale
Calibration 2 pts
Input 3-wire (2-wires for Conductivity cell; 1 wire for
Thermistor)
Output 4-20 mA
Operating
Voltage DC 12 V to 24 V
Load 100 Ohms max. for 12 V;
600 Ohms max. for 24V
Housing 77 x 77 x 28 mm, field mountable
9Appendix 1
Connecting Amp Meter for Calibration
Figure 3- Method One
Figure 4- Method Two
10 Ordering Information
pH
Item Cat Code
pH Transmitter ECPHXTR
Combination pH Electrode, General, integral 5m cable ECARTSO05B
Combination pH Electrode, w/PMP, integral 5m cable ECARGTSO05B
Dissolved Oxygen
Item Cat Code
Dissolved Oxygen Transmitter ECDOXTR
General Purpose D.O. probe, 0.5 – 40 ppm, Industrial,
integral 5m cable ECDOGEN
General Purpose D.O. probe, 0 – 10 ppm, Industrial,
integral 5m cable ECDOTPll
ORP
Item Cat Code
ORP Transmitter ECORPXTR
Combination Platinum ORP Electrode, w/PMP,
integral 5m cable ECHTPTTSO05B
Combination Gold ORP Electrode, w/PMP, integral
5m cable ECHTAUTTSO05B
Conductivity
Item Cat Code
Conductivity Transmitter ECCONXTR
2-Pin SS,k=1.0, integral 3m cable ECCONSEN46
Temperature
Item Cat Code
Temperature Transmitter ECTEMPXTR
Pt 100 probe, SS316 ECPT10001M or
ECPT10005M
Power Supply
Item Cat Code
120V Power Supply EC-120-XTR
220V Power Supply EC-220-XTR
