YOKOGAWA EJX Series User manual

User’s
Manual
Contents
1. Introduction
1.1 ForSafeUseofProduct..............................................2
1.2 Warranty......................................................................3
1.3 ATEXDocumentation..................................................4
2. HandlingCautions
2.1 ModelandSpecicationsCheck.................................6
2.2 SelectingtheInstallationLocation..............................6
2.3 PressureConnection..................................................6
2.4 InstallationofanExplosion-ProtectedInstrument......6
2.5 EMCConformityStandards..................................... 15
2.6 PressureEquipmentDirective(PED)...................... 16
2.7 LowVoltageDirective............................................... 17
3. Installation
3.1 Mounting................................................................... 18
3.2 MountingtheDiaphragmSeals......................................18
3.3 DiaphragmSealsInstallationConsideration............ 19
3.4 MountingtheFlushingConnectionRing.................. 20
3.5 AfxingtheTeonFilm............................................. 21
3.6 RotatingTransmitterSection.................................... 22
3.7 ChangingtheDirectionofIntegralIndicator............. 22
4. InstallingImpulsePiping
4.1 ImpulsePipingInstallationPrecautions................... 23
4.2 ImpulsePipingConnectionExamples..................... 25
4.3 ProcessPipingInstallationPrecautions(EJ115)26
5. Wiring
5.1 WiringPrecautions................................................... 28
5.2 ConnectionsofExternalWiringtoTerminalBox...... 28
5.3 Wiring....................................................................... 30
5.4 RTDCableConnection(EJX910A/EJX930A)......... 31
5.5 Grounding................................................................ 34
5.6 PowerSupplyVoltageandLoadResistance........... 34
6. Operation
6.1 PreparationforStartingOperation........................... 35
6.2 ZeroPointAdjustment.............................................. 36
7. ErrorsandCountermeasures
8. ParameterSummary
1
2
3
4
5
6
7
8
EJXandEJA-ESeries
DifferentialPressureand
PressureTransmitters
InstallationManual
IM01C25A01-01E
IM01C25A01-01E
7thEdition
CD-ROMincluded

  <1.Introduction> 1
IM01C25A01-01E
1. Introduction
ThankyouforpurchasingtheDPharpelectronicpressure
transmitter.
Thismanualprovidesthebasicguidelinesforinstallation
andwiringproceduresoftheDPharpEJXSeries
andEJA-ESerieswithBRAINandHARTprotocols.
Itdoesnotprovidetheproductspecicfunctional
specicationsandexplanations,maintenance,
troubleshooting,FOUNDATIONFieldbusTMandPROFIBUS
PAcommunicationoperatingproceduresandhandling
precautionsofsafetytransmitters.Fortheitemswhich
arenotcoveredinthismanual,seetheapplicableuser’s
manualsintheCD-ROMattachedtothismanualaslisted
inTable1.1.
F0101.ai
● Installation manual (this document)
EJX and EJA-E series common manual
<Contents>
• Installation
• Impulse piping installation
• Wiring
• Zeroing
● Attached CD-ROM includes PDF manuals for:
• Product specific manuals, 6 PDFs by model code
• Communication manuals, 6 PDFs
<Contents of product specific manuals>
• Installation • BT200 operation
• Impulse piping installation • Maintenance
• Wiring • Specifications
• Zeroing
Table1.1PDFManualListandApplicableStyleCode
Models DocumentNo. Style
EJX110A
IM01C25B01-01E
S3
EJX120A S1
EJX130A,EJX310A,EJX430A
andEJX440A S2
EJX210A IM01C25C01-01E S2
EJX510AandEJX530A IM01C25F01-01E S2
EJX610AandEJX630A S1
EJX118AandEJX438A IM01C25H01-01E S2
EJX115A IM01C25K01-01E S1
DPharpHART5/HART7
CommunicationType IM01C25T01-06EN —
DPharpFieldbusCommunication
Type IM01C25T02-01E —
DPharpBRAINCommunication
Type IM01C25T03-01E —
DPharpPROFIBUSPA
CommunicationType IM01C25T04-01EN —
Models DocumentNo. Style
EJX910A IM01C25R01-01E S2
EJX930A S1
EJX910AandEJX930AHART
CommunicationType IM01C25R02-01E —
EJX910AandEJX930AFieldbus
CommunicationType IM01C25R03-01E —
Models DocumentNo. Style
EJA110E,EJA120E
IM01C25B01-01E S1
EJA130E,EJA310E,EJA430E
andEJA440E
EJA210E IM01C25C01-01E S1
EJA510EandEJA530E IM01C25F01-01E S1
EJA118EandEJA438E IM01C25H01-01E S1
EJA115E IM01C25K01-01E S1
DPharpHART5/HART7
CommunicationType IM01C25T01-06EN —
DPharpFieldbusCommunication
Type IM01C25T02-01E —
DPharpBRAINCommunication
Type IM01C25T03-01E —
DPharpPROFIBUSPA
CommunicationType IM01C25T04-01EN —
 RegardingThisManual
• Thismanualshouldbepassedontotheenduser.
• Thecontentsofthismanualaresubjecttochange
withoutpriornotice.
• Allrightsreserved.Nopartofthismanualmaybe
reproducedinanyformwithoutYokogawa’swritten
permission.
• Yokogawamakesnowarrantyofanykindwithregard
tothismanual,including,butnotlimitedto,implied
warrantyofmerchantabilityandtnessforaparticular
purpose.
• Ifanyquestionarisesorerrorsarefound,orifany
informationismissingfromthismanual,please
informthenearestYokogawasalesofce.
• Thespecicationscoveredbythismanualarelimited
tothoseforthestandardtypeunderthespecied
modelnumberbreak-downanddonotcovercustom-
madeinstruments.
• Pleasenotethatchangesinthespecications,
construction,orcomponentpartsoftheinstrument
maynotimmediatelybereectedinthismanualat
thetimeofchange,providedthatpostponementof
revisionswillnotcausedifcultytotheuserfroma
functionalorperformancestandpoint.
1
Introduction

  <1.Introduction> 2
IM01C25A01-01E
• Yokogawaassumesnoresponsibilitiesforthis
productexceptasstatedinthewarranty.
• Ifthecustomeroranythirdpartyisharmedbytheuse
ofthisproduct,Yokogawaassumesnoresponsibility
foranysuchharmowingtoanydefectsintheproduct
whichwerenotpredictable,orforanyindirect
damages.
• WhendescribingthemodelnamelikeEJ110
inthismanual,itshowstheapplicabilityforboth
EJX110AandEJA110E.Thesamerepresentations
areusedfortheothermodels,too.
NOTE
ForFOUNDATIONFieldbusandPROFIBUSPAprotocol
versions,pleaserefertomanualsintheattachedCD-
ROM,inadditiontothismanual.
• Thefollowingsafetysymbolmarksareusedinthis
manual:
WARNING 
Indicatesapotentiallyhazardoussituationwhich,ifnot
avoided,couldresultindeathorseriousinjury.
CAUTION
Indicatesapotentiallyhazardoussituationwhich,ifnot
avoided,mayresultinminorormoderateinjury.Itmay
alsobeusedtoalertagainstunsafepractices.
IMPORTANT
Indicatesthatoperatingthehardwareorsoftwarein
thismannermaydamageitorleadtosystemfailure.
NOTE
Drawsattentiontoinformationessentialfor
understandingtheoperationandfeatures.
 Directcurrent
1.1 ForSafeUseofProduct
Fortheprotectionandsafetyoftheoperatorandthe
instrumentorthesystemincludingtheinstrument,please
besuretofollowtheinstructionsonsafetydescribed
inthismanualwhenhandlingthisinstrument.Incase
theinstrumentishandledincontradictiontothese
instructions,Yokogawadoesnotguaranteesafety.
Pleasegiveyourattentiontothefollowings.
(a) Installation
• Theinstrumentmustbeinstalledbyanexpert
engineeroraskilledpersonnel.Theprocedures
describedaboutINSTALLATIONarenotpermittedfor
operators.
• Incaseofhighprocesstemperature,careshould
betakennottoburnyourselfbecausethesurfaceof
bodyandcasereachesahightemperature.
• Theinstrumentinstalledintheprocessisunder
pressure.Neverloosentheprocessconnectorbolts
toavoidthedangerousspoutingofprocessuid.
• Duringdrainingcondensatefromthepressure
detectorsection,takeappropriatecaretoavoid
contactwiththeskin,eyesorbody,orinhalationof
vapors,iftheaccumulatedprocessuidmaybetoxic
orotherwiseharmful.
• Whenremovingtheinstrumentfromhazardous
processes,avoidcontactwiththeuidandtheinterior
ofthemeter.
• Allinstallationshallcomplywithlocalinstallation
requirementandlocalelectricalcode.
(b) Wiring
• Theinstrumentmustbeinstalledbyanexpert
engineeroraskilledpersonnel.Theprocedures
describedaboutWIRINGarenotpermittedfor
operators.
• Pleaseconrmthatvoltagesbetweenthepower
supplyandtheinstrumentbeforeconnectingthe
powercablesandthatthecablesarenotpowered
beforeconnecting.
(c) Operation
• Wait5min.afterpoweristurnedoff,beforeopening
thecovers.
• Donotopenthecoverinwetweatherorhumid
environment.Ifthecoverisopened,statedenclosure
protectionisnotapplicable.

  <1.Introduction> 3
IM01C25A01-01E
(d) Maintenance
• Pleasedonotcarryoutexceptbeingwrittento
maintenancedescriptions.Whentheseprocedures
areneeded,pleasecontactnearestYOKOGAWA
ofce.
• Careshouldbetakentopreventthebuildupofdrift,
dustorothermaterialonthedisplayglassandname
plate.Incaseofitsmaintenance,softanddryclothis
used.
(e) ExplosionProtectedTypeInstrument
• Usersofexplosionproofinstrumentsshouldreferrst
tosection2.4(InstallationofanExplosionProtected
Instrument)ofthismanual.
• Theuseofthisinstrumentisrestrictedtothosewho
havereceivedappropriatetraininginthedevice.
• Takecarenottocreatesparkswhenaccessingthe
instrumentorperipheraldevicesinahazardous
location.
(f) Modication
• Yokogawawillnotbeliableformalfunctionsor
damageresultingfromanymodicationmadetothis
instrumentbythecustomer.
1.2 Warranty
• Thewarrantyshallcovertheperiodnotedonthe
quotationpresentedtothepurchaseratthetimeof
purchase.Problemsoccurredduringthewarranty
periodshallbasicallyberepairedfreeofcharge.
• Incaseofproblems,thecustomershouldcontactthe
Yokogawarepresentativefromwhichtheinstrument
waspurchased,orthenearestYokogawaofce.
• Ifaproblemariseswiththisinstrument,pleaseinform
usofthenatureoftheproblemandthecircumstances
underwhichitdeveloped,includingthemodel
specicationandserialnumber.Anydiagrams,
dataandotherinformationyoucanincludeinyour
communicationwillalsobehelpful.
• Responsiblepartyforrepaircostfortheproblems
shallbedeterminedbyYokogawabasedonour
investigation.
• ThePurchasershallbeartheresponsibilityfor
repaircosts,evenduringthewarrantyperiod,ifthe
malfunctionisdueto:
- Improperand/orinadequatemaintenancebythe
purchaser.
- Failureordamageduetoimproperhandling,use
orstoragewhichisoutofdesignconditions.
- Useoftheproductinquestioninalocation
notconformingtothestandardsspeciedby
Yokogawa,orduetoimpropermaintenanceofthe
installationlocation.
- Failureordamageduetomodicationorrepair
byanypartyexceptYokogawaoranapproved
representativeofYokogawa.
- Malfunctionordamagefromimproperrelocationof
theproductinquestionafterdelivery.
- Reasonofforcemajeuresuchasres,
earthquakes,storms/oods,thunder/lightening,
orothernaturaldisasters,ordisturbances,riots,
warfare,orradioactivecontamination.
1
Introduction

  <1.Introduction> 4
IM01C25A01-01E
1.3 ATEXDocumentation
ThisisonlyapplicabletothecountriesinEuropeanUnion.
GB
DK
I
E
NL
SF
P
F
D
S
LT
LV
PL
EST
SLO
H
BG
RO
M
CZ
SK
GR

  <2.HandlingCautions> 5
IM01C25A01-01E
2. HandlingCautions
Whenthetransmitterisdelivered,visuallycheckthem
tomakesurethatnodamageoccurredduringshipment.
Alsocheckthatalltransmittermountinghardwareshown
inFigure2.1isincluded.Ifthetransmitterwasordered
withoutthemountingbracketorwithouttheprocess
connector,thetransmittermountinghardwareisnot
included.
Table2.1 ApplicableModelCodeforMounting
Hardware
Applicable
model Sufxcode Partname Qty
EJ110
EJ120
EJ130
EJX910A
EJX930A
Process
connections
1,2,3and4
Processconnectorbolt 4
Processconnector 2
Processconnector
gasket 2
EJ210
EJ310
EJ430
EJ440
Process
connections
1,2,3and4
Processconnectorbolt 2
Processconnector 1
Processconnector
gasket 1
EJ110
EJ120
EJ130
EJ310
EJ430
EJ440
EJ118
EJ438
EJ115
EJX910A
EJX930A
Mountingbracket
B,D,G,J,KandM
U-bolt 1
U-boltnut 2
Mountingbracket
(Lorattype) 1
Transmittermounting
bolt 4
EJ510
EJ530
EJX610A
EJX630A
Mountingbracket
FandL
U-bolt(LandS) 1ea.
U-boltnut(LandS) 2ea.
Mountingbracket 1
EJX910A
EJX930A
External
temperatureinput
B,CandD RTDcable 1
External
temperatureinput
1,2,3and4 Cablegland 2
EJ210
EJ438Optioncode/TF1 Teonlm 1
Fluorinatedoil 1
EJ118Optioncode/TF1 Teonlm 2
Fluorinatedoil 2
EJX910A
EJX930A - 
1
2
3
4
1
2
3
4
B
C
D
 - 
B
D
G
J
K
M
EJ110
EJ120
EJ130
EJ310
EJ430
EJ440
- 
1
2
3
4
 - 
B
D
G
J
K
M
-  -  B
J
EJ210
1
2
3
4
 -  - 
EJ510
EJ530
EJX610A
EJX630A
EJ118
EJ438
F
L
-  - 
F0201.ai
B
D
J
K
EJ115 -  - 
Mounting bracket
(Flat type)
F0202.ai
Teflon film
Fluorinated oil
Bolt
Process connector
Process connector
Gasket
U-bolt nut
U-bolt
Mounting bracket
(L type)
Transmitter mounting bolt
Cable gland and RTD cable
(EJX910A and EJX930A only)
U-bolt nut (L)
Mounting bracket
U-bolt (L)
U-bolt (S)
U-bolt nut (S)
Figure2.1 TransmitterMountingHardware
HandlingCautions
2

  <2.HandlingCautions> 6
IM01C25A01-01E
2.1 ModelandSpecications
Check
Themodelnameandspecicationsareindicatedonthe
nameplateattachedtothecase.
F0203.ai
Figure2.2 NamePlate
2.2 SelectingtheInstallation
Location
Thetransmitterisdesignedtowithstandsevere
environmentalconditions.However,toensurethatitwill
provideyearsofstableandaccurateperformance,take
thefollowingprecautionswhenselectingtheinstallation
location.
(a)AmbientTemperature
Avoidlocationssubjecttowidetemperaturevariations
orasignicanttemperaturegradient.Ifthelocationis
exposedtoradiantheatfromplantequipment,provide
adequatethermalinsulationand/orventilation.
(b)AmbientAtmosphere
 Donotinstallthetransmitterinacorrosive
atmosphere.Ifthiscannotbeavoided,theremustbe
adequateventilationaswellasmeasurestoprevent
theleakingofrainwaterandthepresenceofstanding
waterintheconduits.
(c)ShockandVibration
 Althoughthetransmitterisdesignedtoberelatively
resistanttoshockandvibration,aninstallationsite
shouldbeselectedwherethisiskepttoaminimum.
(d)InstallationofExplosion-protectedTransmitters
 Anexplosion-protectedtransmittersiscertiedfor
installationinahazardousareacontainingspecic
gastypes.Seesubsection2.4“Installationofan
Explosion-ProtectedInstrument.”
2.3 PressureConnection
WARNING 
• Neverloosentheprocessconnectorboltswhenan
instrumentisinstalledinaprocess.Thedeviceis
underpressure,andalossofsealcanresultina
suddenanduncontrolledreleaseofprocessuid.
• Whendrainingtoxicprocessuidsthathave
condensedinsidethepressuredetector,take
appropriatestepstopreventthecontactofsuch
uidswiththeskinoreyesandtheinhalationof
vaporsfromtheseuids.
Thefollowingprecautionsmustbeobservedinorderto
safelyoperatethetransmitterunderpressure.
(a)Makesurethattheprocessconnectorboltsare
tightenedrmly.
(b)Makesurethattherearenoleaksintheimpulse
piping.
(c) Neverapplyapressurehigherthanthespecied
maximumworkingpressure.
2.4 InstallationofanExplosion-
ProtectedInstrument
NOTE
ForFoundationFieldbusandPROFIBUSPAexplosion
protectedtype,pleaserefertomanualintheattached
CD-ROM.
Ifacustomermakesarepairormodicationtoan
intrinsicallysafeorexplosionproofinstrumentandthe
instrumentisnotrestoredtoitsoriginalcondition,its
intrinsicallysafeorexplosionproofconstructionmaybe
compromisedandtheinstrumentmaybehazardousto
operate.PleasecontactYokogawabeforemakingany
repairormodicationtoaninstrument.
CAUTION
Thisinstrumenthasbeentestedandcertiedas
beingintrinsicallysafeorexplosionproof.Please
notethatsevererestrictionsapplytothisinstrument’s
construction,installation,externalwiring,maintenance
andrepair.Afailuretoabidebytheserestrictionscould
maketheinstrumentahazardtooperate.
WARNING 
Maintainingthesafetyofexplosionproofequipment
requiresgreatcareduringmounting,wiring,and
piping.Safetyrequirementsalsoplacerestrictionson
maintenanceandrepair.Pleasereadthefollowing
sectionsverycarefully.
WARNING 
Therangesettingswitchmustnotbeusedina
hazardousarea.

  <2.HandlingCautions> 7
IM01C25A01-01E
IMPORTANT
Forcombinedapprovaltypes
Onceadeviceofmultipleapprovaltypeisinstalled,
itshouldnotbere-installedusinganyotherapproval
types.Applyapermanentmarkinthecheckboxof
theselectedapprovaltypeonthecerticationlabelon
thetransmittertodistinguishitfromunusedapproval
types.
2.4.1 FMApproval
a. FMIntrinsicallySafeType
CautionforFMintrinsicallysafetype.(Following
contentsrefer“DOC.No.IFM022-A12”)
Note1. ModelEJX/EJA-ESeriesDifferential,gauge
andabsolutepressuretransmitterswithoptional
code/FS1areapplicableforuseinhazardous
locations.
• ApplicableStandard:FM3600,FM3610,FM3611,
FM3810
• IntrinsicallySafeforClassI,Division1,GroupsA,
B,C&D.ClassII,Division1,GroupsE,F&Gand
ClassIII,Division1,ClassI,Zone0inHazardous
Locations,AExiaIIC
• NonincendiveforClassI,Division2,Groups
A,B,C&D.ClassII,Division2,GroupsF&G
andClassI,Zone2,GroupsIIC,inHazardous
Locations.
• Outdoorhazardouslocations:NEMATYPE4X
• TemperatureClass:T4
• Ambienttemperature:–60to60°C
Note2. EntityParameters
• IntrinsicallySafeApparatusParameters
 [GroupsA,B,C,D,E,FandG]
Vmax=30V Ci=6nF
Imax=200mA Li=0µH
Pmax=1W
* AssociatedApparatusParameters
 (FMapprovedbarriers)
Voc≤30V Ca>6nF
Isc≤200mA La>0µH
Pmax≤1W
• IntrinsicallySafeApparatusParameters
 [GroupsC,D,E,FandG]
Vmax=30V Ci=6nF
Imax=225mA Li=0µH
Pmax=1W
* AssociatedApparatusParameters
 (FMapprovedbarriers)
Voc≤30V Ca>6nF
Isc≤225mA La>0µH
Pmax≤1W
• EntityInstallationRequirements
 Vmax≥VocorUoorVt,Imax≥IscorIoorIt,
 Pmax(orPo)≤Pi,CaorCo≥Ci+Ccable,
 LaorLo≥Li+Lcable
Note3. Installation
• Barriermustbeinstalledinanenclosurethat
meetstherequirementsofANSI/ISAS82.01.
• Controlequipmentconnectedtobarriermustnot
useorgeneratemorethan250VrmsorVdc.
• InstallationshouldbeinaccordancewithANSI/ISA
RP12.6“InstallationofIntrinsicallySafeSystems
forHazardous(Classied)Locations”andthe
NationalElectricCode(ANSI/NFPA70).
• Thecongurationofassociatedapparatusmustbe
FMRCApproved.
• Dust-tightconduitsealmustbeusedwhen
installedinaClassII,III,GroupE,FandG
environments.
• Associatedapparatusmanufacturer’sinstallation
drawingmustbefollowedwheninstallingthis
apparatus.
• Themaximumpowerdeliveredfromthebarrier
mustnotexceed1W.
• Noteawarninglabelworded“SUBSTITUTION
OFCOMPONENTSMAYIMPAIRINTRINSIC
SAFETY,”and“INSTALLINACCORDANCEWITH
DOC.No.IFM022-A12”
Note4. MaintenanceandRepair
• Theinstrumentmodicationorpartsreplacement
byotherthanauthorizedrepresentativeof
YokogawaElectricCorporationisprohibitedand
willvoidFactoryMutualIntrinsicallysafeand
NonincendiveApproval.
F0204.ai
Class I, II, III, Division 1,
Groups A, B, C, D, E, F, G
Class 1, Zone 0 in
Hazardous (Classified)
Locations AEx ia IIC
Pressure Transmitters Safety Barrier
Supply
Hazardous Location Nonhazardous Location
General
Purpose
Equipment
+
–
+
–
+
–
+
–
[Intrinsically Safe]
HandlingCautions
2

  <2.HandlingCautions> 8
IM01C25A01-01E
F0205.ai
Pressure Transmitters
Supply
Hazardous Location Nonhazardous Location
+
–
+
–
Class I, II, Division 2,
Groups A, B, C, D, F, G
Class 1, Zone 2, Group IIC,
in Hazardous (Classified)
Locations
Not Use
Safety Barrier
[Nonincendive]
General
Purpose
Equipment
b. FMExplosionproofType
CautionforFMexplosionprooftype.
Note1. ModelEJX/EJA-ESeriespressuretransmitters
withoptionalcode/FF1areapplicableforusein
hazardouslocations.
• ApplicableStandard:FM3600,FM3615,FM3810,
ANSI/NEMA250
• ExplosionproofforClassI,Division1,GroupsB,C
andD.
• Dust-ignitionproofforClassII/III,Division1,
GroupsE,FandG.
• Enclosurerating:NEMATYPE4X
• TemperatureClass:T6
• AmbientTemperature:–40to60°C
• SupplyVoltage:42Vdcmax.
• Outputsignal:4to20mA
Note2. Wiring
• AllwiringshallcomplywithNationalElectrical
CodeANSI/NFPA70andLocalElectricalCodes.
• WheninstalledinDivision1,“FACTORYSEALED,
CONDUITSEALNOTREQUIRED.”
Note3. Operation
• Keepthe“WARNING”nameplateattachedtothe
transmitter.
 WARNING:OPENCIRCUITBEFORE
REMOVINGCOVER.FACTORYSEALED,
CONDUITSEALNOTREQUIRED.INSTALLIN
ACCORDANCEWITHTHEUSERSMANUALIM
01C25.
• Takecarenottogeneratemechanicalsparking
whenaccessingtotheinstrumentandperipheral
devicesinahazardouslocation.
Note4. MaintenanceandRepair
• Theinstrumentmodicationorpartsreplacement
byotherthanauthorizedrepresentativeof
YokogawaElectricCorporationisprohibitedand
willvoidFactoryMutualExplosionproofApproval.
c. FMIntrinsicallySafeType/FM
ExplosionproofType
ModelEJX/EJA-ESeriespressuretransmitters
withoptionalcode/FU1or/V1U1canbeselected
thetypeofprotection(FMIntrinsicallySafeorFM
Explosionproof)foruseinhazardouslocations.
Note1. Fortheinstallationofthistransmitter,oncea
particulartypeofprotectionisselected,any
othertypeofprotectioncannotbeused.The
installationmustbeinaccordancewiththe
descriptionaboutthetypeofprotectioninthis
instructionmanual.
Note2. Inordertoavoidconfusion,unnecessary
markingiscrossedoutonthelabelother
thantheselectedtypeofprotectionwhenthe
transmitterisinstalled.
2.4.2 CSACertication
a. CSAIntrinsicallySafeType
CautionforCSAIntrinsicallysafeandnonincendive
type.(Followingcontentsreferto“DOCNo.ICS013-
A13”)
Note1. ModelEJX/EJA-ESeriesdifferential,gauge,
andabsolutepressuretransmitterswithoptional
code/CS1areapplicableforuseinhazardous
locations
Certicate:1606623
[ForCSAC22.2]
• ApplicableStandard:C22.2No.0,C22.2No.0.4,
C22.2No.25,C22.2No.94,C22.2No.157,
C22.2No.213,C22.2No.61010-1,
C22.2No.60079-0
• IntrinsicallySafeforClassI,Division1,Groups
A,B,C&D,ClassII,Division1,GroupsE,F&G,
ClassIII,Division1
• NonincendiveforClassI,Division2,GroupsA,B,
C&D,ClassII,Division2,GroupsE,F&G,Class
III,Division1
• Enclosure:Type4X
• Temp.Code:T4
• Amb.Temp.:–50*to60°C
 *–15°Cwhen/HEisspecied.
• ProcessTemperature:120°Cmax.
[ForCSAE60079]
• ApplicableStandard:CAN/CSAE60079-11,
CAN/CSAE60079-15,IEC60529:2001
• ExiaIICT4,ExnLIICT4
• AmbientTemperature:–50to60°C
• Max.ProcessTemp.:120°C
• Enclosure:IP66/IP67

  <2.HandlingCautions> 9
IM01C25A01-01E
Note2. EntityParameters
• Intrinsicallysaferatingsareasfollows:
 MaximumInputVoltage(Vmax/Ui)=30V
 MaximumInputCurrent(Imax/Ii)=200mA
 MaximumInputPower(Pmax/Pi)=0.9W
 MaximumInternalCapacitance(Ci)=10nF
 MaximumInternalInductance(Li)=0µH
• Type"n"orNonincendiveratingsareasfollows:
 MaximumInputVoltage(Vmax/Ui)=30V
 MaximumInternalCapacitance(Ci)=10nF
 MaximumInternalInductance(Li)=0µH
• InstallationRequirements
 Uo≤Ui,Io≤Ii,Po≤Pi,
 Co≥Ci+Ccable,Lo≥Li+Lcable
 Voc≤Vmax,Isc≤Imax,
 Ca≥Ci+Ccable,La≥Li+Lcable
 Uo,Io,Po,Co,Lo,Voc,Isc,CaandLaare
parametersofbarrier.
Note3. Installation
• Inanysafetybarreirusedoutputcurrentmust
belimitedbyaresistor'R'suchthatIo=Uo/Ror
Isc=Voc/R.
• ThesafetybarriermustbeCSAcertied.
• Inputvoltageofthesafetybarriermustbeless
than250Vrms/Vdc.
• InstallationshouldbeinaccordancewithCanadian
ElectricalCodePartIandLocalElectricalCode.
• Dust-tightconduitsealmustbeusedwhen
installedinClassIIandIIIenvironments.
• Theinstrumentmodicationorpartsreplacement
byotherthanauthorizedrepresentativeof
YokogawaElectricCorporationandYokogawa
CorporationofAmericaisprohibitedandwill
voidCanadianStandardsIntrinsicallysafeand
nonincendiveCertication.
F0206.ai
Class I, II, III, Division 1,
Groups A, B, C, D, E, F, G
Pressure Transmitters Safety Barrier
Supply
Hazardous Location Nonhazardous Location
General
Purpose
Equipment
+
–
+
–
+
–
+
–
[Intrinsically Safe]
Group IIC, Zone 0
F0207.ai
Pressure Transmitters
Supply
Hazardous Location Nonhazardous Location
+
–
+
–
Class I, II, Division 2,
Groups A, B, C, D, F, G
Class III, Division 1.
Not Use
Safety Barrier
[Nonincendive]
CSA Certified
Equipment
([nL] or
nonincendive)
Group IIC, Zone 2
b. CSAExplosionproofType
CautionforCSAexplosionprooftype.
Note1. ModelEJX/EJA-ESeriespressuretransmitters
withoptionalcode/CF1areapplicableforusein
hazardouslocations:
• Certicate:2014354
• ApplicableStandard:C22.2No.0,
C22.2No.0.4,C22.2No.0.5,C22.2No.25,
C22.2No.30,C22.2No.94,C22.2No.61010-1,
C22.2No.60079-0,C22.2No.60079-1
• Explosion-proofforClassI,GroupsB,CandD.
• Dustignition-proofforClassII/III,GroupsE,Fand
G.
• Enclosure:TYPE4X
• TemperatureCode:T6...T4
• ExdIICT6...T4
• Enclosure:IP66/IP67
• MaximumProcessTemperature:120°C(T4),
100°C(T5),85°C(T6)
• AmbientTemperature:–50*to75°C(T4),
–50*to80°C(T5),–50*to75°C(T6)
 *–15°Cwhen/HEisspecied.
• SupplyVoltage:42Vdcmax.
• OutputSignal:4to20mAdc
Note2. Wiring
• AllwiringshallcomplywithCanadianElectrical
CodePartIandLocalElectricalCodes.
• Inhazardouslocation,wiringshallbeinconduitas
showninthegure.
• WARNING:
 ASEALSHALLBEINSTALLEDWITHIN50cmOF
THEENCLOSURE.
 UNSCELLEMENTDOITÊTREINSTALLÉÀ
MOINSDE50cmDUBOÎTIER.
• WARNING:
 WHENINSTALLEDINCL.I,DIV2,SEALNOT
REQUIRED.
 UNEFOISINSTALLÉDANSCLI,DIV2,AUCUN
JOINTN'ESTREQUIS.
Non-hazardous
Location Equipment
42 V DC Max.
4 to 20 mA DC
Signal
Non-Hazardous
Locations
Hazardous Locations Division 1
50 cm Max.
Sealing Fitting Conduit
SUPPLY
PULSE
CHECK
ALARM
Transmitter
F0208.ai
Non-Hazardous
Locations
Hazardous Locations Division 2
Non-hazardous
Location Equipment
42 V DC Max.
4 to 20 mA DC
Signal Sealing Fitting
SUPPLY
PULSE
CHECK
ALARM
Transmitter
F0209.ai
HandlingCautions
2

  <2.HandlingCautions> 10
IM01C25A01-01E
• Allwiringshallcomplywithlocalinstallation
requirementsandlocalelectricalcode.
• Inhazardouslocations,thecableentrydevices
shallbeofacertiedameprooftype,suitablefor
theconditionsofuseandcorrectlyinstalled.
• Unusedaperturesshallbeclosedwithsuitable
ameproofcertiedblankingelements.(Theplug
attachedisameproofcertied.)
Note3. Operation
• WARNING:
 AFTERDE-ENERGIZING,DELAY5MINUTES
BEFOREOPENING.
 APRÉSPOWER-OFF,ATTENDRE5MINUTES
AVANTD'OUVRIR.
• WARNING:
 WHENAMBIENTTEMPERATURE≥65°C,USE
THEHEAT-RESISTINGCABLES≥90°C.
 QUANDLATEMPÉRATUREAMBIANTE≥65°C,
UTILISEZDESCÂBLESRÉSISTANTESÁLA
CHALEUR≥90°C.
• Takecarenottogeneratemechanicalsparking
whenaccessingtotheinstrumentandperipheral
devicesinahazardouslocation.
Note4. MaintenanceandRepair
• Theinstrumentmodicationorpartsreplacement
byotherthanauthorizedrepresentativeof
YokogawaElectricCorporationandYokogawa
CorporationofAmericaisprohibitedandwillvoid
CanadianStandardsExplosionproofCertication.
c. CSAIntrinsicallySafeType/CSA
ExplosionproofType
ModelEJX/EJA-ESeriespressuretransmitterswith
optionalcode/CU1or/V1U1canbeselectedthe
typeofprotection(CSAIntrinsicallySafeorCSA
Explosionproof)foruseinhazardouslocations.
Note1. Fortheinstallationofthistransmitter,oncea
particulartypeofprotectionisselected,any
othertypeofprotectioncannotbeused.The
installationmustbeinaccordancewiththe
descriptionaboutthetypeofprotectioninthis
instructionmanual.
Note2. Inordertoavoidconfusion,unnecessary
markingiscrossedoutonthelabelother
thantheselectedtypeofprotectionwhenthe
transmitterisinstalled.
2.4.3 ATEXCertication
(1) TechnicalData
a. ATEXIntrinsicallySafeType(Exceptfor
EJX90A)
CautionforATEXIntrinsicallysafetype.
Note1. ModelEJX/EJA-ESeriespressuretransmitters
withoptionalcode/KS21forpotentially
explosiveatmospheres:
• No.DEKRA11ATEX0228X
• ApplicableStandard:
EN60079-0:2009,EN60079-11:2007,
EN60079-26:2007,EN61241-11:2006
• TypeofProtectionandMarkingcode:
ExiaIICT4Ga
 ExiaIIICT85ºCT100ºCT120ºCDb
• Group:II
• Category:1G,2D
• AmbientTemperatureforEPLGa:
–50to60°C
• AmbientTemperatureforEPLDb:
–30*to60°C
*–15°Cwhen/HEisspecied.
• ProcessTemperature(Tp.):120°Cmax.
• MaximumSurfaceTemperatureforEPLDb:
T85°C(Tp.:80°C)
T100°C(Tp.:100°C)
T120°C(Tp.:120°C)
• Enclosure:IP66/IP67
Note2 ElectricalData
• IntypeofexplosionprotectionintrinsicsafetyExia
IICorExiaIIIC,onlyforconnectiontoacertied
intrinsicallysafecircuitwithfollowingmaximum
values:
 Ui=30V
 Ii=200mA
 Pi=0.9W
 (LinearSource)
 Maximuminternalcapacitance;Ci=27.6nF
 Maximuminternalinductance;Li=0µH
Note3. Installation
• Refertothecontroldrawing.Allwiringshallcomply
withlocalinstallationrequirements.
Transmitter
Supply Safety Barrier *1
Nonhazardous Location
[Control Drawing]
Hazardous Location
+
–
+
–
F0210.ai
 *1:Inanysafetybarriersusedtheoutputcurrentmustbe
limitedbyaresistor“R”suchthatIo=Uz/R.
Note4. MaintenanceandRepair
• Theinstrumentmodicationorpartsreplacement
byotherthanauthorizedrepresentativeof
YokogawaElectricCorporationisprohibitedand
willvoidDEKRAIntrinsicallysafeCertication.
Note5. SpecialConditionsforSafeUse

  <2.HandlingCautions> 11
IM01C25A01-01E
WARNING 
• InthecasewheretheenclosureofthePressure
Transmitterismadeofaluminium,ifitismounted
inanareawheretheuseofcategory1G
apparatusisrequired,itmustbeinstalledsuch,
that,evenintheeventofrareincidents,ignition
sourcesduetoimpactandfrictionsparksare
excluded.
• Electrostaticchargemaycauseanexlosion
hazard.Avoidanyactionsthatcausethe
gerenationofeletrostaticcharge,suchasrubbing
withadryclothoncoatingfaceoftheproduct.
• IncaseoftheenclosureofthePressure
Transmitterwithpaintlayers,ifitismountedinan
areawheretheuseofcategory2Dapparatusis
required,itshallbeinstalledinsuchawaythatthe
riskfromelectrostaticdischargesandpropagating
brushdischargescausedbyrapidowofdustis
avoided.
• TosatisfyIP66orIP67,applywaterproofglandsto
theelectricalconnectionport.
• Whenthelightningprotectoroptionisspecied,
theapparatusisnotcapableofwithstandingthe
500VinsulationtestrequiredbyEN60079-11.This
mustbetakenintoaccountwheninstallingthe
apparatus.
b. ATEXIntrinsicallySafeTypeforEJX910A
andEJX930A
CautionforATEXIntrinsicallysafetype.
Note1. ModelEJXSeriespressuretransmitterswith
optionalcode/KS2forpotentiallyexplosive
atmospheres:
• No.KEMA06ATEX0037X
• ApplicableStandard:
EN50014:1997,EN50020:2002,
EN50284:1999,EN50281-1-1:1998
• TypeofProtectionandMarkingcode:
EExiaIICT4
• Group:II
• Category:1G,1D
• AmbientTemperatureforgas-proof:
–50*to60°C
 *–15°Cwhen/HEisspecied.
• ProcessTemperature(Tp.):120°Cmax.
• MaximumSurfaceTemperaturefordust-proof:
T85°C(Tamb.:–40*to60°C,Tp.:80°C)
T100°C(Tamb.:–40*to60°C,Tp.:100°C)
T120°C(Tamb.:–40*to60°C,Tp.:120°C)
 *–15°Cwhen/HEisspecied.
• Enclosure:IP66andIP67
Note2. ElectricalData
[Supply/Outputcircuit(terminals+and-)]
 IntypeofexplosionprotectionintrinsicsafetyEEx
iaIIC,onlyforconnectiontoacertiedintrinsically
safecircuitwithfollowingmaximumvalues:
Ui=30V
Ii=200mA
Pi=0.9W
 Effectiveinternalcapacitance;Ci=10nF
 Effectiveinternalinductance;Li=0mH
[PulseOutputcircuit(terminals-andpulse)]
 IntypeofexplosionprotectionintrinsicsafetyEEx
iaIIC,onlyforconnectiontoacertiedintrinsically
safecircuitwithfollowingmaximumvalues:
Ui=30V
 Ii=200mA
 Pi=0.9W
 Ci=10nF
 Li=0mH
[Externaltemperatureinputcircuit(connector)]
 IntypeofexplosionprotectionintrinsicsafetyEEx
iaIIC,withfollowingmaximumvalues:
Uo=30V
 Io=95.4mA
Po=468mW
 Co=11nF
 Lo=3.9mH
Note3. Installation
• Allwiringshallcomplywithlocalinstallation
requirements.(Refertotheinstallationdiagram)
• Whentheanalogandpulsecircuitsareconnected
toseparatebarriers,itshallbeassuredthatthe
voltagedifferencebetweentheseoutputcircuitsis
notmorethan30V.
• Whenusedinapotentiallyexplosiveatmosphere,
Requiringtheuseofapparatusofequipment
category1Dor2D,certiedcableentrydevices
shallbeusedthataresuitablefortheapplication
andcorrectlyinstalled.
Note4. MaintenanceandRepair
• Theinstrumentmodicationorpartsreplacement
byotherthanauthorizedrepresentativeof
YokogawaElectricCorporationisprohibitedand
willvoidKEMAIntrinsicallysafeCertication.
Note5. SpecialConditionsforSafeUse
• InthecasewheretheenclosureofthePressure
Transmitterismadeofaluminium,ifitismounted
inanareawheretheuseofcategory1G
apparatusisrequired,itmustbeinstalledsuch,
that,evenintheeventofrareincidents,ignition
sourcesduetoimpactandfrictionsparksare
excluded.
HandlingCautions
2

  <2.HandlingCautions> 12
IM01C25A01-01E
Transmitter
Supply Safety Barrier*1
Nonhazardous Location
[Installation Diagram] (for EJX910A and EJX930A)
Hazardous Location
+
–
+
–
F0211.ai
Sensor out
RTD sensor
*2
● Without pulse output
● With pulse output
Transmitter
Supply
Safety Barrier*1
Nonhazardous Location
Hazardous Location
+
–
+
–
+
Sensor out
RTD sensor
*2
Safety Barrier*1
+
–
Pulse
*1: • Inanysafetybarriersusedtheoutputcurrentmustbe
limitedbyaresistor“R”suchthatIo=Uz/R.
 • ThesafetybarriershallbecertiedbynotifybodyEUas
ATEX.
 • Whenusingnonisolationbarrier,connect toISearthing
system.
*2: • RTDsensorispreparedbytheuser.
 • Thesensorsignallinemustwithstandatestvoltageof
500VAC.
WARNING 
TosatisfyIP66orIP67,applywaterproofglandstothe
electricalconnectionport.
c. ATEXFlameproofType
CautionforATEXameprooftype.
Note1. ModelEJX/EJA-ESeriespressuretransmitters
withoptionalcode/KF22forpotentially
explosiveatmospheres:
• No.KEMA07ATEX0109X
• ApplicableStandard:EN60079-0:2009,
EN60079-1:2007,EN60079-31:2009
• TypeofProtectionandMarkingCode:
 ExdIICT6...T4Gb,ExtbIIICT85°CDb
• Group:II
• Category:2G,2D
• Enclosure:IP66/IP67
• TemperatureClassforgas-poof:
T6,T5,andT4
• AmbientTemperatureforgas-proof:
–50to75°C(T6),–50to80°C(T5),and
–50to75°C(T4)
• MaximumProcessTemperature(Tp.)forgas-
proof:
 85°C(T6),100°C(T5),and120°C(T4)
• MaximumSurfaceTemperaturefordust-proof:
T85°C(Tamb.:–30*to75°C,Tp.:85°C)
*–15°Cwhen/HEisspecied.
Note2. ElectricalData
• Supplyvoltage:42Vdcmax.
• Outputsignal:4to20mA
Note3. Installation
• Allwiringshallcomplywithlocalinstallation
requirement.
• Thecableentrydevicesshallbeofacertied
ameprooftype,suitablefortheconditionsofuse.
Note4. Operation
• Keepthe“WARNING”labelattachedtothe
transmitter.
 WARNING:AFTERDE-ENERGIZING,DELAY
5MINUTESBEFOREOPENING.WHENTHE
AMBIENTTEMP.≥65°C,USEHEAT-RESISTING
CABLEANDCABLEGLAND≥90°C.
• Takecarenottogeneratemechanicalsparking
whenaccessingtotheinstrumentandperipheral
devicesinahazardouslocation.
Note5. SpecialConditionsforSafeUse
WARNING 
• Electrostaticchargemaycauseanexlosion
hazard.Avoidanyactionsthatcausethe
gerenationofeletrostaticcharge,suchasrubbing
withadryclothoncoatingfaceoftheproduct.
• InthecasewheretheenclosureofthePressure
Transmitterismadeofaluminium,ifitismounted
inanareawheretheuseofcategory2Dapparatus
isrequired,itshallbeinstalledinsuchaway
thattheriskfromelectrostaticdischargesand
propagatingbrushdischargescausedbyrapid
owofdustisavoided.
• Theinstrumentmodicationorpartsreplacement
byotherthananauthorizedRepresentativeof
YokogawaElectricCorporationisprohibitedand
willvoidthecertication.
• TosatisfyIP66orIP67,applywaterproofglandsto
theelectricalconnectionport.

  <2.HandlingCautions> 13
IM01C25A01-01E
d. ATEXIntrinsicallySafeType/ATEX
FlameproofType
ModelEJX/EJA-ESeriespressuretransmitterswith
optionalcode/KU22or/V1U1canbeselectedthe
typeofprotectionATEXFlameproof,IntrinsicallySafe.
Exia,orExicforuseinhazardousarea.
Note1. Fortheinstallationofthistransmitter,oncea
particulartypeofprotectionisselected,any
othertypeofprotectioncannotbeused.The
installationmustbeinaccordancewiththe
descriptionaboutthetypeofprotectioninthis
user’smanual.
Note2. Forcombinedapprovaltypes
Onceadeviceofmultipleapprovaltypeis
installed,itshouldnotbere-installedusingany
otherapprovaltypes.Applyapermanentmark
inthecheckboxoftheselectedapprovaltype
onthecerticationlabelonthetransmitterto
distinguishitfromunusedapprovaltypes.
● ATEXIntrinsicallySafeExic
CautionforATEXintrinsicallysafeExic
• ApplicableStandard:
EN60079-0:2009/EN60079-0:2012,
EN60079-11:2012
• TypeofProtectionandMarkingCode:
II3GExicIICT4Gc
• AmbientTemperature:–30*to+60°C
*–15°Cwhen/HEisspecied.
• AmbientHumidity:
0to100%(Nocondensation)
• MaximumProcessTemperature:120°C
• IPCode:IP66
• Ambientpollutiondegree:2
• Overvoltagecategory:I
Note1. ElectricalData
 Ui=30V
 Ci=27.6nF
 Li=0µH
Note2. Installation
• Allwiringshallcomplywithlocalinstallation
requirements.(refertothecontroldrawing)
• Cableglands,adaptersand/orblankingelements
shallbeofEx“n”,Ex“e”orEx“d”andshallbe
installedsoastomaintainthespecieddegreeof
protection(IPCode)ofthetransmitters.
Note3. MaintenanceandRepair
• Theinstrumentmodicationorpartsreplacement
byotherthanauthorizedrepresentativeof
YokogawaElectricCorporationisprohibitedand
willvoidATEXintrinsicallysafe.
Transmitter Associated
Apparatus
Nonhazardous Area
[Control Drawing]
Hazardous Area
+
–
F0212.ai
Note4. SpecicConditionsofUse
WARNING 
• Electrostaticchargemaycauseanexplosion
hazard.Avoidanyactionsthatcausethe
gerenationofeletrostaticcharge,suchasrubbing
withadryclothoncoatingfaceoftheproduct.
• Whenthelightningprotectoroptionisspecied,
theapparatusisnotcapableofwithstandingthe
500VinsulationtestrequiredbyEN60079-11.This
mustbetakenintoaccountwheninstallingthe
apparatus.
(2) ElectricalConnection
Amarkindicatingtheelectricalconnectiontypeis
stampedneartheelectricalconnectionport.These
marksareasfollowed.
F0214.ai
Location of the mark
Screw Size Marking
ISO M20 × 1.5 female
ANSI 1/2 NPT female
M
N or W
(3) Installation
WARNING 
• Allwiringshallcomplywithlocalinstallation
requirementsandthelocalelectricalcode.
• ThereisnoneedforconduitsealinDivision1
andDivision2hazardouslocationsbecausethis
productissealedatthefactory.
HandlingCautions
2

  <2.HandlingCautions> 14
IM01C25A01-01E
(4) Operation
WARNING 
• OPENCIRCUITBEFOREREMOVINGCOVER.
INSTALLINACCORDANCEWITHTHISUSER’S
MANUAL
• Takecarenottogeneratemechanicalsparking
whenaccesstotheinstrumentandperipheral
devicesinahazardouslocation.
(5) MaintenanceandRepair
WARNING 
Theinstrumentmodicationorpartsreplacementby
otherthananauthorizedRepresentativeofYokogawa
ElectricCorporationisprohibitedandwillvoidthe
certication.
(6) NamePlate
F0215.ai
 Name plate
 Tag plate for flameproof type
 Tag plate for intrinsically safe Ex ia
WARNING
D
D
WARNING
No. KEMA 07ATEX0109 X
Ex d IIC T6...T4 Gb, Ex tb IIIC T85°C Db
Enlcosure : IP66/IP67
TEMP. CLASS T6 T5 T4
MAX PROCESS TEMP.(Tp.) 85 100 120 °C
Tamb. -50 to 75 80 75 °C
T85°C(Tamb.:-30(-15) to 75°C, Tp.:85°C)(for Dust)
No. DEKRA 11ATEX 0228 X
Ex ia IIC T4 Ga Ta: -50 TO 60°C
Ex ia IIIC T85°C T100°C T120°C Db Ta:-30(-15) TO 60°C
IP66/IP67
MAX. PROCESS TEMP.(Tp.) 120°C
T85°C(Tp.:80°C), T100°C(Tp.:100°C), T120°C(Tp.:120°C)
Ui=30V, Ii=200mA , Pi=0.9W, Ci=27.6nF, Li=0µH
POTENTIAL ELECTROSTATIC
CHARGING HAZARD
- SEE USER’S MANUAL
AFTER DE-ENERGIZING, DELAY 5 MINUTES BEFORE
OPENING.
WHEN THE AMBIENT TEMP. ≥ 65°C, USE THE
HEAT-RESISTING CABLE & CABLE GLAND ≥ 90°C
POTENTIAL ELECTROSTATIC CHARGING HAZARD
 Tag plate for intrinsically safe type
(for EJX910A and EJX930A)
D
No. KEMA 06ATEX0037 X
EEx ia IIC T4
IP66 and IP67
Tamb. -50(-15) to 60°C MIN Tamb.for DUST -40(-15°C)
MAX PROCESS TEMP.(Tp) 120°C
T85°C(Tp.:80°C), T100°C(Tp.:100°C), T120°C(Tp.:120°C)
Supply/Pulse circuit
Ui=30 V, Ii=200 mA, Pi=0.9 W, Ci=10 nF, Li=0 mH
Sensor circuit
Uo=30 V, Io=95.4 mA, Po=468 mW, Co=11 nF, Lo=3.9 mH
 Tag plate for intrinsically safe Ex ic
WARNING
Ex ic IIC T4 Gc
IP66
Tamb -30(-15) TO 60°C
MAX. PROCESS TEMP. 120°C
Ui=30V, Ci=27.6nF, Li=0µH
POTENTIAL ELECTROSTATIC
CHARGING HAZARD
- SEE USER’S MANUAL
*3
*3
*3
F0215.ai
 Name plate
 Tag plate for flameproof type
 Tag plate for intrinsically safe Ex ia
WARNING
D
D
WARNING
No. KEMA 07ATEX0109 X
Ex d IIC T6...T4 Gb, Ex tb IIIC T85°C Db
Enlcosure : IP66/IP67
TEMP. CLASS T6 T5 T4
MAX PROCESS TEMP.(Tp.) 85 100 120 °C
Tamb. -50 to 75 80 75 °C
T85°C(Tamb.:-30(-15) to 75°C, Tp.:85°C)(for Dust)
No. DEKRA 11ATEX 0228 X
Ex ia IIC T4 Ga Ta: -50 TO 60°C
Ex ia IIIC T85°C T100°C T120°C Db Ta:-30(-15) TO 60°C
IP66/IP67
MAX. PROCESS TEMP.(Tp.) 120°C
T85°C(Tp.:80°C), T100°C(Tp.:100°C), T120°C(Tp.:120°C)
Ui=30V, Ii=200mA , Pi=0.9W, Ci=27.6nF, Li=0µH
POTENTIAL ELECTROSTATIC
CHARGING HAZARD
- SEE USER’S MANUAL
AFTER DE-ENERGIZING, DELAY 5 MINUTES BEFORE
OPENING.
WHEN THE AMBIENT TEMP. ≥ 65°C, USE THE
HEAT-RESISTING CABLE & CABLE GLAND ≥ 90°C
POTENTIAL ELECTROSTATIC CHARGING HAZARD
 Tag plate for intrinsically safe type
(for EJX910A and EJX930A)
D
No. KEMA 06ATEX0037 X
EEx ia IIC T4
IP66 and IP67
Tamb. -50(-15) to 60°C MIN Tamb.for DUST -40(-15°C)
MAX PROCESS TEMP.(Tp) 120°C
T85°C(Tp.:80°C), T100°C(Tp.:100°C), T120°C(Tp.:120°C)
Supply/Pulse circuit
Ui=30 V, Ii=200 mA, Pi=0.9 W, Ci=10 nF, Li=0 mH
Sensor circuit
Uo=30 V, Io=95.4 mA, Po=468 mW, Co=11 nF, Lo=3.9 mH
 Tag plate for intrinsically safe Ex ic
WARNING
Ex ic IIC T4 Gc
IP66
Tamb -30(-15) TO 60°C
MAX. PROCESS TEMP. 120°C
Ui=30V, Ci=27.6nF, Li=0µH
POTENTIAL ELECTROSTATIC
CHARGING HAZARD
- SEE USER’S MANUAL
*3
*3
*3
MODEL:Speciedmodelcode.
STYLE:Stylecode.
SUFFIX:Speciedsufxcode.
SUPPLY:Supplyvoltage.
OUTPUT:Outputsignal.
MWP:Maximumworkingpressure.
CALRNG:Speciedcalibrationrange.
NO.:Serialnumberandyearofproduction*1.
TOKYO180-8750JAPAN:
Themanufacturernameandtheaddress*2.
 *1:Therstnumberinthesecondblockof“NO.”column
isthelastonenumberoftheproductionyear.
second block
NO. 91K819857 132 7
The year 2011
 *2:“180-8750”isazipcodewhichrepresentsthe 
followingaddress.
2-9-32Nakacho,Musashino-shi,TokyoJapan
 *3:TheidenticationnumberofNotiedBody.
2.4.4 IECExCertication
ModelEJXSeriespressuretransmitterswith
optionalcode/SU2canbeselectedthetypeof
protection(IECExIntrinsicallySafe/typenor
ameproof)foruseinhazardouslocations.
Note1. Fortheinstallationofthistransmitter,oncea
particulartypeofprotectionisselected,any
othertypeofprotectioncannotbeused.The
installationmustbeinaccordancewiththe
descriptionaboutthetypeofprotectioninthis
instructionmanual.
Note2. Inordertoavoidconfusion,unnecessary
markingiscrossedoutonthelabelother
thantheselectedtypeofprotectionwhenthe
transmitterisinstalled.
a. IECExIntrinsicallySafeType/typen
CautionforIECExIntrinsicallysafeandtypen.
Note1. ModelEJXSeriesdifferential,gauge,and
absolutepressuretransmitterswithoptional
code/SU2areapplicableforuseinhazardous
locations
• No.IECExCSA05.0005
• ApplicableStandard:IEC60079-0:2000,
IEC60079-11:1999,IEC60079-15:2001

  <2.HandlingCautions> 15
IM01C25A01-01E
• ExiaIICT4,ExnLIICT4
• AmbientTemperature:–50to60°C
• Max.ProcessTemp.:120°C
• Enclosure:IP66/IP67
Note2. EntityParameters
• Intrinsicallysaferatingsareasfollows:
MaximumInputVoltage(Vmax/Ui)=30V
MaximumInputCurrent(Imax/Ii)=200mA
MaximumInputPower(Pmax/Pi)=0.9W
MaximumInternalCapacitance(Ci)=10nF
MaximumInternalInductance(Li)=0µH
• Type"n"ratingsareasfollows:
MaximumInputVoltage(Vmax/Ui)=30V
MaximumInternalCapacitance(Ci)=10nF
MaximumInternalInductance(Li)=0µH
• InstallationRequirements
Uo≤Ui,Io≤Ii,Po≤Pi,
Co≥Ci+Ccable,Lo≥Li+Lcable
Voc≤Vmax,Isc≤Imax,
Ca≥Ci+Ccable,La≥Li+Lcable
Uo,Io,Po,Co,Lo,Voc,Isc,CaandLaare
parametersofbarrier.
Note3. Installation
• Inanysafetybarrierusedoutputcurrentmustbe
limitedbyaresistor'R'suchthatIo=Uo/R.
• ThesafetybarriermustbeIECExcertied.
• Inputvoltageofthesafetybarriermustbeless
than250Vrms/Vdc.
• Theinstrumentmodicationorpartsreplacement
byotherthanauthorizedrepresentativeof
YokogawaElectricCorporationandwillvoidIECEx
Intrinsicallysafeandtypencertication.
F0216.ai
EJX Series Pressure
Transmitters
IECEx certified
Safety Barrier
Supply
Hazardous Location Nonhazardous Location
General
Purpose
Equipment
+
–
+
–
+
–
+
–
[Intrinsically Safe]
Group IIC, Zone 0
F0217.ai
EJX Series Pressure
Transmitters
Supply
Hazardous Location Nonhazardous Location
+
–
+
–
Not Use
Safety Barrier
[type n]
IECEx Certified
Equipment [nL]
EJX Series Pressure
Transmitters
Group IIC, Zone 2
b. IECExFlameproofType
CautionforIECExameprooftype.
Note1. ModelEJX/EJA-ESeriespressuretransmitters
withoptionalcode/SF2or/SU2areapplicable
foruseinhazardouslocations:
• No.IECExCSA07.0008
• ApplicableStandard:IEC60079-0:2004,
IEC60079-1:2003
• FlameproofforZone1,ExdIICT6...T4
• Enclosure:IP66/IP67
• MaximumProcessTemperature:120°C(T4),
100°C(T5),85°C(T6)
• AmbientTemperature:–50to75°C(T4),
–50to80°C(T5),–50to75°C(T6)
• SupplyVoltage:42Vdcmax.
• OutputSignal:4to20mAdc
Note2. Wiring
• Inhazardouslocations,thecableentrydevices
shallbeofacertiedameprooftype,suitablefor
theconditionsofuseandcorrectlyinstalled.
• Unusedaperturesshallbeclosedwithsuitable
ameproofcertiedblankingelements.
Note3. Operation
• WARNING:
AFTERDE-ENERGIZING,DELAY5MINUTES
BEFOREOPENING.
• WARNING:
 WHENAMBIENTTEMPERATURE≥65°C,USE
THEHEAT-RESISTINGCABLES≥90°C.
• Takecarenottogeneratemechanicalsparking
whenaccessingtotheinstrumentandperipheral
devicesinahazardouslocation.
Note4. MaintenanceandRepair
• Theinstrumentmodicationorpartsreplacement
byotherthanauthorizedrepresentativeof
YokogawaElectricCorporationisprohibitedand
willvoidIECExCertication.
2.5 EMCConformityStandards
EN61326-1ClassA,Table2(foruseinindustrial
locations)
EN61326-2-3
CAUTION
TomeetEMCregulations,Yokogawarecommends
thatcustomersrunsignalwiringthroughmetal
conduitsoruseshieldedtwisted-paircablingwhen
installingEJX/EJA-ESeriestransmittersinaplant.
HandlingCautions
2

  <2.HandlingCautions> 16
IM01C25A01-01E
2.6 PressureEquipment
Directive(PED)
(1) General
• EJX/EJA-ESeriespressuretransmittersare
categorizedaspipingunderthepressureaccessories
sectionofdirective97/23/EC,whichcorrespondsto
Article3,Paragraph3ofPED,denotedasSound
EngineeringPractice(SEP).
• EJX110A-MS,EJX110A-HS,
EJX110A-VS,EJA110Ewith/HG,EJ130,
EJ440,EJ510-D,EJ530-D,
EJX610A-D,andEJX630A-Dcanbeusedabove
200barandthereforeconsideredasapartofa
pressureretainingvesselwherecategoryIII,Module
Happlies.Thesemodelswithoptioncode/PE3
conformtothatcategory.
(2) TechnicalData
• Modelswithout/PE3
Article3,Paragraph3ofPED,denotedasSound
EngineeringPractice(SEP).
• Modelswith/PE3
 Module:H
 TypeofEquipment:PressureAccessory-Vessel
 Typeofuid:LiquidandGas
 Groupofuid:1and2
Model Capsule
code
PS*1
(bar) V(L) PS.V (bar.L) Category*2
EJA110E M,H,V 160 0.01 1.6
Article3,
Paragraph3
(SEP)
EJ110F,L
EJX110A
M,H,V 250 0.01 2.5
EJA110E
withcode
/HG
EJ110
withcode/
PE3
M,H,V 250 0.01 2.5 III
EJ130M,H 500 0.01 5.0
Article3,
Paragraph3
(SEP)
EJ130
withcode/
PE3
M,H 500 0.01 5.0 III
EJ310L,M,A,B 160 0.01 1.6
Article3,
Paragraph3
(SEP)
EJ430H,A,B 160 0.01 1.6
Article3,
Paragraph3
(SEP)
EJ440C,D 500 0.1 5.0
Article3,
Paragraph3
(SEP)
Model Capsule
code
PS*1
(bar) V(L) PS.V (bar.L) Category*2
EJ440
withcode/
PE3
C,D 500 0.1 5.0 III
EJ510
EJX610A
A,B,C 100 0.1 10 Article3,
Paragraph3
(SEP)
D 700 0.1 70
EJ510,
EJX610A
withcode/
PE3
D 700 0.1 70 III
EJ530,
EJX630A
A,B,C 100 0.1 10 Article3,
Paragraph3
(SEP)
D 700 0.1 70
EJ530,
EJX630A
withcode/
PE3
D 700 0.1 70 III
EJX910A L 160 0.01 1.6 Article3, Paragraph3
(SEP)
M,H 250 0.01 2.5
EJX910A
withcode/
PE3
M,H 250 0.01 2.5 III
EJX930A M,H 500 0.01 5.0
Article3,
Paragraph3
(SEP)
EJX930A
withcode/
PE3
M,H 500 0.01 5.0 III
*1: PSismaximumpressureforvesselitselfbasedon
PressureEquipmentDirective97/23/EC.Referto
GeneralSpecicationformaximumworkingpressureofa
transmitter.
*2: ReferredtoTable1coveredbyANNEXIIofECDirective
onPressureEquipmentDirective97/23/EC
(3) Operation
CAUTION
• Thetemperatureandpressureofuidshould
bemaintainedatlevelsthatareconsistentwith
normaloperatingconditions.
• Theambienttemperatureshouldbemaintained
atalevelthatisconsistentwithnormaloperating
conditions.
• Pleasetakecaretopreventwaterhammerandthe
likefrominducingexcessivepressuresinpipes
andvalves.Ifphenomenaarelikely,installasafety
valveortakesomeotherappropriatemeasureto
preventpressurefromexceedingPS.
• Takeappropriatemeasuresatthedeviceor
systemleveltoprotecttransmittersiftheyaretobe
operatednearanexternalheatsource.

  <2.HandlingCautions> 17
IM01C25A01-01E
2.7 LowVoltageDirective
Applicablestandard:EN61010-1
(1) PollutionDegree2
 "Pollutiondegree"describesthedegreetowhich
asolid,liquid,orgaswhichdeterioratesdielectric
strengthorsurfaceresistivityisadhering."2"applies
tonormalindooratmosphere.Normally,onlynon-
conductivepollutionoccurs.Occasionally,however,
temporaryconductivitycausedbycondensationmust
beexpected.
(2) InstallationCategoryI
 "Overvoltagecategory(Installationcategory)"
describesanumberwhichdenesatransient
overvoltagecondition.Itimpliestheregulationfor
impulsewithstandvoltage."I"appliestoelectrical
equipmentwhichissuppliedfromthecircuitwhen
appropriatetransientovervoltagecontrolmeans
(interfaces)areprovided.
HandlingCautions
2

  <3.Installation> 18
IM01C25A01-01E
3. Installation
IMPORTANT
• Whenweldingpipingduringconstruction,take
carenottoallowweldingcurrentstoowthrough
thetransmitter.
• Donotsteponthisinstrumentafterinstallation.
• ForEJ430,EJ440andEJ438,
theatmosphericopeningislocatedonthelow
pressuresidecoverange.ForEJ530and
EJX630AwhosecapsulecodeisA,B,orC,the
pipeoftheatmosphericopeningislocatedonthe
pressuredetectingsection.Theseopeningsmust
notfaceupward.
F00301.ai
Capsule code
Zero-adjustment screw
Pipe
(backside of the instrument)
6




Figure3.1 EJ530andEJX630AHorizontal
MountingPosition
3.1 Mounting
■ Thetransmittercanbemountedonanominal
50mm(2-inch)pipeusingthemountingbracket
supplied,asshowninFigure3.2and3.3.Tightenthe
(four)boltsthatholdthetransmitterwithatorqueof
approximately39N·m{4kgf·m}.
Transmitter
mounting bolt
U-bolt nut
Mounting bracket
50 mm(2-inch) pipe
U-bolt
F0302.ai
Figure3.2 TransmitterMounting
(HorizontalImpulsePipingType)
Vertical pipe mounting
(Process connector upside)
Transmitter
mounting bolt
Mounting
bracket
U-bolt nut
U-bolt
50 mm
(2-inch) pipe
Vertical pipe mounting
(Process connector downside)
F0303.ai
Figure3.3 TransmitterMounting
(VerticalImpulsePipingType)
Vertical pipe mounting
50 mm
(2-inch) pipe
U-bolt (L)
U-bolt (S)
Mounting
bracket
U-bolt
nut (S)
U-bolt nut (L)
Horizontal pipe mounting
F0304.ai
Figure3.4 EJ510andEJ530Mounting
3.2 MountingtheDiaphragmSeals
IMPORTANT
• Pleaseuseagasketwithaninsidediameter(ød)
thatisgreaterthanthediameterofthediaphragm
seal.Ifagasketwithasmallerinsidediameteris
used,thediaphragmmaynotfunctioncorrectly.
• Duringthediaphragmsealinstallation,ensureas
faraspossiblethatnosealliquidheadpressureis
appliedtothediaphragmseals.
• Exercisecaresoasnottodamagediaphragm
surfaces.Sincethediaphragmprotrudesapprox.
1mmfromtheangesurface,donotplacethe
pressuredetectorsectionfacedownonasurface
asthiscandamagethediaphragm.
• Donotsharplybendortwistcapillarytubeorapply
excessivestresstothem.
• Neverloosenthefourboltssecuringthecover
angeorthescrewsatthejointsbetweenthe
capillarytubeandcoveranges.Ifthesealliquid
leaks,thetransmittercannotbeused.
