GENLED Acolyte DiGidot CTRLPIXELTRMR User manual

Page 1Acolyte is a quality division of GENLED Brands™| www.AcolyteLED.com |Acolyte | Architectural Lighting Solutions
PXLNET TRANSMITTER MANUAL
CTRLPIXELTRMR
RoHS SPI DMX IP40
REV. 20SEP2023

Page 2Acolyte is a quality division of GENLED Brands™| www.AcolyteLED.com |Acolyte | Architectural Lighting Solutions Page 2Acolyte is a quality division of GENLED Brands™| www.AcolyteLED.com |Acolyte | Architectural Lighting Solutions
THANK YOU FOR CHOOSING ACOLYTE AND DIGIDOT!
Acolyte and DiGidot offer powerful products and solutions to control LED pixels.
C4 controllers are the heart of our control system, offering great exibility and simple
infrastructures. To benet from all our system advantages, we offer innovative accessories like
range extending equipment. These products allow you to send PxLNet, which is a high speed,
long-range SPI protocol. Install C4 controllers and PxLNet Transmitters in a central place for
easy access and maintenance.
Have fun creating mesmerizing lighting installations!
The Acolyte and DiGidot teams

Page 3Acolyte is a quality division of GENLED Brands™| www.AcolyteLED.com |Acolyte | Architectural Lighting Solutions
INDEX
Introduction 4
Contents 4
PxLNet Transmitter Features 4
Technical Drawings 5
Product Description 6
Technical Specications 7
Before Installation 8
Installation & Wiring 9
Mounting 10
Power Supply 11
Connecting Power 11
Wiring Schemes 12
Operation 14
Tips & Troubleshooting 15
General Information 15
Compliances 16

Page 4Acolyte is a quality division of GENLED Brands™| www.AcolyteLED.com |Acolyte | Architectural Lighting Solutions
INTRODUCTION
CONTENTS
PXLNET TRANSMITTER FEATURES
SPI protocols are sensitive to data distortion and often only work safely over up to 6.5 ft
(2 m) of cable distance. The PxLNet Transmitter is a small extension module that can be
connected to the C4 controller outputs. It converts SPI or DMX TTL signals to PxLNet to
send them across large distances. It can convert any industry standard SPI protocol that can
be output from an SPI controller. Output the same number of universes with this transmitter
as sent from the SPI controllers output port(s). This product can not only convert SPI
protocols but it also converts DMX TTL signals to standard DMX512. That means the PxLNet
Transmitter can be used to connect four differential DMX signals up to 1640 ft (500 m) away.
The onboard voltage regulator accepts voltages ranging from 12-24 VDC. Installation is easy
thanks to the RJ45 outputs, which quickly connect to our PxLNet Transceiver modules.
NOTE: We take great care with our products and have a standard of quality control, but we advise you to double-check for
missing or damaged items. In case of any missing or damaged items, please contact your supplier immediately. Never use
damaged products!
• Connects directly to C4 controller IO port
• Converts SPI and DMX TTL to PxLNet and DMX respectively
• Flexible operating voltage from 12-24 VDC
• 4 isolated RJ45 bus ports for PxLNet
• Built-in power supply for C4 controller
• Can be used with any third-party SPI controller
• One PxLNet Transmitter
• One 2 pin header, DC power terminal connector (already inserted)
• One quick start instruction card

Page 5Acolyte is a quality division of GENLED Brands™| www.AcolyteLED.com |Acolyte | Architectural Lighting Solutions
TECHNICAL DRAWINGS
0.98 in.
(25 mm)
2.56 in.
(65 mm)
2.56 in. (65 mm)
0.59 in.
(15.5 mm)
0.37 in.
(9.5 mm)

Page 6Acolyte is a quality division of GENLED Brands™| www.AcolyteLED.com |Acolyte | Architectural Lighting Solutions
PRODUCT DESCRIPTION
1. 4 PxLNet RJ45 output ports
2. Status LED power on (green)
3. Status LED transmitting data (yellow)
4. Power input (Left = DC- (GND) Right = DC+)
5. Power indicator LED (blue)
6. I/O Connector to C4 controllers
7. Mounting hole
Pin 1: Orange/White = (DMX) Data +
Pin 2: Orange = (DMX) Data -
Pin 3: --
Pin 4: --
Pin 5: --
Pin 6: --
Pin 7: Brown/White = (DMX) GND/DC -
Pin 8: Brown = (DMX) GND/DC

Page 7Acolyte is a quality division of GENLED Brands™| www.AcolyteLED.com |Acolyte | Architectural Lighting Solutions
TECHNICAL SPECIFICATIONS
Electrical
Input Voltage: 12-24 VDC
Max. power consumption: 1 W
Mechanical
Dimensions: 2.56 x 2.56 x 0.98 in. | 65 x 65 x 25 mm (L x W x H)
Net weight: 2.61oz (74gr)
Environmental
Operation Temperature (Tc): 32 to 122°F (0 to 50°C)
Max. ambient Temp. (Tamax): 104°F (40°C)
Storage temperature: -4 to 122°F (-20 to 50°C)
Max. operating relative humidity: 90% (indoor use only)
Protection
IP rating: IP40 (indoor use only)
DC input: Overvoltage protection (max. 24VDC)
Reverse polarity protection: Yes
Connectivity
Power wiring: Recommended: max. 14 AWG (2,5 mm2)
Quality
Warranty: 5-year factory warranty
Components: RU Certied
Compliances: CE, RoHS, ETL pending
Applied standards: EN60950-1:2006 +A11:2009 + A1:2010 + A12:2011 +
A2:2013, IEC60950-1 / EN60950-1, EN61006-6-3,
EN55032

Page 8Acolyte is a quality division of GENLED Brands™| www.AcolyteLED.com |Acolyte | Architectural Lighting Solutions
BEFORE INSTALLATION
Before installing our products it’s important to note the following safety and installation
instructions.
SAFETY INSTRUCTIONS
• Before installation and use of this product, read this manual carefully.
• Make sure these instructions are handed over to those responsible for installation, use
and maintenance of this product.
• Local electrical and safety rules and guidelines always overrule this manual.
• Installation should only be carried out by professional certied installers that are qualied
to work on electrical installations.
• Do not conduct any repairs of this device (there are no user serviceable parts inside).
Any unapproved repairs and/or product modications will void product warranty.
Acolyte and DiGidot Technologies B.V. cannot be held liable for any consequences.
• Repairs of this product may only be carried out by DiGidot Technologies B.V.
• Repairs and maintenance of the installation may only be carried out by qualied
technicians.
• Always disconnect the mains power when working on a high voltage electric installation.
Failure to do so may result in product damage and/or personal injury.
• Do not connect or modify this product other than described in this manual.
• Never use a product that is visibly damaged or does not work correctly. Never use a
product if it starts to smoke or if a crackling/sizzling noise is audible. If this is the case,
disconnect the power to the device and contact Acolyte immediately.
• The only way to power off this product is to disconnect it from the power source.
• The product is designed for indoor use (dry locations) only.

Page 9Acolyte is a quality division of GENLED Brands™| www.AcolyteLED.com |Acolyte | Architectural Lighting Solutions
INSTALLATION AND WIRING
WIRING
Please follow these instructions when connecting your controls system. Make sure to power
the C4 controller and PxLNet Transmitter individually. Use the supplied Power Jack cable to
power the C4 controller.
PxLNet Transmitter
12-24V DC
C4 Extended or C4 Live controller

Page 10Acolyte is a quality division of GENLED Brands™| www.AcolyteLED.com |Acolyte | Architectural Lighting Solutions
MOUNTING
Before mounting and connecting power to the PxLNet Transmitter, make sure to follow these
steps:
1. Disconnect power from the C4 controller.
2. Remove the terminal connector from the C4 controller I/O port.
3. Connect the I/O connector of the PxLNet Transmitter to the I/O port of the C4 controller in
the upright position. Be sure the connector is straight and rmly inserted.
4. Install the C4 and PxLNet Transmitter by inserting athead screws, spaced according to the
drawing below, in the mounting surface. Leave about 0.2 in. (4-5 mm) between the surface
and underside of the screw heads.
5. Position the mounting holes of both devices over the screws and slide them in place.
WARNING!
• This product should not be subjected to high temperatures (risk of fatal damage).
• Keep this product away from direct sunlight, rain or other moisture (risk of fatal damage).
• Do not use this product outdoors or in humid environments (short-circuit risk).

Page 11Acolyte is a quality division of GENLED Brands™| www.AcolyteLED.com |Acolyte | Architectural Lighting Solutions
POWER SUPPLY
CONNECTING POWER
Connect the power supply, DC+ and DC- (GND) to the corresponding power inputs of the
DiGidot PxLNet Transmitter terminal connector. When the Transmitter is powered and started
up, the status light next to the power input will show a blue light.
To power this product, the DC+ and DC- (GND) of the terminal connector must be
connected to a SELV rated power supply that provides appropriate power at the required
supply voltage (12-24 VDC).
IMPORTANT:
• This product should not be subjected to high temperatures (risk of fatal damage).
• Keep this product away from direct sunlight, rain or other moisture (risk of fatal damage).
• Do not use this product outdoors or in humid environments (short-circuit risk).

Page 12Acolyte is a quality division of GENLED Brands™| www.AcolyteLED.com |Acolyte | Architectural Lighting Solutions
WIRING SCHEMES
The following wiring schemes show various options to connect the PxLNet Transmitter.
WIRING SCHEME 1: CONNECT TRANSMITTER TO C4 CONTROLLER
The PxLNet Transmitter connects directly to the C4 controller. A PxLNet Transceiver Bus
Adapter (sold separately) must be placed on the terminal connector when using third party
SPI controllers.
PxLNet Transmitter
12-24V DC
C4 Extended or C4 Live controller
PxLNet
Ethernet
Ethernet
PxLNet
PxLNet
PxLNet
IMPORTANT:
The C4 controller is powered separately. This is done with a separate DC-Jack power
cable. See ‘Installation & Wiring’ section for more information about power distribution.

Page 13Acolyte is a quality division of GENLED Brands™| www.AcolyteLED.com |Acolyte | Architectural Lighting Solutions
WIRING SCHEME 2: CONNECTING TO PXLNET TRANSCEIVER
The PxLNet Transmitter can be connected to a PxLNet Transceiver to send signals across large
distances. For more wiring options, please refer to the PxLNet Transceiver manual.
WIRING SCHEME 3: CONNECTING TO DMX PRODUCTS
When connecting a DMX product where the wires need to be inserted in wire terminals or
soldered, the network cable must be stripped and wires must be connected as shown below.
(The indicated wire colors are according to the T-568B and ANSI ESTA E1-11 standard.)
PxLNet TransmitterPxLNet Transceiver
PxLNe
PxLNe
PxLNe
PxLNe
Cat-5 E cable
Max. 820 ft (250 m)
5-48V DC 12-24V DC
LEDs
DMX
DMX Out
GND
Data +
Data -
GND
Data +
Data -
GND
Data +
Data -
GND
Data +
Data -
DMX Out
DMX Out
DMX Out
DMX
DMX
DMX
Cat-5 E cable
Max. 1640 ft (500 m)
12-24V DC

Page 14Acolyte is a quality division of GENLED Brands™| www.AcolyteLED.com |Acolyte | Architectural Lighting Solutions
WIRING SCHEME 4: CONNECTING TO DMX ADAPTERS
We offer RJ45 to XLR adapters to connect to any DMX controlled device with a 3-pin XLR
connector. (The RJ45 pinout is according to the ANSI ESTA E1-11 standard and can also be
inserted directly in any DMX device with RJ45 input.)
SPI
A PxLNet Transmitter automatically converts any SPI output protocol to PxLNet and sends
it up to 820 ft (250 m) away to a PxLNet Transceiver, where it is converted to the original
protocol.
DMX
To transmit the DMX protocol directly from the PxLNet Transmitter, select ‘DMX TTL’ as
output protocol in the C4 controller interface. (The RJ45 pinout is according to ANSI ESTA
E1-11 standard, which means the RJ45 connector can be plugged in directly into DMX device
inputs or use a DMX XLR adapter. For the exact pinout, check product description above.)
PxLNet Transmitter
DMX Out
DMX Out
DMX Out
DMX Out
12-24V DC
DMX
DMX
DMX
DMX
Cat-5 E cable
Max. 1640 ft (500 m)
OPERATION

Page 15Acolyte is a quality division of GENLED Brands™| www.AcolyteLED.com |Acolyte | Architectural Lighting Solutions
TIPS & TROUBLESHOOTING
1. If run into any trouble, please check your setup according to following checklist:
2. Double check all cables and connections.
3. Double check any soldered connections.
4. Double check the network cable pinout and crimped connectors.
5. Is the C4 controller powered correctly?
6. Are the LEDs powered correctly?
7. Are all power supplies connected correctly to your mains power supply?
8. Is your network setup done correctly?
• Prevent IP Address conicts
• Make sure that the subnet mask is set correctly and that all IP addresses are set within
the appropriate range.
• Refer to further troubleshooting tips in the C4 Controller user manual.
9. Are the C4 controller inputs and outputs congured correctly?
• Make sure that the IC/SPI protocol is congured correctly.
• Make sure that input and output matches the system setup. Use the highlight option to
test the outputs.
10. Double check that all grounds (DC-) from any power supplies for any lighting products
controlled by one C4 controller and PxLNet Transmitter are connected.
GENERAL INFORMATION
ONLINE RESOURCES
For technical specications, latest documentation, manuals, product information and further
support please visit www.digidot.eu.
REMARKS
We’ve taken great care in writing this manual. However, if you encounter any discrepancies or
something isn’t clear, please contact us.

Page 16Acolyte is a quality division of GENLED Brands™| www.AcolyteLED.com |Acolyte | Architectural Lighting Solutions
COMPLIANCES & EU DECLARATION OF CONFORMITY
This product was designed and produced by DiGidot Technologies B.V., Amsterdam, The Netherlands.
CE MARKING
DiGidot Technologies BV hereby declares that this product complies with and was tested according to all
essential requirements of all relevant CE directives.
WARRANTY
This product has a carry-in manufacturer’s warranty of 5 years which covers any design faults, production
faults and component failures. Warranty is void if the product was installed or used incorrectly or not in
accordance with this manual, and/or if the product was damaged due to external factors, modied or
electrically overloaded. Warranty conditions of DiGidot Technologies B.V. apply. Warranty claims must be
issued by email to [email protected].
DISPOSAL AND RECYCLING
This product should not be disposed of with other household waste. When you decide to dispose of this
product and/or its battery, obey local environmental and recycling regulations.
FEEDBACK
Tell us all about your experience with the PxLNet Controller! The continuous development of this control platform is only
possible thanks to feedback from our users. If you have any suggestions, please contact us by email: [email protected].
IMPRINT
DiGidot Technologies BV Valschermkade 27-28 1059 CD Amsterdam The Netherlands
Phone: [phone]
[email protected] www.digidot.eu
Chamber of commerce registration: 67637825
VAT identication no.: NL857103581B01
Managing director: Stefan Verhoef
COPYRIGHT
© 2021 DiGidot Technologies BV. All rights reserved.
Errors and omissions excepted. The information in this document is subject to change at any time without prior notice. Visit
our digidot.eu for the most recent version of this document. It’s not allowed to copy or reproduce, translate or publish the
information within this document without prior written approval from DiGidot Technologies BV.
DISCLAIMER
Acolyte and DiGidot Technologies B.V. cannot be held liable for improper handling, product installation, usage or storage.
Acolyte and DiGidot Technologies B.V. explicitly reject any form of liability claims in advance, whether it concerns direct
or indirect disadvantages, damage, injuries, loss of income or other nancial, materialistic or personal consequences that
are directly or indirectly caused by use of this product or its owner or user. Any form of intended or unintended misuse of
this information and/or Acolyte and DiGidot products indemnies Acolyte and DiGidot Technologies B.V. from liability and
warranty obligations.
5Yr
