EV LIGHT HL RGBW-S User manual

HL RGBW-S
USER Manual
Please read it carefully

1
Menu
1. Safety Guideline..............................................................................................................................................2
2. Technical Parameter....................................................................................................................................... 3
3. Parts .................................................................................................................................................................3
4. Installation .................................................................................................................................................... 4
4.1. Hoisting ......................................................................................................................................................4
4.2. DMX512 Connection ..................................................................................................................................4
5. Lighting Setting Parrameter Reset ................................................................................................................ 5
5.1. Control panel ........................................................................................................................................... 5
5.2. Main Function ......................................................................................................................................... 5
6. Lighting Control ..............................................................................................................................................8
6.1. Master/Slave Built In Preprogrammed Function .................................................................................... 8
6.2. DMX Controller ...................................................................................................................................... 8
6.3. DMX Channel ..........................................................................................................................................9
7. DMX512 configuration ................................................................................................................................. 10
8.Troubleshooting ............................................................................................................................................ 11
9.Fixture Cleaning .............................................................................................................................................11

2
1. Safety Guideline
WARNING
Please read the instruction carefully which includes important
information about the installation, usage and maintenance.
Please keep this User Guide for future consultation. If you sell the unit to another user, be sure
that they also receive this instruction manual.
Important:
Damages caused by the disregard of this user manual are not subject to warranty. The dealer
will not accept liability for any resulting defects or problems.

Unpack and check carefully that there is no transportation damage before using the unit.

The unit is for indoor use only. Use only in a dry location.
 DO install and operate by qualified operator.

DO NOT allow children to operate the fixture.

The unit must be installed in a location with adequate ventilation, at least 50cm from adjacent
surfaces.
 Be sure that no ventilation slots are blocked, otherwise the unit will be overheated.

Before operating, ensure that the voltage and frequency of power supply match the power
requirements of the unit.

It’s important to ground the yellow/green conductor to earth in order to avoid electric shock.
 Maximum ambient temperature TA: 40℃.
 DO NOT connect the device to any dimmer pack.
 During initial start-up some smoke or smell may arise. This is a normal process and does not
necessarily mean that the device is defective, and it will decrease gradually within 15 minutes.

Make sure there are no flammable materials close to the unit while operating to avoid fire hazard.

Examine the power wires carefully; replace them immediately if there is any damage.

Unit’s surface temperature may reach up to 65℃. DO NOT touch the housing bare-handed during its
operation, and allow about 15 minutes for cooling the unit down before replacing bulb or
maintenance as it could be very hot.

Avoid any inflammable liquids, water or metal objects entering the unit. Once it happens, cut off

3
the mains power immediately.
 DO NOT operate in dirty or dusty environment, do clean fixtures regularly.
 DO NOT touch any wire during operation as there might be a hazard of electric shock.

Avoid power wires together twist other cables.

DO NOT open the unit as there are no user serviceable parts inside.

Never try to repair the unit by yourself. Repairs carried out by unskilled people can lead to damage or
malfunction. Please contact the nearest authorized technical assistance center if needed.
 Disconnect the mains power if the fixture is has not been used for a long time.
 DO use the original packing materials before transporting it again.
Cautions:
 To prevent or reduce the risk of electrical shock or fire, do not expose the unit to rain or moisture.
 DO replace the bulb once it is damaged, deformed or life-expired.

DO NOT look directly at the light while the bulb is on.
 Never touch bulb with bare fingers, as it is very hot after using.

DO NOT start on the unit when housing is damaged.
2.Technical Parameter:
1.Input Voltage:
AC 100~240V, 50/60Hz
2.Total Power consumption:
72W
3.LED Sources:
CREE LED
4.Beam Angle:
35°or 60°
5.Color:
RGBW linear color mixing
6.Color Temperature:
color cast calibration setting、color
temperature output inside device
7.Dimmer：
0-100% linearly dimming，5 types dimmer
modes，smooth dimming, flicker-free；
8.Shutter：
independent electronic strobe；
9.Control Mode：
Standard DMX512
10.channel modes:
4,5,7, 9 CH；
11.Waterproof Grade
IP20
12.Work Environment Temperature
-20°C～40°C

4
13.Dimension:
303x175x175mm
14.N.W:
3.25Kgs
3.Parts
Standard accessories
1. 1PCS 1.5m POWERCON
2. 1PCS 1.5m three core DMX signal wire
Optional accessories:
1. Handle 2.Lamp hook (various models available)
4.Lighting setting parameter reset
4.1.Hoisting
The lamp hook or safety rope can be used according to the situation.
Lamp hook (only one lamp can be hoisted)
We provide different types of lamp hooks for
selection. The following installationdrawing is for
reference.
Use screws and nuts to fix the lamp hook on the
lamp through the hole above the lamp. Fix the lamp
on the bracket.
4.2. DMX512 Connection
DMX signal line (30 lamps in series)
Power supply (one power supply is connected to only one lamp)
The following installation drawing is for reference:
