Event Lighting WDMXTRXIP User manual

WDMXTRXIP
WDMX Transmitter and Receiver
USER MANUAL
For your safety, please read this user manual carefully before use.
Event Lighting reserves the right to revise the manual at any time. Information and specifications
within this manual are subject to change without notice. Event Lighting assumes no liability or
responsibility for any errors or omissions. Please consult Event Lighting for any clarification or
information regarding this item.
Version 1.0

www.event-lighting.com.au
1
Technical Specifications
• Power: 100 - 240V, 50 - 60Hz
• Power Consumption: 1.75W
• Power Connection: Seetronic® Outdoor Powerkon Input
• Max Transaction Power: 23dBm
• Receiver Sensitivity: -94dBm
• Band: 2.402Ghz - 2.480Ghz, ISM, 79 channels
• Spread Spectrum: FHSS, 1100 hops/s
• Modulation: GFSK
• Channel Groups: 6 in ELDMX mode
• DMX Interface: Seetronic® 3 Pin Outdoor in / out DMX Interfaces
• Housing Materials: Die-cast Aluminium Housing
• IP Rating: IP65
Setup Mode
To enter Setup Mode, press and hold the button whilst powering up. Once the device powers up,
the unit will be in Setup Mode.
The light will be lit a specific colour to indicate the protocol being used for the transmission as
shown in Table 1 below.
Pressing the button will cycle through the colours and once you want to set the protocol pressing
the button for more than 1s will save the protocol.
The transmitters, receivers and transceivers will remember the protocol used even after a power
cycle with their built in memory chip.
Protocols Table 1
Colour
Protocol
Red
ELDMX Transmit and receive
Green
W-DMX Receive
Blue
W-DMX G3 Transmit
Use Mode
Changing Channel Group
Pressing the Button will show you the current channel group being used and pressing it again will
cycle through the groups. The colour of the light will indicate the group as shown in Table 2.

www.event-lighting.com.au
2
Status Indicators Table 2
Protocol
Action
Description
ELDMX
Solid Colour (Red, Green,
Blue,
Yellow, Cyan, Magenta)
1 of the 6 colour groups
Flashing Red
Transmitting DMX
Flashing Green
Receiving DMX
W-DMX Receive
White
No connection
Red
Deleting Connection
Red Fast Flash
Connection Lost
Green Fast Flash
Connecting to Transmitter
Green Slow Flash
Connected but no DMX signal
Green
Connected with DMX signal
W-DMX Transmit
Red
Deleting All Receivers
Blue Fast Flash
Connecting with the receivers
Blue Slow Flash
No DMX input
Blue
Transmitting DMX
W-DMX Mode
Transmitters
Pressing the button momentarily will connect to all unconnected receivers in the coverage area.
Pressing the button for more than 3s will disconnect all receivers in the coverage area.
Receivers
Pressing the button for more than 3s will disconnect the device with a transmitter.
Note: The receiver will not connect with a new transmitter unless it is disconnected first.

www.event-lighting.com.au
3
Common Applications
One to One
One to Many
Many* to Many (*6 channel groups maximum in WIDMX)
Repeater (*6 channel groups maximum in WIDMX)
