CYP CSI-8H8CV2IR User manual

CSI-8H8CV2IR
8 HDMI over CAT6 Point-to-Point Transmitter
(with IR Matrix)
Operation Manual
Operation Manual

DISCLAIMERS
The information in this manual has been carefully checked and
is believed to be accurate. Cypress Technology assumes no
responsibility for any infringements of patents or other rights of third
parties which may result from its use.
Cypress Technology assumes no responsibility for any inaccuracies
that may be contained in this document. Cypress also makes no
commitment to update or to keep current the information contained
in this document.
Cypress Technology reserves the right to make improvements to this
document and/or product at any time and without notice.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted,
transcribed, stored in a retrieval system, or any of its part translated
into any language or computer le, in any form or by any means—
electronic, mechanical, magnetic, optical, chemical, manual, or
otherwise—without express written permission and consent from
Cypress Technology.
© Copyright 2011 by Cypress Technology.
All Rights Reserved.
Version 1.1 August 2011
TRADEMARK ACKNOWLEDGMENTS
All products or service names mentioned in this document may be
trademarks of the companies with which they are associated.

SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or
operate this equipment and before connecting the power supply.
Please keep the following in mind as you unpack and install this
equipment:
• Always follow basic safety precautions to reduce the risk of re,
electrical shock and injury to persons.
• To prevent re or shock hazard, do not expose the unit to rain,
moisture or install this product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through any
openings or empty slots in the unit, as you may damage parts
inside the unit.
• Do not attach the power supply cabling to building surfaces.
• Use only the supplied power supply unit (PSU). Do not use the PSU
if it is damaged.
• Do not allow anything to rest on the power cabling or allow any
weight to be placed upon it or any person walk on it.
• To protect the unit from overheating, do not block any vents or
openings in the unit housing that provide ventilation and allow for
sufcient space for air to circulate around the unit.
REVISION HISTORY
VERSION NO. DATE DD/MM/YY SUMMARY OF CHANGE
VR0 11/07/12 Preliminary Release
VR1 17/02/13 Add CAT5e/6/7 Cable Spec.

CONTENTS
1. Introduction...............................................................1
2. Applications..............................................................1
3. Package Contents ...................................................1
4. System Requirements...............................................1
5. Features.....................................................................2
6. Operation Controls and Functions..........................3
6.1 Front Panel .........................................................3
6.2 Rear Panel..........................................................4
6.3 Remote Control for IR Matrix............................5
6.4 IR Custom Code................................................5
6.5 Discrete IR Codes..............................................6
6.6 IR Dip Switch Position with Output Selection..6
6.7 IR Cable Pin Assignment...................................7
6.8 RS-232 Pin Assignments.....................................8
6.9 RS-232 Commands for IR Matrix.......................9
7. Connection Diagram .............................................11
8. Specications .........................................................13
9. Acronyms ................................................................14

1
1. INTRODUCTION
The 8 HDMI over CAT6 Point-to-Point Transmitter (with IR Matrix)
supports the transmission of Video (up to 1080p Full HD/1920×1200@60
Hz) with multichannel digital audio, up to eight pairs of high denition
source and CAT5e/6 output. It supports digital audio formats such
as LPCM 7.1CH, Dolby TrueHD, Dolby Digital Plus and DTS-HD Mater
Audio. 3D content can be displayed when connecting a 3DTV and 3D
source. The Transmitter allows the point-to-point connection between
source equipment and output display, over distances up to 100
meters along with PoE (Power over Ethernet) feature. There is a built-
in crosspoint IR matrix providing additional control over 8-in-8-out IR
channels.
2. APPLICATIONS
• Commercial advertising and display
• Lecture room display and control
• Hyper market demonstration and control
• Any Smart AV Installation
3. PACKAGE CONTENTS
• HDMI over CAT6 Transmitter with 8×8 IR Matrix
• 8×Receiver for HDMI over CAT6 (Optional)
• 2×IR Extender
• 2×IR Blaster
• 24 V/6.25 A DC Adaptor
• Remote Control with 3V battery
• Operation Manual
4. SYSTEM REQUIREMENTS
• HDMI equipped input source devices with HDMI cables
• HDMI equipped output displays (TVs or monitors) or HDMI equipped
AV receivers with HDMI cables
• Industry standard CAT5e/6/7 cables

2
5. FEATURES
• HDMI, HDCP1.1 and DVI compliant
• Supports HDMI 3D, 4k x 2k features
• Supports Stereo digital audio signal input and output
• Supports high bit-rate audio up to 192 kHz
• Supports resolutions VGA~WUXGA and 480i~1080p dependent upon
the output display’s EDID settings
• Supports extension up to 100 meters through CAT5e/6
• Supports 3D signal display dependent upon the output display's
EDID settings
• Supports HDMI input up to 10 meters at 8-bit resolution or 3 meters at
12-bit resolution
• Supports bi-directional IR from input and output locations
• Supports RS-232, remote control and on-panel control
• Supports PoE (Power over Ethernet) on compatible receivers only
• 2U size design
Note: The PoE function is designed for powering compatible receiver
units only—non-PoE receivers will need their own power supply.
Receivers of another brand may not be compatible.

3
6. OPERATION CONTROLS AND FUNCTIONS
6.1 Front Panel
IR
Power All Lock Enter
12
5678
34
8 HDMI Over CAT6 Transmitter w/IR Matrix
2 3 4 5 6 71
1
LCM: Displays the information for each IR input and output setting.
2
IR: IR Receiver window (accepts the remote control signal of this
device and all output displays or source devices).
3
Power: Press this button to power the device on/off. The LED will
illuminate green when the power is on, red when it is in 'Standby'
mode.
4
All: Press this button to select all IR output with one IR input signal.
The sequence should be pressed ALL → Number Key → ENTER.
5
Lock: Press this button to lock all the buttons on the panel; press
again to unlock. The LED will illuminate in green when locked.
6
Enter: Press this button to conrm when changing a setting.
7
Selection 1~8
When selecting the IR input for a specic IR output, press the
Number Key rst to select the output and then press the Number
Key again to select the input.

4
6.2 Rear Panel
RS232
MAIN
RS232
AUX
CAT Out CAT Out CAT Out
HDMI In 1 HDMI In 2 HDMI In 3
CAT Out
HDMI In 4
CAT Out
HDMI In 5
CAT Out
HDMI In 6
CAT Out
HDMI In 7
CAT Out
HDMI In 8
DC 24V
1
2
3
4
V+
GND
GND
V+
GND
12345678All
IR Extender
IR Blaster
21
43 6
7
5
1
RS-232 AUX: Connect to a device that can be controlled (via D-Sub
9-pin male cable) by RS-232 commands.
2
RS-232 MAIN: Connect to a PC or laptop with D-Sub 9-pin male
cable for the transmission of RS-232 commands.
3
IR Blaster 1~All: Connect the supplied IR blasters (included in the
package) for IR signal transmission, IR signals will be relayed from the
designated output IR extender. For the "All" port, the IR signals will be
relayed from all output at the same time. Place the IR blaster in direct
line-of-sight of the equipment to be controlled.
4
IR Extender 1~All: Connect the supplied IR extenders (included in
the package) for IR signal reception the signal will be relayed to the
designated output device via the IR blaster. For the "All" port, the
signal will be relayed to all outputs. Ensure that remote being used is
within the direct line-of-sight of the IR extender.
5
HDMI In 1~8: Connect to the HDMI input source devices such as a
DVD player or a Set-top Box with HDMI cables or DVI to HDMI cables.
6
CAT Out 1~8: Connect to the CAT in port of receiver units with a
single CAT5e/6/7 cable for HDMI Audio/Video and IR/RS-232 control
signal sending.
Note: Do NOT connect these CAT outputs to the LAN port of
receiver units—this will cause serious damage to the receiver unit.
7
DC 24V: Plug the 24 V DC power supply (included in the package)
into the unit and connect the adaptor to an AC outlet. This unit will
also power PoE (Power over Ethernet) capable receiver units.

5
6.3 Remote Control for IR Matrix
The remote control unit included in the package is
for IR Matrix only, and can be used to control the
IR channel mapping of individual or all receivers,
depends on the dipswitch setting.
There are total of four dipswitches, when all of
them are set to ON/↑, the remote control unit is
able to control the IR routing of all receivers. For
example, if you want to set up the bi-directional IR
channel between Output A receiver and Input 5,
simply press A rst and then press 5.
You can set the remote control unit to control the
IR routing of single receiver only, please refer to
the dipswitch settings in section 6.6. For example,
when all dipswitches are set to OFF/↓, only the IR
channel of Output A receiver can be selected,
when you want to set up the bi-directional IR channel between
Output A receiver and Input 3, simply press 3.
6.4 IR Custom Code
NO. DATA NO. DATA
1 88 A 8A
2 8C B 8E
3 90 C 92
4 85 D C6
5 C2 E 99
6 9C F 98
7 D8 G 84
8 87 H 97
H
8
1A
B
2
C
3
4D
5E
6F
7G
CR-110
IN OUT

6
6.5 Discrete IR Codes
Select /
Dipswitch
Custom
Code
output A ↓↓↓↓ 807F
output B ↑↓↓↓ 807B
output C ↓↑↓↓ 8077
output D ↑↑↓↓ 8073
output E ↓↓↑↓ 803F
output F ↑↓↑↓ 803B
output G ↓↑↑↓ 8037
output H ↑↑↑↓ 8033
6.6 IR Dip Switch Position with Output Selection
Selects
OUTPUT A
Selects
OUTPUT E
Selects
OUTPUT B
Selects
OUTPUT F
Selects
OUTPUT C
Selects
OUTPUT G
Selects
OUTPUT D
Selects
OUTPUT H

7
6.7 IR Cable Pin Assignment
3
1
3
1
2
2
Power 5 V
IR Blaster Signal
NC
IR Signal
Power 5 V
Grounding
IR Receiver
IR Blaster

8
6.8 RS-232 Pin Assignments
CSI-8H8CV2IR
Remote Control Console
PIN Assignment PIN Assignment
1 NC 1 NC
2 TX 2 RX
3 RX 3 TX
4 NC 4 NC
5 GND 5 GND
6 NC 6 NC
7 NC 7 NC
8 NC 8 NC
9 NC 9 NC
Baud Rate: 19200 bps/A or 9600/B
Data bit: 8-bit
Parity: None
Stop bit: 1-bit
Flow Control: None

9
6.9 RS-232 Commands for IR Matrix
Command A Description
A1~A8 Switch Output A to 1~8
B1~B8 Switch Output B to 1~8
C1~C8 Switch Output C to 1~8
D1~D8 Switch Output D to 1~8
E1~E8 Switch Output E to 1~8
F1~F8 Switch Output F to 1~8
G1~G8 Switch Output G to 1~8
H1~H8 Switch Output H to 1~8
ABCD...1~ABCD...8 Switch Output A B C D... to 1~8 at the same
time
P0 Power OFF
P1 Power ON
I1~I8 Switch all the Output to 1~8
ST Display the current matrix status and F/W version
RS System reset to A1, B2, C3, D4, E5, F6, G7, H8
?Display all available commands
Note: 1. Press "ALL" + "ENTER" +"1" buttons all together from the panel
to switch RS-232 to A and the LCM will display baud rate
19200bps.
2. Command "RS" will reset output A~H to 1~8 and shut down
the device automatically.

10
Command B Description
POWER 00 Power Off (Standby)
POWER 01 Power On
PORT 11~18 Output A select Input1~8
PORT 21~28 Output B select Input1~8
PORT 31~38 Output C select Input1~8
PORT 41~48 Output D select Input1~8
PORT 51~58 Output E select Input1~8
PORT 61~68 Output F select Input1~8
PORT 71~78 Output G select Input1~8
PORT 81~88 Output H select Input1~8
Note: 1. Press "ALL" + "ENTER" +"2" buttons all together from the panel
to switch RS-232 to B and the LCM will display baud rate
9600bps.
2. All the commands will not be executed unless followed with a
carriage return. All letters are not case-sensitive.

11
7. CONNECTION DIAGRAM
RS232
MAIN
RS232
AUX
CAT Out CATOut CAT Out
HDMI In 1 HDMIIn 2 HDMI In 3
CAT Out
HDMI In 4
CAT Out
HDMI In 5
CAT Out
HDMI In 6
CAT Out
HDMI In 7
CAT Out
HDMI In 8
DC 24V
1
2
3
4
V+
GND
GND
V+
GND
12345678All
IR Extender
IR Blaster
ZONE A
RX
ZONE
B
Power
Extender Blaster
IR2
IR1
RS232Out CAT5e/6In
Link RX Power
Extender Blaster
IR2
IR1
RS232Out CAT5e/6In
Link
ZONE C
RX Power
Extender Blaster
IR2
IR1
RS232Out CAT5e/6In
Link
ZONE
D
RX Power
Extender Blaster
IR2
IR1
RS232Out
CAT5e/6In
Link
RX Power
Extender Blaster
IR2
IR1
RS232Out CAT5e/6In
Link RX Power
Extender Blaster
IR2
IR1
RS232Out CAT5e/6In
Link RX Power
Extender Blaster
IR2
IR1
RS232Out CAT5e/6In
Link
ZONE
EZONE FZONE GZONE H
RX Power
Extender Blaster
IR2
IR1
RS232Out CAT5e/6In
Link
LAN
DC 24V
IR-In
RS-232 Service
A
HDMI Out
1
HDMI In
B
HDMI Out
2
HDMI In
C
HDMI Out
3
HDMI In
D
HDMI Out
4
HDMI In
E
HDMI Out
5
HDMI In
F
HDMI Out
6
HDMI In
G
HDMI Out
7
HDMI In
H
HDMI Out
8
HDMI In
12
34
V+
GND
GND
GND
V+
12
34
V+
GND
GND
GND
V+
123456 87
IR BLASTER
1.5m
60°
IR RECEIVER
7m
3m 3m
60°
m
Receiver Units
Single
CAT 5e/6
Cable
RS-232
HDMI Outputs
IR Out/In
Displays
RS-232 Equipped
PC or Notebook
8x8 HDMI Matrix
Transmitter
Source
Equipment
HDMI
Inputs

12
RS232
MAIN
RS232
AUX
CAT Out CATOut CAT Out
HDMI In 1 HDMIIn 2 HDMI In 3
CAT Out
HDMI In 4
CAT Out
HDMI In 5
CAT Out
HDMI In 6
CAT Out
HDMI In 7
CAT Out
HDMI In 8
DC 24V
1
2
3
4
V+
GND
GND
V+
GND
12345678All
IR Extender
IR Blaster
ZONE A
RX
ZONE B
Power
Extender Blaster
IR2
IR1
RS232Out CAT5e/6In
Link RX Power
Extender Blaster
IR2
IR1
RS232Out CAT5e/6In
Link
ZONE C
RX Power
Extender Blaster
IR2
IR1
RS232Out CAT5e/6In
Link
ZONE D
RX Power
Extender Blaster
IR2
IR1
RS232Out CAT5e/6In
Link
RX Power
Extender Blaster
IR2
IR1
RS232Out CAT5e/6In
Link RX Power
Extender Blaster
IR2
IR1
RS232Out CAT5e/6In
Link RX Power
Extender Blaster
IR2
IR1
RS232Out CAT5e/6In
Link
ZONE E
ZONE
FZONE GZONE
H
RX Power
Extender Blaster
IR2
IR1
RS232Out CAT5e/6In
Link
LAN
DC 24V
IR-In
RS-232 Service
A
HDMI Out
1
HDMI In
B
HDMI Out
2
HDMI In
C
HDMI Out
3
HDMI In
D
HDMI Out
4
HDMI In
E
HDMI Out
5
HDMI In
F
HDMI Out
6
HDMI In
G
HDMI Out
7
HDMI In
H
HDMI Out
8
HDMI In
12
34
V+
GND
GND
GND
V+
12
34
V+
GND
GND
GND
V+
123456 87
IR BLASTER
1.5m
60°
IR RECEIVER
7m
3m 3m
60°
m
Power Supply
Power Supply
8x8 HDMI Matrix
Transmitter
IR Out (All)
IR In (ALL)
IR Out/In
HDMI
Outputs

13
8. SPECIFICATIONS
Video Bandwidth 300 MHz/10.2 Gbps
Input Ports 8×HDMI, 9×IR Extender, 1×RS-232
Output Ports 8×CAT5e/6/7, 9×IR Blaster, 1×RS-232
Input/Output Resolution VGA~WUXGA, 480i~1080p@24/50/60,
4kx2k@24/25/30
ESD Protection Human-body Model:
±8 kV (Air-gap discharge)
±4 kV (Contact discharge)
Power Supply 24 V/6.25 A DC (US/EU standards, CE/FCC/
UL certied)
Dimensions 432 mm (W)×210 mm (D)×93 mm (H)
Weight 3312 g
Chassis Material Metal
Silkscreen Color Black
Operating Temperature 0 ºC~40 ºC/32 ºF~104 ºF
Storage Temerature −20 ºC~60 ºC/−4 ºF~140 ºF
Relative Humidity 20~90 % RH (non-condensing)
Power Consumption 90 W (Including Transmitter)
CAT5e/6/7 Cable Specication
Cable
Type
Range Pixel clock
rate
Video Data
Rate
Supported Video
CAT5e/6/7 100 m <=225 MHz <=5.3 Gbps
(HD Video)
Up to 1080p, 60 Hz,
36 bits, 3D (data
rates lower than 5.3
Gbps or below 225
MHz TMDS clock).
70 m >225 MHz > 5.3 Gbps
(Ultra HD
Video)
4K2K, 30Hz video
formats

14
9. ACRONYMS
ACRONYM COMPLETE TERM
DTS Digital Theater System
DVI Digital Visual Interface
EDID Extended Display Identication Data
HDCP High-bandwidth Digital Content Protection
HDMI High-Denition Multimedia Interface
LCM Liquid Crystal Module
USB Universal Serial Bus
VGA Video Graphics Array
WUXGA Widescreen Ultra Extended Graphics Array

Home page: http://www.cypress.com.tw
CYPRESS TECHNOLOGY CO., LTD
20120620 MPM-CSI8H8CV2IR
