Everex CloudBook CE1200V Series User manual

User Guide
CloudBook CE1200V

CloudBook User Guide
2
Copyright©2008
All Rights Reserved - Printed in Taiwan
Everex CloudBook User Guide
Original Issue: 2008/01
This manual guides you in setting up and using your new CloudBook (Ultra-
Mobility personal computer). Information in this manual has been carefully
checked for accuracy and is subject to change without notice.
No part of this manual may be reproduced, stored in a retrieval system, or
transmitted, in any form or by any means, electronic, mechanical, photocopy,
recording, or otherwise, without prior written permission.
Trademarks
Product names used herein are for identification purposes only and may be the
trademarks of their respective companies.
VIA C7TM M is registered trademark of VIA Technologies, Inc.
Sound Blaster, Sound Blaster Pro are trademarks of Creative Technology.
Google™, Gmail™, Gtalk™, Google Documents & Spreadsheets™, Google
News™, Google Maps™, Google Product Search™, Picasa™, Blogger™,
YouTube™, Google Toolbar™ and the Google logo are trademarks or
registered trademarks of Google Corporation in the United States and other
countries.
Mozilla™, Mozilla Firefox™ and Mozilla Thunderbird™ are trademarks of
Mozilla Foundation.
Skype™ is a registered trademark of Skype Limited.

Notebook User Guide
3
Meebo™ is a registered trademark of Meebo, Inc.
OpenOffice 2.2™ is a registered trademark of Sun Microsystems.
Wikipedia™ is a registered trademark of Wikimedia Foundation.
Apple and iPod are trademarks of Apple Inc., registered in the U.S. and other
countries.
GIMP, TotemPlayer and RhythmBox are Open Source projects produced by
their respective communities and volunteers.
All other brands or product names mentioned in this manual are trademarks or
registered trademarks of their respective companies.

CloudBook User Guide
4
FCC Information to User
Safety and Care Instructions
No matter what your level of experience with computers, please make sure you
read the safety and care instructions. This information can help protect you
and your computer from possible harm.
Radio and television interference
Warning: Use the specified shielded power cord and shielded signal cables
with this computer, so as not to interfere with radio and television reception. If
you use other cables, it may cause interference with radio and television
reception.
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does not cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encourage to try to correct the interference by one or more
of the following measures:
•Reorient or relocate the receiving antenna
•Increase the separation between the device and receiver
•Connect the device into an outlet on a circuit different from that to
which the receiver is connected.
•Consult the dealer or an experienced radio/television technician for help.

Notebook User Guide
5
You may find helpful the following booklet, prepared by the Federal
Communications Commission: Interference Handbook (stock number 004-
000-00345-4). This booklet is available from the U.S. Government Printing
Office, Washington, DC20402
Warning: The user must not modify or change this computer without
approval. Modification could void authority to this equipment.
FCC RF Exposure
FCC RF Radiation Exposure Statement:
This Transmitter must not be co-located or operating in conjunction with any
other antenna or transmitter.
This equipment complies with FCC RF radiation exposure limits set forth for
an uncontrolled environment. This equipment should be installed and operated
with a minimum distance of 20 centimeters between the radiator and your
body.
15.247 (b)(4), the EUT meets the requirement that it be operated in a manner
that ensures the public is not exposed to radio frequency energy levels in
excess of the Commission’s guidelines (1.1307, 1.1310, 2.1091 and 2.1093)
5.105 Federal Communications Commission (FCC) Requirements, Part
15
This equipment has been tested and found to comply with the limits for a class
B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that

CloudBook User Guide
6
interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following measures:
---Reorient or relocate the receiving antenna.
---Increase the separation between the equipment and receiver.
---Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
---Consult the dealer or an experienced radio/TV technician for help.
5.21 Regulatory information/Disclaimers
Installation and use of this Wireless LAN device must be in strict accordance
with the instructions included in the user documentation provided with the
product. Any changes or modifications (including the antennas) made to this
device that are not expressly approved by the manufacturer may void the user’s
authority to operate the equipment. The manufacturer is not responsible for
any radio or television interference caused by unauthorized modification of
this device, or the substitution of the connecting cables and equipment other
than manufacturer specified. It is the responsibility of the user to correct any
interference caused by such unauthorized modification, substitution or
attachment. Manufacturer and its authorized resellers or distributors will
assume no liability for any damage or violation of government regulations
arising from failing to comply with these guidelines.

Notebook User Guide
7
Canadian Department of Communications Compliance
Statement
Shielded Cables Notice
All connections to other computing devices must be made using shielded
cables to maintain compliance with FCC regulations.
Peripheral Devices Notice
Only peripherals (input/output devices, terminals, printers, etc) certified to
comply with Class B limits may be attached to this equipment. Operation with
non-certified peripherals is likely to result in interference to radio and TV
reception.
Optical Disk Drive Notice
The optical disk drive is Class 1 Laser Product.
Caution
Changes or modifications not expressly approved by the manufacturer may
void the user’s authority, which is granted by the Federal Communications
Commission, to operate this computer.
Use Conditions
This part complies with Part 15 of the FCC Rules. Operation is subject to the
following conditions: (1) this device may not cause harmful interference, and

CloudBook User Guide
8
(2) this device must accept any interference received, including interference
that may cause undesired operation.
European Notice
For the following equipment: Notebook PC
Is herewith confirmed to comply with the requirements set out in the
Council Directive on the Approximation of the Laws of the Member
States relating to Electromagnetic Compatibility (89/336/EEC), Lowvoltage
Directive (73/23/EEC) and the Amendment Directive
(93/68/EEC), the procedures given in European Council Directive
99/5/EC and 89/3360EEC.
The equipment was passed. The test was performed according to the
following European standards:
EN 300 328-2 V.1.2.1 (2001-12)
EN 301 489-1 V.1.3.1 (2001-09) / EN 301 489-17 V.1.1.1 (2000-09)
EN 50371: 2002
EN 55022: 2006
EN 55024: 2001
EN 60950: 2000
EN 61000-3-2: 2000
EN 61000-3-3: 1995 + A1: 2001

Notebook User Guide
9
802.11b and 802.11g Restrictions:
- European standards dictate maximum radiated transmit power of 100mW
EIRP and frequency range 2.400-2.4835GHz;
- In France, the equipment must be restricted to the 2.4465-2.4835GHz
frequency range and must be restricted to indoor use."

CloudBook User Guide
10
About Your CloudBook
Congratulation for having purchased your new CloudBook.
This CloudBook incorporates the newest technology features
to serve your daily computing needs anywhere you go.

Notebook User Guide
11
About Your User Guide
Welcome to your New CloudBook User Guide. This manual
introduces you to the basic concepts of your new CloudBook.
This manual is divided into eight chapters.
Chapter 1 Introduction
Chapter 2 Getting Started
Chapter 3 Using Your CloudBook
Chapter 4 Multimedia Setup
Chapter 5 Connecting External devices
Chapter 6 System BIOS Setup
Chapter 7 Upgrade Options
Chapter 8 Care and Maintenance
Appendix A System Specifications

CloudBook User Guide
12
Table of Contents
ABOUT YOUR CLOUDBOOK............................................................. 10
ABOUT YOUR USER GUIDE............................................................... 11
1INTRODUCTION............................................................................. 17
1.1 FEATURE HIGHLIGHT .................................................................... 18
1.2 UNPACKING THE CLOUDBOOK ...................................................... 19
1.3 THE INSIDE OF THE CLOUDBOOK .................................................. 20
CloudBook Status Icons................................................................ 23
The Function of Easy Buttons ...................................................... 24
1.4 THE LEFT SIDE OF THE CLOUDBOOK............................................. 24
1.5 THE RIGHT SIDE OF THE CLOUDBOOK .......................................... 25
1.6 THE UNDERSIDE OF THE CLOUDBOOK .......................................... 27
1.7 CLOUDBOOK ACCESSORIES........................................................... 28
2GETTING STARTED...................................................................... 29
2.1 USING THE BATTERY PACK ........................................................... 30
Extending Battery Life.................................................................. 32
2.2 CONNECTING THE AC POWER SOURCE.......................................... 32
2.3 STARTING YOUR CLOUDBOOK...................................................... 34
2.4 ADJUSTING THE DISPLAY CONTROLS ............................................ 35
3USING YOUR CLOUDBOOK........................................................ 37
3.1 STARTING YOUR OPERATING SYSTEM .......................................... 38
3.2 UNDERSTANDING THE KEYBOARD FUNCTIONS ............................. 38
Basic Keyboard Functions ........................................................... 40
Cursor Control Keys .................................................................... 41
Screen Control Keys..................................................................... 42
Hot Keys....................................................................................... 42

Notebook User Guide
13
Special Function Keys.................................................................. 43
3.3 USING THE TOUCHPAD POINTING DEVICE .......................................44
3.4 CONFIGURING YOUR SCREEN DISPLAY .........................................46
Possible Display Configurations.................................................. 46
3.5 KNOWING THE POWER SAVING FEATURES .................................... 47
3.6 WORKING WITH THE BUILT-IN HDD............................................... 48
3.7 USING FLASH MEMORY CARDS..................................................... 49
Flash Memory Card .....................................................................49
4FUN WITH MULTIMEDIA............................................................ 51
4.1 MULTIMEDIA FEATURES................................................................ 52
4.2 AUDIO SOUND SYSTEM FEATURES ................................................52
4.3 SETTING UP THE AUDIO DRIVER PROPERTIES................................53
Using an External Microphone.................................................... 53
4.4 PLAYING AUDIO AND SOUND ........................................................53
4.5 PLAYING VIDEO AND MPEG FILES ...............................................53
5CONNECTING TO PERIPHERALS............................................. 55
5.1 USING THE USB PORT...................................................................56
5.2 USINGANEXTERNALDVI-IPORT .......................................................57
5.3 USING THE EXTERNAL AUDIO SYSTEM.......................................... 58
5.4 USING THE LAN PORT...................................................................59
5.5 USING THE WIRELESS LAN........................................................... 60
6CUSTOMIZINGYOUR CLOUDBOOK..........................................61
6.1 RUNNING THE BIOS SETUP PROGRAM ..........................................62
6.2 USING THE MAIN MENU SETUP .....................................................64
6.2.1 Internal HDD Sub-Menu...................................................66
6.3 USING THE ADVANCED CMOS SETUP........................................... 67
6.4 SECURITY MENU SETUP ................................................................68
6.5 USING THE BOOT SETUP................................................................70

CloudBook User Guide
14
6.6 HOW TO EXIT THE SETUP PROGRAM.............................................. 71
6.7 HOW TO UPGRADE THE BIOS........................................................ 72
7USING OPTIONS............................................................................. 73
SYSTEM UPGRADE................................................................................... 74
7.1 MEMORY UPGRADE....................................................................... 74
7.2 WIRELESS MODULE INSTALLATION............................................... 74
8CARING FOR YOUR CLOUDBOOK........................................... 75
8.1 IMPORTANT SAFETY INSTRUCTIONS .............................................. 76
8.2 CLEANING YOUR CLOUDBOOK ..................................................... 78
8.3 MAINTAINING THE LCD QUALITY ................................................ 79
8.4 MAINTAINING YOUR HARD DISK .................................................. 79
8.5 BATTERY CARE GUIDELINES......................................................... 80
8.6 WHEN YOU TRAVEL...................................................................... 81
APPENDIX A SYSTEM SPECIFICATION........................................ 83
SYSTEM SPECIFICATION .......................................................................... 84
Processor Unit.............................................................................. 84
System Memory............................................................................. 84
LCD Display................................................................................. 84
VGA System.................................................................................. 84
Storage.......................................................................................... 85
Audio System ................................................................................ 85
Touchpad...................................................................................... 85
Keyboard...................................................................................... 85
Flash BIOS................................................................................... 85
I/O Ports....................................................................................... 85
Wireless devices ........................................................................... 86
AC/DC Power Supply Adapter..................................................... 86
Battery.......................................................................................... 86

Notebook User Guide
15
Weight and Dimension .................................................................86

CloudBook User Guide
16
This page is intended to be blank.

Introduction1
17
1 Introduction
Your CloudBook is a slim, sleek ultra-portable
computer. This device matches all the demands for
high performance computing and multimedia
technology.
Your CloudBook runs a wide variety of software to
meet your personal productivity, entertainment, and
professional applications needs.

CloudBook User Guide
18
1.1 Feature Highlight
Before we identify each part of your CloudBook, we will first introduce you to
other notable features of the device.
Processing Unit
•Your CloudBook runs on VIA C7TM M microprocessor that is integrated
with 128KB L2 Cache. Check with your dealer on the CPU type and
speed.
•Fully compatible with an entire library of PC software based on operating
systems such as Linux.
Memory
This CloudBook provides one memory slot for installing DDRII SDRAM 200-
pin SODIMM modules up to 1GB using 512MB or 1024MB DDRII SDRAM
modules.
Wide Screen LCD Display
Provides 7" 800 x 480 (16:10) wide screen LCD display.
Wireless LAN
IEEE 802.11b/g, USB Dongle Module.
USB 2.0
Provides two USB2.0 ports for fastest I/O data transmission.
Graphic System
Provides blazing graphics controller embedded in VX700 chipset

Introduction1
19
PCI Local Bus Architecture
32-bit PCI Enhanced IDE optimizes the data transfer between the CPU and
PATA hard disk drives. Support ultra DMA ATA-66 PIO Mode up to PIO
Mode 4, bus mastering for LBA Scheme.
Audio System
Full-duplex 16-bit stereo audio system output. Sound Blaster compatible.
Flash BIOS
Flash BIOS allows you to easily upgrade the System BIOS using the Phoenix
Flash utility program.
Power and System Management
•Integrated SMM (System Management Mode) on system chipset that shuts
down components not in use to reduce power consumption.
•Closing the CloudBook (lowering the cover) allows you to suspend the
system operation instantly and resume at the press of the power button.
•System Password for User and Supervisor included on the BIOS SETUP
Program to protect unauthorized use of your CloudBook.
1.2 Unpacking the CloudBook
Your CloudBook comes securely packaged in a sturdy cardboard shipping
carton. Upon receiving your CloudBook, open the carton and carefully remove
the contents. In addition to this User Guide, the shipping carton should also
contain the following items:
;The CloudBook

CloudBook User Guide
20
;An AC Adapter and AC Power Cord
;Li-Ion Battery Pack
;Quick Setup Manual
Carefully inspect each component to make sure that nothing is missing and/or
damaged. Be sure to save the shipping materials and the carton in case you
need to ship the CloudBook or store for an extended period of time.
1.3 The Inside of the CloudBook
The CloudBook is compact design with features on every side. First, look at
the inside of the system. The following sections describe the inside features.
