Everex StepNote XT5000T User manual

1

Notebook User Guide
Copyright©2006
All Rights Reserved - Printed in Taiwan
Notebook Computer User Guide
Original Issue: 2006/11
This manual guides you in setting up and using your new notebook computer.
Information in this manual has been carefully checked for accuracy and is
subject to change without notice.
No part of this manual may be reproduced, stored in a retrieval system, or
transmitted, in any form or by any means, electronic, mechanical, photocopy,
recording, or otherwise, without prior written permission.
Trademarks
Product names used herein are for identification purposes only and may be the
trademarks of their respective companies.
Microsoft, Windows XP, Windows Vista, and Windows Sound System are
trademarks of Microsoft Corporation.
AMD and AMD TurionTM 64 x 2 Mobile Technology are registered trademark
of Advanced Micro Devices, Inc.
Sound Blaster, Sound Blaster Pro are trademarks of Creative Technology.
All other brands or product names mentioned in this manual are trademarks or
registered trademarks of their respective companies.
2

Notebook User Guide
FCC Information to User
Safety and Care Instructions
No matter what your level of experience with computers, please make sure you
read the safety and care instructions. This information can help protect you
and your computer from possible harm.
For Safety Regulation:
zRisk of explosion if battery is replaced by an incorrect type.
zFor electrical safety concerns, only use telephone cables rated
26AWG or higher.
zThe Optical drive is a Class 1 Laser Product.
zLi-Ion battery is vulnerable, do not charge it with other power
adapter, or it may cause fire or explosion.
zFor the power supply of this equipment,
⇓An approved power cord has to be used.
⇓Make sure the socket and any extension cord(s) you use can
support the total current load of all the connected devices.
⇓Before cleaning the computer, make sure it is disconnected
from any external power supplies (i.e. AC adapter).
Radio and television interference
Warning: Use the specified shielded power cord and shielded signal cables
with this computer, so as not to interfere with radio and television reception. If
you use other cables, it may cause interference with radio and television
reception.
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
3

Notebook User Guide
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does not cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encourage to try to correct the interference by one or more
of the following measures:
•Reorient or relocate the receiving antenna
•Increase the separation between the device and receiver
•Connect the device into an outlet on a circuit different from that to
which the receiver is connected.
•Consult the dealer or an experienced radio/television technician for help.
You may find helpful the following booklet, prepared by the Federal
Communications Commission: Interference Handbook (stock number 004-
000-00345-4). This booklet is available from the U.S. Government Printing
Office, Washington, DC20402
Warning: The user must not modify or change this computer without
approval. Modification could void authority to this equipment.
FCC RF Exposure
FCC RF Radiation Exposure Statement:
This Transmitter must not be co-located or operating in conjunction with any
other antenna or transmitter.
This equipment complies with FCC RF radiation exposure limits set forth for
an uncontrolled environment. This equipment should be installed and operated
with a minimum distance of 20 centimeters between the radiator and your
body.
4

Notebook User Guide
15.247 (b)(4), the EUT meets the requirement that it be operated in a manner
that ensures the public is not exposed to radio frequency energy levels in
excess of the Commission’s guidelines (1.1307, 1.1310, 2.1091 and 2.1093)
5.105 Federal Communications Commission (FCC) Requirements, Part
15
This equipment has been tested and found to comply with the limits for a class
B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following measures:
---Reorient or relocate the receiving antenna.
---Increase the separation between the equipment and receiver.
---Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
---Consult the dealer or an experienced radio/TV technician for help.
5.21 Regulatory information / Disclaimers
Installation and use of this Wireless LAN device must be in strict accordance
with the instructions included in the user documentation provided with the
product. Any changes or modifications (including the antennas) made to this
device that are not expressly approved by the manufacturer may void the user’s
5

Notebook User Guide
authority to operate the equipment. The manufacturer is not responsible for
any radio or television interference caused by unauthorized modification of
this device, or the substitution of the connecting cables and equipment other
than manufacturer specified. It is the responsibility of the user to correct any
interference caused by such unauthorized modification, substitution or
attachment. Manufacturer and its authorized resellers or distributors will
assume no liability for any damage or violation of government regulations
arising from failing to comply with these guidelines.
Radio Frequency Interference Requirements
This device is restricted to INDOOR USE due to its operation in the 5.15 to
5.25GHz frequency range. According to FCC 15.407(e), requires this product
to be used indoors for the frequency range 5.15 to 5.25GHz to reduce the
potential for harmful interference to co-channel of the Mobile Satellite
Systems.
High power radars are allocated as primary user of the 5.25 to 5.35GHz and
5.65 to 5.85GHz bands. These radar stations can cause interference with and /
or damage this device
USA Under Laboratories
This model has applied and passed the UL certificate.
Canadian Department of Communications Compliance
Statement
This Class B digital apparatus meets all requirement of the Canadian
Interference-Causing Equipment Regulations.
Shielded Cables Notice
6

Notebook User Guide
All connections to other computing devices must be made using shielded
cables to maintain compliance with FCC regulations.
Peripheral Devices Notice
Only peripherals (input/output devices, terminals, printers, etc) certified to
comply with Class B limits may be attached to this equipment. Operation with
non-certified peripherals is likely to result in interference to radio and TV
reception.
Optical Disk Drive Notice
The optical disk drive is Class 1 Laser Product.
Caution
Changes or modifications not expressly approved by the manufacturer may
void the user’s authority, which is granted by the Federal Communications
Commission, to operate this computer.
Use Conditions
This part complies with Part 15 of the FCC Rules. Operation is subject to the
following conditions: (1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference
that may cause undesired operation.
European Notice
For the following equipment: Notebook PC
Is herewith confirmed to comply with the requirements set out in the
Council Directive on the Approximation of the Laws of the Member
7

Notebook User Guide
States relating to Electromagnetic Compatibility (89/336/EEC), Lowvoltage
Directive (73/23/EEC) and the Amendment Directive
(93/68/EEC), the procedures given in European Council Directive
99/5/EC and 89/3360EEC.
The equipment was passed. The test was performed according to the
following European standards:
EN 300 328-2 V.1.2.1 (2001-12)
EN 301 489-1 V.1.3.1 (2001-09) / EN 301 489-17 V.1.1.1 (2000-09)
EN 50371: 2002
EN 55022: 2001
EN 55024: 2001
EN 60950: 2000
EN 61000-3-2: 2000
EN 61000-3-3: 1995 + A1: 2001
802.11b and 802.11g Restrictions:
- European standards dictate maximum radiated transmit power of 100mW
EIRP
and frequency range 2.400-2.4835GHz;
- In France, the equipment must be restricted to the 2.4465-2.4835GHz
frequency range and must be restricted to indoor use."
Regulatory statement (R&TTE / WLAN IEEE 802.11a)
8

Notebook User Guide
Operation of this device is subjected to the following National regulations and
may be prohibited to use if certain restriction should be applied.
Austria Limited to 5150 – 5250 MHz
Belgium 5250 - 5350 MHz excluded
Croatia Licence required
Italy General authorization required if used outside
own premises
Latvia Limited to 5150 – 5300 MHz, Under Study
5150-
5350MHz
Luxembourg None; General authorization required for
public service
Austria Not implemented; Military band
Bulgaria Not implemented
Croatia Not implemented
Czech
Republic
Not implemented; Planned
France Not implemented; France will implement this
band identified by the ERC DEC(99)23 when
the efficiency of the mitigation techniques
made mandatory by this Decision is ensured
Hungary Not implemented; Equipment/ Standard not
available
Italy General authorization required if used outside
own premises
Luxembourg None; General authorization required for
public service
5470-
5725MHz
Slovak
Republic
Not implemented; Military services
9

Notebook User Guide
For DVD Players with both 525p and 625p progressive
scan outputs:
‘CONSUMERS SHOULD NOTE THAT NOT ALL HIGH DEFINITION
TELEVISION SETS ARE FULLY COMPATIBLE WITH THIS
PRODUCT AND MAY CAUSE ARTIFACTS TO BE DISPLAYED IN
THE PICTURE. IN CASE OF 525 OR 625 PROGRESSIVE SCAN
PICTURE PROBLEMS, IT IS RECOMMENDED THAT THE USER
SWITCH THE CONNECTION TO THE ‘STANDARD DEFINITION’
OUTPUT. IF THERE ARE QUESTIONS REGARDING OUR TV SET
COMPATIBILITY WITH THIS MODEL 525p AND 625p DVD PLAYER,
PLEASE CONTACT OUR CUSTOMER SERVICE CENTER.’
“This product incorporates copyright protection technology that is protected
by U.S. patents and other intellectual property rights. Use of this copyright
protection technology must be authorized by Macrovision, and is intended for
home and other limited viewing uses only unless otherwise authorized by
Macrovision. Reverse engineering or disassembly is prohibited.”
“U.S. Patent Nos. 4,631,603; 4,819,098; 4,907,093; 5,315,448; and 6,516,132.”
10

Notebook User Guide
About Your Notebook Computer
Congratulation for having purchased your new Everex
StepNote. This notebook incorporates the newest features to
serve all your computing needs
11

Notebook User Guide
About Your User Guide
Welcome to your Everex StepNote User Guide. This
manual introduces you to the basic concepts of your new
computer.
This manual is divided into eight chapters.
Chapter 1 Introduction
Chapter 2 Getting Started
Chapter 3 Using Your Notebook Computer
Chapter 4 Multimedia Setup
Chapter 5 Connecting External devices
Chapter 6 System BIOS Setup
Chapter 7 Upgrade Options
Chapter 8 Care and Maintenance
Appendix A System Specifications
Appendix B System Recovery and Driver Installation
12

Notebook User Guide
Table of Contents
ABOUT YOUR NOTEBOOK COMPUTER........................................11
ABOUT YOUR USER GUIDE...............................................................12
1INTRODUCTION............................................................................. 19
1.1 FEATURE HIGHLIGHT.....................................................................20
1.2 UNPACKING THE COMPUTER .........................................................22
1.3 THE INSIDE OF THE NOTEBOOK .....................................................23
Notebook Status Icons .................................................................. 25
The Function of Easy Buttons....................................................... 27
1.4 THE FRONT SIDE OF THE NOTEBOOK............................................. 28
1.5 THE REAR SIDE OF THE NOTEBOOK...............................................30
1.6 THE LEFT SIDE OF THE NOTEBOOK................................................ 31
1.7 THE RIGHT SIDE OF THE NOTEBOOK.............................................. 32
1.8 THE UNDERSIDE OF THE NOTEBOOK.............................................. 34
1.9 NOTEBOOK ACCESSORIES.............................................................. 35
1.10 NOTEBOOK OPTIONS .....................................................................36
2GETTING STARTED ...................................................................... 37
2.1 USING THE BATTERY PACK ...........................................................38
Extending Battery Life..................................................................40
2.2 CONNECTING THE AC POWER SOURCE.......................................... 41
2.3 STARTING YOUR COMPUTER .........................................................42
2.4 ADJUSTING THE DISPLAY CONTROLS ............................................43
2.5 TURNING OFF YOUR COMPUTER....................................................43
3USING YOUR NOTEBOOK...........................................................45
3.1 STARTING YOUR OPERATING SYSTEM...........................................46
3.2 UNDERSTANDING THE KEYBOARD FUNCTIONS..............................46
13

Notebook User Guide
Basic Keyboard Functions ........................................................... 49
Cursor Control Keys .................................................................... 50
Screen Control Keys..................................................................... 51
Windows Hot Keys........................................................................ 51
Special Function Keys.................................................................. 51
3.3 USING THE TOUCHPAD POINTING DEVICE ....................................... 53
3.4 CONFIGURING YOUR SCREEN DISPLAY ......................................... 55
Possible Display Configurations.................................................. 56
Changing the Display Properties under Windows.................................. 56
3.5 KNOWING THE POWER SAVING FEATURES .................................... 57
3.6 WORKING WITH THE BUILT-IN HDD............................................... 58
3.7 HOW TO ACCESS THE OPTICAL DRIVE........................................... 59
3.8 EXPRESSCARD............................................................................... 60
What is ExpressCard ?................................................................. 60
Inserting and Removing a ExpressCard....................................... 61
3.9 USING FLASH MEMORY CARDS..................................................... 63
What is Flash Memory Card?...................................................... 63
4FUN WITH WINDOWS VISTA EXPERIENCE.......................... 67
4.1 WHAT IS WINDOWS VISTA? .......................................................... 68
4.2 GET READY FOR WINDOWS VISTA ................................................ 68
4.3 ENJOY YOUR MULTIMEDIA APPLICATION..................................... 71
Internet Explorer.......................................................................... 71
Windows Calendar ....................................................................... 71
Windows Contacts........................................................................ 72
Windows Defender ....................................................................... 73
Windows DVD Maker................................................................... 74
Windows Fax and Scan ................................................................ 75
Windows Live Messenger Download ........................................... 76
Windows Mail............................................................................... 77
Windows Media Center................................................................ 78
14

Notebook User Guide
Windows Media Player................................................................. 79
Windows Meeting Space...............................................................79
Windows Movie Maker.................................................................80
Windows Photo Gallery................................................................ 81
Windows Update........................................................................... 82
Windows Sidebar and Gadgets..................................................... 83
Gaming ......................................................................................... 84
Windows Flip and Windows Flip 3D............................................ 85
5CONNECTING TO PERIPHERALS.............................................87
5.1 USING THE USB PORT................................................................... 88
5.2 USINGAN EXTERNAL DVI-IPORT .......................................................89
5.3 USING THE IEEE 1394 PORT .........................................................91
5.4 USING THE TV PORT .....................................................................92
5.5 USING THE EXTERNAL AUDIO SYSTEM.......................................... 93
5.6 USING THE LAN PORT...................................................................94
5.7 USING THE WIRELESS LAN........................................................... 95
5.8 USING THE MODEM PORT.............................................................. 95
6CUSTOMIZING YOURNOTEBOOK..............................................97
6.1 RUNNING THE BIOS SETUP PROGRAM ..........................................98
6.2 USING THE MAIN MENU SETUP ...................................................100
6.2.1 Sata Hard Drive1 Sub-Menu...........................................102
6.2.2 Sata Hard Drive2 Sub-Menu...........................................103
6.2.3 CD/DVD ROM Sub-Menu............................................... 104
6.3 USING THE INFO MENU SETUP..................................................... 105
6.4 USING THE ADVANCED CMOS SETUP.........................................106
6.5 SECURITY MENU SETUP ..............................................................107
6.6 USING THE BOOT SETUP..............................................................109
6.7 HOW TO EXIT THE SETUP PROGRAM............................................ 110
6.8 HOW TO UPGRADE THE BIOS......................................................111
15

Notebook User Guide
7USING OPTIONS........................................................................... 113
SYSTEM UPGRADE................................................................................. 114
7.1 MEMORY UPGRADE..................................................................... 114
Installing Memory Module......................................................... 115
7.2 HARD DISK UPGRADE ................................................................. 117
7.3 WIRELESS MODULE INSTALLATION............................................. 118
8CARING FOR YOUR NOTEBOOK............................................ 119
8.1 IMPORTANT SAFETY INSTRUCTIONS ............................................ 120
8.2 CLEANING YOUR COMPUTER ...................................................... 122
8.3 MAINTAINING THE LCD QUALITY .............................................. 123
8.4 MAINTAINING YOUR HARD DISK ................................................ 123
8.5 BATTERY CARE GUIDELINES....................................................... 124
8.6 WHEN YOU TRAVEL.................................................................... 125
APPENDIX A SYSTEM SPECIFICATION...................................... 127
Processor Unit............................................................................ 128
System Memory........................................................................... 128
LCD Display............................................................................... 128
VGA System................................................................................ 128
Storage........................................................................................ 129
Audio System .............................................................................. 129
ExpressCard............................................................................... 129
Touchpad.................................................................................... 129
Keyboard.................................................................................... 130
Flash BIOS ................................................................................. 130
I/O Ports..................................................................................... 130
Wireless devices ......................................................................... 130
AC/DC Power Supply Adapter................................................... 130
Battery........................................................................................ 130
Weight and Dimension ............................................................... 131
16

Notebook User Guide
APPENDIX B SYSTEM RECOVERY AND DRIVER
INSTALLATION................................................................................... 133
B.1 SYSTEM RECOVERY..................................................................... 134
Using Recovery Disk .................................................................. 134
B.2 DEVICE DRIVERS INSTALLATION................................................. 151
Installing Windows Vista from Optical Disk Drive......................151
driver installation note:.............................................................. 152
Installing the SATA IDE Driver .................................................152
Installing the Chipset (SMU) Driver.......................................... 153
Installing the VGA Driver ..........................................................153
Installing Resolution Utility ....................................................... 154
Installing the Audio Driver.........................................................154
Installing the Modem Driver...................................................... 155
Installing ALPS - Touchpad driver............................................. 155
Installing LiteOn Wireless LAN Driver...................................... 156
Installing CdRdr Utility.............................................................. 156
Installing Card Reader Utility....................................................156
Installing Silent Mode Utility ..................................................... 157
Installing Hotkey Utility............................................................. 157
Technical Support....................................................................... 159
17

Notebook User Guide
This page is intended to be blank.
18

Introduction1
1 Introduction
Your Everex Computer is a fully Windows®
compatible portable computer. With the latest
features in mobile computing and multimedia
technology, this notebook is a natural choice for uses
seeking portability and performance.
Your Everex StepNote XT Series Notebook runs a
wide variety of business, personal productivity,
entertainment and professional applications and is
ideal for use in the office, home and on the road.
19

Notebook User Guide
1.1 Feature Highlight
Before we identify each part of your Everex StepNote Notebook, we will first
introduce you to other notable features of your computer.
Processing Unit
•Your notebook runs on AMD TurionTM 64 x 2 or AMD SempronTM
processor, that is integrated with 1M L2 Cache. Check with your dealer on
the CPU type and speed.
•Fully compatible with an entire library of PC software based on operating
systems such as Windows Vista.
Memory
This notebook provides two memory slots for installing DDRII SDRAM 200-
pin SODIMM modules up to 4GB using 256MB, 512MB, 1024MB or 2048MB
DDRII SDRAM modules.
Wide Screen LCD Display
Provides extraordinary 17" WXGA+ 1440 x 900 wide screen LCD display. It is
the best choice for you to watch DVD movie.
Wireless LAN
IEEE 802.11b/g, Mini Card (BTO)
Graphic System
Provides blazing graphics controller embedded in Nvidia C51D chipset.
20
