EVERSAN
EVERSAN, INC. • 34 Main Street, Whitesboro, NY 13492 • 1-800-383-6060 Fax: 315-736-4058
www.eversan.com
MODEL 9176
BASEBALL/SOFTBALL SCOREBOARD
INSTALLATION INSTRUCTIONS
These instructions must be followed to ensure correct operation. The warranty will be violated and
considered null if inspection and operating procedures are disregarded.
Should you require assistance or have any questions, please call (800) 383-6060.
Check List
Model 9175 Scoreboard
Control Console with LCD readout
Two Conductor Control Cable (Cabled Systems Only)
(4) Mounting Brackets
(2) Antenna (Wireless Systems Only)
NOTE: Please check that these items are available prior to initial test of the scoreboard. If you are
missing any items, please call (800) 383-6060 for assistance.
Customer Shipping Inspection
A. Unpack scoreboard.
B. Unpack cable and control console.
Plug the console cable and console into the console connector on back (see diagram)
C. Testing - Remove (4) four screws holding the access panel on the 120VAC box. There is a
standard 120-volt plug for testing. After testing cut connector provided. Match colors on power
cable provided to three wires on 120V box. This board requires 120VAC at approximately 6
AMP. (see diagram)
NOTE: FAILURE TO TEST SCOREBOARD PRIOR TO INSTALLATION
WILL VOID ALL WARRANTEES.
Power scoreboard using 120VAC and test scoreboard using the operating instructions provided.
SHOULD THERE BE A MALFUNCTION OR SHIPPING DAMAGE,
NOTIFY THE SHIPPER AND EVERSAN IMMEDIATELY.
Page 2
EVERSAN
EVERSAN, INC. • 34 Main Street, Whitesboro, NY 13492 • 1-800-383-6060 Fax: 315-736-4058
www.eversan.com
6
Page 3
EVERSAN
EVERSAN, INC. • 34 Main Street, Whitesboro, NY 13492 • 1-800-383-6060 Fax: 315-736-4058
www.eversan.com
Installation
1. It is recommended that a professional sign company be hired to install the scoreboard. SEE
DRAWINGS
2. Eversan recommends a minimum depth of 5 ft. and a 2ft. footer diameter.
3. Calculate the wind loading by standard formula for height and dimension of sign.
NOTE: Check local codes for your area.
4. Prepare and sink I-beams, W6 x 15 I-Beam conforming to ASTM A36 recommended minimum,
align with plumb line and careful measurements.
5. Determine height of lowest point for scoreboard. Mark and align on all mounting beams parallel to
visual ground sighting.
6. Drill and bolt (3/8 hardened bolts) or weld provided bottom Z-brackets to the posts as shown in the
installation diagram.
7. Lift scoreboard set onto Z bracket. Secure temporarily with a clamp.
8. Place the top Z-brackets on the board and install in the same manner as the lower.
9. The board is now ready to be wired.
Instructions for Wiring
1. Determine 120VAC entrance and run conduit to pre-installed electric box on back of scoreboard.
See diagram.
2. The scoreboard draws under 6 amp but requires its own circuit breaker. Eversan, Inc.
recommends using a 10 amp, GFCI breaker.
CAUTION: Cabled Version Only
The data cable is a pre-wired, 1 pair twisted shielded. Any cable splicing should be color-
coded or failure of the computer power supply will result. Continuity of the shield is essential in
reducing possible damage due to lightening.
Electrical Specifications:
Electric outlets for scoreboards are always on a “clean” unused, switched breaker box. Pay
close attention to the power source and connections. It is recommended that a key-switch or
switched breaker box be used to turn off the system at the end of use each day, turning off the
Control Console does not power down the scoreboard. The scoreboard should always be
powered down when not in use.
Power up Sequence
120VAC Operation
1. Plug the control console into the scoreboard using the cable provided. Any of the 2-pin
connectors on the control console can be used. The connector for the scoreboard is located
on the back. (Cabled System only)(see Diagram)
2. Power up the scoreboard using 120VAC,connection on back of scoreboard. (see Diagram)
