EVERSPRING TSC06-C User manual

TSC06-X
Wireless IP Gateway
User Manual
Version: 1.0
Date: 016-07- 7

TSC06-C Gateway User Manual
Table of Contents
1. Copyright and Confidential.................................................................................1
. Disclaimer .............................................................................................................1
3. Revision Record....................................................................................................1
4. Introduction ..........................................................................................................2
5. Overview ...............................................................................................................2
5.1. Sockets ..............................................................................................................2
5. . Buttons ..............................................................................................................3
5.3. LED.....................................................................................................................4
5.3.1. Power LED.....................................................................................................4
5.3. . Connection LED............................................................................................4
5.3.3. Network 1 LED .............................................................................................5
5.3.4. Network LED .............................................................................................5
5.4. USB ....................................................................................................................5
6. Specification .........................................................................................................7
6.1. Power function .................................................................................................7
6. . RF function........................................................................................................7
7. How to search the device? .................................................................................7
8. Web Configuration...............................................................................................9
8.1. Network Settings ...........................................................................................10
8. . System Settings .............................................................................................12
8. .1. NTP Settings...............................................................................................13
8. . . Gateway Registration ................................................................................14
8. .3. U-Net Message Forward ...........................................................................14
8.3. VPN Settings...................................................................................................15
8.4. Language Settings .........................................................................................18
8.5. Update Settings..............................................................................................19
8.5.1. In Linux Runtime .......................................................................................20
8.5. . In the Boot Time........................................................................................21
9. U-Net Bind ..........................................................................................................22
10. Warnning.........................................................................................................23

TSC06-C Gateway User Manual
Page 1 of 5
1. Copyright and Confidential
The information contained in this document or diagram is confidential and
proprietary to Chromagic Technologies Ltd. Co. This information may not be
distributed or used for any purpose other than the evaluation of Chromagic’s
solutions, nor may it be disclosed to any party without the prior written consent
from Chromagic. All Rights Reserved.
2. Disclaimer
This document or diagram and the information contained herein is provided on
an "AS IS" basis and Chromagic DISCLAIMS ALL WARRANTIES, EXPRESS OR
IMPLIED, INCLUDING BUT NOT LIMITED TO ANY WARRANTY THAT THE USE
OF THE INFORMATION HEREIN WILL NOT INFRINGE ANY RIGHTS OR ANY
IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE.
3. Revision Record
Date Version Description
016-07- 5 1.0 The first release.

TSC06-C Gateway User Manual
Page of 5
4. Introduction
The gateway is a transceiver which belongs to the member of U-Net series and
is fully compatible with any U-Net enabled devices. It can reliably and
remotely control and monitor your U-Net enabled devices. Whether you be on
site and log in through your network, or away from the premises while logging
in through the internet, you’ll always have access to control and monitor your
security system. You can achieve a better control of your home security to
make your home safer than ever before.
. Overview
Figure 1: The overview of TSC06-C
.1. Sockets
DC Jack:
Input the DC power voltage 9V and current A.
DC Jack
RJ45
Connect
button
Reset
Dummy
USB
LEDs

TSC06-C Gateway User Manual
Page 3 of 5
RJ-45 Socket:
There are two RJ-45 sockets. TSC06-C has the Ethernet hub function.
These two sockets are linked. In SFR, one will connect to SFR modem;
another will connect to SFR mini hub.
.2. Buttons
There are two buttons on TSC06-C: one is the reset button (near the dummy
USB socket), and another is the connection button (near the RJ-45 socket).
Reset Button:
This button will reboot the system. If the system is halting, the user can
press this button.
Note: TSC06-C has a battery inside its body. If the DC power is cut off, the
unit will automatically switch to the battery power. As a result, the device
would be still halting and need to be reset.
Connection Button:
Enable the firmware upgrade function in boot time.
After pressing the reset button or powering on the device, press the
connection button for more than three times. To ensure the function is
enabled, please check the connection LED is blinking in red and green.
Set all settings of the device to factory default.
After pressing the reset button or powering on the device, press and
hold the connection button until the connection LED turns on the red
and green light and then turns off. Then release the connection
button.
Manually enable the bind function.
After the system boots up, press the connection button once.
Manually cancel the bind function.
When the system is in the binding mode, press the connection button
once.

TSC06-C Gateway User Manual
Page 4 of 5
.3. LED
Figure : The definition of the LEDs.
The function & name of these LEDs:
LED A: Power LED.
LED B: Connection LED.
LED C: Network 1 LED.
LED D: Network LED.
.3.1. Power LED
The green light is on:
The power is on.
The orange light is on:
The Flash is writing data.
The orange light flashes once every 5 seconds:
The system time is not synchronized after boot up.
.3.2. Connection LED
The green light is on:
The connection to the server is successful.
The red light is on:

TSC06-C Gateway User Manual
Page 5 of 5
The DHCP function is enabled but couldn’t get the IP information.
Blinking in red and green:
The firmware upgrade function is enabled in bootloader runtime.
The green light is blinking in second: (0.5s On, 0.5s Off)
The system is in the binding mode.
The green light is turn on seconds and turn off seconds:
The system’s inclusion of other U-Net device is successful.
The green light is blinking: (0.1s On, 0.1s Off)
If the system binding exceeds time limit, it will persist for 4 seconds.
If the system is aborting binding mode, it will persist for 1 second.
The green light and the red light are blinking 3 times (Orange):
The system boots up OK.
.3.3. Network 1 LED
The green light is on:
The RJ-45 socket 1 is connecting.
The green light is flash:
The RJ-45 socket 1 is in active
.3.4. Network 2 LED
The green light is on:
The RJ-45 socket is connecting.
The green light is flash:
The RJ-45 socket is in active
.4. USB
There are four USB sockets. One is dummy socket on the side of the body, and
the other USB sockets are inside the box. In SFR, the dummy USB will provide

TSC06-C Gateway User Manual
Page 6 of 5
the power to the mini hub. USB sockets &3 can be used for plugging the 3G
dongle. USB 4 is only for power supply.

TSC06-C Gateway User Manual
Page 7 of 5
6. Specification
6.1. Power function
1. Operating temp:-10~40℃
. Operating Humidity:85%(maximum,relative humidity)
3. Storage temp:- 0~60℃
4. Input:adapter:9V/battery:6V
5. Battery type:rechargeable battery 100mA
6. Adapter: INPUT :AC100~ 40V 50/60Hz 0.5A
OUTPUT:DC 9V 000 mA
7. DSL USB power:
(1) this connection can use DSL USB output voltage
( ) Need to be able DSL provides voltage to 9V
(3) DSL USB power can charge battery
8. Low power detect: Gateway must detect for low battery and report to server
6.2. RF function
1. RF Compatibility:
Protocol Stack : U-Net 4.0
Profile: Home Automation Security
2. Frequency range:916.00MHz
3. Modulation: FSK
4. Coverage Range :Free Space 100M
5. RF Antenna: The gateway uses built-in antenna
7. How to search the device?
In default, TSC06-C will enable the DHCP function to get the IP address. If the
DHCP function failed, you will see the “Connection LED” lights up in red. In this
case TSC06-C will set the IP address to default 19 .168.1. .
Static IP: 19 .168.1.

TSC06-C Gateway User Manual
Page 8 of 5
Netmask: 55. 55. 55.0
Gateway: 19 .168.1.1
DNS1: 19 .168.1.1
Otherwise TSC06-C will get the IP address from the DHCP server, and you can
use the utility “Gateway Finder” to find out the assigned IP address.
The “Gateway Finder” is designed with .Net Framework; you must install .Net
Framework (can be downloaded freely) in your system first.
Execute the “GatewayFinder.exe”.
Figure 3: Gateway Finder
Just click the “Search” button, and you will find out TSC06-C IP address.
Figure 4: Gateway Finder Find Out the IP Address
If it can’t get a response within about 5 seconds, it will show timeout.
Figure 5: Gateway Finder Timeout

TSC06-C Gateway User Manual
Page 9 of 5
8. Web Configuration
Use the browser (IE or Firefox) to access TSC06-C. Just enter the URL
http://(IP Address)/ in your browser. For the first time access of TSC06-C web
server, you will be requested to login. The default user name is “webadmin” and
the password is “admin”.
Figure 6: First Time Access of TSC06-C Web Server.

TSC06-C Gateway User Manual
Page 10 of 5
8.1. Network Settings
Set the IP address using the DHCP or the static IP address.
Figure 7: Network Settings DHCP
Click the “Manual Setting the IP address” item to set the static IP address.
Figure 8: Network Settings DHCP

TSC06-C Gateway User Manual
Page 11 of 5
After setting OK, don’t forget to press the “submit” button.
Figure 9: Network Setting Submit
After 0 seconds, the browser will connect to new IP address.
And you must re-login.
Figure 10: Browser Auto Connect to New IP Address

TSC06-C Gateway User Manual
Page 1 of 5
Figure 11: The Browser Connected to New IP Address
8.2. System Settings
The system settings will set the NTP function and the message server.
Figure 1 : System Settings

TSC06-C Gateway User Manual
Page 13 of 5
8.2.1. NTP Settings
TSC06-C does not have RTC (real-time clock). That means if the power is off,
the system time will be reset or stopped.
So at the boot time, TSC06-C will synchronize the system time with the NTP
server.
The default NTP settings:
NTP function enable: Yes
NTP Server: clock.via.net
Time Zone: 0
If TSC06-C failed to connect to the NTP server, it will try again after 1 hour.
If time synchronization is OK, after 4 hours it will synchronize again.
After boot up, if TSC06-C detects the system time is not correctly synchronized,
the power LED will flash once every 5 seconds.
The user can set the NTP settings from the browser.
Figure 13: System Settings

TSC06-C Gateway User Manual
Page 14 of 5
8.2.2. Gateway Registration
If this function is enabled, after boot up TSC06-C will send the registration
information to the server every 150 seconds.
Figure 14: System Setting Gateway Registration
8.2.3. U-Net Message Forward
If this function is enabled, when the U-Net devices report the state to TSC06-C,
it can forward the message to the server.

TSC06-C Gateway User Manual
Page 15 of 5
Figure 15: System Setting Message Notification
8.3. VPN Settings
A VPN (Virtual Private Network) is a network that uses a public
telecommunication infrastructure, such as the Internet, to provide remote
offices or individual users with secure access to their organization's network.
Figure 16: The VPN link.
TSC06-C will use the OpenVPN to provide the VPN function.
The user can see the OpenVPN state or settings from the browser.

TSC06-C Gateway User Manual
Page 16 of 5
Figure 17 VPN Settings
There are two secret keys in OpenVPN: one is for OpenVPN and the other is for
OpenSSL. The keys do not store in the Linux file system. They will be stored in
the Flash, and encrypted.
Before running OpenVPN, these keys must have existed. The user can upload
the key in the “Update” page. Just upload the key file instead of the firmware
file.
Figure 18: Upload the Key File

TSC06-C Gateway User Manual
Page 17 of 5
Figure 19: Upload Key OK
If the VPN function is enabled and established. The connection LED will turn
green light on.

TSC06-C Gateway User Manual
Page 18 of 5
8.4. Language Settings
Change the language of the web page display.
Figure 0: Language Settings
Figure 1: Language Changed to French.
