EVERSPRING HSC04-0 User manual

- 1 -
HSC04-0 U-Net Gateway
User Manual
1. Introduction
The HSC04 Gateway is a member of the U-Net series and is fully compatible
with any U-Net enabled devices. It can remotely control and monitor your
U-Net enabled devices. Whether onsite or logged in through the internet, you
will always have access to control and monitor your control system. With this
system you can achieve a better control of your home security to make your
life safer and easier than ever.
2. Appearance
Figure 1 HSC04 Appearance
2.1 Sockets
DC Jack: DC power voltage
9V, current 2A.
RJ-45 socket: HSC04 has
an Ethernet hub function
and is equipped with two
linked RJ-45 sockets.
2.2 Buttons
HSC04 has two buttons:
One reset button and a
connection button (next to
the RJ-45 socket).
■Reset Button:
This button will reboot the system. The user can press this button when the
system is halting.
Note: HSC04 is equipped with internal battery power, which will be
automatically switched to when DC power is cut off. The device will still
be halting.
■Connection Button:
‧ Manually enable the bind function:
Press the connection button once after the system is powered on.
 ‧ Manually cancel the bind function:
Press the connection button once when the system is in bind mode.
2.3. LED
Figure 2 HSC04Front View
LED1 LED2 LED3 LED4

- 2 -
Definition of LED:
LED1 Power LED2 Connection
LED3 Network 1
LED
LED4 Network 2
LED
2.3.1 Power LED
Green light: The power is on.
 Red light: The Flash is writing data.
 Red light flashes every 5 seconds: The system time is not synchronized
after boot up.
2.3.2. Connection LED
Green light: OpenVPN has successfully connected to the server.
Red light: The DHCP function is enabled but could not obtain IP
information.
Red and green light flashes: The firmware upgrade function is enabled in
bootloader time.
Green light flashes with an interval of 0.5 seconds: The system is in
binding mode.
Green light flashes with an interval of 2 seconds: The system has
successfully added other U-Net devices.
Green light flashes with an interval of 0.1 seconds: If code learning has
timed out it will continue to flash for 4 seconds.
If code learning is aborted it will continue to flash for 1 second.
Green and red light flash 3 times: The system has successfully booted.
2.3.3 Network 1 LED
Green light: The RJ-45 socket near the connection button is connecting.
2.3.4 Network 2 LED
Green light: The RJ-45 socket near the DC power jack is connecting.
2.4 USB
There are three USB sockets in the box, which can plug to the 3G dongle.
3. Installation
Figure 3 Upper cover installation
‧ Press and hold the latch.
‧ Slide to release the upper cover.
‧ Fit the latch to replace the upper cover.
Figure 4 Battery installation

- 3 -
‧ Stick the double-sided tape to where you wish to place the batteries.
‧ Attach batteries and insert power cables to complete installation.
4. U-Net Binding
U-Net binding is an operation of the HSC04 used to include other U-NET
devices.
We will describe how to use the connection button to operate the binding
function below:
Start binding:
Press the connection button once and the connection LED will flash green.
Device binding:
The connection LED on the HSC04 will stop flashing and turn on and off with
an interval of 2 seconds if binding was successful.
Cancel binding:
Press the connection button when the connection LED is blinking in binding
mode and the connection LED will flash rapidly and stop binding.
Binding timeout:
Timeout will happen when binding mode has been idle for 30 seconds. The
connection LED will rapidly flash 4 seconds when this happens.
Specifications
Operating temperature range
-10°C to +40°C
Operating humidity 5 - 85% RH
Adapter I/P: 100-240Vac 50/60Hz 0.5A
O/P: DC9V 2000mA
Battery type AA batteries x5
Transmission range Indoors 30m; Outdoors >150m (Open space)
Frequency range 923 MHz
** Specifications are subject to change without notice
