1. OVERVIEW
The 7800MDM-12G is a bi-directional multiplexer/demultiplexer for converting UHD signals between quad-
link 3G and 12G SDI. It bridges the gap between quad-link and native 12G equipment in UHD
infrastructures.
Features & Benefits
•Converts between 12G (SMPTE ST 2082) SDI and Quad-Link 3G SDI
•Bi-Directional – a single card can be used to wrap a device with both inputs and outputs
•Modular and front accessible – can be hot-swapped without de-cabling
•High Density – bi-directional conversion on a single-slot card
•Dual 12G input (software selectable as to source) and dual 12G outputs for signal distribution
when equipped with optional second input SFP
•VistaLINK capable for remote monitoring, control and configuration capabilities via SNMP using
VistaLINK PRO, CP-2116E or CP-2232E Control Panels. VistaLINK is available when modules are
used with the 7800FR or 7801FR with 7800/7801FC frame controller installed.
•Web GUI for remote monitoring, control and configuration capabilities when modules are used with
the 7800FR or 7801FR with 7800/7801FC frame controller installed.
Figure 1-1: 7800MDM-12G Block Diagram

7800MDM-12G
12G to/from Quad-Link 3G Bi-Directional Converter for UHD Signals
Page - 2 Revision 1.0
This page left intentionally blank

7800MDM-12G
12G to/from Quad-Link 3G Bi-Directional Converter for UHD Signals
Revision 1.0 Page - 3
2. INSTALLATION
The 7800MDM-12G module comes with a companion rear plate and occupies two slots in the 7800FR
frame. Refer to Figure 2-1 for the 7800MDM-12G rear plate layout.
Figure 2-1: 7800MDM-12G Rear Plate

7800MDM-12G
12G to/from Quad-Link 3G Bi-Directional Converter for UHD Signals
Page - 4 Revision 1.0
2.1. INPUT/OUTPUT CONNECTIONS
3G IN A/B/C/D: DIN connectors used to input Quad-Link 3G SDI video streams.
3G OUT A/B/C/D: DIN connectors used to output Quad-Link 3G SDI video streams.
12 OUT/IN 1/2: When used with Evertz SFP3TR-DIN-12G, these provide main and backup DIN
connectors used to input and/or output 12 SDI video streams.
2.2. ETHERNET CONNECTION
All 7800MDM-12G modules are designed to use either 10Base-T (10 Mbps) or 100Base-TX (100 Mbps)
also known as Fast Ethernet, twisted pair Ethernet cabling systems. When connecting for 10Base-T
systems, category 3, 4, or 5 UTP cable as well as EIA/TIA – 568-100ΩSTP cable may be used. When
connecting for 100Base-TX systems, category 5 UTP cable is required. Make the network connection by
plugging one end of a “straight through” cable into the RJ-45 receptacle of 7800MDM-12G module and the
other end into a port of the supporting hub. If you are connecting the 7800MDM-12G module directly to an
Ethernet port on a computer, you will have to use a “crossover” cable.
Straight-through RJ-45 cables can be purchased or can be constructed using the pin out information in
Table 2-1. A color-code wiring table is provided in Table 2-1 for the current RJ-45 standards (AT&T 258A
or EIA/TIA 258B color coding shown). Also, refer to the notes following the table for additional wiring guide
information.
Pin
1
Pin #
Signal
EIA/TIA 568A
AT&T 258A or
EIA/TIA 568B
10BaseT
or 100BaseT
1 Transmit + White/Green White/Orange X
2 Transmit – Green/White or White
Orange/White or
Orange
X
3 Receive + White/Orange White/Green X
4 N/A Blue/White or Blue Blue/White or Blue
Not used
(required)
5 N/A White/Blue White/Blue
Not used
(required)
6 Receive – Orange/White or Orange Green/White or Green X
7 N/A White/Brown White/Brown
Not used
(required)
8 N/A Brown/White or Brown Brown/White or Brown
Not used
(required)
Table 2-1: Colour Code Wiring for the Current RJ 45 Standards
Note the following cabling information for this wiring guide:
•Only two pairs of wires are used in the 8-pin RJ 45 connector to carry Ethernet signals.
•Even though pins 4, 5, 7 and 8 are not used, it is mandatory that they be present in the cable.
•10BaseT and 100BaseT use the same pins; a crossover cable made for one will work with the
other.
•Pairs may be solid colors and not have a stripe.
•Category 5 cables must use Category 5 rated connectors.

7800MDM-12G
12G to/from Quad-Link 3G Bi-Directional Converter for UHD Signals
Revision 1.0 Page - 5
The maximum cable run between the 7800MDM-12G module and the supporting hub is
300 ft (90 m).

7800MDM-12G
12G to/from Quad-Link 3G Bi-Directional Converter for UHD Signals
Page - 6 Revision 1.0
This page left intentionally blank

7800MDM-12G
12G to/from Quad-Link 3G Bi-Directional Converter for UHD Signals
Revision 1.0 Page - 7
3. SPECIFICATIONS
3.1. SERIAL DIGITAL VIDEO INPUT
Standard
11.88Gb/sec SMPTE 2082 (on Evertz SFP3TR-DIN-12G)
2.970 Gb/sec SMPTE 425M* (All other DIN connectors – 3G IN A-D)
Number of Inputs
1x Quad-Link 3G-SDI signal (3G IN A-D)
2x 12G-SDI inputs (one per SFP) used as a main and backup
Connector
DIN 1.0/2.3 CECC 22 230, DIN 47297 and DIN 41626
Signal Level
1V nominal
Input Equalization
Automatic to 40m @ 11.88 Gbs with Belden 1694 or equivalent
3.2. SERIAL DIGITAL VIDEO OUTPUT
Standard
11.88Gb/sec SMPTE 2082 (on Evertz SFP3TR-DIN-12G)
2.970 Gb/sec SMPTE 425M* (All other DIN connectors – 3G IN A-D)
Number of Outputs
1x Quad-Link 3G-SDI signal (3G OUT A-D)
2x 12G-SDI outputs (one per SFP) used as a main and backup
Connector
DIN 1.0/2.3 CECC 22 230, DIN 47297 and DIN 41626
Signal Level
800 mV nominal
3.3. ELECTRICAL
Voltage
+12VDC
Power
24.5 Watts
EMI/RFI
Complies with FCC regulations for class A devices.
Complies with EU EMC directive.
3.4. PHYSICAL
Number of slots
7800FR Frame
1
7801FR Frame
1

7800MDM-12G
12G to/from Quad-Link 3G Bi-Directional Converter for UHD Signals
Page - 8 Revision 1.0
This page left intentionally blank

7800MDM-12G
12G to/from Quad-Link 3G Bi-Directional Converter for UHD Signals
Revision 1.0 Page - 9
4. WEB INTERFACE
The 7800MDM-12G can be controlled using Web Interface. WebEasy operates using Ethernet and SNMP
control protocols. The 7800MDM-12G DOES NOT HAVE card edge controls. As a result, 7800FC
modules must be installed in all frames that house 7800MDM-12G modules, or the card must be
connected directly with an Ethernet cable.
For the sake of brevity, the following sections describe module controls in terms of the parameters found
within the Web Interface screens for the 7800MDM-12G. As additional features and options are released,
additional sections will be appended to this manual to show those control screens.
After the card has been installed and configured with the required network addresses for the control port, it
can be completely configured using the web interface. For doing this, simply type the IP address of the
control port of the 7800MDM-12G module in the web browser.

Note: The computer must be on the same Subnet in order to have communication with
the module.
Figure 4-1: WebEASY® - Login Menu
Login and Password are “customer”.
There are four different menus on the web interface as shown in Figure 4-2.

7800MDM-12G
12G to/from Quad-Link 3G Bi-Directional Converter for UHD Signals
Page - 10 Revision 1.0
Figure 4-2: WebEASY®- 7800MDM-12G Menu
4.1. VIDEO
Figure 4-3: WebEASY® - Video Tab
Output Video
Input Source:This parameter allows the user to select the input source for each output path. For the
Quad-Link Output Path, the options are 12G IN 1 or 12G IN 2. The 12G Output Path option is Quad-
Link 3G SDI IN.
Configured Input Source: This parameter reports the input source configured for each output path.
For the Quad-Link Output Path, the options are 12G IN 1 or 12G IN 2. The 12G Output Path option is
Quad-Link 3G SDI IN.
Image Division Type: This parameter allows the user to select the division type for each output path.
For the Quad-Link Output Path, the options are 2-Sample Interleave Division or Square Division. The
12G Output Path option is 2-Sample Interleave Division.

7800MDM-12G
12G to/from Quad-Link 3G Bi-Directional Converter for UHD Signals
Revision 1.0 Page - 11
Video Delay: This parameter displays the video delay through the card for each output path. Values
are in ms.
Quad-Link 3G SDI Output Link Type: This parameter allows the user to select the link type for the
Quad-Link 3G SDI Output Path. The options are 3G Level A and B.
Input Video
12G Input Frame Rate: This parameter allows the user to select the frame rate for the 12G input. This is
not automatically discovered and must be set. The user can select between 59.94 Hz and 50 Hz.
4.2. QUAD-LINK 3G SDI INPUT MONITOR
Figure 4-4: WebEASY® - Quad-Link 3G SDI Input Monitor Tab

7800MDM-12G
12G to/from Quad-Link 3G Bi-Directional Converter for UHD Signals
Page - 12 Revision 1.0
Quad-Link 3G SDI Input Detected
Image: This parameter reports the input image detected on the Quad-Link 3G SDI input. The possible
values are:
- Not Present
- 3840x2160/59.94/P
- 3840x2160/50/P
Image Division: This parameter reports the type of image division detected on the Quad-Link 3G SDI
input. The possible values are:
- N/A
- 2-Sample Interleave Division
- Square Division
Transport Standards: This parameter reports the detected standard on each input BNC. The possible
values are:
- Not Present
- Unknown
- 525i/59.94 (Unsupported)
- 1080i/59.94 (Unsupported)
- 720p/59.94 (Unsupported)
- 1080p/59.94 (425 Level A)
- 1080p/59.94 (425M Level B)
- 625i/50 (Unsupported)
- 1080i/50 (Unsupported)
- 720p/50 (Unsupported)
- 1080p/50 (425M Level A)
- 1080p/50 (425M Level B)
Payload IDs: This parameter reports the detected Payload ID on each input BNC, and on each link per
input BNC in the case of Level B inputs.
Quad-Link 3G SDI Input Faults: This parameter reports video presence on each input BNC.
