Novus NV-DVR04 User manual

NV-DVR04
NV-DVR04NET
u s e r ’s m an u al
i n s t r u k c ja obsł u g i

NV-DVR04
NV-DVR04NET
u s e r ’s m an u al

NV-DVR1004 / NV-DVR1004NET ver. 1.0 - User’s manual
All rights reserved © NOVUS Security Sp. z o.o.
4
WARNINGS AND PRECAUTIONS
WARNING!
READ, KEEP AND FOLLOW THESE INSTRUCTIONS. ALL THE SAFETY
AND OPERATING INSTRUCTIONS SHOULD BE READ BEFORE THE
PRODUCT IS OPERATED.
WARNING:
TO REDUCE THE RISK OF FIRE OR E ECTRIC SHOCK DO NOT EXPOSE THIS UNIT TO
RAIN OR MOISTURE IF THIS UNIT IS DESIGNED FOR INDOOR USE ON Y.
WARNING!
USER IS NOT A OWED TO DISASSEMB E THE CASING IF THERE ARE NO USER-
SERVICEAB E PARTS INSIDE THIS UNIT. ON Y AUTHORIZED SERVICE PERSONNE
MAY OPEN THE UNIT
INSTA ATION AND SERVICING SHOU D ON Y BE DONE BY QUA IFIED SERVICE
PERSONNE AND CONFORM TO A OCA REGU ATIONS
WARNING!
DIGITA MU TIP EXER IS SENSITIVE TO E ECTROSTATIC DISCHARGES THEREFORE IT
SHOU D BE USED IN ACCORDANCE WITH OPERATING AND MAINTENANCE RU ES FOR
DEVICES BASED ON CMOS/MOSFET TECHNO OGY.
INFORMATION
This device complies with all requirements included in directives: 89/336/EEC, 93/68/EEC,
72/23/EEC
INFORMATION
Translation is based on original English user’s manual. Data included in the following user’s manual is up to
date at the time of printing. Novus Security Sp z o.o. holds exclusive rights to modify this manual. The producer
reserves the rights for device specification modification and change in the design without prior notice.

NV-DVR1004 / NV-DVR1004NET ver. 1.0 - User’s manual
All rights reserved © NOVUS Security Sp. z o.o.
5
WARNINGS AND PRECAUTIONS
1. Installation and servicing of NV- DVR1004 or NV-DVR1004NET should only be carried out by
qualified service personnel and conform to all local regulations.
2. Do not place the Multiplexer in areas where ventilation openings might be blocked or covered.
3. There are no user-serviceable parts inside this unit. Only authorized service personnel may open the
unit. The equipment should be protected from mechanical damage and kept clean at all times.
4. Protect this device from being exposed to dust and moisture. In the event of the Multiplexer coming
into direct contact with water unplug the device immediately and contact qualified service
personnel. Dusty (soiled/dirty) equipment may be the cause of fire and / or electrical shock.
5. Unplug the unit from the outlet before cleaning. This device can be cleaned only with a clean damp
cloth. Try to avoid using chemically active liquid cleaners or aerosol. In the event of strong dirt it is
allowed to use gentle cleaning lotion.
6. Power supply wires as well as signal wires should be fixed in the way that there is no risk of
mechanical damage, Please take extra caution not to overload sockets and extension cords to
prevent from the risk of fire.
7. In order to prevent the unit from damage, video channel and signal wires should be equipped with
appropriate surge protection device conforming to European Union standards. We also advice
utilizing video and data transmission protection.
8. It is not allowed to operate this device in conditions not complying with exploitation requirements
in the range of power supply, relative air humidity or air temperature..
9. Metal objects cannot be put inside the device. It can cause major malfunction and/or damage the
unit. In the event of the above, user should contact service immediately for further assistance.

NV-DVR1004 / NV-DVR1004NET ver. 1.0 - User’s manual
All rights reserved © NOVUS Security Sp. z o.o.
6
TABLE OF CONTENTS
1. FOREWORD ..............................................................................................................................................7
1.1 Main characteristics.............................................................................................................................7
1.2 NV-DVR1004 and NV-DVR1004NET TECHNICA SPECIFICATION ..................................... ...8
2. DEVICE POWER UP ................................................................................................................................9
2.1 Preparing the equipment for operation ...............................................................................................9
2.2 Electric connectors of NV-DVR1004 back panel.............................................................................10
2.3 Electric connectors of NV-DVR1004NET back panel ....................................................................11
2.4 External Devices Connection...........................................................................................................12
2.5 HDD Installation..............................................................................................................................14
2.5.1 Swappable bay HDD installation .........................................................................................14
2.5.2 Internal HDD installation (inside the Multiplexer) ...............................................................14
2.6 Device power on and power off. ......................................................................................................15
3. FRONT PANEL DESCRIPTION ...........................................................................................................16
3.1 NV-DVR1004 front panel description ............................................................................................16
3.2 NV-DVR1004NET front panel description.....................................................................................18
4. DEVICE MENU........................................................................................................................................ 20
4.1 System..............................................................................................................................................21
4.2 Cameras............................................................................................................................................ 23
4.3 Recording.........................................................................................................................................24
4.4 Alarm setup......................................................................................................................................26
4.5 Schedule...........................................................................................................................................27
4.6 Event ist .........................................................................................................................................28
4.7 HDD Management ...........................................................................................................................29
4.8 Network setup ..................................................................................................................................30
4.9 Default setup ....................................................................................................................................31
. RECORD.................................................................................................................................................. .32
6. PLAYBACK.............................................................................................................................................. 33
6.1 Time Search .....................................................................................................................................33
6.2 Searching Recorded Data From The Event ist ...............................................................................34
7. BACKUP ...................................................................................................................................................35
7.1. HDD backup on PC.......................................................................................................................... 35
7.2. Compact Flash Backup (NV-DVR-1004NET only).........................................................................35
7.2.1 Single Image Backup ............................................................................................................35
7.2.2 AVI Backup ..........................................................................................................................36
8. ALARM DEVICES INPUTS AND OUTPUTS CONNECTION .........................................................37
9. SPEED DOME CAMERA - CONNECTION AND CONTROL (NV-DVR1004NET ONLY)...........38
9.1 Novus Speed Dome Camera Connection ..........................................................................................38
9.2 Camera Control .................................................................................................................................40
10. NETWORK FUNCTION (NV-DVR1004NET)....................................................................................41
10.1 Computer Hardware Requirements ...............................................................................................41
10.2 Network Settings Configuration ..................................................................................................... 42
10.3 Initiating Connection.......................................................................................................................43
10.4 User Interface View ........................................................................................................................44
10.5 User Interface Function Description................................................................................................44
10.5.1 Display Settings ...................................................................................................................44
10.5.2 Transmission Speed .............................................................................................................45
10.5.3 Saving images on PC ..........................................................................................................46
10.5.4 Network Applet Configuration.............................................................................................48
10.5.4.1 Multiplexer ogs - system registry........................................................................48
10.5.4.2 System Settings ..................................................................................................... 48
10.5.4.3 User Accounts Management..................................................................................49
10.5.4.4 Network Connection Parameters ..........................................................................49
10.5.4.5 Alarm Event Notification ...................................................................................... 50
10.5.6 Multiplexer Remote Control ......................................................................................................51

NV-DVR1004 / NV-DVR1004NET ver. 1.0 - User’s manual
All rights reserved © NOVUS Security Sp. z o.o.
7
FOREWORD
1. FOREWORD
Digital Multiplexer NV-DVR1004 / NV-DVR1004NET was design specifically to work in CCTV
surveillance systems. This device incorporates the advantages of digital image recording with the
simplicity of installation and operation of time lapse recorders. This device utilizes very effective
compression method, ensuring high quality, detailed images.
1.1 Main characteristics.
 User friendly interface, with functions known from analog multiplexers;
 The simplicity and convenience of using HDD instead of video tapes;
 Immediate access to stored material;
 Menu access protected by password;
 M-JPEG compression algorithm with various image quality settings;
 Schedule recording with selection of mode and recording speed;
 The possibility of installing two HDD 3.5’’ IDE, one of them placed in swappable bay;
 Simultaneous real time display of all channels;
 Adjustable recording speed, up to 25 fields per second (PA );
 Alarm recording function;
 Motion detection functions;
 The possibility of remote control and viewing the images using the Ethernet (protocol TCP/IP)
(NV-DVR1004NET only);
 Files backup feature (JPG, AVI format) to Compact Flash memory card or utilizing network
(NV-DVR1004NET only);
 PTZ cameras control using front panel buttons (NV-DVR1004NET only);

NV-DVR1004 / NV-DVR1004NET ver. 1.0 - User’s manual
All rights reserved © NOVUS Security Sp. z o.o.
8
NV-DVR04 and NV-DVR04NET TECHNICAL SPECIFICATION
1.2. NV-DVR04 and NV-DVR04NET TECHNICAL SPECIFICATION
Video Input: 4 Video inputs (BNC), 1Vp-p/75 Ω;
Video Output:
1 Output (BNC), 1Vp-p/75 Ω to Main monitor (NV-DVR1004);
(2 Outputs (BNC), 1Vp-p/75 Ω to Main monitor
in NV-DVR1004NET only);
1 Output S-Video to Main monitor (NV-DVR1004);
Video Compression: M-JPEG;
Resolution: 640 x 272 (recording), 720x576 (displaying);
Recording modes: Continuous/Manual/Time-lapse/Alarm/Motion detection;
Recording speed: Up to 25 frames / sec. (PA );
Live mode displaying speed: 100 frames / sec. (PA );
Searching modes: Time / date search, Event search ;
Display modes: Full screen, Split screen: 4;
Video loss detection: Yes;
Ethernet: Integrated network card (RJ 45);
(NV-DVR-1004NET only);
Event list: Yes, 64 events for each HDD;
HDD: The possibility of installing two HDD 3.5’’ IDE, one of them
placed in swappable bay;
Compact Flash: Integrated slot for memory card connection (CF type I and II)
Alarm Input/Output: 4 inputs/ 1 relay output;
RS-48 communication port: 4-pin screwless terminal (NV-DVR-1004NET only);
Menu Setting: On Screen Display;
User Interface: Multilevel menu in English;
Clock: Built in Real Time Clock (RTC);
Watchdog function: Yes;
Dimensions: 432 (width) x 55 (height) x 321 (lenght) mm;
Power Supply: 90~260 V AC ;
Operating Temperature: 0°C~ +40°C;

NV-DVR1004 / NV-DVR1004NET ver. 1.0 - User’s manual
All rights reserved © NOVUS Security Sp. z o.o.
9
DEVICE POWER UP
2. DEVICE POWER UP
2.1 Preparing the equipment for operation.
Please take extra caution when unpacking the device.
Please ensure that following items are included in the package:
If the equipment has been damaged during transport, the contents of package should be packed back to
the original box. Contact the supplier for further assistance.
WARNING !
It is not allowed to power on the equipment directly after it has been brought from a place of low
temperature. If the device has been brought from the area of lower temperature the user should
wait until the equipment will warms up slowly and reaches the room temperature.
Condensation of moisturized air may cause short circuit and damage the device.
Net cross cable for Multiplexer-PC
connection
(NV-DVR1004NET only)
HDD Swappable Bay lock-keys Power Supply cord
CD-ROM containing necessary
Software and Manuals
User’s Manual
Digital Multiplexer NV-DVR04 or NV-DVR04NET
NV-DVR1004
NV-DVR1004NET
i n s t ru k c ja o b słu g i

NV-DVR1004 / NV-DVR1004NET ver. 1.0 - User’s manual
All rights reserved © NOVUS Security Sp. z o.o.
10
1. CAMERA OUT : video loop-through output;
2. POWER:
power switch ;
3. ~90~260V:
power supply socket ;
4. ALARM IN, Relay:
4 alarm inputs, 1 alarm relay ;
. MONITOR OUT: Main monitor connection, S-Video format;
6. MONITOR OUT:
output connection for Main monitor; user may select one of various split
screen display options, 1 Composite connector and 1 S-Video socket to connect
additional Main monitor;
7. CAMERA IN:
video inputs for camera connection ;
8. :
cooling fan (do not block or cover!);
2.2 Electric connectors on back panel of the NV-DVR04 multiplexer.
NV-DVR1004
1
2 3 4 7 5 6
8
DEVICE POWER UP

NV-DVR1004 / NV-DVR1004NET ver. 1.0 - User’s manual
All rights reserved © NOVUS Security Sp. z o.o.
11
1. Ethernet: RJ-45 socket for net computer connection;
2. network activity EDs;
3. COM PORT :
RS-232 port for diagnostic ;
4. R -485:
RS-485 port for PTZ control ;
. CAMERA OUT :
video loop-through output;
6. MONITOR OUT:
output connections for Main monitor; user might select one of various split
screen display option, 2 Composite connectors
7. POWER, ~100~240V:
power supply socket and power switch;
8. ALARM IN, Relay:
4 alarm inputs, 1 alarm relay ;
9. CAMERA IN:
video inputs for camera connection ;
10. :
cooling fan (do not block or cover!);
2.3 Electric connectors on back panel of the NV-DVR04NET multiplexer.
9
NV-DVR1004NET
3 4 5 6 7
8 10
DEVICE POWER UP
1 2

NV-DVR1004 / NV-DVR1004NET ver. 1.0 - User’s manual
All rights reserved © NOVUS Security Sp. z o.o.
12
2.4 External Devices Connection
All installation procedures should be conducted by qualified personnel.
Before device installation and operation please analyze the schematics shown below. Depending on specific
user needs and requirements each system will consist of various number of external devices. Monitors,
cameras and other devices are not included and must be purchased separately. Detailed description of devices
connection is included in next chapters of this manual.
Alarm
System
Modules
Main Monitor
(BN and/or S-Video)
Standard ameras
External Devices
onnected to Alarm
Inputs
PIR Detectors
Reed Relays
External Devices
onnected to Alarm Relays
E.g. alarm lights, sirens etc..
DEVICE POWER UP
NV-DVR1004

NV-DVR1004 / NV-DVR1004NET ver. 1.0 - User’s manual
All rights reserved © NOVUS Security Sp. z o.o.
13
DEVICE POWER UP
Alarm
System
Modules
ompact Flash memory card
Main Monitor
(BN )
Standard ameras
P omputers
for Remote Acces
External Devices
onnected to Alarm
Inputs
PIR Detectors
Reed Relays
External Devices
onnected to Alarm
Relays
E.g. alarm lights, sirens etc..
LAN / WAN
NV-DVR1004NET
RS-485
Video
Speed Dome ameras

NV-DVR1004 / NV-DVR1004NET ver. 1.0 - User’s manual
All rights reserved © NOVUS Security Sp. z o.o.
14
DEVICE POWER UP
2. HDD Installation
Two HDDs can be installed in NV-DVR1004 and NV-DVR1004NET Digital Multiplexers. One of
these disks can be installed inside the device, second might be placed in swappable bay.
WARNING: Producer advices utilizing Maxtor or Hitachi HDDs.
Max. allowed capacity of single HDD is 400GB.
Before installing HDD please make sure that jumpers are set properly!
In the event of using only one HDD it must be set as MASTER. In the event of two HDD, one of them
must be set in MASTER mode and the second in S AVE mode. HDD configuration of specified type
and manufacturer is described in the HDD manual supplied with the HDD.
2. .1 Swappable bay HDD installation
Before installation disconnect power supply cord.
Place the properly set HDD in swappable bay and then screw it to the casing utilizing 4 supplied
screws. Place the swappable bay in the Multiplexer and close it with the key, attached in the package.
2.4.2 Internal HDD installation (inside the DVR)
WARNING!
Internal HDD should be installed by qualified service personnel.
The housing of the Multiplexer can be opened only for internal HDD installing according to the
installing procedure described in this manual on page 52.
If the Multiplexer housing is opened for a different purpose the warranty is void.

NV-DVR1004 / NV-DVR1004NET ver. 1.0 - User’s manual
All rights reserved © NOVUS Security Sp. z o.o.
15
DEVICE POWER UP
2.6 Device power on and power off.
Before powering on the device please make sure that the power supply (voltage and frequency)
conforms to device requirements. Also make sure that the power switch is set to „0”, HDD swappable
bay is locked with the key and that the all external devices are connected properly.
WARNING: We do not advice to connect any additional devices (such us cameras, monitors, etc..)
while device operation.
Device power on is activated by switching the power switch to position „1”.
The loading procedure of the operating system takes about 30 seconds.
During this procedure various information will appear on the screen.
During this procedure please do not press any buttons on the front panel of this device.
The loading procedure is finished when camera images will appear on the Main monitor along with
their descriptions and the system time.
To power off the device stop the recording and shut down the device using power switch.

NV-DVR1004 / NV-DVR1004NET ver. 1.0 - User’s manual
All rights reserved © NOVUS Security Sp. z o.o.
16
FRONT PANEL DESCRIPTION
3. NV-DVR1004 Front Panel Description
18
19
12 16 6 7 8 9 10 11 17
20
5 4 3 2 1 13 14 15
Icon Fuction
1
1. Channel 1 selection.
2. Password input, digit 1.
2
1. Channel 2 selection.
2. Password input, digit 2.
3
1. Channel 3 selection.
2. Password input, digit 3.
4
1. Channel 4 selection.
2. Password input, digit 4.
Quad Quad display selection (2x2).
Rec Recording ON button;
Rew Search
Rewind playback. Pressing that button will give following rewind speeds:
x2, x8, x16.
STOP Playback stop.
Pause
Pause. Press that button in playback mode to play field by field.
1
2
3
4
5
9
6
7
8

NV-DVR1004 / NV-DVR1004NET ver. 1.0 - User’s manual
All rights reserved © NOVUS Security Sp. z o.o.
17
FRONT PANEL DESCRIPTION
Icon Function
F.Fwd Search
Fast Forward playback. Pressing that button will give following fast forward
speeds:
x2, x8, x16.
PLAY Playback menu entering.
MENU On Screen Display menu activating;
 Przycisk zmiany położenia kursora w lewo.
 Przycisk zmiany położenia kursora w górę.
 Przycisk zmiany położenia kursora w prawo.
 Przycisk zmiany położenia kursora w dół.
ENTER
1. Przycisk pozwalający na wybór pod-menu lub zatwierdzający zmiany
w menu.
2. Jeśli system nie jest w trybie programowania (menu), naciśnięcie
umożliwia wyświetlenie statusu twardego dysku (lub twardych dysków).
Kieszeń dysku wymiennego.
POWER Dioda ED sygnalizująca włączenie zasilania.
H. . . Dioda ED sygnalizująca pracę dysku twardego.
19
18
17
15
14
16
10
11
12
13
20

NV-DVR1004 / NV-DVR1004NET ver. 1.0 - User’s manual
All rights reserved © NOVUS Security Sp. z o.o.
18
FRONT PANEL DESCRIPTION
3.2 NV-DVR1004NET Front Panel Description
19
20
12 16 6 7 8 9 10 11 17
21
5 4 3 2 1 13 14 15
18
Icon Function
1
1. Channel 1 selection.
2. Password input, digit 1.
2
1. Channel 2 selection.
2. Password input, digit 2.
3
1. Channel 3 selection.
2. Password input, digit 3.
4
1. Channel 4 selection.
2. Password input, digit 4.
Quad Quad display selection (2x2).
Rec Recording ON button;
Rew Search
Rewind playback. Pressing that button will give following rewind speeds:
x2, x8, x16.
STOP Playback stop.
Pause
Pause. Press that button in playback mode to play field by field.
1
2
3
4
5
9
6
7
8

NV-DVR1004 / NV-DVR1004NET ver. 1.0 - User’s manual
All rights reserved © NOVUS Security Sp. z o.o.
19
FRONT PANEL DESCRIPTION
Icon Function
F.Fwd Search
1. Fast Forward playback. Pressing that button will give following fast for-
ward speeds: x2, x8, x16.
2. In live display mode that button activates PTZ control mode.
PLAY Playback menu entering.
MENU On Screen Display menu activating;
 1. Up and left cursor button
2. In PTZ mode that button moves left the camera.
 1. Up and left cursor button
2. In PTZ mode that button moves up the camera.
 1. Up and left cursor button
2. In PTZ mode that button moves right the camera.
 1. Up and left cursor button
2. In PTZ mode that button moves down the camera.
COPY
ENTER
1. In programming mode that button is used to enter sub-menu and edition
field;
2. In live/record mode that button is used to get HDD’s capacity/occupancy
information
3. In playback mode that button activate CF backup.
Compact Flash card slot.
POWER Power on indicator.
H. . . ED informing that HDD’s is in use.
HDD swappable bay.
19
18
17
15
14
16
10
11
12
13
20
21

NV-DVR1004 / NV-DVR1004NET ver. 1.0 - User’s manual
All rights reserved © NOVUS Security Sp. z o.o.
20
URUCHOMIENIE URZĄDZENIA DEVICE MENU
4. DEVICE MENU
Digital Multiplexers NV-DVR1004NET and NV-DVR1004NET are equipped with multi level OSD
(on screen display) sub-menus. This menus are used to program settings and execute functions such us
playback or coping. Menu is displayed in English.
Notice: Device OSD menu is available only while recording is inactive (see chapter 5).
In order to enter device menu press MENU button.
Main menu consist of 7 sub-menus. The contents of sub-menus is described on following pages of this
manual.
This buttons  are used to select menu items.
Selected item is pointed by these icons


, 

 or 

.
Press or button in order to confirm the selection, enter the sub-menu or to modify selected value.
Exiting the menu accepts and saves inputted modifications.
In order to leave selected menu or to return to the higher level menu from individual sub-menus and
modification fields EXIT option should be selected and ENTER button must be pressed. Pressing
MENU button acts similar to the procedures described above.
SETUP MENU


SYSTEM SETUP
CAMERA SETUP
RECORD SETUP
ALARM SETUP
SCHEDULE RECORD
EVENT LIST
HDD MANAGEMENT
DEFAULT SETUP
EXIT
PRESS [UP/DOWN] TO MOVE [MENU] TO EXIT
[RIGHT/LEFT] TO SELECT
