evertz 7700 Series User manual

7700 MultiFrame Manual
7707VB-3-HS-OC48 Triple HD/SDI/ASI/SDTi + Ethernet SONET/SDH Fiber Transceiver
Revision 1.1
TABLE OF CONTENTS
1.
OVERVIEW............................................................................................................................................1
2. INSTALLATION.....................................................................................................................................3
2.1. CARE AND HANDLING OF OPTICAL FIBER...............................................................................4
2.1.1. Safety.......................................................................................................................................4
2.1.2. Assembly..................................................................................................................................4
2.1.3. Labeling....................................................................................................................................5
2.1.4. Handling and Connecting Fibers..............................................................................................5
3. SPECIFICATIONS .................................................................................................................................6
3.1. SERIAL VIDEO INPUT ...................................................................................................................6
3.2. SERIAL VIDEO OUTPUTS:............................................................................................................6
3.3. SERIAL VIDEO MONITOR OUTPUTS:..........................................................................................6
3.4. OPTICAL OUTPUT.........................................................................................................................6
3.5. OPTICAL INPUT.............................................................................................................................7
3.6. ELECTRICAL..................................................................................................................................7
3.7. PHYSICAL......................................................................................................................................7
3.8. COMPLIANCE................................................................................................................................7
4. STATUS INDICATORS AND DISPLAYS..............................................................................................8
4.1. STATUS INDICATOR LEDS ..........................................................................................................8
4.2. CARD EDGE DISPLAY ..................................................................................................................9
4.2.1. STAT Menu............................................................................................................................11
4.2.1.1. Displaying the Optical Link Data Standard .....................................................................12
4.2.1.2. Displaying Optical Power................................................................................................12
4.2.1.3. Displaying the Current Interval Counter..........................................................................12
4.2.1.4. Displaying the Last Interval Counter...............................................................................13
4.2.1.5. Displaying the Errored Seconds Ratio............................................................................14
4.2.1.6. Displaying the Loss of Signal seconds in Line Layer......................................................14
4.2.1.7. Displaying the Link Output Reference Clock Source......................................................14
4.2.1.8. Displaying the Link Input Status......................................................................................15
4.2.1.9. Displaying the TDM Data Errors.....................................................................................15
4.2.1.10. Displaying the Video Standard at Output Ports ..............................................................15
4.2.1.11. Detecting the EDH Presence in a Compatible Signal at Output Ports............................15
4.2.1.12. Displaying the SDTI Status at Output Ports....................................................................16
4.2.1.13. Displaying the Video Standard at Input Ports.................................................................16
4.2.1.14. Detecting the EDH Presence in a Compatible Signal at Input Ports...............................16
4.2.1.15. Displaying the SDTI Status at Input Ports.......................................................................17
4.2.1.16. Displaying the Ethernet Status........................................................................................17
4.2.1.17. Displaying the Ethernet Speed .......................................................................................17
4.2.1.18. Flexible Bandwidth Management Monitoring..................................................................17
4.2.2. Control Menu..........................................................................................................................19
4.2.2.1. Setting the Optical Link Standard ...................................................................................19
4.2.2.2. Setting the Behavior of Laser When There is No Applied Video ....................................20
4.2.2.3. Setting the Clock Source ................................................................................................20

7700 MultiFrame Manual
7707VB-3-HS-OC48 Triple HD/SDI/ASI/SDTi + Ethernet SONET/SDH Fiber Transceiver
Revision 1.1
4.2.2.4. Clearing the Counters.....................................................................................................20
4.2.2.5. Setting the Severe Errored Second Threshold...............................................................21
4.2.2.6. Activating or Deactivating EDH Processing....................................................................21
4.2.2.7. Setting Video Standard on Loss .....................................................................................21
4.2.2.8. Activating or Deactivating EDH Processing....................................................................22
4.2.2.9. Monitoring a Specific Channel........................................................................................22
4.2.2.10. Signal BLOCK Configuration ..........................................................................................22
4.2.2.11. Setting the Orientation of the Text on the Card Edge Display........................................23
5. JUMPERS............................................................................................................................................24
5.1. SELECTING WHETHER LOCAL FAULTS WILL BE MONITORED BY THE GLOBAL FRAME
STATUS...................................................................................................................................................24
5.2. CONFIGURING THE MODULE FOR FIRMWARE UPGRADES..................................................25
5.2.1. Using the Upgrade Jumper....................................................................................................25
5.2.2. Upgrade Serial Port Command..............................................................................................25
Figures
Figure 1-1: 7707VB-3-HS-OC48 Block Diagram ..................................................................................................2
Figure 2-1: 7707VB-3-HS-OC48 Rear Panel........................................................................................................3
Figure 2-2: Reproduction of Laser Certification and Identification Label..............................................................5
Figure 4-1: Location of Status Indicators and Controls.........................................................................................8
Figure 4-2: Card Edge Menu...............................................................................................................................10
Figure 4-3: STAT Menu Structure......................................................................................................................11
Figure 4-4: Control Menu ....................................................................................................................................19
Figure 5-1: Location of Status Indicators and Jumpers ......................................................................................24
Tables
Table 4-1: Current Interval Counter Menu ..........................................................................................................13
Table 4-2: Last Interval Counter Menu................................................................................................................14

7700 MultiFrame Manual
7707VB-3-HS-OC48 Triple HD/SDI/ASI/SDTi + Ethernet SONET/SDH Fiber Transceiver
Revision 1.1
REVISION HISTORY
REVISION DESCRIPTION DATE
1.0 First release Jan 08
1.1 Changed Ethernet FBM parameters Jul 08
Information contained in this manual is believed to be accurate and reliable. However, Evertz assumes no responsibility for the use thereof nor for
the rights of third parties, which may be affected in any way by the use thereof. Any representations in this document concerning performance of
Evertz products are for informational use only and are not warranties of future performance, either expressed or implied. The only warranty offered
by Evertz in relation to this product is the Evertz standard limited warranty, stated in the sales contract or order confirmation form.
Although every attempt has been made to accurately describe the features, installation and operation of this product in this manual, no warranty is
granted nor liability assumed in relation to any errors or omissions unless specifically undertaken in the Evertz sales contract or order confirmation.
Information contained in this manual is periodically updated and changes will be incorporated into subsequent editions. If you encounter an error,
please notify Evertz Customer Service department. Evertz reserves the right, without notice or liability, to make changes in equipment design or
specifications.

7700 MultiFrame Manual
7707VB-3-HS-OC48 Triple HD/SDI/ASI/SDTi + Ethernet SONET/SDH Fiber Transceiver
Revision 1.1
WARNING
Never look directly into an optical fiber. Non-reversible damage to the eye can
occur in a matter of milliseconds.

7700 MultiFrame Manual
7707VB-3-HS-OC48 Triple HD/SDI/ASI/SDTi + Ethernet SONET/SDH Fiber Transceiver
Revision 1.1 7707VB-3-HS-OC48 - 1
1. OVERVIEW
The 7707VB-3-HS-OC48 is a VistaLINK
®
enabled, fiber transreceiver for HD-SDI, SD-SDI, DVB-ASI or
SDTi video signal that transports signals at OC-48/STM-16 data rates (2488.32 Mb/s) and interfaces
directly to SONET/SDH infrastructure. The card also has a built-in Ethernet transceiver with a 10/100/1000
Base-T port. This dual fiber single card combines up to one HD-SDI plus two asynchronous SDI, DVB-ASI
or SDTi signals using Time Domain Multiplex (TDM) technology. A companion 7707VB-3-HS-OC48 card
acts as a demultiplexer for the incoming signal and converts them back to separate SDI video feeds, while
utilizing a separate fiber for the outgoing signal.
The 7707VB-3-HS-OC48 will transparently pass incoming HD and SD-SDI video feeds with embedded
AES audio or any other data in the horizontal or vertical ancillary data space. Monitoring and control of
card status and parameters is provided locally at the card edge or remotely via VistaLINK
®
.
The fiber output is available in an assortment of optical wavelengths, accommodating standard, CWDM or
DWDM transmission schemes.
7707VB13-3-HS-OC48 1310 nm FP -7dBm output, suitable for distances up to 50 Km
7707VB15-3-HS-OC48 1550 nm DFB 0dBm output, suitable for distances up to 75 Km
There are several versions with built in isolators specifically suited to coarse wave division multiplexing
(CWDM) applications. These versions all have 0dBm output and are suitable for distances up to 75 Km.
7707VB27-3-HS-OC48 1270 nm DFB
7707VB29-3-HS-OC48 1290 nm DFB
7707VB31-3-HS-OC48 1310 nm DFB
7707VB33-3-HS-OC48 1330 nm DFB
7707VB35-3-HS-OC48 1350 nm DFB
7707VB37-3-HS-OC48 1370 nm DFB
7707VB43-3-HS-OC48 1430 nm DFB
7707VB45-3-HS-OC48 1450 nm DFB
7707VB47-3-HS-OC48 1470 nm DFB
7707VB49-3-HS-OC48 1490 nm DFB
7707VB51-3-HS-OC48 1510 nm DFB
7707VB53-3-HS-OC48 1530 nm DFB
7707VB55-3-HS-OC48 1550 nm DFB
7707VB57-3-HS-OC48 1570 nm DFB
7707VB59-3-HS-OC48 1590 nm DFB
7707VB61-3-HS-OC48 1610 nm DFB
There are several versions with built in isolators specifically suited to dense wave division multiplexing
(DWDM) applications. The DWDM versions are suitable for distances >120 km @ 270 Mb/s (for DWDM
applications contact the factory).
7707VBDyyy-3-HS-OC48 DWDM DFB laser output, yyy – ITU channel number
The 7707VB-3-HS-OC48 occupies two card slots in the 3 RU frame, which will hold up to 7 modules or
one card slot in the 1RU frame, which will hold up to three modules. One 7707VB-3-HS-OC48 module
can also be installed in the S7701 stand-alone enclosure.

7700 MultiFrame Manual
7707VB-3-HS-OC48 Triple HD/SDI/ASI/SDTi + Ethernet SONET/SDH Fiber Transceiver
7707VB-3-HS-OC48 - 2 Revision 1.1
Features:
•Transports signal over OC-48/STM-16 data rates (2488.32 Mb/s)
•Single card TDM multiplexer and demultiplexer for two bi-directional asynchronous SD-SDI, SDTi
and DVB-ASI signals
•Built-in Ethernet transceiver with one 10/100/1000 Base-T port with FBM (Fiber Bandwidth
Management)
•Interfaces directly to SONET/SDH infrastructure
•Uncompressed, full-rate video transport
•Signal transport uninterrupted by loss of any HD, SD-SDI, DVB-ASI or SDTi input feed
•Transparently passes embedded AES or any other data in the horizontal or vertical ancillary data
space
•Stratum 3 wander/holdover/jitter compliance
•Wide input frequency range tolerance (±50ppm)
•Comprehensive signal and card status monitoring via four character card-edge display
•VistaLINK
®
– enabled offering remote monitoring, control and configuration capabilities via SNMP.
VistaLINK
®
is available when modules are used with the 3RU 7700FR-C frame, a 7700FC
VistaLINK
®
Frame Controller module in slot 1 of the frame using the 9000NCP Network Control
Panel or Evertz VistaLINK
®
PRO or other third party SNMP manager software.
•Automatic coaxial equalization up to 100m at 1.485Gb/s and 250m at 270Mb/s (Belden 1694A or
equivalent cable)
•Fully hot-swappable from front of frame with no fiber/coax disconnect/reconnect required
•Supports single-mode and multi-mode fiber optic cable
•Optical output wavelengths of 1310nm, 1550nm and up to 16 CWDM wavelengths
•DWDM wavelengths also available
•SC/PC, ST/PC, FC/PC fiber connectors available
FIBER
OUTPUT
OPTICAL
TRANSMITTER
HD/SDI/ASI/SDTi
VIDEO INPUT
HD/SDI/ASI/SDTi
VIDEO MONITOR
OUTPUT
INPUT
STAGE
1
INPUT
STAGE
2
INPUT
STAGE
3
OUTPUT
STAGE
1
OUTPUT
STAGE
2
OUTPUT
STAGE
3
MONITOR
SELECTOR
CONTROL/
INDICATION
VistaLINK
®
Interface
LOCAL
CONTROL
LOCAL
INDICATION
10/100/1000
ETHERNET
RJ45
FIBER
INPUT
OPTICAL
RECEIVER
SONET/
SDH TDM
MUX
OUTPUT
STAGE
HD/SDI/ASI/SDTi
VIDEO MONITOR
OUTPUT
OUTPUT
STAGE
SONET/
SDH TDM
DEMUX
FBM Technology
HD/SDI/ASI/SDTi
VIDEO OUTPUT
SDI/ASI/SDTi VIDEO
INPUT
SDI/ASI/SDTi VIDEO
INPUT
SDI/ASI/SDTi VIDEO
OUTPUT
SDI/ASI/SDTi VIDEO
OUTPUT
Figure 1-1: 7707VB-3-HS-OC48 Block Diagram

7700 MultiFrame Manual
7707VB-3-HS-OC48 Triple HD/SDI/ASI/SDTi + Ethernet SONET/SDH Fiber Transceiver
Revision 1.1 7707VB-3-HS-OC48 - 3
2. INSTALLATION
The 7707VB-3-HS-OC48 comes with a companion rear plate that has 8 BNC connectors and two SC/PC
(shown), ST/PC or FC/PC optical connector. For information on mounting the rear plate and inserting the
module into the frame see section 3 of the 7700FR chapter.
Figure 2-1: 7707VB-3-HS-OC48 Rear Panel
HD/SD IN 1: One BNC input connection for HD-SDI, SDI/SDTi video signals compatible with HD-
SDI (SMPTE 292M), SD-SDI (SMPTE 259M-C), SDTi (SMPTE 305.2M) and DVB-
ASI standards (auto sensing). These inputs provide adaptive compensation for up to
100m of industry standard Belden 1694A cable at 1.485Gb/s or 250m of 1694A
cable at 270Mb/s.
SD IN 2, 3: Two independent BNC input connectors for 10-bit serial digital video signals
compatible with the SMPTE 259M, DVB-ASI or SMPTE 305M standards. These

7700 MultiFrame Manual
7707VB-3-HS-OC48 Triple HD/SDI/ASI/SDTi + Ethernet SONET/SDH Fiber Transceiver
7707VB-3-HS-OC48 - 4 Revision 1.1
inputs provide adaptive compensation for up to 250m of industry standard Belden
8281 cable, at 270Mb/s.
HD/SD OUT1: One BNC connection, reclocked SDI/SDTi video signals compatible with HD-SDI
(SMPTE 292), SD-SDI (SMPTE 259M-C), SDTi (SMPTE 305.2M) and DVB-ASI
standards.
SD OUT 2, 3: Two independent BNC output connectors for 10-bit serial digital video signals
compatible with the SMPTE 259M, DVB-ASI or SMPTE 305M standards.
MON OUT 1, 2: User selectable video loopback outputs. Any of the inputs or the outputs can source
this port for reclocked loop back functionality. Selection is controlled via the card
edge menu or VistaLINK
®
. If EDH correction is activated, the selected output will be
EDH corrected.
OPTICAL INPUT: SC/PC, SC/PC with cover (shown), ST/PC or FC/PC female connector. This wide
range input accepts optical wavelengths of 1270nm to 1610nm, accommodating
standard or CWDM transmission schemes.
OPTICAL OUTPUT: Output SC/PC, SC/PC with cover (shown), ST/PC or FC/PC female connector. This
optical output contains the two input SDI video signals. Any ancillary data (e.g.
embedded audio, closed captioning, etc) present in the input SDI video stream prior
to multiplexing is transparently passed through to the fiber output.
2.1. CARE AND HANDLING OF OPTICAL FIBER
2.1.1. Safety
!
CLASS 1 LASER PRODUCT
Background colour: yellow
Triangular band: black
Symbol: black
2.1.2. Assembly
Assembly or repair of the laser sub-module is done only at Evertz facility and performed only by qualified
Evertz technical personnel.

7700 MultiFrame Manual
7707VB-3-HS-OC48 Triple HD/SDI/ASI/SDTi + Ethernet SONET/SDH Fiber Transceiver
Revision 1.1 7707VB-3-HS-OC48 - 5
2.1.3. Labeling
The Certification and Identification labels are combined into one label. As there is inadequate space on
the product to place the label, it is reproduced here in the manuals.
•There is no date of manufacture on this label as it can be traced by the bar code label placed on
the printed circuit board of each Evertz plug-in module
•The Model number is one of: 7707VB13-3-HS-OC48, 7707VB15-3-HS-OC48,
7707VBxx-3-HS-OC48, (xx = 27, 29, 31, 33, 35, 37, 43, 45, 47, 49, 51, 53, 55, 57, 59, 61)
7707VBDyyy-8 (Dyyy represents ITU Grid Channel: D200, D210, D220, D230, D240, D250, D260,
D270, D280, D290, D300, D310, D320, D330, D340, D350, D360, D370, D380, D390, D400,
D410, D420, D430, D440, D450, D460, D470, D480, D490, D500, D510, D520, D530, D540,
D550, D570, D580, D590, D600)
Figure 2-2: Reproduction of Laser Certification and Identification Label
2.1.4. Handling and Connecting Fibers
"
Never touch the end face of an optical fiber. Always keep dust caps on optical fiber
connectors when not connected. Always remember to properly clean the optical
end face of a connector before making a connection.
The transmission characteristics of the fiber are dependent on the shape of the optical core and therefore
care must be taken to prevent fiber damage due to heavy objects or abrupt fiber bending. Evertz
recommends that you maintain a minimum bending radius of 5 cm to avoid fiber-bending loss that will
decrease the maximum attainable distance of the fiber cable. The Evertz fiber optic modules come with
cable lockout devices to prevent the user from damaging the fiber by installing a module into a slot in the
frame that does not have a suitable I/O module. For further information about the care and handling of the
fiber optic cable see section 3 of the Fiber Optics System Design section of this manual binder.

7700 MultiFrame Manual
7707VB-3-HS-OC48 Triple HD/SDI/ASI/SDTi + Ethernet SONET/SDH Fiber Transceiver
7707VB-3-HS-OC48 - 6 Revision 1.1
3. SPECIFICATIONS
3.1. SERIAL VIDEO INPUT
Standards:
HD/SDI Inputs: SMPTE 292M, SMPTE 259-C, SMPTE305.2M, DVB-ASI
SDI Inputs: SMPTE 259M-C, SMPTE 305M(SDTi), DVB-ASI
Number of Inputs: 1 HD/SDI
2 independent SDI, SDTi or DVB-ASI 270Mb/s signals
Connector: 3 BNC input per IEC 60169-8 Amendment 2
Equalization: Automatic 250m (min) @ 270 Mb/s with Belden 1694 or equivalent cable
Return Loss: > 15 dB up to 1.5Gb/s
Frequency Offset Tolerance: ±50ppm
3.2. SERIAL VIDEO OUTPUTS:
Standards:
HD/SDI Inputs: SMPTE 292M, SMPTE 259-C, SMPTE305.2M, DVB-ASI
SDI Inputs: SMPTE 259M-C, SMPTE 305M(SDTi), DVB-ASI
Number of Outputs: 3 Independent SDI, SDTi or DVB-ASI 270Mb/s signals + 2 monitor
outputs
Connectors: BNC per IEC 60169-8 Amendment 2
Signal Level: 800mV(nominal)
DC Offset: 0V ±0.5V
Rise and Fall Time: 900ps(nominal)
Overshoot: < 10% of amplitude
Return Loss: > 12dB
Wide Band Jitter: < 0.2UI
3.3. SERIAL VIDEO MONITOR OUTPUTS:
Standards:
HD/SDI Inputs: SMPTE 292M, SMPTE 259-C, SMPTE305.2M, DVB-ASI
SDI Inputs: SMPTE 259M-C, SMPTE 305M(SDTi), DVB-ASI
Number of Outputs: 2 signals user-selectable from the 3 inputs and 3 outputs
Connectors: BNC per IEC 60169-8 Amendment 2
Signal Level: 800mV(nominal)
DC Offset: 0V ±0.5V
Rise and Fall Time: 900ps(nominal)
Overshoot: < 10% of amplitude
Return Loss: > 14dB
Wide Band Jitter: < 0.2UI
3.4. OPTICAL OUTPUT
Standards: OC-48/STM-16
Number of Outputs: 1
Connector: Female SC/PC, ST/PC or FC/PC
Return Loss: > 14 dB
Wide Band Jitter: < 0.2UI

7700 MultiFrame Manual
7707VB-3-HS-OC48 Triple HD/SDI/ASI/SDTi + Ethernet SONET/SDH Fiber Transceiver
Revision 1.1 7707VB-3-HS-OC48 - 7
Fiber Size: 9 µm core / 125 µm overall
Wavelengths:
Standard: 1310nm, 1550nm (nominal)
CWDM: 1270nm to 1610nm (See ordering information)
DWDM: C-Band channel 20 to 60, 100GHz spacing (ITU-T G.694.1 compliant)
Output Power:
1310nm FP: -7dBm ±1dBm
1550nm & CWDM: 0 dBm ±1dBm
DWDM: +7dBm ±1dBm
3.5. OPTICAL INPUT
Number of Inputs: 1
Standards: OC-48/STM-16
Connector: Female SC/PC, ST/PC or FC/PC
Return Loss: > 25dB
Wavelength: 1270nm to 1610nm
Maximum Input Power:
Standard: -1dBm
High Sensitivity (-H): -8dBm
Optical Sensitivity:
Standard: -21dBm
High Sensitivity (-H): -28dBm
3.6. ELECTRICAL
Voltage: +12VDC
Power: 10 Watts (Non DWDM)
13 Watts (DWDM)
3.7. PHYSICAL
Number of slots: 2
3.8. COMPLIANCE
Electrical Safety: CSA Listed to CSA C22.2 No. 60065-03, UL 60065-03
IEC 60065-(2001-12) 7th Edition
Complies with CE Low voltage directive 93/68/EEC
Laser Safety: Complies with 24 CFR 1040.10 and 1040.11 except for deviations
pursuant to LN No. 50, dated July 26, 2001
Complies with IEC 60825-1, Am. 2
EMI/RFI: Complies with FCC regulations for class A devices.
Complies with EU EMC directive 89/336/EEC.

7700 MultiFrame Manual
7707VB-3-HS-OC48 Triple HD/SDI/ASI/SDTi + Ethernet SONET/SDH Fiber Transceiver
7707VB-3-HS-OC48 - 8 Revision 1.1
4. STATUS INDICATORS AND DISPLAYS
The 7707VB-3-HS-OC48 has 8 LED Status indicators and a 4 digit alphanumeric display on the front card
edge to show operational status of the card at a glance. The card edge pushbutton and toggle switch are
used to select various displays on the alphanumeric display. Figure 4-1 shows the locations of the
indicators, pushbutton and toggle switch.
Alpha-numeric
Display
7707VB-3-HS-OC48
Green Module OK LED
12
31
Toggle Switch
Pushbutton
Red Local Fault LED
78
Video IN Video OUT Ethernet Payload
23
Figure 4-1: Location of Status Indicators and Controls
4.1. STATUS INDICATOR LEDS
LOCAL FAULT: On the 7707VB-3-HS-OC48 board this Red LED will be ON if a laser fault exists, or
if the laser is set to Discontinuous mode with no valid inputs present, or if a local
input power fault exists (i.e.: a blown fuse).
The LOCAL FAULT indications can also be reported to the frame through the
FRAME STATUS jumper.
MODULE OK: This Green LED indicates good module health. It will be ON when a valid input
signal is present, and the laser and board power are good.
VIDEO IN STATUS LED:
GREEN Valid signal input. No errors.
RED Valid signal input. Errors detected.
OFF No valid input detected.
YELLOW Input is blocked by the user from being transported through fiber.
VIDEO OUT STATUS LED:
GREEN Valid signal at output. No errors.
RED Valid signal at output. Errors detected.
OFF No valid output detected.
YELLOW Output is blocked by the user from being transported through fiber.
ETHERNET STATUS LED:
GREEN Connection established.
BLINK Sending or receiving data.
OFF No valid connection.
PAYLOAD STATUS LED:
GREEN Payload OK.
RED Errors detected.

7700 MultiFrame Manual
7707VB-3-HS-OC48 Triple HD/SDI/ASI/SDTi + Ethernet SONET/SDH Fiber Transceiver
Revision 1.1 7707VB-3-HS-OC48 - 9
4.2. CARD EDGE DISPLAY
Additional signal and status monitoring is provided via the 4-digit dot-matrix display located at the card-
edge. The card edge toggle switch is used to select whether you are displaying status from the card
(monitoring mode) or setting control parameters for the card (control mode). Press the toggle switch to
select ‘monitor mode’ (STAT) or ‘control mode’ (CTRL).
Figure 4-2 shows the menu structure for the 7707VB-3-HS-OC48 card.
Level 1 Level 2 Level 3 Level 4 Level 5 Level 6
STD OC, STM
PWR -40 to 0 dB
TIME 0 to 899
15M ESL, SESL, ESS, SESS,
ESP, SESP, SEFS 0 to 9999
TIME 0 to 1439
CIC
24H ESL, SESL, ESS, SESS,
ESP, SESP, SEFS 0 to 9999
LIC 15M, 24H
ESL, SESL, ESS, SESS,
ESP, SESP, SEFS 0 to 9999
ESR SECT, LINE, PATH 0.0% - 100%
LOSL 0 to 9999
OUT REF ERR, XO, HOLD,
LINK
FIBR
REF INP LOS, FOS, OK
TDMD LOSS, ERR, OK
STD {HD Standards List} ASI, N270, P270, SDTI-
N270, SDTI-P270, LOSS
EDH PRES, LOSS
VO1
SDTI PRES, LOSS
STD ASI, N270, P270, SDTI-
N270, SDTI-P270, LOSS
EDH PRES, LOSS
VOUT
VO2, VO3
SDTI PRES, LOSS
STD {HD Standards List} ASI, N270, P270, SDTI-
N270, SDTI-P270, LOSS
EDH PRES, LOSS
VI1
SDTI PRES, LOSS
STD ASI, N270, P270, SDTI-
N270, SDTI-P270, LOSS
EDH PRES, LOSS
VINP
VI2, VI3
SDTI PRES, LOSS
LINK UP, DOWN
PORT SPD 10, 100, 1000, DOWN
STAT
ETH FBM OFF, 100, 300, 500,
700, 1000, AUTO
STD BACK, OC, STMCTRL FIBR LASR BACK, CONT, DISC

7700 MultiFrame Manual
7707VB-3-HS-OC48 Triple HD/SDI/ASI/SDTi + Ethernet SONET/SDH Fiber Transceiver
7707VB-3-HS-OC48 - 10 Revision 1.1
REF HOLD, LINK, XO,
AUTO
CIC ALL, 15M, 24H CLR, BACK
LOSL CLR, BACK
CESR CLR, BACK
SETH SESS, SESL, SESP,
SEFS 1 to 9999
VINP VI1, VI2, VI3 BACK, EDH OFF, ON
EDH OFF, ON
VO1 OSTD {HD Standards List}
ASI, N270, P270, OFF
EDH OFF, ON
VOUT
VO2, VO3 OSTD ASI, N270, P270, OFF
VMON1 BACK, VO1, VO2, VO3, VI1,
VI2, VI3
VMON2 BACK, VO1, VO2, VO3, VI1,
VI2, VI3
PSWD 0 to 9999
PWSL 0 to 9999
VOUT VO1, VO2, VO3 DIS, EN
VIN VI1, VI2, VI3 DIS, EN
This area visible
only if correct
password is entered ETH OFF, 100, 300, 500,
700, 1000, AUTO
DISP HORZ, VERT
Figure 4-2: Card Edge Menu

7700 MultiFrame Manual
7707VB-3-HS-OC48 Triple HD/SDI/ASI/SDTi + Ethernet SONET/SDH Fiber Transceiver
Revision 1.1 7707VB-3-HS-OC48 - 11
4.2.1. STAT Menu
When in monitoring mode, the toggle switch determines what data is being displayed on the alphanumeric
display. Each time the toggle switch is pressed up/down, the display advances to the next/previous
option. The card-edge pushbutton and toggle switch are used to navigate through the display menu.
Figure 4-3 provides a quick reference to the monitoring mode display. The details of the each of the
displays are described in the sections 4.2.1.1 to 4.2.1.12. For information about setting up the module in
control mode (CTRL) see section 4.2.2.
Level 1 Level 2 Level 3 Level 4 Level 5 Level 6
STD OC, STM
PWR -40 to 0 dB
TIME 0 to 899
15M ESL, SESL, ESS, SESS,
ESP, SESP, SEFS 0 to 9999
TIME 0 to 1439
CIC
24H ESL, SESL, ESS, SESS,
ESP, SESP, SEFS 0 to 9999
LIC 15M, 24H
ESL, SESL, ESS, SESS,
ESP, SESP, SEFS 0 to 9999
ESR SECT, LINE, PATH 0.0% - 100%
LOSL 0 to 9999
OUT REF ERR, XO, HOLD,
LINK
FIBR
REF INP LOS, FOS, OK
TDMD LOSS, ERR, OK
STD {HD Standards List} ASI, N270, P270, SDTI-
N270, SDTI-P270, LOSS
EDH PRES, LOSS
VO1
SDTI PRES, LOSS
STD ASI, N270, P270, SDTI-
N270, SDTI-P270, LOSS
EDH PRES, LOSS
VOUT
VO2, VO3
SDTI PRES, LOSS
STD {HD Standards List} ASI, N270, P270, SDTI-
N270, SDTI-P270, LOSS
EDH PRES, LOSS
VI1
SDTI PRES, LOSS
STD ASI, N270, P270, SDTI-
N270, SDTI-P270, LOSS
EDH PRES, LOSS
VINP
VI2, VI3
SDTI PRES, LOSS
LINK UP, DOWN
PORT SPD 10, 100, 1000, DOWN
STAT
ETH FBM OFF, 100, 300, 500,
700, 1000, AUTO
Figure 4-3: STAT Menu Structure

7700 MultiFrame Manual
7707VB-3-HS-OC48 Triple HD/SDI/ASI/SDTi + Ethernet SONET/SDH Fiber Transceiver
7707VB-3-HS-OC48 - 12 Revision 1.1
4.2.1.1. Displaying the Optical Link Data Standard
STAT
FIBR
STD
OC
STM
The STD menu displays the current transmission standard implemented by the
card.
OC is displayed for SONET transmission.
STM is displayed for SDH transmission. These modes can be set through the
control menu, see section 4.2.2.
4.2.1.2. Displaying Optical Power
STAT
FIBR
PWR
-40 to 0 dBm
The 7707VB-3-HS-OC48 can measure and display optical power over a range of
-40 to 0dBm in 1dBm increments.
4.2.1.3. Displaying the Current Interval Counter
STAT
FIBR
CIC
15M, 24H
TIME
ESL
SESL
ESS
SESS
ESP
SESP
SEFS
The Current Interval Counter menu provides the user with an option to monitor
15m or 24h counters to detect errored transmission.
The following parameters are available:
TIME, ESL, SESL, ESS, SESS, ESP, SESP, SEFS
For a detailed description see Table 4-1.
0 to 899
(15H, TIME)
0 to 1439
(24H, TIME)
0 to 9999

7700 MultiFrame Manual
7707VB-3-HS-OC48 Triple HD/SDI/ASI/SDTi + Ethernet SONET/SDH Fiber Transceiver
Revision 1.1 7707VB-3-HS-OC48 - 13
STAT/FIBR/CIC 15M 24H
TIME Displays elapsed time in seconds from 0 to
899 of the 15 minute interval
Displays elapsed time in seconds
from 0 to 1439 of the 24 hour
interval
ESL Current 15 minute interval, errored
seconds line Current 24 hour interval, errored seconds line
SESL Current 15 minute interval, severe errored
seconds line Current 24 hour interval, severe errored seconds line
ESS Current 15 minute interval, errored
seconds section Current 24 hour interval, errored seconds section
SESS Current 15 minute interval, severe errored
seconds section Current 24 hour interval, severe errored seconds section
ESP Current 15 minute interval, errored
seconds path Current 24 hour interval, errored seconds path
SESP Current 15 minute interval, severe errored
seconds path Current 24 hour interval, severe errored seconds path
SEFS Current 15 minute interval, severe errored
seconds frame Current 24 hour interval, severe errored seconds frame
Table 4-1: Current Interval Counter Menu
For detailed information about these parameters, refer to section 4.2.1.4.
4.2.1.4. Displaying the Last Interval Counter
STAT
FIBR
LIC
15m, 24h
ESL
SESL
ESS
SESS
ESP
SESP
SEFS
0 to 9999
Displays the last interval counter for the following parameters:
ESL, SESL, ESS, SESS, ESP, SESP, SEFS
For a detailed description see Table 4-2.

7700 MultiFrame Manual
7707VB-3-HS-OC48 Triple HD/SDI/ASI/SDTi + Ethernet SONET/SDH Fiber Transceiver
7707VB-3-HS-OC48 - 14 Revision 1.1
STAT/LIC 15M 24H
ESL Last 15 minute interval, errored seconds
line Last 24 hour interval, errored seconds line
SESL Last 15 minute interval, severe errored
seconds line Last 24 hour interval, severe errored seconds line
ESS Last 15 minute interval, errored seconds
section Last 24 hour interval, errored seconds section
SESS Last 15 minute interval, severe errored
seconds section Last 24 hour interval, severe errored seconds section
ESP Last 15 minute interval, errored seconds
path Last 24 hour interval, errored seconds path
SESP Last 15 minute interval, severe errored
seconds path Last 24 hour interval, severe errored seconds path
SEFS Last 15 minute interval, severe errored
seconds frame Last 24 hour interval, severe errored seconds frame
Table 4-2: Last Interval Counter Menu
4.2.1.5. Displaying the Errored Seconds Ratio
STAT
FIBR
ESR
SECT
LINE
PATH
0.0% - 100%
Displays the Errored Seconds Ratio in Percentage for Section, Line, and
Path layers from 0.0 to 100%
SECT = Sets the Section Parameter.
LINE = Sets the Line Parameter.
PATH = Sets Path Parameter.
4.2.1.6. Displaying the Loss of Signal seconds in Line Layer
STAT
FIBR
LOSL
0 to 9999
Displays the Loss of Signal seconds in Line Layer.
4.2.1.7. Displaying the Link Output Reference Clock Source
STAT
FIBR
REF
OUT
REF ERR
XO
HOLD
LINK
Displays Link Output Clock Reference Source.
REF ERR = Sets the Reference error.
XO = Indicates the Oscillator.
HOLD = Indicates the Hold Over.
LINK = Indicates the Link Input.

7700 MultiFrame Manual
7707VB-3-HS-OC48 Triple HD/SDI/ASI/SDTi + Ethernet SONET/SDH Fiber Transceiver
Revision 1.1 7707VB-3-HS-OC48 - 15
4.2.1.8. Displaying the Link Input Status
STAT
FIBR
REF
INP
LOS
FOS
OK
Displays Link Input Status.
LOS = Indicates the LINK LOST.
FOS = Indicates the FREQUENCY OFFSET.
OK = Indicates the LINK VALID.
4.2.1.9. Displaying the TDM Data Errors
STAT
TDMD
LOSS
ERR
OK
Displays if there are errors in the clear channel TDM data.
This allows you to monitor if transmission errors are occurring at the SONET
network or at TDM stream.
LOSS = Indicates TDM Data Lost.
ERR = Indicates TDM Error Detected.
OK = Indicates TDM Data is present and no errors are detected.
4.2.1.10. Displaying the Video Standard at Output Ports
STAT
VOUT
VO1, VO2, VO3
STD
{HD Standards List
(VO1 Only)}
ASI
N270
P270
SDTI-N270
SDTI-P270
LOSS
Displays the video standard present at the output ports.
ASI = Indicates DVB-ASI Signal at Output.
N270 = Indicates SMPTE 259M-C, 270 Mb/s 4:2:2 Component 525 line, 4:3
or SMPTE 305M at output.
P270 = Indicates SMPTE 259M-C, 270 Mb/s 4:2:2 Component 625 line, 4:3
SDTI-N270 = Indicates SDTI-N270, component 525 line, SMPTE 305M at
output at 270Mb/s.
SDTI-P270 = Indicates SDTI-P270, component 625 line, SMPTE 305M at
output at 270Mb/s.
LOSS = Loss of Valid Input Signal
4.2.1.11. Detecting the EDH Presence in a Compatible Signal at Output Ports
STAT
VOUT
VO1, VO2, VO3
EDH
PRES
LOSS
Displays video EDH status at the output terminal.
PRES = Indicates EDH Packets present with output signal.
LOSS = Indicates EDH Packets missing from output signal.

7700 MultiFrame Manual
7707VB-3-HS-OC48 Triple HD/SDI/ASI/SDTi + Ethernet SONET/SDH Fiber Transceiver
7707VB-3-HS-OC48 - 16 Revision 1.1
4.2.1.12. Displaying the SDTI Status at Output Ports
STAT
VOUT
VO1, VO2, VO3
SDTI
PRES
LOSS
Displays output video SDTI output status.
4.2.1.13. Displaying the Video Standard at Input Ports
STAT
VINP
VI1, VI2, VI3
STD
{HD Standards
List
(VI1 Only)}
ASI
N270
P270
SDTI-N270
SDTI-P270
LOSS
Displays the video standard present at the input ports.
ASI = Indicates DVB-ASI Signal at Input.
N270 = Indicates SMPTE 259M-C, 270 Mb/s 4:2:2 Component 525 line, 4:3
at input.
P270 = Indicates SMPTE 259M-C, 270 Mb/s 4:2:2 Component 625 line, 4:3
at input.
SDTI-N270 = Indicates SDTI-N270, component 525 line, SMPTE 305M at
input at 270Mb/s.
SDTI-P270 = Indicates SDTI-P270, component 625 line, SMPTE 305M at
input at 270Mb/s.
LOSS = Loss of Valid Input Signal
4.2.1.14. Detecting the EDH Presence in a Compatible Signal at Input Ports
STAT
VINP
VI1, VI2, VI3
EDH
PRES
LOSS
Displays video EDH status at the input terminal.
PRES = Indicates EDH Packets present with the input signal.
LOSS = Indicates EDH Packets missing from the input signal.
