Evocare EV5203R5311 User manual

HOSPITAL OVERBED TABLES
Thank you for purchasing this Evocare Overbed Table. It is strongly
recommended that you read through this user manual prior to using your
Overbed Table for the first time. Your Overbed Table should provide years
of trouble-free use, provided that you adhere to these recommendations.
EV5203R5311
Overbed Tables
EV5203R5311 Deluxe Over bed table (Classic Beech finish) FPY
board with both sides of melamine. (other colours available)
ARTG No: 208845

EV5202 (Crea Base), EV5203 (Grey Base) Pre iu Over bed tables with a
13mm Compact aminate top
Features:
• Two styles of Server Tops are available:
• Server tops approx. 765 x 385 x 19mm, rounded corners of 19mm FPY
board with both sides of melamine
• Server tops approx. 765 x 385 x 13mm made of compact laminate.
• Clearance to the top of the base frame is 90mm, for use under low beds.
• 50mm twin wheel castors, 2 x swivel, 2 locking
• Table Top Dimensions: 765mm x 385mm
• High / ow Adjustment: 715mm to 1145mm
• Safe Working oad (SW ): 10 kg
• Overbed Table Weight: 4 kg
• Spring loaded height adjustment with lever action.
• Single handed height adjustment with lever lock mechanism.
• Painted base, chrome column.
• ARTG No:229804
Standard Top Colours to match Stiegelmeyer Beds
Page 3.
The Evocare Overbed Table’s construction allows for easy cleaning.
Beech Grey Anthracite
Beige Grey indberg Oak

Page 4.
ASSEMBLY
*** DO NOT use if da aged. ***
You are now ready to use your Evocare Overbed Table
Overbed Table Asse bly
1. Position column upside down and insert release
lever. (The release rod inside the column should be
visible in the lower portion of the column. If not
shake the column).
2. The curved side of the of the release lever should
be closest to the top of the table and between the
release rod and the column.
3. Put table top upside down on a flat surface.
4. Hold release lever in column and locate into top
bracket—align holes—install bolts, first through top
bracket, column and release lever, then second
through top bracket and column. Tighten locknuts.
5. Install a bolt through the bolt plate and column—
hand tighten—repeat for other side.
6. Put overbed table on its side to ease pressure
on the bolts—align column and base and tighten
both bolts.
7. Remove the shipping screw (top screw) from the column
and replace with Phillips screw provided.
8. The Overbed Table can now be adjusted to the desired
height.
9. To RAISE the table top, place your hand underneath
the table top and move it upward to the desired
height. Remove hand pressure to set height.
10. To OWER the table top, lift the release lever and
push the table top downward to the desired height.
et go of the release lever to set height.
(The column locks in place when the release lever is released.)

Page 5.
SAFETY:
WARNING: Be sure to read all information and directions before use!!
If you are unable to understand the warnings or instructions contact a therapist or dealer
before using the Overbed Table, otherwise injury or damage may result.
▲ If the Overbed Table is not properly assembled and installed, injury and damage to the
Overbed Table could result.
▲ If components are damaged or missing, contact your dealer immediately. DO NOT use
substitute parts.
▲ WARNING Adjustable overbed tables have a powerful internal spring. Do not
disassemble the table or loosen any screws. Exercise extreme caution when
working near the spring.
▲ Do regularly check frame screws to ensure they are tight.
▲ Regularly check castors roll freely and locks work.
▲ Regular cleaning and inspection is recommended with a damp cloth and mild soapy water
or non-abrasive cleaner.

Page 6.
1. Evocare provides consumers with the following warranty in relation to this roduct, in addition to complying
with the requirements of any relevant legislation, including the Competition and Consumer A ct2010 (Cth) in
Australia and the Consumer Guarantees A ct 1993 in New Zealand (the Acts), except where a New Zealand
consumer acquires the roduct for the purposes of a business.
2. In this warranty, we have used the following definitions:
(a) Form means a warranty claim form issued by Evocare in respect of roducts;
(b) Evocare or our means Evocare Australia ty Limited, ABN 98 078 566 604 of Level 19, 144 Edward Street,
Brisbane 4000;
(c) Products means the goods manufactured for Evocare (including products manufactured by its contract
manufacturers);
(d) Material means a material or component used by Evocare in the manufacture of the roducts;
(e) Retailer means the authorised dealer of roducts from whom the roduct was purchased;
(f) Warranty Period means the warr anty period commencing from the date of purchase of the relevant roduct.
If the roduct or part (as the case may be) is repaired or replaced, there will be no extension to the original
warranty period; and
(g) Workmanship means the handling, assembly and manufacturing processes performed by or on behalf of
Evocare in order to manufacture the roducts.
3. Evocare warrants that for the duration of the Warranty eriod, all roducts will be free of faults arising from
defects in Workmanship or Materials, on the terms and conditions set out in this warranty.
4. Evocare undertakes that if during the Warranty eriod any roduct, or any part of a roduct, has failed to
operate correctly due to faulty Workmanship or defective Material, it will repair or replace the roduct or part
(as the case may be) free of charge provided that the following procedures are met :
(a) The consumer must contact the Retailer or Evocare upon becoming aware of any defect to a roduct upon
which the consumer will be required to complete a Form and provide satisfactory proof of purchase.
(b) Evocare will review the Form to determine whether there is a defect, and if so Evocare agrees to (at its option)
repair, replace or supply equivalent goods, or pay the cost of any of those remedies to the consumer.
(c) If Evocare requests the return of the applicable roduct or part, the consumer will be responsible for the
collection and freight costs of returning that roduct or part to Evocare.
(d) The consumer acknowledges that it is also responsible for the freight costs to deliver any new roduct or
replacement part to it.
5. This warranty is in addition to any non-excludable legal rights or remedies conferred on the consumer under
any applicable Act and any similar laws. To the extent permitted by law, Evocare's liability for any non-
excludable condition or warranty is limited to rectifying any defect at its option, as set out in paragraph 4(b).
6. Subject to the requirements of any applicable Act or legislation and to the extent permitted by law, no liability
(whether expressed or implied) of any nature whatsoever, is accepted by Evocare for any consequential loss,
damage or injury arising as a result of any fault in the roducts.
7. This warranty does not extend to damage to roducts which occurs during transit or transportation, or which is
caused by any abuse, accident or improper installation, connection, use, adjustment or repair or use of goods
otherwise than in accordance with instructions issued by Evocare.
8. The warranty on roducts is waived if any addition or attachment to the roducts do not have Evocare's
approval or are not sold as Evocare products. The roducts are designed to perform specific tasks under
established test loads and unauthorised attachments may produce stresses for which the design is not
appropriate.
9. The following applies to consumers who purchased a relevant roduct in Australia:
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to
a replacement or refund for a ma or failure and compensation for any other reasonably foreseeable loss or
damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable
quality and the failure does not amount to a ma or failure.

Page 7.
WARRANTY
Evocare warrants this Overbed Table, against faulty workmanship, for a period of twelve
months.
NOTE: This does not include staining, accidental damage from misuse and abuse or
neglect or when used for a purpose for which it was not designed.
Evocare must inspect the product within the warranty period for any claims
lodged.
Evocare warranty does not cover product that has been modified from its
original form.
For more information about your Evocare Overbed Table warranty or to order parts call
07 3355 8007.
Manufactured for:
Evocare Australia ty Limited, 260 South ine Road, Enoggera. QLD. 4051.
hone: 07 3355 8000
CLEANING & MAINTENANCE
Regular cleaning and inspection is recommended.
The Overbed Table is maintenance free provided all instructions are followed.
All parts can be cleaned with a damp cloth, warm soapy water or a neutral non-abrasive
cleanser.
E- mail: [e-mail]
Website www.evocare.com.au
