Evolis SOLUTION User manual

Document reference: MU_0011_A_EVOLIS_SOLUTION&VISION_US_ELANCITY
Page 1of 43
Updated on: 03/10/2023
This document is the property of ELANCITY. It cannot be transferred to a third party without prior authorization.
EVOLIS
USER MANUAL
EVOLIS SOLUTION & VISION

Document reference: MU_0011_A_EVOLIS_SOLUTION&VISION_US_ELANCITY
Page 2of 43
Updated on: 03/10/2023
This document is the property of ELANCITY. It cannot be transferred to a third party without prior authorization.
1. SOFTWARE............................................................................................................................................... 4
1.1 EVOCOM/EVOGRAPH .................................................................................................................................. 4
1.1.1 Installation .................................................................................................................................... 4
1.1.2 Presentation of the software ...................................................................................................... 10
1.2 EVOMOBILE ............................................................................................................................................ 10
1.2.1 Installation .................................................................................................................................. 11
1.2.2 Presentation of the software ...................................................................................................... 11
2. CONNECTION TO THE RADAR SPEED SIGN ............................................................................................. 12
2.1 USB CONNECTION VIA EVOCOM ............................................................................................................... 12
2.2 BLUETOOTH CONNECTION VIA EVOCOM ..................................................................................................... 13
2.3 BLUETOOTH CONNECTION VIA EVOMOBILE................................................................................................. 14
3. SPECIFIC PROGRAMMING ..................................................................................................................... 16
3.1 SETTING A SPECIFIC SPEED .......................................................................................................................... 20
3.2 TRICOLOR DISPLAY .................................................................................................................................... 21
3.3 SPY MODE ............................................................................................................................................... 21
3.3.1 Activation of spy mode via Evocom: ........................................................................................... 21
3.3.2 Spy mode activation via EVOMOBILE:......................................................................................... 22
3.4 FLASH MODE ........................................................................................................................................... 23
3.5 TIME SLOTS OR SCHOOL MODE .................................................................................................................... 24
3.6 ALTERNATIVE DISPLAY................................................................................................................................ 25
3.7 AMBER DISPLAY ONLY ................................................................................................................................ 25
4. MODIFICATION OF THE MESSAGES ........................................................................................................ 26
4.1 EDITION OF A MESSAGE.............................................................................................................................. 27
4.2 EDITION OF AN IMAGE MESSAGE .................................................................................................................. 28
5. SUMMARY ............................................................................................................................................. 29
5.1 EVOCOM .............................................................................................................................................. 29
5.2 EVOMOBILE ......................................................................................................................................... 30
6. STATISTIC DATA .................................................................................................................................... 31
6.1 SETTINGS FOR ADVANCED STATISTICS MANAGEMENT FUNCTIONS ....................................................................... 31
6.2 RECOVERY OF STATISTICS DATA.................................................................................................................... 31
6.2.1 Recovery of statistics data via EVOCOM..................................................................................... 31
6.2.2 Recovery of statistics data via EVOMOBILE ................................................................................ 33
6.3 USE OF STATISTICS DATA ............................................................................................................................ 35
6.3.1 Graphics visualization ................................................................................................................. 35
6.3.2 Average speeds ........................................................................................................................... 37
6.3.3 Maximum speeds ........................................................................................................................ 38
6.3.4 Number of vehicles...................................................................................................................... 38
6.3.5 Speed distribution ....................................................................................................................... 39
6.3.6 Percentiles................................................................................................................................... 41
6.4 EVOGRAPH FUNCTIONS........................................................................................................................... 41
6.4.1 Dates selection............................................................................................................................ 41
6.4.2 Printing to a PDF file ................................................................................................................... 42
6.4.3 Export to Excel............................................................................................................................. 42
6.4.4 Modify campaign information .................................................................................................... 42
7. CONNECT OPTION.................................................................................................................................. 43
8. AFTER SALE SERVICE .............................................................................................................................. 43

Document reference: MU_0011_A_EVOLIS_SOLUTION&VISION_US_ELANCITY
Page 3of 43
Updated on: 03/10/2023
This document is the property of ELANCITY. It cannot be transferred to a third party without prior authorization.
Thank you for choosing the EVOLIS radar speed sign.
The sign will encourage drivers to slow down by displaying:
- Their speed,
- A flashing "danger" symbol for excessive speeds (optional),
- 5 (modifiable) messages according to their speed.
The system also records traffic statistics (average speeds, maximum speeds, number of vehicles,
distribution by speed range and percentiles, and data for one or both traffic directions).
Our Evocom/Evograph software is used to set up the system and download the statistics via USB cable
(standard), Bluetooth (standard), Smartphone (Evomobile app) and via an internet connection (Evoweb
system option).
This user manual covers the following models:
Please note that depending on the model, some options may not be available. Not all versions are
available in all countries.
EVOLIS VISION
Displays speed
and messages
EVOLIS VISION
AMBER
Displays speed
and messages Amber
EVOLIS VISION XL
Displays speed
in large size numbers
but no messages

Document reference: MU_0011_A_EVOLIS_SOLUTION&VISION_US_ELANCITY
Page 4of 43
Updated on: 03/10/2023
This document is the property of ELANCITY. It cannot be transferred to a third party without prior authorization.
1. SOFTWARE
1.1 Evocom/Evograph
Our software and user manuals are available on our website www.elancity.net in the "Our services" tab.
Click on the Evocom Evograph link.
1.1.1 Installation
We recommend using Windows 10 or Windows 11 to install the Evocom software. As earlier versions
of Windows are no longer supported by Microsoft, compatibility problems may occur.
Once the software installer has been downloaded, open the Evosetup.exe file.
Please note that you must have administrator rights on your computer.
Please follow the steps below:

Document reference: MU_0011_A_EVOLIS_SOLUTION&VISION_US_ELANCITY
Page 5of 43
Updated on: 03/10/2023
This document is the property of ELANCITY. It cannot be transferred to a third party without prior authorization.
Select your language and click on “OK” to continue.
Click on “Next”
To continue, click on “Next”. If you want to select a different installation location, click on “Browse”.

Document reference: MU_0011_A_EVOLIS_SOLUTION&VISION_US_ELANCITY
Page 6of 43
Updated on: 03/10/2023
This document is the property of ELANCITY. It cannot be transferred to a third party without prior authorization.
Click on “Next” to continue.
If you want to select another location to create shortcuts, click on “Browse”.
Click on “Next” to continue.
If you want to select additional installation shortcut options, click on the desired options then click on
“Next”.
Click on “Install” to continue.

Document reference: MU_0011_A_EVOLIS_SOLUTION&VISION_US_ELANCITY
Page 7of 43
Updated on: 03/10/2023
This document is the property of ELANCITY. It cannot be transferred to a third party without prior authorization.
The software is being installed.
Your software is installed.
Click on “Finish” to continue.
At the end of the installation, the program will automatically start the installation of the USB and
Bluetooth drivers necessary for the communication between your computer and the radar speed sign.
Please follow the steps below:

Document reference: MU_0011_A_EVOLIS_SOLUTION&VISION_US_ELANCITY
Page 8of 43
Updated on: 03/10/2023
This document is the property of ELANCITY. It cannot be transferred to a third party without prior authorization.
Click on “Extract” to continue.
Click on “Next” to continue.
Click on “I accept the terms of this agreement” then on “Next” to continue.
The installation of the drivers is finished. Click on “Finish” to continue.
Once the installation is finished, the Evocom software will start automatically.

Document reference: MU_0011_A_EVOLIS_SOLUTION&VISION_US_ELANCITY
Page 9of 43
Updated on: 03/10/2023
This document is the property of ELANCITY. It cannot be transferred to a third party without prior authorization.
The first time the software is opened, the version history will be displayed.
Uncheck the “Show on startup” box, then click on “OK” if you do not want it to be displayed the next
time you start the software.

Document reference: MU_0011_A_EVOLIS_SOLUTION&VISION_US_ELANCITY
Page 10 of 43
Updated on: 03/10/2023
This document is the property of ELANCITY. It cannot be transferred to a third party without prior authorization.
1.1.2 Presentation of the software
By default, the software presents a summary of the statistics available in your radar speed sign.
Home screen, for the management of your statistics and the connection
to Evomobile.
Set-up of the “SP” position for the dial. See section 3
Set-up of the radar speed sign messages. See section 4
Summary page including all the details of your equipment.
1.2 Evomobile
The app is available from the Google Play Store and the App Store. Search for "EvoMobile" in the search
bar and install the application.
EVOMOBILE - App on Google Play Evomobile in the App Store (apple.com)
Minimum versions required:
•Android 5 (Smartphone)
•iOS 10 (iPad and iPhone)
Please note that the iOS application is only compatible with radar speed signs with
BLE technology, manufactured from 2021

Document reference: MU_0011_A_EVOLIS_SOLUTION&VISION_US_ELANCITY
Page 11 of 43
Updated on: 03/10/2023
This document is the property of ELANCITY. It cannot be transferred to a third party without prior authorization.
1.2.1 Installation
Once the application is downloaded from your store, press on:
You will then be asked for access authorizations. Make sure you accept them all:
1.2.2 Presentation of the software
Reload the radar speed sign’s parameters.
Detect new equipment.
Display the application details.
Statistics: Retrieve the statistics stored in your radar speed sign.
Configuration: Change the name or your radar speed sign, manage the
configurations, delete data, etc.
Simulation: Test the radar speed sign’s active configuration.
Diagnostics: Information on the health of your radar speed sign (battery level,
equipment condition, license update, etc.).
EvoCloud (Option): Synchronize GPRS data.
EvoMap (Option): Locate your radar speed sign on a map.

Document reference: MU_0011_A_EVOLIS_SOLUTION&VISION_US_ELANCITY
Page 12 of 43
Updated on: 03/10/2023
This document is the property of ELANCITY. It cannot be transferred to a third party without prior authorization.
2. CONNECTION TO THE RADAR
SPEED SIGN
2.1 USB connection via EVOCOM
Connect your computer to the radar speed sign via the USB cable provided
Position the speed dial on the speed of your
choice on the SOLUTION model
Press and hold the key to turn.
the radar speed sign “ON” on the VISION model
Start the Evocom program available on your desktop.
Click on “yes”
A window allows you to select your product.
VISION
SOLUTION

Document reference: MU_0011_A_EVOLIS_SOLUTION&VISION_US_ELANCITY
Page 13 of 43
Updated on: 03/10/2023
This document is the property of ELANCITY. It cannot be transferred to a third party without prior authorization.
2.2 Bluetooth connection via EVOCOM
The Solution radar speed sign communicates via Bluetooth directly with your laptop (if equipped with
the integrated module) or via a Bluetooth key (optional item for PC not equipped with the internal
module).
Usually, the transfer takes place in a maximum range of approximately 5 to 10 meters.
Please note, the connection may be disrupted by an athermic windscreen or weather conditions.
On the desktop of your PC, select Bluetooth and click on the icon to
make sure that Bluetooth is activated.
Turn the radar speed sign on and next to your computer.
Start a search for peripheral devices via the menu “Add a
Peripheral”. Your PC will automatically detect all the devices within
its range.
In the list, search for the device you want to connect with.
“ELANCITE_RADAR_V4_XXXX”, “ELAN4-XXXX” or “ELAN5-
XXXX”
Click on “Connect”. EVOCOM will ask you for the Bluetooth
security code when you first connect to your equipment. The
radar speed sign will then be recognized automatically.
If you are asked for a code at this step (Previous versions of radar speed signs), enter the Bluetooth
code indicated in the document delivered with the manual and on the door keys.

Document reference: MU_0011_A_EVOLIS_SOLUTION&VISION_US_ELANCITY
Page 14 of 43
Updated on: 03/10/2023
This document is the property of ELANCITY. It cannot be transferred to a third party without prior authorization.
A message will indicate the operation has been successful.
Start the Evocom program available on your desktop.
Click on “yes”
A window allows you to select your product.
On ELAN4_XXXX and ELAN5_XXXX models you will be asked for the Bluetooth code at this step
during the first connection.
2.3 Bluetooth connection via EVOMOBILE
To connect to the radar speed sign in the best possible conditions, you must be with 10 meters of the
device.
On your Smartphone, click on the application icon:

Document reference: MU_0011_A_EVOLIS_SOLUTION&VISION_US_ELANCITY
Page 15 of 43
Updated on: 03/10/2023
This document is the property of ELANCITY. It cannot be transferred to a third party without prior authorization.
The application will automatically search for available Bluetooth devices.
Your radar speed sign will appear with the name
“ELANCITE_RADAR_V4_XXXX”, “ELAN4-XXXX” or “ELAN5-XXXX”
You will need the 4-digit PIN code delivered with your equipment.
1. Click on your device.
2. Enter the code.
3. Then click on “OK”.
4. The association with your equipment has been completed.
IF YOUR RADAR SPEED SIGN DOES NOT APPEAR IN THE LIST, MAKE SURE
THAT BLUETOOTH IS ACTIVATED ON YOUR SMARTPHONE

Document reference: MU_0011_A_EVOLIS_SOLUTION&VISION_US_ELANCITY
Page 16 of 43
Updated on: 03/10/2023
This document is the property of ELANCITY. It cannot be transferred to a third party without prior authorization.
3. SPECIFIC PROGRAMMING
Specific programming allows you to modify the different parameters of your radar speed sign if you wish
a set-up other than the one proposed on the pre-programmed positions.
The option to activate “spy” mode is only available with the EVOMOBILE
application. A computer with the EVOCOM software must be used for any
other modifications.
Reminder of the pre-programmed speed positions:
EVOLIS SOLUTION:
Speed limit
selector
Description Minimum speed
triggering the display
Speed triggering a
color change
Speed triggering
flashing numbers
Visual
20 mph 9 mph 21 mph 26 mph
30 mph
9 mph
31 mph 36 mph
50 mph
9 mph
51 mph 56 mph
60 mph
9 mph
61 mph 66 mph
70 mph
9 mph
71 mph 76 mph
SP / 30 mph
9 mph
31 mph 36 mph
The “SP” positions correspond to the factory settings for the 30-mph zone
The speed selection dial or the speed limit selector must be set to “SP” to be able to program the different
specific configuration modes defined below.

Document reference: MU_0011_A_EVOLIS_SOLUTION&VISION_US_ELANCITY
Page 17 of 43
Updated on: 03/10/2023
This document is the property of ELANCITY. It cannot be transferred to a third party without prior authorization.
Evolis Vision pre-programmed settings
Speed
limit
selector
Description
Minimum
speed
triggering the
display
Speed
triggering a
color change
Speed triggering
flashing
numbers
Visual
20 mph 9 mph
21 mph
26 mph
25 mph
9 mph
26 mph
31 mph
30 mph
9 mph
31 mph
36 mph
35 mph
9 mph
36 mph
41 mph
40 mph
9 mph
41 mph
46 mph
45 mph
9 mph
46 mph
51 mph
50 mph
9 mph
51 mph
56 mph
55 mph
9 mph
56 mph
61 mph
60 mph
9 mph
61 mph
66 mph
SP / 65 mph
9 mph
65 mph
71 mph
The “SP” positions correspond to the factory settings for the 65-mph zone
* Text display not available on Mobility and Vision XL models
To change these settings, please refer to the Evocom software user manual.

Document reference: MU_0011_A_EVOLIS_SOLUTION&VISION_US_ELANCITY
Page 18 of 43
Updated on: 03/10/2023
This document is the property of ELANCITY. It cannot be transferred to a third party without prior authorization.
Evolis Vision AMBER pre-programmed settings
Speed
limit
selector
Description
Minimum speed
triggering the
display
Maximum speed
displayed
Speed triggering
flashing numbers
Visual
20 mph 9 mph
21 mph
21 mph
25 mph
9 mph
26 mph
26 mph
30 mph
9 mph
31 mph
31 mph
35 mph
9 mph
36 mph
36 mph
40 mph
9 mph
41 mph
41 mph
45 mph
9 mph
46 mph
46 mph
50 mph
9 mph
51 mph
51 mph
55 mph
9 mph
56 mph
56 mph
60 mph
9 mph
61 mph
61 mph
SP / 65 mph
9 mph
66 mph
66 mph
The “SP” positions correspond to the factory settings for the 65-mph zone
* Text display not available on Mobility and Vision XL models
To change these settings, please refer to the Evocom software user manual.

Document reference: MU_0011_A_EVOLIS_SOLUTION&VISION_US_ELANCITY
Page 19 of 43
Updated on: 03/10/2023
This document is the property of ELANCITY. It cannot be transferred to a third party without prior authorization.
Evolis Vision XL pre-programmed settings
Speed
limit
selector
Description
Minimum speed
triggering the
display
Maximum speed
displayed
Speed triggering
flashing numbers
Visual
25 mph
9 mph
26 mph
26 mph
30 mph
9 mph
31 mph
31 mph
35 mph
9 mph
36 mph
36 mph
40 mph
9 mph
41 mph
41 mph
45 mph
9 mph
46 mph
46 mph
50 mph
9 mph
51 mph
51 mph
55 mph
9 mph
56 mph
56 mph
60 mph
9 mph
61 mph
61 mph
65 mph
9 mph
66 mph
66 mph
SP / 70 mph
9 mph
71 mph
71 mph
The “SP” positions correspond to the factory settings for the 70-mph zone
* Text display not available on Mobility and Vision XL models
To change these settings, please refer to the Evocom software user manual.

Document reference: MU_0011_A_EVOLIS_SOLUTION&VISION_US_ELANCITY
Page 20 of 43
Updated on: 03/10/2023
This document is the property of ELANCITY. It cannot be transferred to a third party without prior authorization.
3.1 Setting a specific speed
Once connected to the radar speed sign via EVOCOM, click on the Settings tab
1. Change the name of the radar speed
sign.
2. Change the different thresholds to
change the speed color.
3. Activate the different specific modes,
see below.
4. Change the different thresholds to
display messages.
1. Threshold from which the radar
speed sign displays a message.
2. Threshold to change the speed
display to red.
3. Threshold to trigger flashing of the
speed display.
4. Threshold to display “DANGER” (anti-
race mode)
Settings to trigger the messages display.
In this example, message 1 is triggered from 13 mph, until message 2 is triggered from 19 mph
Once the settings are changed, click on the button to load the settings in the radar speed sign.
