EWM Pico 220 cel puls vrd User manual

Operating instructions
EN
Welding machine
Pico 220 cel puls
Pico 220 cel puls vrd (AUS)
Pico 220 cel puls vrd (RU)
099-002057-EW501
Observe additional system documents!
8.02.2023

General instructions
WARNING
Read the operating instructions!
The operating instructions provide an introduction to the safe use of the products.
• Read and observe the operating instructions for all system components, especially the sa-
fety instructions and warning notices!
• Observe the accident prevention regulations and any regional regulations!
• The operating instructions must be kept at the location where the machine is operated.
• Safety and warning labels on the machine indicate any possible risks.
Keep these labels clean and legible at all times.
• The machine has been constructed to state-of-the-art standards in line with any applicable
regulations and industrial standards. Only trained personnel may operate, service and re-
pair the machine.
• Technical changes due to further development in machine technology may lead to a dif-
fering welding behaviour.
In the event of queries on installation, commissioning, operation or special conditions at the
installation site, or on usage, please contact your sales partner or our customer service
department on [phone].
A list of authorised sales partners can be found at www.ewm-group.com/en/specialist-dealers.
Liability relating to the operation of this equipment is restricted solely to the function of the equipment. No
other form of liability, regardless of type, shall be accepted. This exclusion of liability shall be deemed ac-
cepted by the user on commissioning the equipment.
The manufacturer is unable to monitor whether or not these instructions or the conditions and methods
are observed during installation, operation, usage and maintenance of the equipment.
An incorrectly performed installation can result in material damage and injure persons as a result. For this
reason, we do not accept any responsibility or liability for losses, damages or costs arising from incorrect
installation, improper operation or incorrect usage and maintenance or any actions connected to this in
any way.
© EWM AG
Dr. Günter-Henle-Strasse 8
56271 Mündersbach Germany
Tel.: [phone], Fax: -244
Email: [email protected]
www.ewm-group.com
The copyright to this document remains the property of the manufacturer.
Copying, including extracts, only permitted with written approval.
The content of this document has been prepared and reviewed with all reasonable care. The information
provided is subject to change; errors excepted.
Data security
The user is responsible for backing up data of all changes from the factory setting. The user is liable for
erased personal settings. The manufacturer does not assume any liability for this.

Contents
Notes on using these operating instructions
099-002057-EW501
8.02.2023
3

Contents
Notes on using these operating instructions
4
099-002057-EW501
8.02.2023
1 Contents
1Contents .......................................................................................................................................... 4
2For your safety................................................................................................................................ 6
2.1 Notes on using these operating instructions .......................................................................... 6
2.2 Explanation of icons ............................................................................................................... 6
2.3 Safety instructions .................................................................................................................. 7
2.4 Transport and installation ..................................................................................................... 11
3Intended use ................................................................................................................................. 13
3.1 Applications .......................................................................................................................... 13
3.2 Software version .................................................................................................................. 13
3.3 Documents which also apply ............................................................................................... 13
3.3.1 Warranty ............................................................................................................... 13
3.3.2 Declaration of Conformity ..................................................................................... 13
3.3.3 Welding in environments with increased electrical hazards ................................. 13
3.3.4 Service documents (spare parts and circuit diagrams) ........................................ 13
3.3.5 Calibration/Validation ............................................................................................ 13
3.3.6 Part of the complete documentation ..................................................................... 14
4Machine description – quick overview ....................................................................................... 15
4.1 Front view ............................................................................................................................. 15
4.2 Rear view ............................................................................................................................. 16
4.3 Machine control – Operating elements ................................................................................ 17
5Design and function ..................................................................................................................... 18
5.1 Transport and installation ..................................................................................................... 18
5.1.1 Machine cooling .................................................................................................... 18
5.1.2 Workpiece lead, general ....................................................................................... 18
5.1.3 Ambient conditions ............................................................................................... 18
5.1.4 Transport belt ........................................................................................................ 19
5.1.4.1 Adjusting the length of the carrying strap .............................................. 19
5.1.5 Notes on the installation of welding current leads ................................................ 19
5.1.6 Stray welding currents .......................................................................................... 19
5.1.7 Mains connection .................................................................................................. 20
5.1.7.1 Mains configuration ............................................................................... 21
5.2 MMA welding ........................................................................................................................ 21
5.2.1 Connecting the electrode holder and workpiece lead .......................................... 21
5.2.2 Welding task selection .......................................................................................... 23
5.2.3 Hotstart ................................................................................................................. 24
5.2.4 Arcforce................................................................................................................. 24
5.2.5 Antistick................................................................................................................. 24
5.2.6 Average value pulse welding ................................................................................ 25
5.2.7 Expert menu (MMA) .............................................................................................. 26
5.3 TIG welding .......................................................................................................................... 26
5.3.1 Shielding gas supply (shielding gas cylinder for welding machine) ..................... 26
5.3.1.1 Connecting the shielding gas supply ..................................................... 27
5.3.2 Connecting a TIG welding torch with rotating gas valve ...................................... 28
5.3.3 Welding task selection .......................................................................................... 28
5.3.4 Arc ignition ............................................................................................................ 29
5.3.4.1 Liftarc ..................................................................................................... 29
5.3.5 Average value pulse welding ................................................................................ 29
5.3.6 Expert menu (TIG) ................................................................................................ 30
5.4 Dirt filter ................................................................................................................................ 31
5.5 Remote control ..................................................................................................................... 31
5.5.1 RT1 19POL ........................................................................................................... 31
5.5.2 RTG1 19POL ........................................................................................................ 32
5.5.3 RTF1 19POL ......................................................................................................... 32
5.6 Power-saving mode (Standby) ............................................................................................. 32
5.7 Arc length restriction (USP).................................................................................................. 32
5.8 Voltage reducing device ....................................................................................................... 32
5.9 Machine configuration menu ................................................................................................ 33

Contents
Notes on using these operating instructions
099-002057-EW501
8.02.2023
5
6Maintenance, care and disposal ................................................................................................. 34
6.1 General ................................................................................................................................ 34
6.1.1 Cleaning ............................................................................................................... 34
6.1.2 Dirt filter ................................................................................................................ 34
6.2 Maintenance work, intervals ................................................................................................ 35
6.2.1 Daily maintenance tasks ...................................................................................... 35
6.2.2 Monthly maintenance tasks .................................................................................. 35
6.2.3 Annual test (inspection and testing during operation) .......................................... 35
6.3 Disposing of equipment ....................................................................................................... 36
7Rectifying faults ........................................................................................................................... 37
7.1 Checklist for rectifying faults ................................................................................................ 37
7.2 Error messages (power source) .......................................................................................... 37
7.3 Software version of the machine control ............................................................................. 38
7.4 Resetting welding parameters to the factory settings .......................................................... 39
8Technical data .............................................................................................................................. 40
8.1 Pico 220 cel puls .................................................................................................................. 40
8.2 Pico 220 cel puls (AUS/RU) ................................................................................................. 41
9Accessories .................................................................................................................................. 42
9.1 Transport system ................................................................................................................. 42
9.2 19-pole remote control ......................................................................................................... 42
9.2.1 Connection cables ................................................................................................ 42
9.2.2 Extension cable .................................................................................................... 42
9.3 Options ................................................................................................................................. 42
9.4 General accessories ............................................................................................................ 42
10 Appendix ....................................................................................................................................... 43
10.1 Parameter overview ............................................................................................................. 43
10.1.1 MMA welding ........................................................................................................ 43
10.1.2 TIG welding .......................................................................................................... 43
10.1.3 Basic parameters (independent of process) ........................................................ 44
10.2 Searching for a dealer ......................................................................................................... 45

For your safety
Notes on using these operating instructions
6
099-002057-EW501
8.02.2023
2 For your safety
2.1 Notes on using these operating instructions
DANGER
Working or operating procedures which must be closely observed to prevent imminent
serious and even fatal injuries.
• Safety notes include the "DANGER" keyword in the heading with a general warning symbol.
• The hazard is also highlighted using a symbol on the edge of the page.
WARNING
Working or operating procedures which must be closely observed to prevent serious
and even fatal injuries.
• Safety notes include the "WARNING" keyword in the heading with a general warning sym-
bol.
• The hazard is also highlighted using a symbol in the page margin.
CAUTION
Working or operating procedures which must be closely observed to prevent possible
minor personal injury.
• The safety information includes the "CAUTION" keyword in its heading with a general warn-
ing symbol.
• The risk is explained using a symbol on the edge of the page.
Technical aspects which the user must observe to avoid material or equipment damage.
Instructions and lists detailing step-by-step actions for given situations can be recognised via bullet
points, e.g.:
• Insert the welding current lead socket into the relevant socket and lock.
2.2 Explanation of icons

For your safety
Safety instructions
099-002057-EW501
8.02.2023
7
Symbol
Description
Symbol
Description
Indicates technical aspects which the
user must observe.
Activate and release / Tap / Tip
Switch off machine
Release
Switch on machine
Press and hold
Incorrect / Invalid
Switch
Correct / Valid
Turn
Input
Numerical value – adjustable
Navigation
Signal light lights up in green
Output
Signal light flashes green
Time representation (e.g.: wait 4 s / ac-
tuate)
Signal light lights up in red
Interruption in the menu display (other
setting options possible)
Signal light flashes red
Tool not required/do not use
Signal light lights up in blue
Tool required/use
Signal light flashes blue
2.3 Safety instructions

For your safety
Safety instructions
8
099-002057-EW501
8.02.2023
WARNING
Risk of accidents due to non-compliance with the safety instructions!
Non-compliance with the safety instructions can be fatal!
• Carefully read the safety instructions in this manual!
• Observe the accident prevention regulations and any regional regulations!
• Inform persons in the working area that they must comply with the regulations!
Risk of injury from electrical voltage!
Voltages can cause potentially fatal electric shocks and burns on contact. Even low vol-
tages can cause a shock and lead to accidents.
• Never touch live components such as welding current sockets or stick, tungsten or wire
electrodes!
• Always place torches and electrode holders on an insulated surface!
• Wear the full personal protective equipment (depending on the application)!
• The machine may only be opened by qualified personnel!
• The device must not be used to defrost pipes!
Hazard when interconnecting multiple power sources!
If a number of power sources are to be connected in parallel or in series, only a techni-
cal specialist may interconnect the sources as per standard IEC 60974-9:2010: Installa-
tion and use and German Accident Prevention Regulation BVG D1 (formerly VBG 15) or
country-specific regulations.
Before commencing arc welding, a test must verify that the equipment cannot exceed
the maximum permitted open circuit voltage.
• Only qualified personnel may connect the machine.
• When taking individual power sources out of operation, all mains and welding current leads
must be safely disconnected from the welding system as a whole. (Hazard due to reverse
polarity voltage!)
• Do not interconnect welding machines with pole reversing switch (PWS series) or machines
for AC welding since a minor error in operation can cause the welding voltages to be com-
bined, which is not permitted.
Risk of injury due to radiation or heat!
Arc radiation can lead to skin and eye injuries.
Contact with hot workpieces and sparks can lead to burns.
• Use hand shield or welding helmet with the appropriate safety level (depends on the appli-
cation).
• Wear dry protective clothing (e.g. hand shield, gloves, etc.) in accordance with
the applicable regulations of your country.
• Persons who are not directly involved should be protected with a welding curtain or suitable
safety screen against radiation and the risk of blinding!

For your safety
Safety instructions
099-002057-EW501
8.02.2023
9
WARNING
Risk of injury due to improper clothing!
During arc welding, radiation, heat and voltage are sources of risk that cannot be
avoided. The user has to be equipped with the complete personal protective equipment
at all times. The protective equipment has to include:
• Respiratory protection against hazardous substances and mixtures (fumes and vapours);
otherwise implement suitable measures such as extraction facilities.
• Welding helmet with proper protection against ionizing radiation (IR and UV radiation) and
heat.
• Dry welding clothing (shoes, gloves and body protection) to protect against warm environ-
ments with conditions comparable to ambient temperatures of 100 °C or higher and arcing
and work on live components.
• Hearing protection against harming noise.
Explosion risk!
Apparently harmless substances in closed containers may generate excessive pressure
when heated.
• Move containers with inflammable or explosive liquids away from the working area!
• Never heat explosive liquids, dusts or gases by welding or cutting!
Fire hazard!
Due to the high temperatures, sparks, glowing parts and hot slag that occur during
welding, there is a risk of flames.
• Be watchful of potential sources of fire in the working area!
• Do not carry any easily inflammable objects, e.g. matches or lighters.
• Ensure suitable fire extinguishers are available in the working area!
• Thoroughly remove any residue of flammable materials from the workpiece prior to starting
to weld.
• Only further process workpieces after they have cooled down. Do not allow them to contact
any flammable materials!

For your safety
Safety instructions
10
099-002057-EW501
8.02.2023
CAUTION
Smoke and gases!
Smoke and gases may lead to shortness of breath and poisoning! The ultraviolet radia-
tion of the arc may also convert solvent vapours (chlorinated hydrocarbon) into poiso-
nous phosgene.
• Ensure sufficient fresh air!
• Keep solvent vapours away from the arc beam field!
• Wear suitable respiratory protection if necessary!
• To prevent the formation of phosgene, residues of chlorinated solvents on workpieces must
first be neutralised using appropriate measures.
Noise exposure!
Noise exceeding 70 dBA can cause permanent hearing damage!
• Wear suitable ear protection!
• Persons located within the working area must wear suitable ear protection!
According to IEC 60974-10, welding machines are divided into two classes of
electromagnetic compatibility (the EMC class can be found in the Technical
data) > see 8 chapter:
Class A machines are not intended for use in residential areas where the power supply comes
from the low-voltage public mains network. When ensuring the electromagnetic compatibility of
class A machines, difficulties can arise in these areas due to interference not only in the supply
lines but also in the form of radiated interference.
Class B machines fulfil the EMC requirements in industrial as well as residential areas, inclu-
ding residential areas connected to the low-voltage public mains network.
Setting up and operating
When operating arc welding systems, in some cases, electro-magnetic interference can occur
although all of the welding machines comply with the emission limits specified in the standard.
The user is responsible for any interference caused by welding.
In order to evaluate any possible problems with electromagnetic compatibility in the
surrounding area, the user must consider the following: (see also EN 60974-10 Appendix A)
• Mains, control, signal and telecommunication lines
• Radios and televisions
• Computers and other control systems
• Safety equipment
• The health of neighbouring persons, especially if they have a pacemaker or wear a hearing
aid
• Calibration and measuring equipment
• The immunity to interference of other equipment in the surrounding area
• The time of day at which the welding work must be carried out
Recommendations for reducing interference emission
• Mains connection, e.g. additional mains filter or shielding with a metal tube
• Maintenance of the arc welding system
• Welding leads should be as short as possible and run closely together along the ground
• Potential equalization
• Earthing of the workpiece. In cases where it is not possible to earth the workpiece directly,
it should be connected by means of suitable capacitors.
• Shielding from other equipment in the surrounding area or the entire welding system
Electromagnetic fields!
The power source can create electrical or electromagnetic fields that may impair the
function of electronic systems such as EDP and CNC devices, telecommunication,
power and signal lines as well as pacemakers and defibrillators.
• Follow the maintenance instructions > see 6.2 chapter!
• Unwind the welding leads completely!
• Shield radiation-sensitive equipment or facilities appropriately!
• The function of pacemakers may be impaired (seek medical advice if necessary).

For your safety
Transport and installation
099-002057-EW501
8.02.2023
11
CAUTION
Obligations of the operator!
The respective national directives and laws must be complied with when operating the
machine!
• Implementation of national legislation relating to framework directive 89/391/EEC on the int-
roduction of measures to encourage improvements in the safety and health of workers at
work and associated individual guidelines.
• In particular, directive 89/655/EEC concerning the minimum safety and health requirements
for the use of work equipment by workers at work.
• The regulations applicable to occupational safety and accident prevention in the country
concerned.
• Setting up and operating the machine as per IEC 60974.-9.
• Brief the user on safety-conscious work practices on a regular basis.
• Regularly inspect the machine as per IEC 60974.-4.
The manufacturer's warranty becomes void if non-genuine parts are used!
• Only use system components and options (power sources, welding torches, electrode hold-
ers, remote controls, spare parts and replacement parts, etc.) from our range of products!
• Only insert and lock accessory components into the relevant connection socket when the ma-
chine is switched off.
Requirements for connection to the public mains network
High-performance machines can influence the mains quality by taking current from the mains
network. For some types of machines, connection restrictions or requirements relating to the
maximum possible line impedance or the necessary minimum supply capacity at the interface
with the public network (Point of Common Coupling, PCC) can therefore apply. In this respect,
attention is also drawn to the machines' technical data. In this case, it is the responsibility of the
operator, where necessary in consultation with the mains network operator, to ensure that the
machine can be connected.
2.4 Transport and installation
WARNING
Risk of injury due to improper handling of shielding gas cylinders!
Improper handling and insufficient securing of shielding gas cylinders can cause seri-
ous injuries!
• Observe the instructions from the gas manufacturer and any relevant regulations concern-
ing the use of compressed air!
• Do not attach any element to the shielding gas cylinder valve!
• Prevent the shielding gas cylinder from heating up.

For your safety
Transport and installation
12
099-002057-EW501
8.02.2023
CAUTION
Risk of accidents due to supply lines!
During transport, attached supply lines (mains leads, control cables, etc.) can cause
risks, e.g. by causing connected machines to tip over and injure persons!
• Disconnect all supply lines before transport!
Risk of tipping!
There is a risk of the machine tipping over and injuring persons or being damaged itself
during movement and set up. Tilt resistance is guaranteed up to an angle of 10° (ac-
cording to IEC 60974-1).
• Set up and transport the machine on level, solid ground.
• Secure add-on parts using suitable equipment.
Risk of accidents due to incorrectly installed leads!
Incorrectly installed leads (mains, control and welding leads or intermediate hose pack-
ages ) can present a tripping hazard.
• Lay the supply lines flat on the floor (avoid loops).
• Avoid laying the leads on passage ways.
Risk of injury from heated coolant and its connections!
The coolant used and its connection or connection points can heat up significantly
during operation (water-cooled version). When opening the coolant circuit, escaping
coolant may cause scalding.
• Open the coolant circuit only when the power source or cooling unit is switched off!
• Wear proper protective equipment (protective gloves)!
• Seal open connections of the hose leads with suitable plugs.
The units are designed for operation in an upright position!
Operation in non-permissible positions can cause equipment damage.
• Only transport and operate in an upright position!
Accessory components and the power source itself can be damaged by incorrect connection!
• Only insert and lock accessory components into the relevant connection socket when the
machine is switched off.
• Comprehensive descriptions can be found in the operating instructions for the relevant ac-
cessory components.
• Accessory components are detected automatically after the power source is switched on.
Protective dust caps protect the connection sockets and therefore the machine against dirt and
damage.
• The protective dust cap must be fitted if there is no accessory component being operated on
that connection.
• The cap must be replaced if faulty or if lost!

Intended use
Applications
099-002057-EW501
8.02.2023
13
3 Intended use
WARNING
Hazards due to improper usage!
The machine has been constructed to the state of the art and any regulations and stand-
ards applicable for use in industry and trade. It may only be used for the welding proce-
dures indicated at the rating plate. Hazards may arise for persons, animals and material
objects if the equipment is not used correctly. No liability is accepted for any damages
arising from improper usage!
• The equipment must only be used in line with its designated purpose and by trained or
expert personnel!
• Do not improperly modify or convert the equipment!
3.1 Applications
Arc welding machine for MMA DC welding with TIG DC welding with lift arc (touch starting) as secondary
process.
3.2 Software version
The software version of the machine control can be displayed in the machine configuration menu
(menu Srv) > see 5.9 chapter.
3.3 Documents which also apply
3.3.1 Warranty
For more information refer to the "Warranty registration" brochure supplied and our information regarding
warranty, maintenance and testing at www.ewm-group.com!
3.3.2 Declaration of Conformity
This product corresponds in its design and construction to the EU directives listed in the decla-
ration. The product comes with a relevant declaration of conformity in the original.
The manufacturer recommends carrying out the safety inspection according to national and in-
ternational standards and guidelines every 12 months (from commissioning).
3.3.3 Welding in environments with increased electrical hazards
Power sources with this marking can be used for welding in an environment with increased
electrical hazard (e.g. boilers). For this purpose, appropriate national or international regulations
must be followed. The power source must not be placed in the danger zone!
3.3.4 Service documents (spare parts and circuit diagrams)
WARNING
No improper repairs and modifications!
To prevent injuries and damage to the machine, only competent personnel (authorised
service personnel) are allowed to repair or modify the machine.
Unauthorised manipulations will invalidate the warranty!
• Instruct competent personnel (authorised service personnel) to repair the machine.
Original copies of the circuit diagrams are enclosed with the unit.
Spare parts can be obtained from the relevant authorised dealer.
3.3.5 Calibration/Validation
An original certificate is enclosed with the product. The manufacturer recommends calibration / validation
at intervals of 12 months (from commissioning).

Intended use
Documents which also apply
14
099-002057-EW501
8.02.2023
3.3.6 Part of the complete documentation
This document is part of the complete documentation and valid only in combination with all other
parts of these instructions! Read and observe the operating instructions for all system
components, especially the safety instructions!
The illustration shows a general example of a welding system.
Figure 3-1
Item
Documentation
A.1
Power source
A.2
Remote control
A.3
Welding torch
A
Complete documentation

Machine description – quick overview
Front view
099-002057-EW501
8.02.2023
15
4 Machine description – quick overview
4.1 Front view
Figure 4-1
Item
Symbol
Description 0
1
Carrying strap > see 5.1.4.1 chapter
2
Machine control > see 4.3 chapter
3
Connection socket, "+" welding current
• MMA: Electrode holder or workpiece lead connection
• TIG: Connection for workpiece lead
4
Cooling air outlet
5
Machine feet
6
Connection socket, 19-pole
Remote control connection
7
Connection socket, "-" welding current
• TIG: Welding current lead connection for TIG welding torch
• MMA: Electrode holder or workpiece lead connection

Machine description – quick overview
Rear view
16
099-002057-EW501
8.02.2023
4.2 Rear view
Figure 4-2
Item
Symbol
Description 0
1
Mains connection cable > see 5.1.7 chapter
2
Cooling air inlet
3
Main Switch
Switching the machine on or off.

Machine description – quick overview
Machine control – Operating elements
099-002057-EW501
8.02.2023
17
4.3 Machine control – Operating elements
Figure 4-3
Item
Symbol
Description 0
1
Display, 3-digit
2
Collective interference signal light
For error messages, > see 7.2 chapter
3
Excess temperature signal light
In case of excess temperature, temperature monitors de-activate the power unit, and
the excess temperature control lamp comes on. Once the machine has cooled down,
welding can continue without any further measures.
4
VRD
Voltage reduction device (VRD) signal light > see 5.8 chapter
5
AMP%
Hotstart current signal light
6
Welding parameter setting rotary transducer
Setting of welding current and other welding parameter and their values
7
sec
Hotstart time signal light
8
Select welding parameters button
This button is used to select the welding parameters depending on the welding process
and operating mode used.
9
Pulse welding (average value pulses) signal light > see 5.2.6 chapter
On: ------- Function switched on
Not on: -- Function switched off
Flashing: Parameter selection and frequency setting :
10
AMP
Main current signal light
Imin to Imax (1 A increments)
11
Welding procedure/power-saving mode push-button
--------- Selection of MMA welding procedure/electrode type setting
Signal light
R RB
illuminated in green = electrode type rutile
Signal light
R RB
illuminated in red = electrode type rutile basic
Signal light
RC
B C
illuminated in green = electrode type basic/rutile cellulose
Signal light
RC
B C
illuminated in red = electrode type cellulose
---------- Selection of TIG welding procedure
Press for 2 s to put the machine into power-saving mode. To reactivate, activate one of
the operating elements > see 5.6 chapter.

Design and function
Transport and installation
18
099-002057-EW501
8.02.2023
5 Design and function
5.1 Transport and installation
WARNING
Risk of accident due to improper transport of machines that must not be lifted!
Do not lift or suspend the machine! The machine can drop and cause injuries! The
handles, straps or brackets are suitable for transport by hand only!
• The machine must not be suspended or lifted using a crane.
5.1.1 Machine cooling
Insufficient ventilation results in a reduction in performance and equipment damage.
• Observe the ambient conditions!
• Keep the cooling air inlet and outlet clear!
• Observe the minimum distance of 0.5 m from obstacles!
5.1.2 Workpiece lead, general
CAUTION
Risk of burning due to incorrect welding current connection!
If the welding current plugs (machine connections) are not locked or if the workpiece
connection is contaminated (paint, corrosion), these connections and leads can heat up
and cause burns when touched!
• Check welding current connections on a daily basis and lock by turning to the right when
necessary.
• Clean workpiece connection thoroughly and secure properly. Do not use structural parts of
the workpiece as welding current return lead!
5.1.3 Ambient conditions
The machine must not be operated in the open air and must only be set up and operated on a
suitable, stable and level base!
• The operator must ensure that the ground is non-slip and level, and provide sufficient lighting
for the place of work.
• Safe operation of the machine must be guaranteed at all times.
Equipment damage due to contamination!
Unusually high amounts of dust, acids, corrosive gases or substances can damage the machine
(observe maintenance intervals > see 6.2 chapter).
• Avoid large amounts of smoke, steam, oily fumes, grinding dust and corrosive ambient air!
In operation
Temperature range of the ambient air:
• -25 °C to +40 °C (-13 °F to 104 °F)
Relative humidity:
• up to 50 % at 40 °C (104 °F)
• up to 90 % at 20 °C (68 °F)
Transport and storage
Storage in a closed room, temperature range of the ambient air:
• -30 °C to +70 °C (-22 °F to 158 °F)
Relative humidity
• up to 90 % at 20 °C (68 °F)

Design and function
Transport and installation
099-002057-EW501
8.02.2023
19
5.1.4 Transport belt
5.1.4.1 Adjusting the length of the carrying strap
To demonstrate adjustment, lengthening the strap is shown in the figure. To shorten, the strap's
loops must be inched in the opposite direction.
Figure 5-1
5.1.5 Notes on the installation of welding current leads
• Use an individual welding lead to the workpiece for each welding machine!
Figure 5-2
• Fully unroll welding current leads, torch hose packages and intermediate hose packages. Avoid loops!
• Always keep leads as short as possible!
Lay any excess cable lengths in meanders.
Figure 5-3
5.1.6 Stray welding currents

Design and function
Transport and installation
20
099-002057-EW501
8.02.2023
WARNING
Risk of injury due to stray welding currents!
Stray welding currents can destroy protective earth conductors, damage machines and
electronic devices and cause overheating of components, leading to fire.
• Check that all welding current connections are firmly secured and electrical connections are
in perfect condition.
• Set up, attach or suspend all conductive power source components such as casing, trans-
port vehicles and crane frames so they are insulated.
• Do not place any other electronic devices such as drills or angle grinders on the power
source, transport vehicle or crane frames unless they are insulated.
• Always put welding torches and electrode holders on an insulated surface when they are
not in use.
Figure 5-4
5.1.7 Mains connection
