eWON FLX3101 User manual

support.ewon.biz
eWON Flexy
Single Ethernet Ext. Card
FLX3 0
This installation guide explains how to install the
eWON Flexy Single Ethernet Extension Card FLX 3101
Installation Guide
IG 017 / Rev 1 2

Table of Contents
. Product Summary ............................................................................................................. 3
2. Safety, Environmental & Regulatory Information ........................................................... 4
2 1 Scope 4
2 2 ESD Damage Prevention 4
2 3 Applicable Directives, Standards and Compliance 4
2 3 1 Applicable European Directives 4
2 3 2 Applicable Safety Standards 4
2 3 3 FCC Compliance 5
2 3 4 Certifications 5
3. Hardware Description ...................................................................................................... 6
3 1 Mechanical Layout and Interfaces 6
3 2 Extension Card Label 7
3 2 1 Label Location and Information Included 7
3 2 2 Part Number Structure for Extension Cards 8
3 3 Front Panel LEDs 8
3 4 Ethernet Port Specifications 9
3 5 eWON Flexy Extension Cards Environmental Conditions 9
3 6 Plugging the Extension Card into the Base Unit 9
3 6 1 Base Unit Slot Compatibility 9
3 6 2 Extension Card Insertion 10
3 6 3 Multiple Ethernet Extension Cards 11
3 6 4 Power Requirements 12
4. Powering On the Base Unit with its Extension Cards .................................................... 3
5. Check Card Detection on the Embedded Web Page ................................................ 4
5 1 Connecting to the Embedded Web Server 14
5 2 Detected Cards Displayed in the System Page 14
Revision .............................................................................................................................. 5
Revision History 15
Page 2 / 15 eWON Flexy Single Ethernet Ext Card FLX3101 | IG 017

Chapter
Product Summary
. Product Summary
The present Installation Guide describes the hardware of the Single Ethernet Extension Card
FLX 3101 of the eWON Flexy family
The eWON Flexy family is a range of modular industrial gateway/router
As the name eWON Flexy suggests, it has been designed to enable numerous different
combinations of Extension Cards and Base Units The present Installation Guide is focusing on
an extension card which, as such, needs to be inserted in one of the Base Units in order to
work The Base Units have their individual Installation Guide IG-014-0-EN “eWON Flexy - Base
Units” The present guide addresses shortly how the Extension Cards integrate the Base Units
and we give some recommendations to mount them (see § 3 6 Plugging the Extension Card
into the Base Unit)
Page 3 / 15 eWON Flexy Single Ethernet Ext Card FLX3101 | IG 017

Chapter 2
Safety, Environmental & Regulatory Information
2. Safety, Environmental & Regulatory Information
2. . Scope
The present heading addresses Safety, Environmental & Regulatory Information for the
Single Ethernet Extension Card FLX 3101 This Extension Card is basically belonging to the
same compliance frame than the Base Units
2.2. ESD Damage Prevention
- Caution -
Contains parts and assemblies susceptible to damage by electrostatic discharge (ESD). Always
use ESD precautions when handling Extension Cards and the opened Base Unit.
The Extension Card described in the present Installation Guide is a module exposing both
sides of an electronic printed circuit board Therefore, it is packed in antistatic ESD bags In
order to avoid ESD damage, the product must be handled with the necessary precaution
including:
•Grounded ESD protective work surface
•Personnel grounding
2.3. Applicable Directives, Standards and Compliance
The Extension Card described in the present Installation Guide belongs to class A
Information Technology Equipment (ITE) In a domestic environment this product may cause
radio interference in which case the user may be required to take appropriate measures
2.3. . Applicable European Directives
The Extension Card described in the present Installation Guide is in conformity with the
following EC directives:
•RoHS Directive 2011/65/EU
•EMC Directive 2004/108/EC
2.3.2. Applicable Safety Standards
The Extension Card described in the present Installation Guide is in conformity with the
following safety standards:
•IEC/EN 60950-1
•UL 60950-1
•CSA-C22 2 No 60950-1-07
Page 4 / 15 eWON Flexy Single Ethernet Ext Card FLX3101 | IG 017

Chapter 2
Safety, Environmental & Regulatory Information
2.3.3. FCC Compliance
The Extension Card described in the present Installation Guide complies with Part 15 of the
FCC Rules
Operating is subject to the following two conditions:
•This device may not cause harmful interference, and
•This device must accept any interference received, including interference that may
cause undesired operation
2.3.4. Certifications
The Extension Card described in the present Installation Guide has been certified by
authorized bodies:
•UL Certificate Of Compliance (COC) # E350576
•CB certificate # DK-29479-M1-UL
These certificates can be downloaded as PDF files on the eWON Support web site:
http://ewon biz/support/docs/flexy
Page 5 / 15 eWON Flexy Single Ethernet Ext Card FLX3101 | IG 017

Chapter 3
Hardware Description
3. Hardware Description
3. . Mechanical Layout and Interfaces
Ethernet Port Connector RJ45 - 10/100 Base-T
Back-plane connector
Page 6 / 15 eWON Flexy Single Ethernet Ext Card FLX3101 | IG 017

Chapter 3
Hardware Description
3.2. Extension Card Label
3.2. . Label Location and Information Included
The identification label of the extension cards is placed on the left hand side (solder side of
the PCB)
The different parts of the label are described below:
PN
Part Number:
identifies the type of the card
Description see 3 2 2 Part Number
Structure for Extension Cards
SN
Serial Number
Structure of the Serial Number
1111-2233-0001-44
1111 = MTID (product related)
2233 = Year Week
0001 = sequential mfg order
44 = product type
MAC MAC-Address
of the Ethernet card
Marks CE, UL, certificate number and logos
if applicable
Page 7 / 15 eWON Flexy Single Ethernet Ext Card FLX3101 | IG 017

Chapter 3
Hardware Description
3.2.2. Part Number Structure for Extension Cards
FLX 3 0 _00
FL FL is the prefix for the extensions of
the eWON Flexy family Only FL (constant)
X
1 alphabetic sign (CAP)
Defines the slots of the base module
in which the extension can be
inserted See also § 3 6 1 Base Unit
Slot Compatibility
A 2 first slots only ●●○○
B 2 last slots only ○○●●
X In any slot ●●●●
3101_00 Single Ethernet Extension Card The suffix _00 is used for software options
3.3. Front Panel LEDs
Item Mark Function Picture
LNK
ON
Link ETH 10/100 present
+ Speed indication
Green = 100 Mbps
Amber = 10 Mbps
ACT Flashing Green
Packets transfer activity
Page 8 / 15 eWON Flexy Single Ethernet Ext Card FLX3101 | IG 017

Chapter 3
Hardware Description
3.4. Ethernet Port Specifications
Characteristic Value
Ethernet Port 10/100Mbps
Default IP mode Static
Default IP address (WAN) 10 1 0 53
Default Subnet Mask 255 255 255 0
3.5. eWON Flexy Extension Cards Environmental Conditions
Characteristic Value
Operating temperature -25 to +70 °C
Storage temperature -40 to +70 °C
Relative humidity 10 to 95% non-condensing
Operating altitude Up to maximum 2000m
Storage altitude Up to maximum 3000m
3.6. Plugging the Extension Card into the Base Unit
3.6. . Base Unit Slot Compatibility
The Single Ethernet Extension Card (FLX 3101) can be inserted in all slots of the Base Unit
Explanation:
The Flexy Base Units feature two type of slots The A slots are the two first slots starting from
the left The B slots are the two last slots Some cards fit in A and B slots Some not Cards that
fit only one type of slot have a mechanical mistake-proof security
Page 9 / 15 eWON Flexy Single Ethernet Ext Card FLX3101 | IG 017

Chapter 3
Hardware Description
The reference code of the Extension Cards includes a letter that defines their compatibility
either with “A” slots, “B” slots or both:
•FLA xxxx - designates cards that fit into “A” slots
•FLB xxxx - designates cards that fit into “B” slots
•FLX xxxx - designates cards that fit into both “A” and “B” slots
In addition to the card reference, each type of extension card bears a visual compatibility
symbol on its front panel The visual symbols are shown in the table below:
●●○○ 2 first slots only (A)
●●●● In any slot (X)
○○●● 2 last slots only (B)
3.6.2. Extension Card Insertion
Please wait 30 seconds after powering off the equipment before inserting (or removing) an
extension card This is to avoid possible damage to the Base Unit and Extension Card
Remove the slot filler of the location where you want to insert the new card To do this, press
on both ends of the cover, note that the hooks (1) are out-centered like shown on the
pictures
Page 10 / 15 eWON Flexy Single Ethernet Ext Card FLX3101 | IG 017

Chapter 3
Hardware Description
Hooks to be pressed are off-centered – press while pulling upwards
Insert the Extension Card carefully and slide it down until the hooks are clicking Make sure
the card is completely inserted
3.6.3. Multiple Ethernet Extension Cards
The eWON Flexy firmware supports up to one Ethernet Extension Card of type FLX 3101
The boot process of the Base Unit includes an automated detection of the inserted
Extension Cards This detection is done sequentially, slot per slot starting from the left to
right Only the first detected Ethernet card (the most left one) will be taken into account by
the Flexy firmware
Additional cards of the same type will be ignored Contrary to slot-specific cards inserted in
a wrong slot, Ethernet cards in excess do not alter proper operation of the Base Unit and
other Extension Cards
Page 11 / 15 eWON Flexy Single Ethernet Ext Card FLX3101 | IG 017

Chapter 3
Hardware Description
3.6.4. Power Requirements
The internal power converter of the eWON Flexy Base units has been dimensioned to cover
a broad range of different combinations of Extension Cards Users should make sure the
total power demand of the Extension Cards does not exceed the capabilities of the Base
Unit That is why the notion of “Energy Points” has been introduced
The Installation Guide IG-014-0-EN “eWON Flexy - Base Units” includes a section giving the
Available Energy Points of each type of Base Unit
The power requirements of each Extension Card is expressed in Energy Demand Points. This
number is meant to check whether the balance with the Available Energy Points of a given Base
nit with Extension Cards is OK or not.
Ethernet Extension Card FLX 3101
Energy Demand Points 1
The Installation Guide IG-014-0-EN “eWON Flexy - Base nits” includes practical examples of power
balance calculations.
Page 12 / 15 eWON Flexy Single Ethernet Ext Card FLX3101 | IG 017

Chapter 4
Powering On the Base Unit with its Extension Cards
4. Powering On the Base Unit with its Extension Cards
When the Base Unit is powered on, it takes approximately 25 seconds for the unit to go
through its self-test procedure The slots in which the extension cards have been inserted
and their type are detected during this process
If the boot process completes normally, you should observe the following LED status
•Base Unit USR flashing green slowly
•Extension Card LNK OFF (the ETH connection is disabled by default)
Page 13 / 15 eWON Flexy Single Ethernet Ext Card FLX3101 | IG 017

Chapter 5
Check Card Detection on the Embedded Web
Page
5. Check Card Detection on the Embedded Web Page
The eWON Flexy Extension Card requires no software configuration It is automatically
detected by the Base Unit when it boots
5. . Connecting to the Embedded Web Server
Configure the network parameters of your configuration PC to encompass the IP range of
the eWON LAN
Connect the PC to one of the LAN port of the eWON Flexy
Open your Internet browser and access the eWON Flexy internal Web page by entering the
LAN IP address in the URL field (the default address is http://10 0 0 53)
The default
•login is adm
•password is adm
- Warning -
For security reasons, changing the default password adm is absolutely required.
To change the adm password, from the menu bar, click on Configuration, Users Setup and double
click on the adm entry to edit its parameters. Enter the new password twice and click Save.
5.2. Detected Cards Displayed in the System Page
The detected card appears in the eWON System hardware configuration page like shown
below
The path to the System hardware configuration page showing the cards detected by the
Base Unit is: Diagnostic (1) > Status (2) > System Info ( ) > System (4). The screen capture
below gives an example of an FLX 3101 extension card that has been detected in slot 1 (5)
Page 14 / 15 eWON Flexy Single Ethernet Ext Card FLX3101 | IG 017

Revision Information
Revision
Revision History
Revision Level Date Description
1 0 05/07/2013 Initial version
1 1 21/11/2015 Official product release version
1 2 18/11/2015 New template
Document build number: 5
Note concerning the warranty and the rights of ownership:
The information contained in this document is subject to modification without notice Check
http://wiki ewon biz for the latest documents releases
The vendor and the authors of this manual are not liable for the errors it may contain, nor for their
eventual consequences
No liability or warranty, explicit or implicit, is made concerning the quality, the accuracy and the
correctness of the information contained in this document In no case the manufacturer's
responsibility could be called for direct, indirect, accidental or other damage occurring from any
defect of the product of errors coming from this document
The product names are mentioned in this manual for information purposes only The trade marks and
the product names or marks contained in this document are the property of their respective owners
This document contains materials protected by the International Copyright Laws All reproduction
rights are reserved No part of this handbook can be reproduced, transmitted or copied in any way
without written consent from the manufacturer and/or the authors of this handbook
eWON sa, Member of ACT'L Group
Samara
tel. [phone]
[email protected]
Yekaterinburg
tel. [phone]
yekat[email protected]
St. Petersburg
tel. [phone]
[email protected]
Moscow
tel. [phone]
[email protected]
Helsinki
tel. [phone]
[e-mail]
Vilnius
tel. [phone]
[email protected]
Riga
tel. [phone]
[email protected]
Мinsk
tel. [phone]
[email protected]
Tallinn
tel. [phone]
[email protected]
Кiev
tel. [phone]
[email protected].ua
