Belkin F5D7000 User manual

Belkin Ltd.
4 Pioneer Avenue
Tuggerah Business Park
Tuggerah, NSW 2259, Australia
[phone]
[phone] fax
Belkin B.V.
Boeing Avenue 333
1119 PH Schiphol-Rijk, The Netherlands
[phone]
[phone] fax
Belkin Tech Support
US: 877-736-5771
800-223-5546 ext. 2263
310-898-1100 ext. 2263
UK: 0845 607 77 87
Australia: 1800 235 546
New Zealand: 0800 235 546
Singapore: 65 64857620
Europe: www.belkin.com/support
Belkin International, Inc.
501 West Walnut Street
Los Angeles, CA 90220-5221, USA
310-898-1100
310-898-1111 fax
Belkin Ltd.
Express Business Park, Shipton Way
Rushden, NN10 6GL, United Kingdom
[phone]
[phone] fax
© 2007 Belkin International, Inc. All rights reserved. All trade names are registered trademarks of
respective manufacturers listed. Windows and Windows Vista are either registered trademarks or
trademarks of Microsoft Corporation in the United States and/or other countries.
P74685-F
Wireless G
Desktop Card

F5D7000
Wireless G
Desktop Card
User Manual

Table of Contents
1 Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Benefits of a Home Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Advantages of a Wireless Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Placement of your Wireless Networking Hardware
for Optimal Performance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
2 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Product Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Applications and Advantages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Product Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3 Installing and Setting up the Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Step 1: Install . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Step 2: Insert. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Step 3: Configure. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4 Using the Belkin Wireless Networking Utility . . . . . . . . . . . . . . . . . . . . . . . . 16
Accessing the Belkin Wireless Networking Utility
from the Windows System Tray . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Setting Wireless Network Profiles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Configuring your Belkin Wireless G Desktop Card to use Security . . . . . . 22
5 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
6 Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

E

Introduction
section
1
1
2
3
4
5
6
Thank you for purchasing the Belkin Wireless G Desktop Card (the
Card). Now you can take advantage of this great new technology
and gain the freedom to network your home and office computers
wirelessly. This Card allows you to connect a desktop computer
to your network. The easy installation and setup will have you
networking wirelessly in minutes. Please be sure to read through this
User Manual completely, and pay special attention to the section
entitled “Placement of your Wireless Networking Hardware for Optimal
Performance” on page 2.
Benefits of a Home Network
Your Belkin Home Network will allow you to:
• Share one high-speed Internet connection with all the computers in
your home
• Share resources, such as files, and hard drives among all the
connected computers in your home
• Share a single printer with the entire family
• Share documents, music, video, and digital pictures
• Store, retrieve, and copy files from one computer to another
• Simultaneously play games online, check Internet email, and chat
Advantages of a Wireless Network
Here are some of the advantages of setting up a Belkin wireless network:
• Mobility – you’ll no longer need a dedicated “computer
room”— now you can work on a networked laptop or desktop
computer anywhere within your wireless range
• Easy installation – Belkin Easy Installation Wizards make
setup simple
• Flexibility – set up and access printers, computers, and
other networking devices from anywhere in your home
• Easy expansion – the wide range of Belkin networking products
lets you expand your network to include devices such as printers
and gaming consoles
• No cabling required – you can spare the expense and hassle
of retrofitting Ethernet cabling throughout the home or office
• Widespread industry acceptance – choose from a wide range
of interoperable networking products

Introduction
2
2
Placement of your Wireless Networking Hardware for
Optimal Performance
Your wireless connection will be stronger the closer your computer is
to your wireless router (or access point). Typical indoor operating range
for your wireless devices is between 100 and 200 feet. In the same way,
your wireless connection and performance will degrade somewhat as the
distance between your wireless router (or access point) and connected
devices increases. This may or may not be noticeable to you. As you
move farther from your wireless router (or access point), connection
speed may decrease. Factors that can weaken signals simply by getting
in the way of your network’s radio waves are metal appliances or
obstructions, and walls.
If you have concerns about your network’s performance that might be
related to range or obstruction factors, try moving the computer to a
position between five and 10 feet from the wireless router (or access
point) in order to see if distance is the problem. If difficulties persist even
at close range, please contact Belkin Technical Support.
Note: While some of the items listed below can affect network
performance, they will not prohibit your wireless network from
functioning; if you are concerned that your network is not operating at its
maximum effectiveness, this checklist may help.
1. Placement of your Wireless Router (or Access Point)
Place your wireless router (or access point), the central connection point
of your network, as close as possible to the center of your wireless
network devices.
To achieve the best wireless network coverage for your “wireless clients,”
(i.e. computers enabled by Belkin Wireless Notebook Cards, Wireless
Desktop Cards, and Wireless USB Adapters):
• Ensure that your wireless router’s (or access point’s) antennas
are parallel to each other, and are positioned vertically (toward
the ceiling). If your wireless router (or access point) itself is
positioned vertically, point the antennas as much as possible in
an upward direction.
• In multistory homes, place the wireless router (or access point) on a
floor that is as close to the center of the home as possible. This may
mean placing the wireless router (or access point) on an upper floor.
• Try not to place the wireless router (or access point) near a cordless
2.4GHz phone.

3
Introduction
section
3
1
2
3
4
5
6
2. Avoid Obstacles and Interference
Avoid placing your wireless router (or access point) near devices that
may emit radio “noise”, such as microwave ovens. Other objects that
can inhibit wireless communication can include:
• Refrigerators
• Washers and/or dryers
• Metal cabinets
• Large aquariums
• Metallic-based, UV-tinted windows
If your wireless signal seems weak in some spots, make sure that
objects such as these are not blocking the signal’s path between
your computers and wireless router (or access point).
3. Cordless Phone Placement
If the performance of your wireless network is impaired after attending
to the above issues, and you have a cordless phone:
• Try moving cordless phones away from the wireless router
(or access point) and your wireless-enabled computers.
• Unplug and remove the battery from any cordless phone
that operates on the 2.4GHz band (check manufacturer’s
information). If this fixes the problem, your phone may
be interfering.
• If your phone supports channel selection, change the
channel on the phone to the farthest channel from your
wireless network as possible. For example, change the
phone to channel 1 and move your wireless router (or
access point) to channel 11. (Your channel selection will
vary depending on your region.) See your phone’s user
manual for detailed instructions.
• If necessary, consider switching to a 900MHz or
5GHz cordless phone.

Introduction
44
4. Choose the “Quietest” Channel for your Wireless Network
In locations where homes or offices are close together, such as
apartment buildings or office complexes, there may be wireless
networks nearby that can conflict with yours. Use the Site Survey
capabilities of your Wireless Networking Utility to locate any other
wireless networks, and move your wireless router (or access point) and
computers to a channel as far away from other networks as possible.
Experiment with more than one of the available channels, in order to
find the clearest connection and avoid interference from neighboring
cordless phones or other wireless devices.
For more Belkin wireless networking products, use the detailed Site
Survey and wireless channel information included in your User Manual.
5. Secure Connections, VPNs, and AOL
Secure connections typically require a user name and password, and
are used where security is important. Secure connections include:
• Virtual Private Network (VPN) connections, often used to connect
remotely to an office network
• The “Bring Your Own Access” program from America Online (AOL),
which lets you use AOL through broadband provided by another
cable or DSL service
• Most online banking websites
• Many commercial websites that require a user name and password
to access your account
Secure connections can be interrupted by a computer’s power
management setting, which causes it to “go to sleep.” The simplest
solution to avoid this is to simply reconnect by re-running the VPN or
AOL software, or by re-logging into the secure website.
A second alternative is to change your computer’s power management
settings so it does not go to sleep; however, this may not be
appropriate for portable computers. To change your power management
setting in Windows, see the “Power Options” item in the Control Panel.
If you continue to have difficulty with Secure Connections, VPNs, and
AOL, please review steps 1–4 above to be sure you have addressed
these issues.
These guidelines should allow you to cover the maximum possible area
with your wireless router. Should you need to cover an even wider area,
we suggest the Belkin Wireless Range Extender/Access Point.
For more information regarding our networking products, visit our
website at www.belkin.com/networking or call Belkin Technical Support.

5
Overview
section
5
2
3
4
5
6
Product Features
The Card complies with the IEEE 802.11g standard in order to
communicate with other 802.11g-compliant wireless devices at
54Mbps. The Card is compatible with all 802.11g devices as well as
other 802.11b products at 11Mbps. 802.11g products operate on the
same 2.4GHz frequency band as 802.11b Wi-Fi® products.
• 2.4GHz ISM (Industrial, Science, and Medical) band operation
• Integrated easy-to-use Wireless Networking Utility
• PCI interface, for operation in virtually any desktop computer
• WPA, WPA2, 64-bit WEP (Wired Equivalent Privacy), or
128-bit encryption
• Wireless access to networked resources
• Support for both Infrastructure and Ad-Hoc (peer-to-peer)
networking modes
• Data rate of up to 54Mbps (802.11g), or 11Mbps (802.11b)
• Easy installation and use
• External antenna
• LED power and network link indicators
1

Overview
6
6
Applications and Advantages
• Wireless roaming with a laptop around the home or office
Offers the freedom of networking—without cables
• Connection rates of up to 54Mbps
Provides immediate wireless connectivity at home, work, and hotspot
locations without compromising the use of existing 802.11b and
802.11g products
• Compatibility with 802.11b products
802.11g wireless LAN solutions are backward-compatible with existing
Wi-Fi (IEEE 802.11b) products and with other products that display the
54g logo
• Difficult-to-wire environments
Enables networking in buildings with solid or finished walls, or open
areas where wiring is difficult to install
• Frequently changing environments
Adapts easily in offices or environments that frequently rearrange or
change locations
• Temporary LANs for special projects or peak time
Sets up temporary networks such as at trade shows, exhibitions, and
construction sites, which need networks on a short-term basis; also
companies who need additional workstations for a peak activity period
• SOHO (Small Office/Home Office) networking needs
Provides the easy and quick, small network installation SOHO
users need
Product Specifications
Host Interface: 32-bit PCI interface
Power Consumption: Tx/Rx peak 510/250mA @ 3.3VDC (max.)
Operating Temperature: 32–140 degrees F (0–60 degrees C)
Storage Temperature: -4–176 degrees F (-20–80 degrees C)
Humidity: Max. 90% (non-condensing)
Typical Operating Range: 100–200 ft. (30–60m) indoors

7
Overview
section
7
1
2
3
4
5
6
Overview
(a) Link LED
Lights up when the Card links to a wireless network
(b) Activity LED
Lights up and flashes when the Card is active
(c) Card Connector
Fits securely into your computer’s PCI slot
(d) Antenna
System Requirements
• PC-compatible desktop computer with one available
PCI slot and CD-ROM drive
• Windows® 2000, XP, or Vista™
Package Contents
• Wireless G Desktop Card
• Quick Installation Guide
• Installation Software CD
• User Manual
(c)
(d)

Installing and Setting up the Card
8
8
For users of Windows Vista, refer to the following installation steps:
Step 1A Install
IMPORTANT: INSTALL THE SOFTWARE BEFORE INSERTING THE CARD.
1A.1 Insert the Installation Software CD into your CD-ROM drive.
1A.2 Select the “Run Installer.exe” option.
1A.3 You may see a window titled, “A program needs your
permission to continue”. Click “Continue”.
1A.4 Click “Next” to begin the installation process.

9
Installing and Setting up the Card
section
9
1
2
3
4
5
6
1A.5 A window may appear with the
message, “Windows can’t verify
the publisher of this driver
software” across the top. This is
normal and does not indicate a
problem. Our software has been
fully tested and is compatible with
this operating system.
1A.6 When the installation
completes, click on “Finish”.
1A.7 When prompted, turn off your
computer and plug in your
Card. Your installation is
now complete.
1A.8 To connect to the Internet,
open the Network and Sharing
Center by first opening the
Control Panel from the
“Start” menu.
1A.9 In the Control Panel, click
on “View network status
and tasks”.

Installing and Setting up the Card
10
10
1A.10 In the Network and Sharing
Center, click on “Connect to
a network”.
1A.11 Select an available wireless
network and click “Connect”.
1A.12 Your Card will attempt to connect
to the selected network.
1A.13 Depending on the security
settings of your wireless network,
you may be prompted to enter
in a network security key or a
passphrase. Click “Connect” after
you have done so.

11
Installing and Setting up the Card
section
11
1
2
3
4
5
6
1A.15 The Network and Sharing Center
should now show the network
connection that you have just
made. The links on the left of the
window allow you to configure
your network connections.
1A.14 After connecting to the
network, you may choose to
save this network and connect
automatically once your Card is
in range.

Installing and Setting up the Card
12
12
For users of other Windows operating systems, refer to the installation
instructions below.
Step 1B Install
IMPORTANT: INSTALL THE SOFTWARE BEFORE INSERTING THE CARD.
1B.1 Insert the Installation Software CD into your CD-ROM drive.
1B.2 The Belkin Wireless Card Installer screen will automatically appear. (This
may take 15–20 seconds.) Click “install” to start the installation.
Note: If the Belkin Wireless Networking Utility screen does not appear
within 20 seconds, access your CD-ROM by double-clicking on the “My
Computer” icon; then, double-click on the CD-ROM drive into which
the installation CD has been placed. Double-click on the folder named
“Files”, then double-click on the icon named “setup.exe”.
1B.3 The first in a series of progress-monitoring screens will let you
know where you are in the setup process.
1B.4 You might see a screen similar to this one.
This DOES NOT mean there is a problem.
Our software has been fully tested and
is compatible with this operating system.
Select “Continue Anyway” and follow the
on-screen instructions.
1B.5 Once the software is installed, you
will be prompted to shut down your
computer. Click “Yes”.

13
Installing and Setting up the Card
section
13
1
2
3
4
5
6
Step 2 Insert
Insert the Card into an Available PCI Slot on your Desktop Computer
2.1 Shut down your computer and disconnect your power cord.
2.2 Remove the screws behind your computer case that secure the
computer cover and remove cover.
Note: Touch any metal part of the case to discharge static
electricity to avoid damage to the product or your computer.
2.3 Locate an empty PCI expansion
slot. It is usually white in color.
Confirm that the Card will fit into
the slot you have chosen. Keep
in mind that the included antenna
needs to be oriented with the top
pointing up. If there are cables and
other connectors in the way, try
to pick the PCI slot that has the
fewest obstructions to the correct
positioning of the antenna.
2.4 Remove the metal port cover from
the back of the computer that
corresponds to the PCI slot you
selected. If there is a screw, place
it in a safe place, as you will be
using it to attach the Card to the
computer later.
2.5 Push the Card firmly into the PCI
slot that you have chosen. Apply
pressure as needed until the
connector is fully seated.

Installing and Setting up the Card
14
14
2.6 Now secure the Card with the screw that you previously
placed in a safe place.
2.7 Carefully screw the antenna onto the threaded connector on
the Card. Turn the antenna until it is vertical and pointing up.
2.8 Replace the computer’s cover. Now that the Card is installed,
you can reconnect the power cord and turn the computer
back on.
2.9 The Belkin Wireless Networking Utility installation is now
complete. Click “Finish” to close the Wizard and restart
your computer.

15
Installing and Setting up the Card
section
15
1
2
3
4
5
6
Step 3 Configure
Connect to a Network
3.1 After restarting your computer,
double-click the Belkin Wireless
Networking Utility icon located on
the desktop screen.
3.2 The Wireless Networking Utility
screen will appear.
Select a network to connect to
by selecting a network from the
“Available Networks” list. Then,
click “Connect”.
Note: In order to see your
available networks, you must be
near a working wireless router or
access point.
3.3 The Belkin Wireless Networking
Utility icon can also be found on
the system tray.
Note: Double-clicking on the
Belkin Wireless Networking
Utility icon on the system tray
will bring up the “Utility” screen.
Installation is now complete.
