Exact solutions GhosT-OLED Series User manual

GhosT-OLED
Transparent OLED display with LG 55EW5F-A
Manual Version 1.3
Date
Revision No.
Author
Checked
Approved
Description
02.01.2020
1.1
DRD
RBR
TSN
Layout change
16.03.2020
1.2
RBR
DRD
DRD
Update TK Mounting
11.02.2021
1.3
DRD
TSN
RBR
Update PCAP
Contact
Tel.: [phone]
E-Mail: [e-mail]
Web: www.exactsolutions.de

Manual GhosT-OLED with LG 55EW5F-A
11.02.2021
Page 2of 45
Table of content
1. Important information 3
1.1 Summary 3
1.2 Safety instructions 3
1.3 Precautions to the AC Adapter and Electrical Power 6
1.4 Precautions in moving the product 7
1.5 Precautions in using the product 7
1.6 Operating conditions 8
2. Overview GhosT-OLED Series 9
2.1 Introduction 9
2.2 GhosT-OLED Half Kit 9
2.3 GhosT-OLED Full Kit 10
2.4 GhosT-OLED Touch Kit 11
2.5 GhosT-OLED Full Kit PCAP 12
2.6 GhosT-OLED Half Kit PCAP 13
3. Scope of delivery 14
4. Installation instructions 14
4.1 Lifting GhosT-OLED Full Kit and Full Kit PCAP out of the case 15
4.2 Lifting GhosT-OLED Full Kit and Full Kit PCAP out of the wooden box 17
4.3 Changing the foot orientation of GhosT-OLED Full Kit and Full Kit PCAP 19
4.4 Set up GhosT-OLED Touch Kit 21
4.5 Connecting GhosT-OLED Half Kit and Half Kit PCAP panel unit with signage box 24
4.6 Mounting GhosT-OLED to walls or furniture 31
4.6.1 Screw hole pattern of all GhosT-OLED versions 31
4.6.2 Ventilation information 33
5. Connector panel and control possibilities 34
6. Specifications 36
7. Product Outlines 38
7.1 Drawing GhosT-OLED Half Kit 38
7.2 Drawing GhosT-OLED Full Kit 39
7.3 Drawing GhosT-OLED Touch Kit 40
7.3.1 Full Kit equipped with Touch Kit 41
7.4 Drawing GhosT-OLED Full Kit PCAP 42

Manual GhosT-OLED with LG 55EW5F-A
11.02.2021
Page 3of 45
7.5 Drawing GhosT-OLED Half Kit PCAP 43
8. Declaration of Conformity 44
Imprint 45
1. Important information
Note: These installation instructions must always be handed over to the installing person
1
Note: Read these instructions carefully before installing the system
Note: Read the LG 55EW5F-A Owner’s Manual and User Guide in the first place
1.1 Summary
The GhosT-OLED series has been designed under the highest attention on safety. However,
improper handling can cause a risk for safety and / or damage. Please read carefully the
instructions provided in this manual in order to avoid damage and ensure personal safety.
Respecting the instructions will also prevent burn-in effects and extend the product’s
lifetime. The GhosT-OLED products are intended to be installed only by fully qualified,
trained and competent persons to provide safe and secure installations.
1.2 Safety instructions
WARNING
Note: Read the safety instructions written in the LG 55EW5F-A Owner’s Manual and User
Guide in the first place.
Note: If you ignore the safety instructions in the LG Manuals for LG 55EW5F-A or in this
manual, humans may be seriously injured or there is a possibility of accident or
death.
•This product can not be installed outdoors. Do not use the system in other operating
conditions than described in chapter 1.6 Operating conditions.
•Keep away from heat sources like heaters. Electrical shock, fire, malfunction or
deformation may occur.
•Keep the packing anti-moisture material or vinyl packing our of the reach of children.
This material is harmful if swallowed. Vinyl packing can cause suffocation.
1
Only a qualified person should install this product

Manual GhosT-OLED with LG 55EW5F-A
11.02.2021
Page 4of 45
•Do not put heavy objects on the product or sit on it. The product may collapse and
drop and people, especially small children, may be injured.
•Do not expose the screen to water, moisture or dust. Install it only in a neat and dry
place. Dust and moisture can cause electrical shock, fire or product damage.
•If smoke can be smelled/detected or if you hear a strange sound or anything else that
is uncommon, unplug the power cord and contact us. If usage is continued, electrical
shock or fire can occur.
•If the screen or the housing breaks, be very careful as broken fragments may cause
injuries. Do not touch broken glass with bare hands, use appropriate safety tools.
Always unplug the power cord, do not keep using the product. If you continue to use
without proper measures, electrical shock or fire can occur.
•In cause of injury, for example caused due to contact with broken glass, please seek
medical help immediately.
•Do not drop an object or apply impact to the product. It can cause injury to humans
and damage the product.
•Do not let the product fall or drop when connecting it with an external device. This
may cause injury and/or damage to the product.
•Do not mount the GhosT-OLED displays onto unstable, non flat, structures, the entire
system might fall down or tilt over. Make sure that the construction to which a
display is mounted can support the given total weight (for weight details please refer
to chapter 6 Specifications). If the product is dropped, humans may be injured or the
product may be broken.
•Make sure you use correct installation equipment (screws, washer etc.) to secure a
safe installation.
•If during the set up of GhosT-OLED Half Kit the signage box is open, make sure the
power cable is not connected, otherwise electric shocks may occur.
•If during the set up of GhosT-OLED Half Kit the signage box is open, make sure not to
touch any other component of the signage box except the ports for the flexible flat
cables, otherwise electric shocks may occur.
•If during the set up of GhosT-OLED Half Kit the signage box is opened, be aware of
sharp edges of the metal housing. If necessary wear protective gloves.
•Do not open the housing of the GhosT-OLED Full Kit otherwise electric shocks may
occur. There is no need for users to open the housing of the Full Kit. Please contact us
for any service works.

Manual GhosT-OLED with LG 55EW5F-A
11.02.2021
Page 5of 45
•Only qualified personnel is allowed to unpack the product, otherwise injury to
humans or damage to the product can occur, refer to chapter 4.1 Lifting GhosT-OLED
Full Kit and Full Kit PCAP out of the case.
•Do not unpack the product in haste, to prevent injuries or damages.
•When changing the orientation of the foot of the GhosT-OLED Full Kit there is a risk
to clamp a finger or something else. Wear apropriate safety clothes and be careful.
•When mounting this partly transparent product make sure people do not overlook
the product. Humans may get injured or the product may be broken.
CAUTION
•Set up the screen in a well ventilated place and make sure ventilation holes are not
blocked. If ventilation is not working correctly fire can break out due to internal heat.
•Do not install the product in an area with poor ventilation and avoid placing it on
cushions or carpets. If ventilation is not working correctly fire can break out due to
internal heat.
•Do not install the product where there are heating objects such as lighting
equipment. Electrical shock, fire, malfunction or deformation may occur.
•Install the product where no EMI occurs.
•Keep the product away from sunlight and do not expose it to any other UV light
sources. Otherwsie the product can be damaged.
•Do not expose the screen to water or moisture to prevent any damage.
•Avoid any force or impacts on the screen.
•If the screen is broken, always unplug all power supplies and other cables from the
display to prevent damage to electronical parts.
•The recommended operating time is less than 18 hours a day.
•Static images on the display can cause image retention (burn in effects). To prevent
such damage, it is recommended to show dynamic content periodically.
•Always operate the system under the specified operating conditions described in
chapter 1.6 Operating conditions.
•If you install the product in a place that does not meet the recommended conditions,
this may cause injuries to humans and cause serious damage to the product’s picture

Manual GhosT-OLED with LG 55EW5F-A
11.02.2021
Page 6of 45
quality, life cycle, and appearance. This caution applies to places where there is an
abundance of fine dust or oil mist, chemical substances are used, the temperature is
very high or low, the humidity is very high, or the product is likely to remain turned
on for a long period of time. Failure to do so will invalidate the warranty.
1.3 Precautions to the AC Adapter and Electrical Power
WARNING
•If water or any foreign substance goes inside the product (display, signage box,
power cord, AC adapter etc.), disconnect the power cord immediately and contact us.
Otherwise, this may cause a fire or electric shock due to damage to the product.
•Do not touch the power plug or AC adapter with wet hands. If the pins of the plug are
wet or dusty, wipe and dry them before use. Otherwise, this may cause a fire or
electric shock.
•Make sure to completely insert the power cord into the AC adapter. If loosely
connected, the poor connection may cause a fire or electric shock
•Be sure to use power cords and AC adapters provided. The use of non-approved
products may cause a fire or electric shock.
•When unplugging the power cord, always pull it by the plug. Do not bend the power
cord with excessive force. The power line can be damaged, which may cause electric
shock or fire.
•Be careful not to step or place heavy objects (electronic appliances, clothing, etc.) on
the power cord or AC adapter. Be careful not to damage the power cord or AC
adapter with sharp objects. Damaged power cords may cause a fire or electric shock.
•Never disassemble, repair or modify the power cord or AC adapter. This may cause a
fire or electric shock.
•Make sure to connect the power cable to the grounded current. You may be
electrocuted or injured.
•Use the rated voltage only. The product can be damaged, or you may be
electrocuted.
•In the presence of thunder and lightning, never touch the power cord and signal
cable because it can be very dangerous. It can cause electric shock.
•Do not connect several extension cords, electrical appliances, or electrical heaters to
a single outlet. Use a power strip with a grounding terminal designed for exclusive
use with the computer. A fire can break out due to overheating.
•Do not touch the power plug with wet hands. Additionally, if the cord pin is wet or
covered with dust, dry the power plug completely or wipe dust off. You may be
electrocuted due to excess moisture.
•If you don’t intend to use the product for a long time, unplug the power cable from
the product. Covering dust can cause a fire, or insulation deterioration can cause
electric leakage, electric shock or fire.

Manual GhosT-OLED with LG 55EW5F-A
11.02.2021
Page 7of 45
•Fix the power cable completely. If the power cable is not fixed completely, a fire can
break out.
•Do not insert a conductor (e.g. a small metal rod or screw driver) into one end of the
power cable while the other end is connected to the input terminal on the wall.
Additionally, do not touch the power cable right after plugging it into the wall input
terminal. You may be electrocuted.
•The appliance coupler is used as the disconnect device.
•Please make sure the device is installed near the wall outlet to which it is connected
and that the outlet is easily accessible.
•As long as this unit is connected to the AC wall outlet, it is not disconnected from the
AC power source even if the unit is turned off
•Be sure to keep the outlet, AC adapter, and pins of the power plug clean from dust
and etc. This may cause a fire.
•Do not unplug the power cord while the product is in use. Electrical shock can
damage the product.
•Use only the power cord supplied with the unit. If you use another power cord, make
sure that it is certified by the applicable national standards when not provided by the
supplier. If the power cable is faulty in any way, please contact the manufacturer or
the nearest authorized repair service provider for a replacement.
1.4 Precautions in moving the product
WARNING
•Make sure to turn off the product before moving it. You may be electrocuted or the
product can be damaged.
•Make sure to remove all cables before moving the product. You may be electrocuted
or the product can be damaged.
•Make sure the panel faces forward and hold the product with at least two persons,
each with both hands to move. If you drop the product, the damaged product can
cause electric shock or fire. Contact an authorized service center for repair.
•Do not shock the product when moving it. You may be electrocuted or the product
can be damaged.
1.5 Precautions in using the product
WARNING
•Do not disassemble, repair or modify the product on your own. Fire or electric shock
can occur. Contact us for check, calibration or repair.
•Prior to every installation, check all mounting threads as well as the rotating
mechanism for any kind of defect and correct function. If a damage or defective
function is detected do not keep using the product and contact us for service.

Manual GhosT-OLED with LG 55EW5F-A
11.02.2021
Page 8of 45
•When the display is to be left unattended for an extended period of time, unplug it
from the wall outlet.
•Keep the product away from water. Fire or electric shock can occur.
•Do not shock or scratch the front and sides of the screen with metallic objects.
Otherwise, it may cause damage to the screen.
•Do not put or store inflammable substances near the product. There is a danger of
explosion or fire due to careless handling of the inflammable substances.
•When cleaning the product, unplug the power cord and scrub gently with a soft cloth
to prevent scratching. Do not clean with a wet cloth or spray water or other liquids
directly onto the product. An electric shock may occur. (Do not use chemicals such as
benzene, paint thinners, or alcohol.) Keep the product clean at all times.
•Use authorized detergent only when cleaning the product. (Do not use benzene,
thinner or alcohol.) Product can be deformed.
•Do not press strongly upon the panel with a hand or sharp object such as nail, pencil,
or pen, or make a scratch on it.
•Do not expose to dripping or splashing and do not place objects filled with liquids,
such as vases, cups, etc. on or over the device (e.g. on shelves above the unit).
•Batteries should not be exposed to excessive heat. For example, keep away from
direct sunlight, open fireplace, and electric heaters.
•Do not place non-rechargeable batteries in charging device.
1.6 Operating conditions
•Temperature: 5°C to 35°C
•Humidity: 10% to 80%
•Operating time: 18 Hrs / 7 days (moving video only)
•Display pattern should be changing continuously to avoid any kind of image retention
(burn in effects)
•No sunlight or any other warm light sources directed onto the screen
•Only indoor operation
•Display must be protected from UV light
•Usage only in well ventilated environments

Manual GhosT-OLED with LG 55EW5F-A
11.02.2021
Page 9of 45
2. Overview GhosT-OLED Series
2.1 Introduction
Displays from GhosT-OLED series are transparent OLED (T-OLED) screens with Full-HD
resolution. The transmittance of the screen is approx. 38%. Thanks to OLED (Organic Light
Emitting Diode) technology, the display shows excellent images even at high viewing angles
and has low power consumption. The transparency is achieved by adding a fifth segment
into the sub pixel structure which consists of four sub pixel emitting red, green, blue and
white light. This fifth segment is transparent. As OLED is a self-emitting technology, there is,
unlike to LCDs, no need for backlight. Displaying black content on a transparent OLED display
will make this content appear transparent.
Optionally, the GhosT-OLED Full Kit or Half Kit, can be equipped with the GhosT-OLED Touch
Kit. The Touch Kit technology is based on IR diodes.
Furthermore the GhosT-OLED PCAP version completes the series and provides an accurate
and bezel-less touch functionality. It is available as Full Kit or Half Kit version.
GhosT-OLED series can be delivered with white or black housing.
The GhosT-OLED series is based on a customisable design concept. Trained personnel can
change the orientation of the foot from table mode to straight mode.
2.2 GhosT-OLED Half Kit
The GhosT-OLED Half Kit is the ideal product for fix installations. It makes installations of the
raw LG T-OLED Panel a lot easier and safer. This is achieved by adding additional parts to the
panel. The LG Signage Box needs to be connected via four flexible flat cables to the panel.
For further information how to connect please refer to chapter 4.5 Connecting GhosT-OLED
Half Kit and Half Kit PCAP panel unit with signage box as well as to the “LG 55EW5F-A Quick set-
up guide”and the “Installation Manual GhosT HK” which is enclosed to the Ghost-OLED Half
Kit packing.
Model Number: GHOST55-HK
Figure 1. GhosT-OLED Half Kit –backside (left) front view (right)

Manual GhosT-OLED with LG 55EW5F-A
11.02.2021
Page 10 of 45
2.3 GhosT-OLED Full Kit
GhosT-OLED Full Kit combines all electronics and the T-OLED panel to one display. It is ideal
for rental applications but also for many fix installations. The orientation of the foot can be
changed by qualified personnel from table mode to straight mode and back. Please refer to
chapter 4.3 Changing the foot orientation of GhosT-OLED Full Kit and to the “Installation
Manual GhosT FK” which is enclosed to the GhosT-OLED Full Kit packing.
Model Number: GHOST55-FK
Figure 2: GhosT-OLED Full Kit in table mode –backside (left) front view (right)
Figure 3: GhosT-OLED Full Kit in straight mode –backside (left) and front view (right)

Manual GhosT-OLED with LG 55EW5F-A
11.02.2021
Page 11 of 45
2.4 GhosT-OLED Touch Kit
This version combines the advantages of the T-OLED technology with the multi touch
capable primeTOUCH technology. Despite the touch capability it still provides a narrow and
stable frame. The GhosT-OLED Touch Kit can be mounted in front of the Full Kit or Half Kit
version. Please refer to chapter 4.4 Set up GhosT-OLED Touch Kit and to the “Installation
Manual GhosT TK” which is enclosed to the GhosT-OLED Touch Kit packing.
Model Number: GHOST55-TK
Figure 4: GhosT-OLED Touch Kit –backside (left) and front view (right)
Figure 5: GhosT-OLED Touch Kit in front of Full Kit (table mode) –backside (left) and front view (right)

Manual GhosT-OLED with LG 55EW5F-A
11.02.2021
Page 12 of 45
2.5 GhosT-OLED Full Kit PCAP
This version combines the advantages of the T-OLED technology with the multi touch
capable projected capacitive touch technology. Despite the touch capability it still provides a
clean and neat look with a flat surface and without an uprising bezel. Please refer to chapter
4.3 Changing the foot orientation of GhosT-OLED Full Kit and to the “Installation Manual
GhosT FK” which is enclosed to the GhosT-OLED Full Kit packing.
Model Number: GHOST55-FK-TC
Figure 6: GhosT-OLED Full Kit PCAP in table mode –backside (left) and front view (right)
Figure 7: GhosT-OLED Full Kit PCAP in straight mode –backside (left) and front view (right)

Manual GhosT-OLED with LG 55EW5F-A
11.02.2021
Page 13 of 45
2.6 GhosT-OLED Half Kit PCAP
This version combines the advantages of the T-OLED technology with the multi touch
capable projected capacitive touch technology. Despite the touch capability it still provides a
clean and neat look with a flat surface and without an uprising bezel. For further information
how to connect please refer to chapter 4.5 Connecting GhosT-OLED Half Kit and Half Kit
PCAP panel unit with signage box as well as to the “LG 55EW5F-A Quick set-up guide”and the
“Installation Manual GhosT HK-TC” which is enclosed to the Ghost-OLED Half Kit packing.
Model Number: GHOST55-HK-TC
Figure 8: GhosT-OLED Half Kit PCAP –backside (left) and front view (right)

Manual GhosT-OLED with LG 55EW5F-A
11.02.2021
Page 14 of 45
3. Scope of delivery
Note: Please check the delivery for completeness and damage immediately after you
receive the shipment. Please contact your supplier in case of missing or damaged
parts.
Accessory scope of delivery for each GhosT-OLED model
Item
Full Kit
GHOST55-
FK
Half Kit
GHOST55-
HK
Touch Kit
GHOST55-
TK
Full Kit PCAP
GHOST55-
FK-TC
Half Kit PCAP
GHOST55-
HK-TC
Power cable (IEC C14)
1
1
0
1
1
External IR receiver (3.5mm jack)
1
1
0
1
1
Remote control
1
1
0
1
1
Display Port cable
1
1
0
1
1
LAN cable CAT 5
1
1
0
1
1
D-Sub 9 pol. to 3,5mm jack cable (4 pol.)
1
1
0
1
1
3,5mm jack cable (4 pol.)
1
1
0
1
1
LC cable
0
1
0
0
1
Flexible flat cables
0
4
0
0
4
Sticker set to fix flexible flat cables
0
1
0
0
1
Touch Kit support brackets incl. screws
0
0
2 (left & right)
0
0
USB extender (A type)
0
0
1
1
1
USB male/mal (A type) cable
0
0
0
1
0
Mini USB to USB (A type) cable
0
0
0
0
1
USB Stick (instructions, manuals, demo
content)
1
1
1
1
1
Printed quick start manual
1
1
1
1
1
4. Installation instructions
WARNING: Read the following instructions carefully to prevent injuries to humans or
damages to the system.
Prior to every installation check all mounting threads as well as the rotating
mechanism for any kind of defect and correct function. If a damage or
defective function is detected do not keep using the product and contact us
for service.
A corresponding Installation manual is enclosed to any GhosT-OLED delivery.
Go to https://exactsolutions.de/de/produkte/ghost-oled/ to “Videos” to watch the video
“How to handle GhosT-OLED series”

Manual GhosT-OLED with LG 55EW5F-A
11.02.2021
Page 15 of 45
Note: Minimum two Persons are required to unpack and set up the GhosT-OLED products
Note: For mounting the GhosT-OLED at least three persons are required
Note: As T-OLED technology is susceptible to burn in effects only show moving content
Note: Use only the appropriate tools and mounting materials
4.1 Lifting GhosT-OLED Full Kit and Full Kit PCAP out of the case
No tools required
➢Carefully remove small front cover first, then remove the larger back cover:

Manual GhosT-OLED with LG 55EW5F-A
11.02.2021
Page 16 of 45
➢Grab with one hand under the panel unit, and with the other hand grab the handle:
➢Place the GhosT OLED on a flat and clean surface. If necessary, take further
precautions for a secure stand of the display:
➢Plug in power supply and remote-control cable with external IR sensor to turn it on

Manual GhosT-OLED with LG 55EW5F-A
11.02.2021
Page 17 of 45
4.2 Lifting GhosT-OLED Full Kit and Full Kit PCAP out of the wooden box
Required Tools: (Cordless) screw driver
➢Unscrew the back cover and carefully take it away:
➢Grab with one hand under the panel unit directly behind the glass, and with the
other hand grab the handle. Then carefully lift the GhosT-OLED a bit until you can
change the position of the hand on the panel unit:
Note: Make sure that the GhosT-OLED cannot tilt during changing the grab of the hand on
the panel unit

Manual GhosT-OLED with LG 55EW5F-A
11.02.2021
Page 18 of 45
➢Carefully lift the GhosT-OLED out of the wooden box:
➢Place the GhosT-OLED on a flat and clean surface. If necessary, take further
precautions for a secure stand of the display

Manual GhosT-OLED with LG 55EW5F-A
11.02.2021
Page 19 of 45
4.3 Changing the foot orientation of GhosT-OLED Full Kit and Full Kit PCAP
Required Tools: 6mm Allen Key
➢Use a soft and clean underlay with a thickness of about 3-5mm. Make sure the glass
rests safely and that there is no force applied to the glass:
➢Loosen the two screws at the left and right side with a 6mm Allen Key. It will take
only a few rotations (2-3) until the mechanism is unlocked. Always secure the panel
during your work:

Manual GhosT-OLED with LG 55EW5F-A
11.02.2021
Page 20 of 45
➢Carefully rotate the panel by 90° to the front. Secure the glass. No force should ever
be applied:
➢Tighten the screws until the green mark fills exactly half of the slot:
