ExBrite LSJSBM6028BLAL Series User manual

See Better with Smart Lights
Installation and Operating Manual
The clock version
LSJSBM6028BLALXXX
LSJSBM3872BLALXXX
LSJSBM6028FLALXXX
LSJSBM3872FLALXXX
The standard version
LSJSBM3036BLWXXX
LSJSBM2436BLWXXX
LSJBS3535BLWXXX LSJSBM3036DKSXFLX
LSJSBM2436FLWXXX

See Better with Smart Lights
WARNING AND SAFETY INSTRUCTIONS
Please make sure that you carefully read through this instruction sheet refer back to them during installation
to ensure your product is fitted safely and correctly before installing your LED Lighted Mirror fixture. Keep
these instructions for future use.
WARNING Risk of Fire and Electric Shock
●All fittings must be installed in accordance with current IEE wiring regulations. If in doubt, consult a
qualified electrician.
●Switch off the electrical supply at the main circuit board BEFORE installation and maintenance.
●Suitable for indoor use only. This product should be positioned well away from curtains and fabrics.
Never cover the mirror.
●Regularly check the cord, the transformer and all other parts for damage. If any part is damaged the
product should not be used.
INSTALLATION SAFETY
●Inspect the product immediately upon receipt for the transit damage or missing parts. Handle the
product with care and protect against knocks to all sides and edges of the glass.
●Ensure there are no hidden pipes or cables in the wall before drilling.
●Wear suitable eye protection when drilling. Take care if drilling on tiled surfaces in case the drill slips.
CAUTION
The light source of this product is non‐changeable light diodes (LED). Do not disassemble the product, as the
light diodes can cause damage to the eyes.
NOTE: The important safeguards and instructions that appear in this manual are not meant to cover all
possible conditions and situations that may occur. It must be understood that common sense, caution and
care, are factors that can’t be built into any product. These factors must be supplied by the person(s) caring
for and operating the fixture. Do not install this fixture in hazardous locations.

See Better with Smart Lights
CHECK PRODUCT LIST AFTER OPENING THE PACKAGE
●LED Lighted Mirror ‐‐1 pcs ●Screws for wall ‐‐3~6 pcs
●Mounting bar ‐‐1 pcs ●Type A Plastic Anchor ‐‐3~6 pcs
●Installation Manual ‐‐1 pcs ●Type B Plastic Anchor ‐‐3~6 pcs
TOOLS YOU MAY NEED
INSTALLATION MANUAL
1Level and mark the location (vertically hanging and horizontally hanging)
Notes: 1. Fix the mounting bar into the wall firstly with the distance as above drawing;
2. For the mirror with ON/OFF button in the right bottom side, we have the special design to
hang the mirror either vertically or horizontally;
3. The distance between each 2 hanging holes is 7⅞ inch.

See Better with Smart Lights
2Place the mounting bar against the
wall and make some marks on the wall
3Drill the holes and place
the suitable plastic anchors
4Screw the mounting bar onto
the wall with the screw
5Connect the mirror with the main supply.
●We provide plug with mirrors.
●Optional to cut the plug directly, then connect
to electrical wiring if using wall switch.
ATTENTION: PLEASE CUT OFF THE MAIN POWER
SUPPLY BEFORE WIRING !
6Hang the mirror onto the mounting bar (vertically hanging and horizontally hanging)

See Better with Smart Lights
OPERATION INSTRUCTION
ON/OFF and CCT adjustment
ON/OFF button
●Button turns blue when connected to main supply.
●Button always on as long as connecting to main supply.
●Short‐touch the button to turn on/off the mirror.
●Adjusting color temperatures (CCT) between warm white and
cool white by long‐touching the button for seconds.
●Finish setting by withdrawing your finger when the color
reaches the one you need.
●Optional to be wired to wall switch by ON/OFF memory
function.
ON/OFF and Dimmer
Press and hold on for 3‐5 seconds
●Short‐touch the button to turn on/off the mirror.
●Long touching the button to adjust the brightness (Dimming).
Anti‐Fog Function
Defogger button
●Mirror begins to be warm and defog after pressing the defogger
button. Press again to quit the anti‐fog function.
●Note: The defogger will stop automatically after 60 minutes of
continuous operation to prevent any damage caused by
prolonged high temperature.

See Better with Smart Lights
Clock/Temperature
(This operation is specific to the clock version)
●Turn off the light to set the clock.
●Long touch button 1 or 2 for seconds, the Hour will
flash, then short‐touch button 1 and 2 to set Hour.
●Wait for seconds after setting up the Hour, then it
will automatically switch to the Minute flash.
●Short‐touch button 1and 2 to set up the Minute.
●Wait seconds after you finish the time setting, the
time will be saved automatically.
●The clock shows for 5s, and shift to the temperature
showing for 2s, then go back to show the clock.
●It automatically displays the indoor temperature by auto sensing through the temperature sensor.
●DO NOT cover the temperature sensor.
●Night light will be auto‐on/off according to the brightness surrounding when the rocker switch is
keeping turned on.
●If need turn off the nightlight at night, please turn off the rocker switch manually.
AFTERCARE INSTRUCTIONS
Clean using a soft dry cloth only when turned off. Never use cleaning agents or abrasive materials. Do not
allow moisture to come into contact with lamp.
THANK YOU FOR YOUR SUPPORT.
We wish you have wonderful experience in our product. If you have any other needs or queries, please feel
free to contact us by email [e-mail], and get replies within 48 business hours.
