ExBrite DHMC2028V5RX User manual

LED Lighted Medicine Cabinet
Installation and Operating Manual
DHMC2028V5RX / DHMC2028V5LX
W20” x H28”
DHMC2432V5RX / DHMC2432V5LX
W24” x H32”
Series : LED Cabinet with external storage shelf and
Night light
DHMC2432V5RY / DHMC2432V5LY
W24” x H32”
DHMC3032V5TX W30” x H32” DHMC3632V5FX / DHMC3632V5FB
W36” x H32”

LED Lighted Medicine Cabinet
Installation and Operating Manual
DHMC4832V5FX / DHMC4832V5FB
W48” x 32”
For easy and safe installation, please refer to the following:
Read all instructions thoroughly before installing the enclosed product.
Read and take note of all safety, care and maintenance information.
PLEASE KEEP THIS INSTRUCTION MANUAL FOR FUTURE REFERENCE
DURING PRODUCT OPERATION AND MAINTENANCE.
Series : LED Cabinet with external storage shelf and
Night light

LED Lighted Medicine Cabinet
INSTALLATION INSTRUCTIONS
WARNING AND SAFETY INSTRUCTIONS
Before installing your LED Medicine Cabinet fixture,please make sure that you carefully
read through this instruction sheet, refer back to them during installation to ensure your
product is fitted safely and correctly. Keep these instructions for future use.
WARNING Risk of Fire and Electric Shock
●All fittings must be installed in accordance with current IEE wiring regulations. If in
doubt, consult a qualified electrician.
●Switch off the electrical supply at the main circuit board BEFORE installation and
maintenance.
●Suitable for indoor use only. This product should be positioned well away from
curtains and fabrics. Never cover the mirror.
●Regularly check the cord, the transformer and all other parts for damage, if any part is
damaged the product should not be used.
INSTALLATION SAFETY
●Inspect the product immediately upon receipt for any possible damage during
transportation or missing parts. Handle the product with care and protect against
knocks to all sides and edges of the glass.
●Ensure there are no hidden pipes or cables in the wall before drilling.
●Wear suitable eye protection when drilling. Take care if drilling on tiled surfaces in
case the drill slips.
CAUTION
The light source of this product is non-changeable light diodes (LED). Do not
disassemble the product, as the light diodes can cause damage to the eyes.
NOTE:The important safeguards and instructions that appear in this manual are not
meant to cover all possible conditions and situations that may occur. It must be
understood that common sense, caution and care are factors that can't be built into
any product. These factors must be supplied by the person(s) caring for and operating
the fixture. Do not install this fixture in hazardous locations.

LED Lighted Medicine Cabinet
Z-Bar x1
Z-Hook x1
Matching screws x2
hinge cover X 2-6
for spare
30”*26”/20”*28”:
Glass shelves x 2
Other size:
Glass shelves x 3
Side panels x 2
Side panel lids x4 ,
Matching screws
x10
Wire caps x3 Anchor x5-7Round head
screw x5-7
REQUIRTOOLSED
PARTS SUPPLIED

LED Lighted Medicine Cabinet
Verify minimum clearances
STEP 1
STEP 2
Cabinet installation Instructions for Hanging Walls

LED Lighted Medicine Cabinet
The side panels and cabinets are individually packaged ,
you need follow the STEP 5 to STEP 7 to install the side panels
for hanging walls version,for embedded installation no need
install the side boards.
Press down the side
panels until they are
clamped tightly with
the cabinet.
Align the slots inside of the side
panels and cabinet.
Cabinet installation Instructions for Hanging Walls
STEP 5
STEP 3
Secure the bar with round-head screws
STEP 4

LED Lighted Medicine Cabinet
Cabinet installation Instructions for Hanging Walls
STEP 7 STEP 8

LED Lighted Medicine Cabinet
Cabinet installation Instructions for Hanging Walls
Insert the glass shelves between
the layer board clips.

LED Lighted Medicine Cabinet
Cabinet embedded Installation Instructions
Determine the size of the opening
*All diagrams are for reference only.All model dimensions and proportion
sposition will vary.
STEP 1 STEP 2
STEP 4
STEP 3
STEP 2
STEP 4

LED Lighted Medicine Cabinet
1.Insert the hings to the base ,then connect the doors with the cabinet
2.Adjust corresponding screws on the hinge to align the doors, ensure
that gaps are even and the doors open and close smoothly
3.Insert the wire on the door into the terminal on the cabinet and tighten
the screw
Instructions for assembling the doors and cabinet--
Suit for the items which doors and cabinet are separately packaging
(considering the huge weight, we suggest installing the cabinet first,
then assemble the door with cabinnet as below steps)

Short ‐touch the button to turn on/off the mirror.
Adjusting color temperatures (CCT) between warm white and cool
white by long ‐touching the button for seconds.
Finish setting by withdrawing your finger when the color reaches the
one you need.
Optional to be wired to wall switch by ON/OFF memory function.
Short‐touch the button to turn on/off the mirror.
Long touching the button to adjust the brightness (Dimming).
Finish setting by withdrawing your finger when the brightness
reaches the one you need.
Mirror begins to be warm and defog after pressing the defogger button.
Press again to quit the anti ‐fog function.
Note: The defogger will stop automatically after 60
minutes of continuous operation to prevent any
damage caused by prolonged high temperature.
LED Lighted Medicine Cabinet
Manual to turn on/off light,dimming,CCT changing with touch switch

LED Lighted Medicine Cabinet
Manual to setting clock with touch switch
Choose and set the clock and temperature mode
-Turn off the light.
-Long-touch button 2 to choose and set the mode when it flash.
There are two clock and temperature modes to choose.
A: 12C/12F: Fahrenheit (F) and 12 hours
B: 24C/24F: Celsius (C) and 24 hours
The default mode is 12C/12F.
Setting the clock
-Turn off the light to set the clock.
-Long touch button 1 for seconds,the Hour will flash, then short-touch
button1 and 2 to set Hour.
-Wait for seconds after setting up the Hour,then it will automatically switch
to the Minute flash.
-Short-touch button 1and 2 to set up the Minute.
-Wait seconds after you finish the time setting,the time will be saved
automatically.
Turn on/off the touch switches’ blue background ligth
-In default mode the touch switches is with blue background light ,
long-touch button 3 to turn on/off the blue background light.
Remarks:
*The clock shows for 5s, and shift to the temperature showing for 2s, then
go back to show the clock.
*It automatically displays the indoor temperature by auto sensing through
the temperature sensor.
*DO NOT cover the temperature sensor.
Button 1 Button 2 Button 3

LED Lighted Medicine Cabinet
Night Light
Inside Night Light
- The Night Light inside the cabinet will be auto-on/off according to the
brightness surrounding when the door be opened.
- Don’t cover the night light sensor.
External Night Light
-The Night Light will be auto-on/off according to the brightnes surrounding
when the rocker switch is kepping turned on.
- If need turn off the night light at night,please turn off the rocker switch
manually.
- Don’t cover the night light sensor.
