Eurotech FUZ5B-LO Quick start guide

FUZ5B-LO/FUZ6B-HI

Key
Spare
Description
Part List
Part Qty.
Arm Bolts
Back Bolts
FUZ5B-LO Backrest
FUZ6B-HI Backrest
Seat
Armrests
Star Base
Caster
Seat Post(Cylinder)
FUZ5B-LO/FUZ6B-HI
G
F
1
1
1
1
1
1
1
2
5
6
Washers for Arm Bolts
(Ø8.3*12.5*2mm)
Allen Wrench
1
1
6
3
E
D
C
B
A
H
I
K
J
(M8 X 17mm)
(M8 X 15mm)
ASSEMBLY INSTRUCTIONS
(1 left & 1 right armrest)
r

C
K
D
D
H
J
J
H
Press the Casters (G) into the holes at the end of each leg of
the Base (F).
Insert Seat Post (E) into the center hole of the Base (F).
Please be careful to use the correct Arm Bolts (H), Washers (J)
and Armrests (D) which are marked Left and Right.
For easy assembly, place the Seat Cushion (C) face down on a
flat surface. Attach Armrest (D) to the Seat Cushion (C) as
shown using 1 Arm Bolt (H) with 1 Washer (J) on each arm.
Tighten the bolts securely with the enclosed Allen Wrench (K).
Please be careful to use the correct Back Bolts (I).
Attach the Backrest (B) to the Seat Cushion (C) using 3
Back Bolts (I) .
Tighten the bolts securely with the enclosed Allen
Wrench (K).
FUZ5B-LO/FUZ6B-HI
Now turn the assembled seat upright and locate the
center hole of the Mechanism over the Seat Post.
Push down firmly until the connection is secure.
C
B
I
I
K
Seat must slide into the slot on back.
r
r
E
F
G
rr
rr

FUZ5B-LO/FUZ6B-HI
While seated, pull the single rod control
lever completely backward and lean
against the back. When your desired
angle is achieved, return the lever to the
original middle positions to lock your tilt
angle into place. There are 3 positions
that provide 27º of range.
A1 HEADREST HEIGHT ADJUSTMENT A2 HEADREST ANGLE ADJUSTMENT
A1 HEADREST HEIGHT ADJUSTMENT
While seated, hold headrest frame
and move up or down to adjust
height. There are 5 positions with
a 2.36” range of adjustment.
For FUZ6B-HI only.
A2 HEADREST ANGLE ADJUSTMENT
A3 HEADREST FORWARD AND BACKWARD
ADJUSTMENT
While seated, hold the headrest
cushion and turn to adjust the
angle. The Headrest has a 58º angle
adjustment.
For FUZ6B-HI only.
While seated, push the headrest cushion
forward and backward to a desired
position. There is a 3.9" range of adjustment.
For FUZ6B-HI only.
A3 HEADREST FORWARD AND BACKWARD ADJUSTMENT
B1 BACKREST TILT ANGLE ADJUSTMENT
B2 BACKREST TENSION ADJUSTMENT
B2 BACKREST TENSION ADJUSTMENT
While seated, turn the Backrest Tilt
Tension Adjustment knob clockwise or
counterclockwise to adjust the tilt tension
to your preferred level of resistance.
B1 BACKREST TILT ANGLE ADJUSTMENT

FUZ5B-LO/FUZ6B-HI
C1 ARMREST HEIGHT ADJUSTMENT
D1 SEAT HEIGHT ADJUSTMENT
C1 ARMREST HEIGHT ADJUSTMENT
B. The armrest at a 90 angle while the
armrest is 1" higher than the elbow
provides optimum comfort.
A. While seated, push the button on the
outside of each arm and move the armrest
up or down. Release the button when you
have reached your desired height.
There are five positions where the arm
height can be locked.
The arm height adjustment range is 6.3”.
º
D1 SEAT HEIGHT ADJUSTMENT
While seated, pull the single rod control
lever upward and hold it while raising or
lowering the seat to reach your desired
seat height. When the lever is released
to its original position, the seat height is
locked. The seat height adjustment range
is approximately 3.3”.

• For all products except for 24/7 chairs (see below), Eurotech warrants to the original
purchaser all components for the life of the product with the exception of upholstery
and foam, which will be warranted for five years.
• For 24/7 chairs, Eurotech warrants to the original purchaser of all 24/7 chairs all components
for 10 years with the exception of upholstery and foam which will be warranted for 2 years.
• Eurotech warrants to the original purchaser that all parts will be free from material defects.
• Eurotech does not warrant any aftermarket hardware that is installed on the product.
• Eurotech does not warrant customer’s own material.
This warranty is made as of 9/15/16. Please see http://www.eurotechseating.com/warranty-
information for any updates and/or revisions to this warranty.
those specifically described.
Eurotech will repair or replace, at its option, any unaltered components.
• Eurotech’s warranty is limited to the normal use of the product in a forty hour work week
and a 250lb. weight limit unless otherwise noted.
• Eurotech shall NOT be liable for consequential or incidental damage arising from any
product defect.
• Eurotech’s warranty is limited to replacement or repair and does not cover cost of
transportation and labor. There are no other warranties expressed or implied other than
OUR PROMISE.
They say with age comes wisdom. And while we’ve learned a lot since we sold
our first office chair in 1979, even then we knew that superior craftsmanship and
design are essential ingredients in delivering real value for our customers. All
these years later, those three simple pillars still stand behind our promise of
exceptional seating with every chair we sell.
DESIGN CRAFTSMANSHIP VALUE
Eurotech. Sit Smarter.
THE EUROTECH WARRANTY
