Excel Mobility Travelux Tiempo User manual

Travelux Tiempo
User Manual

Contents
1. Introduction
1.1 Dealer Information
2. Product Identication
2.1 Scooter Components
2.2 About The Travelux Tiempo
3. General Safety
3.1 Warnings
4. User Instructions
4.1 Before Driving
4.2 Getting On The Scooter
4.3 Getting Off The Scooter
4.4 Whilst Driving
4.4.1 Driving Up Inclines
4.4.2 Driving Down Inclines
4.5 Steering
4.5.1 Steering Backwards
4.6 EMI / RFI
4.6.1 EMI / RFI Recommendations
5. Scooter Specications
6. Scooter Components
6.1 Dashboard Specications
6.2 Tiller
6.3 Armrests
6.3.1 Armrest Width Adjustment
Page 1
Page 2
Page 3
Page 4
Page 4
Page 5
Page 5
Page 7
Page 7
Page 7
Page 8
Page 8
Page 8
Page 9
Page 9
Page 9
Page 10
Page 10
Page 11
Page 12
Page 13
Page 14
Page 15
Page 15
© 2019 Travelux, part of Van Os Medical Ltd. | Excel House | Ashbrooke Park | Lincoln Way | Sherburn-in-Elmet | North Yorkshire | LS25 6PJ
T: [phone] | E: [e-mail] | W: www.vanosmedical.co.uk
© 2019 Travelux, part of Van Os Medical Ltd. | Excel House | Ashbrooke Park | Lincoln Way | Sherburn-in-Elmet | North Yorkshire | LS25 6PJ
T: [phone] | E: [email protected] | W: www.vanosmedical.co.uk
User Manual | Travelux Tiempo

6.3.2 Armrest Removal
6.4 Freewheel
6.5 Battery
6.5.1 Charging Batteries
6.6 Wheels
6.6.1 PU Tyres
6.6.2 Anti-tip Wheels
7. Transportation
7.1 Disassembly
7.1.2 Assembly
8. Maintenance
8.1 Tyres
8.2 Bodywork
9. Service Checklist
9.1 Service Checklist Form
9.2 Error Codes
10. Warranty Application
10.1 Warranty Conditions
Conformity Declaration Certicate
Page 16
Page 16
Page 17
Page 17
Page 18
Page 18
Page 18
Page 19
Page 19
Page 19
Page 20
Page 20
Page 20
Page 21
Page 22
Page 23
Page 24
Page 24
Page 26
© 2019 Travelux, part of Van Os Medical Ltd. | Excel House | Ashbrooke Park | Lincoln Way | Sherburn-in-Elmet | North Yorkshire | LS25 6PJ
T: [phone] | E: [email protected] | W: www.vanosmedical.co.uk
User Manual | Travelux Tiempo User Manual | Travelux Tiempo

The warnings mentioned in this user manual must always be followed,
in order to prevent damage to your Travelux Tiempo scooter or and
injury to yourself.
Tip The tips mentioned in this user manual are intended to make better use
of your Travelux Tiempo scooter.
Before you use your new Travelux Tiempo, you must fully read and understand this user manual. Once
you have read this user manual, you agree to the conditions mentioned in this user manual. We want to
thank you for the condence in our Travelux ® products.
The policy of Van Os Medical is focussed on continuously improving the quality and reliability of our
products. We therefore reserve the right without further notice to make any changes to this user
manual.
It is important you read this user manual very carefully, before you use your scooter. This user manual
contains important information about the safe use and maintenance of your scooter. We recommend
you keep this user manual safe because it is also your proof of warranty.
The safety instructions within this user manual are general guidelines, which must be seen as overall
guidelines. It is possible that you develop your own way to make common movements. However we
always advise you to consult a professional for assistance in developing safe and effective techniques,
regarding your daily activities within your physical capabilities, for operating your product safely.
Your new scooter requires frequent general maintenance to prolong the life of your scooter, much of
which you can do yourself. We advise you to take your scooter to a professional for a check at least
once a year. You will nd a maintenance schedule further on in this user manual.
Attention!
In this user manual you will nd tips and warnings. These are clearly identied by symbols and display
of the text. See examples below.
Warning
1. Introduction
1
© 2019 Travelux, part of Van Os Medical Ltd. | Excel House | Ashbrooke Park | Lincoln Way | Sherburn-in-Elmet | North Yorkshire | LS25 6PJ
T: [phone] | E: [e-mail] | W: www.vanosmedical.co.uk
© 2019 Travelux, part of Van Os Medical Ltd. | Excel House | Ashbrooke Park | Lincoln Way | Sherburn-in-Elmet | North Yorkshire | LS25 6PJ
T: [phone] | E: [email protected] | W: www.vanosmedical.co.uk
User Manual | Travelux Tiempo

Company Name :
Dealer Address :
Telephone Number :
Email Address :
Website Address :
..............................................................................................
..............................................................................................
..............................................................................................
..............................................................................................
..............................................................................................
1.1 Enter Your Authorised Dealer Information
2
© 2019 Travelux, part of Van Os Medical Ltd. | Excel House | Ashbrooke Park | Lincoln Way | Sherburn-in-Elmet | North Yorkshire | LS25 6PJ
T: [phone] | E: [email protected] | W: www.vanosmedical.co.uk
User Manual | Travelux Tiempo User Manual | Travelux Tiempo

3
Your scooter is equipped with a unique serial number. You will nd this number on the frame of your
scooter. Please see below for an example of the frame label sticker. Here you will nd details of all the
information on the frame label along with an explanation listed below.
1. Production Date
The date of manufacture.
2. Serial Number
Every scooter has its own unique serial number. You need this number if you have any technical
questions or if you want to order any parts under warranty for the scooter.
3. Maximum Weight
The maximum weight allowed on the scooter.
4. Model Number
This number indicates which model of scooter you have. You need this number when you have any
technical questions or if you want to order any parts for the scooter.
5. Model Name
The model name of your scooter starts with the brand name Travelux. The brand name Travelux,
followed by the additional model description forms the model name of the scooter. You need the
model name if you have any technical questions or if you want to order any parts for the scooter, in this
case the Travelux Tiempo.
6. Description
The intended use of your scooter is described here.
7. Warranty
Here, the warranty period of your scooter is reected. Section 9 describes the warranty conditions in
further detail.
113
SN
MAX.
KG
00/00/0000
Garantie:
Warranty:
Garantie:
10 jaar
10 years
10 ans
(uitgezonderd van garantie zijn onderdelen die onderhevig zijn aan slijtage)
(parts subject to normal usage wear and tear are excluded from warranty)
(la garantie exclue les pièces d´usures normal)
24 maanden
24 months
24 mois
Travelux Tiempo
Lightweight 4 mph scooter.
Van Os Medical UK Ltd. Excel House 2 Ashbrooke Park Lincoln Way Sherburn in Elmet North Yorkshire LS25 6PJ | www.vanosmedical.co.uk
10
10
2
2
1
2
3
4
5
67
2. Product Identication
© 2019 Travelux, part of Van Os Medical Ltd. | Excel House | Ashbrooke Park | Lincoln Way | Sherburn-in-Elmet | North Yorkshire | LS25 6PJ
T: [phone] | E: [e-mail] | W: www.vanosmedical.co.uk
© 2019 Travelux, part of Van Os Medical Ltd. | Excel House | Ashbrooke Park | Lincoln Way | Sherburn-in-Elmet | North Yorkshire | LS25 6PJ
T: [phone] | E: [email protected] | W: www.vanosmedical.co.uk
User Manual | Travelux Tiempo

4
Your scooter is equipped with various components and parts. You should know these components and
parts before proceeding to use the Travelux Tiempo scooter.
1. Backrest
2. Armrests
3. Seat
4. Dashboard
5. Tiller
6. Basket
7. Tiller Adjustment
8. Battery
9. Freewheel Lever
10. Rear Wheels
11. Front Wheels
1
2
3
4
56
789
10
2.1 Scooter Components
The Travelux Tiempo is a comfortable and lightweight 4 mph travel scooter with the ability to
dismantle into sections for transportation. This scooter comes with a range of features including all
black puncture proof PU tyres, swivel chair, adjustable tiller, width adjustable and removable armrests.
The Travelux Tiempo is also available in 4 striking metallic colours. Suitable for users up to 17 Stone in
weight. The Travelux Tiempo is a scooter that comes standard with;
• PU tyres
• Small storage basket
• Angle adjustable tiller
• Electromagnetic brake
• User friendly dashboard
• Wig-wag operation system
• Easy adjustable steering column
• LED energy efcient longer lasting bulbs
• Swivel chair with foldable backrest
2.2 About The Travelux Tiempo
11
• Width adjustable and ipback removable
armrests
• Removable battery pack for optional remote
charging
• Available colours: Benz Silver, Cooper Blue,
Gallardo Orange and Tuscan Red
© 2019 Travelux, part of Van Os Medical Ltd. | Excel House | Ashbrooke Park | Lincoln Way | Sherburn-in-Elmet | North Yorkshire | LS25 6PJ
T: [phone] | E: [email protected] | W: www.vanosmedical.co.uk
User Manual | Travelux Tiempo User Manual | Travelux Tiempo

Van Os Medical will not take responsibility for any injuries or property damage, in the unlikely event of
an accident when the recommendations and warnings described in this user manual are not followed.
The Travelux Tiempo is a very safe product when used correctly and if operated incorrectly may cause
injuries or damage.
Protect your scooter by checking it regularly. When any part of your Travelux Tiempo doesn’t function
correctly, a dangerous situation could occur. Therefore, you must keep your scooter in perfect
condition, to ensure safe use. Periodical inspection, a correct adjustment and replacement of broken
or worn parts in quick time will result in use for years without any problems. An authorised Travelux
dealer, who will only use Travelux replacement parts, will take care of your scooter and make sure you
can use your scooter for years without problems.
To prevent any damage to your property, the scooter or the user of the scooter, you must read the
following warnings. Failure to follow all the instructions in this user manual may result in damage to the
scooter or serious injury.
3.1 Warnings!
• Always operate your scooter with thought, care and safety.
• Do not drive into kerbs.
• It is important that the maximum user weight is not exceeded. The maximum user weight is the
weight of the person including luggage etc.
• Unauthorised modication and or use of parts not supplied by Travelux will invalidate the scooter
warranty which may lead to user injury or and damage to the scooter.
• Do not let children play with or on your scooter and allow any children to sit on your lap
• To avoid a tipping hazard, do not make sharp turns at full speed.
• All wheels must be in contact with the oor at all times during use. This will ensure the scooter is
properly balanced.
• Do not use your scooter when it is damaged or has any malfunction.
• Do not attempt to use your scooter on an escalator. Always use an elevator.
• Do not carry passengers under any circumstances.
• Always make sure the scooter is off before mounting or dismantling.
• Do not drive backwards or across on an incline or across an uneven surface.
• Always make sure the seat is locked forward before operating your scooter.
• Always come to a full stop before charging direction from forward to reverse or from reverse to
forward.
• Do not use your scooter if you are under the inuence of alcohol, drugs or medication an offence
under The Road Trafc Act 1998.
• Do not climb ramps or kerbs that exceed your scooters capacity.
• Always approach inclines straight on.
• Always be aware of and careful near mechanical pinch points especially when assembling and
disassembling to your scooter.
3. General Safety
5
© 2019 Travelux, part of Van Os Medical Ltd. | Excel House | Ashbrooke Park | Lincoln Way | Sherburn-in-Elmet | North Yorkshire | LS25 6PJ
T: [phone] | E: [e-mail] | W: www.vanosmedical.co.uk
© 2019 Travelux, part of Van Os Medical Ltd. | Excel House | Ashbrooke Park | Lincoln Way | Sherburn-in-Elmet | North Yorkshire | LS25 6PJ
T: [phone] | E: [email protected] | W: www.vanosmedical.co.uk
User Manual | Travelux Tiempo

• Never sit on your scooter when it is being transported.
• If you need to transport the scooter by car, you should always do this with the right system
• Always keep extra care when driving on soft or uneven surfaces such as grass and gravel.
• Always cross streets at intersections and use crosswalks or the most direct route, making sure that
your path is clear and that you are visible to motor trafc.
• Never drive backwards off a kerb.
• Never drive a kerb or step up or down if it is higher than one third of the diameter of the wheels
in cm.
• Do not drive your scooter in icy or salted conditions.
• Always check with your doctor to determine if any of the medications you are taking may affect
your judgment and/or your ability to operate your scooter. Also check with your physician
concerning your physical ability to operate a scooter.
• Do not tow any type of load with the scooter.
• When driving outside, use pavements or bicycle lanes. Never drive in car lanes.
• Do not drive beside a river, port, or lake without a fence or railing.
• If possible, avoid driving in the rain or at night.
• Keep your arms on or inside the armrests and feet on the footplate or footrests at all times.
• Do not attempt to cross over a gap greater than 4”/10 cm.
• Be aware of trafc and other road users when crossing or using roads.
• Never ride on motorways or dual carriageways.
Any changes to the Travelux Tiempo scooter, which are structural
changes, are always at the expense of the warranty.
Warning
6
© 2019 Travelux, part of Van Os Medical Ltd. | Excel House | Ashbrooke Park | Lincoln Way | Sherburn-in-Elmet | North Yorkshire | LS25 6PJ
T: [phone] | E: [email protected] | W: www.vanosmedical.co.uk
User Manual | Travelux Tiempo User Manual | Travelux Tiempo

User Manual | Travelux Tiempo
It is very important that you teach yourself the correct user instructions. Therefore, you need to know
all the components of the scooter as described in this user manual. Always check with an expert about
developing safe methods regarding your physical abilities to use your scooter.
4.1 Before Driving
Please ensure you have familiarised yourself with how to operate this scooter safely before driving.
This scooter may only be driven on pavement in pedestrian areas up to a max speed of up to 4mph
(6.4 kph).
Before using the scooter in busy or hazardous environments, familiarise yourself with the operation of
the scooter. Practice operating the scooter in a safe open environment.
Practice operating your scooter up to 4 mph until you are condent that you can easily operate and
control the scooter at the higher speed (up to 8 mph).
4.2 Getting On The Scooter
• Before getting on the scooter make sure it is on a at surface.
• The scooter should always be in the drive gear before getting on the scooter.
• Always check if the scooter is turned off before getting on.
• You can do this by checking the LED lights on the dashboard, these should be off (no light).
• If the scooter is off, you eliminate the chance of accidentally touching the levers, possibly causing
injury to yourself or others. The tiller should always be upright.
• You can rotate the chair 90 degrees with the lever on the bottom right side of the chair. This way
you can easily get on and turn the chair back into driving position. You can also do this with the
armrests raised up.
• Put your foot in the middle of the footrest when getting in the scooter to ensure stability.
• If there is a seatbelt present, attach this before driving. For assuming the correct driving posture
you can adjust the tiller to a desired angle.
• Put the key into the ignition and turn one quarter to the right. The LEDs on the dashboard will
now light up and you will be ready to go.
4. User Instructions
7
© 2019 Travelux, part of Van Os Medical Ltd. | Excel House | Ashbrooke Park | Lincoln Way | Sherburn-in-Elmet | North Yorkshire | LS25 6PJ
T: [phone] | E: [e-mail] | W: www.vanosmedical.co.uk
© 2019 Travelux, part of Van Os Medical Ltd. | Excel House | Ashbrooke Park | Lincoln Way | Sherburn-in-Elmet | North Yorkshire | LS25 6PJ
T: [phone] | E: [email protected] | W: www.vanosmedical.co.uk

User Manual | Travelux Tiempo
• When getting off the scooter you should follow the same steps for getting on in reverse order.
• Put the tiller back into the upright position if not already.
• Make sure the scooter is always off and the key is removed from the ignition when getting off the
scooter.
• You can rotate the chair 90 degrees with the lever on the bottom right side of the chair. This way
you can easily get off and turn the chair back into driving position. You can also do this with the
armrests raised up.
4.4 Whilst Driving
• Do not move any part of your body out of the scooter whilst travelling.
• Ensure your clothing and other garments including accessories do not get tangled or caught on
the scooter handles or in the wheels.
• Plan your journey ahead and ensure you have enough power (miles) to take you to your nal
destination to avoid any unplanned routes which could result in injury to yourself and or damage
to your scooter.
4.4.1 Driving Up Inclines
• When driving up any incline always do so by going in a forwards direction and perpendicular to
the ramp or slope.
• Ensure you keep control when going up the incline by driving at a controlled average speed.
• Always keep the scooter in the drive gear and driving whilst going up an incline.
• In the event you stop on an incline, restart and increase speed slowly (The scooter may roll
backward slightly before continuing forward).
4.3 Getting Off The Scooter
• Do not get on or off the scooter whilst driving or and on an incline.
• Do not carry extra weight that exceeds the maximum user weight as the anti-tip
wheels are designed to keep the centre of gravity on the back of the scooter; as this
may cause unintended damage.
• Do not attempt to drive across a sloping surface greater than 3 degrees, this may
cause the scooter to tip over.
• Do not attempt to drive up an incline greater than 10 degrees.
• Do not go backwards down or up an incline.
Warning
8
User Manual | Travelux Tiempo
© 2019 Travelux, part of Van Os Medical Ltd. | Excel House | Ashbrooke Park | Lincoln Way | Sherburn-in-Elmet | North Yorkshire | LS25 6PJ
T: [phone] | E: [email protected] | W: www.vanosmedical.co.uk

User Manual | Travelux Tiempo
• When driving down an incline always do so by going in a forwards direction.
• Ensure you keep control when going down the incline by driving at a controlled average speed
and ready to brake if necessary.
• Always keep the scooter in the drive gear and driving whilst going down an incline.
4.4.2 Driving Down Inclines
Warning
• Never go up or down an incline that is covered with snow, ice, leaves,
pebbles/stones, wet grass or recently mowed grass. Avoid any ground that
may be dangerous to drive on.
• In the event your scooter builds momentum faster then you can control when
going down an incline, always slowly release the gas lever. By feeding less
power the scooter will automatically brake and cause the scooter to slow.
4.5 Steering
Tip The most important action on a scooter is steering. For driving comfort
always drive with arms slightly bent and hands on the handlebar.
• Turn scooter speed down to the lower setting.
• Steer in the desired direction.
• Slowly pull the throttle lever.
4.5.1 Steering Backwards
• Turn scooter speed down to the lower setting.
• Observe surroundings and pay attention to behind your scooter using your mirrors.
• Pull the left throttle lever.
• Turn the handlebar to the left to go left.
• Turn the handlebar to the right to go right.
9
© 2019 Travelux, part of Van Os Medical Ltd. | Excel House | Ashbrooke Park | Lincoln Way | Sherburn-in-Elmet | North Yorkshire | LS25 6PJ
T: [phone] | E: [e-mail] | W: www.vanosmedical.co.uk
© 2019 Travelux, part of Van Os Medical Ltd. | Excel House | Ashbrooke Park | Lincoln Way | Sherburn-in-Elmet | North Yorkshire | LS25 6PJ
T: [phone] | E: [email protected] | W: www.vanosmedical.co.uk

User Manual | Travelux Tiempo
10
The fast development of electronics, mostly in the area of communication, has ooded our world
with electromagnetic (radio) waves transmitted by TV, radio, laptops, microwaves and pacemakers.
These electromagnetic waves are invisible and get stronger the closer one gets to a source. If these
electromagnetic waves cause electrical appliances to stop functioning correctly or even completely
stop working, this is called Electromagnetic Interference (EMI) or Radio Frequency Interference
(RFI).
All electrical vehicles, including scooters, are susceptible for Electromagnetic Interference / Radio
Frequency Interference (RFI). This can result in unexpected movements of your scooter. Should
any unintended movements occur, or the brakes don’t work as normal, turn off your scooter
immediately. The FDA has ruled that every scooter should be able to resist EMI / RFI up to a
certain level. The higher the level of interference it can withstand, the better the protection against
EMI / RFI is. This is measured in volts per meter (V/m). The minimum resistance level against EMI /
RFI should be 20 V/m. This product has been tested and found to have a resistance level of 20 V/m.
4.6 EMI / RFI
• Do not use personal electronic communication devices like a mobile phone, when using your
scooter.
• Be extra careful when in the neighbourhood of radio and TV towers.
• Turn off your scooter when you are standing still for a longer time.
• If unintended movement or brake release occurs, turn off the scooter as soon as it is safe to
do so.
• Report all incidents of unintended movement or brake release to the manufacturer and note
whether there is a radio wave source nearby.
• Be aware that adding accessories or components, modifying the scooter may make it more
susceptible to interference from radio wave sources. (Note: there is no easy way to evaluate
their effect on the overall immunity of the scooter).
4.6.1 EMI / RFI Recommendations
User Manual | Travelux Tiempo
© 2019 Travelux, part of Van Os Medical Ltd. | Excel House | Ashbrooke Park | Lincoln Way | Sherburn-in-Elmet | North Yorkshire | LS25 6PJ
T: [phone] | E: [email protected] | W: www.vanosmedical.co.uk

Total length 102 cm
Total width 51 cm
Total height 90 cm
Total weight 48 kg
Max User weight 113 kg
Seat width 41 cm
Seat depth 40 cm
Seat height 50 to 55 cm (adjustable)
Turning radius 115 cm
Ground clearance 8 cm
Max. speed 4 mph
Battery 2 x 12V / 12Ah
Charger 24V / 4Ah
Range 16 km (10 miles)
Available colours Benz Silver, Gallardo Orange, Cooper Blue and Tuscan Red
© 2019 Travelux, part of Van Os Medical Ltd. | Excel House | Ashbrooke Park | Lincoln Way | Sherburn in Elmet | North Yorkshire | LS25 6PJ
T: [phone] | E: [e-mail] | W: www.vanosmedical.co.uk
User Manual | Travelux Tiempo
Below you nd the specications for The Travelux Tiempo.
5. Scooter Specications
11
© 2019 Travelux, part of Van Os Medical Ltd. | Excel House | Ashbrooke Park | Lincoln Way | Sherburn-in-Elmet | North Yorkshire | LS25 6PJ
T: [phone] | E: [e-mail] | W: www.vanosmedical.co.uk
© 2019 Travelux, part of Van Os Medical Ltd. | Excel House | Ashbrooke Park | Lincoln Way | Sherburn-in-Elmet | North Yorkshire | LS25 6PJ
T: [phone] | E: [email protected] | W: www.vanosmedical.co.uk

In this Section the different components of the Travelux Tiempo are described. On the scooter
are a number of components present which are adjustable. If you want to add or remove any
of its components, make any adjustments of replace components, you should always follow the
instructions described in this user manual.
The Travelux Tiempo is equipped with a clear dashboard. The dashboard consists or different
components that all have a different function. Below, several components are explained further:
© 2019 Travelux, part of Van Os Medical Ltd. | Excel House | Ashbrooke Park | Lincoln Way | Sherburn in Elmet | North Yorkshire | LS25 6PJ
T: [phone] | E: [email protected] | W: www.vanosmedical.co.uk
User Manual | Travelux Tiempo
6. Scooter Components
1
2
3
6
4
7
5
Photo 1 Dashboard display
12
User Manual | Travelux Tiempo
3
© 2019 Travelux, part of Van Os Medical Ltd. | Excel House | Ashbrooke Park | Lincoln Way | Sherburn-in-Elmet | North Yorkshire | LS25 6PJ
T: [phone] | E: [email protected] | W: www.vanosmedical.co.uk

1. On/Off Switch
Using this switch turns the scooter on or off. By inserting the key and turning the key 90 degrees
clockwise.This will start the scooter and by turning the key counter-clockwise this will turn the scooter
off. The Travelux Tiempo is designed to give one beep at the time when switched on along with the
battery indicator bulbs lighting up.
2. Speed Controller
This speed controller dial enables you to increase or decrease the speed of the scooter. To increase the
speed turn the dial right and to decrease the speed turn the dial to the left.
3. Control Levers
The Travelux Tiempo scooter is operated by a wig-wag system. To travel forward with you scooter, pull
the right lever towards yourself and to travel backward pull the left lever toward yourself when sat
down.
4. Battery Indicator
The battery indicator shows the level of power in the battery. Green means the battery is fully charged
and red means the power is running low and it is time to charge the battery.
5. Horn
By pressing this button, you can sound the horn. When used you will hear a beeping sound used as the
horn.
6. Lighting
This button turns on the lights on your scooter. The most important purpose of the lights is to be seen
by other road users or and pedestrians, to improve your safety. To turn the lights off, press the light
button again.
7. Parking Brake (not pictured)
The Travelux TIempo is equipped with automatic braking. When the forward or backward control lever
is released, the scooter will brake automatically to a standstill.
6.1 Dashboard Specications
13
Tip
It is important to avoid completely running out of power until the
battery is at. By recharging the battery when it hits 20 percent, you
can extend the battery life.
User Manual | Travelux Tiempo
© 2019 Travelux, part of Van Os Medical Ltd. | Excel House | Ashbrooke Park | Lincoln Way | Sherburn in Elmet | North Yorkshire | LS25 6PJ
T: [phone] | E: [e-mail] | W: www.vanosmedical.co.uk
© 2019 Travelux, part of Van Os Medical Ltd. | Excel House | Ashbrooke Park | Lincoln Way | Sherburn-in-Elmet | North Yorkshire | LS25 6PJ
T: [phone] | E: [e-mail] | W: www.vanosmedical.co.uk
© 2019 Travelux, part of Van Os Medical Ltd. | Excel House | Ashbrooke Park | Lincoln Way | Sherburn-in-Elmet | North Yorkshire | LS25 6PJ
T: [phone] | E: [email protected] | W: www.vanosmedical.co.uk

The Travelux Tiempo tiller can be adjusted in angle very easily. By adjusting the tiller into the
desired angle, your riding comfort will be increased. You can adjust the tiller angle by following the
steps below;
• Photo 2 shows the tiller in its most upright position.
• At the bottom of the tiller there is a star knob located at the bottom of the tiller. You must
unscrew this star knob by turning it counter-clockwise (left) to enable you to pull the tiller
towards yourself and adjust the angle.
• To set the adjusted tiller angle, you re-tighten the star knob.
• You should always put the tiller back in an upright position before getting off the scooter.
6.2 Tiller
Photo 2 Upright tiller position Photo 3 Tiller Star knob
14
User Manual | Travelux Tiempo User Manual | Travelux Tiempo
© 2019 Travelux, part of Van Os Medical Ltd. | Excel House | Ashbrooke Park | Lincoln Way | Sherburn in Elmet | North Yorkshire | LS25 6PJ
T: [phone] | E: [email protected] | W: www.vanosmedical.co.uk
Photo 4 Tilted tiller position
6.2 Tiller
© 2019 Travelux, part of Van Os Medical Ltd. | Excel House | Ashbrooke Park | Lincoln Way | Sherburn-in-Elmet | North Yorkshire | LS25 6PJ
T: [phone] | E: [email protected] | W: www.vanosmedical.co.uk

The Travelux Tiempo is equipped with width adjustable and ip-back removable armrests. The armrests
can be folded up or down (see photo 5 and 6). Folding the armrests makes getting on and off of your
scooter easier.
6.3 Armrests
The Travelux Tiempo is also equipped with width adjustable armrests. The width of both armrests can
be adjusted by using the knob located underneath each armrest (see photo 7). To adjust the armrest
width you need to loosen this knob and slowly pull out the armrest, to extend the width. To set this
adjustment, re-tighten the knob to x it.
6.3.1 Armrest Width Adjustment
© 2019 Travelux, part of Van Os Medical Ltd. | Excel House | Ashbrooke Park | Lincoln Way | Sherburn in Elmet | North Yorkshire | LS25 6PJ
T: [phone] | E: [e-mail] | W: www.vanosmedical.co.uk
User Manual | Travelux Tiempo
15
Photo 5 Down armrest Photo 6 Up armrest
Photo 7 Adjustment knob
© 2019 Travelux, part of Van Os Medical Ltd. | Excel House | Ashbrooke Park | Lincoln Way | Sherburn-in-Elmet | North Yorkshire | LS25 6PJ
T: [phone] | E: [e-mail] | W: www.vanosmedical.co.uk
© 2019 Travelux, part of Van Os Medical Ltd. | Excel House | Ashbrooke Park | Lincoln Way | Sherburn-in-Elmet | North Yorkshire | LS25 6PJ
T: [phone] | E: [email protected] | W: www.vanosmedical.co.uk

To make the Travelux Tiempo scooter even more compact for travel you can remove the armrests,
loosen and unscrew fully the same knob located underneath the armrest, which is also used for
adjusting the armrest width.
6.3.2 Armrest Removal
© 2019 Travelux, part of Van Os Medical Ltd. | Excel House | Ashbrooke Park | Lincoln Way | Sherburn in Elmet | North Yorkshire | LS25 6PJ
T: [phone] | E: [email protected] | W: www.vanosmedical.co.uk
User Manual | Travelux Tiempo User Manual | Travelux Tiempo
16
The Travelux Tiempo is equipped with two settings, namely the drive setting and freewheel setting
(see photo 8). The scooter should always be in drive when you want to use it. The freewheel setting
allows you to move the scooter without turning it on. When the scooter is put in freewheel mode, it
can be pushed without the motor giving resistance.
Please ensure the power is off when changing from drive to freewheel. If you turn the power on in
freewheel the scooter will not drive. To correct, turn the power off, change the position to drive and
turn the power on. In drive the electromagnetic brake is engaged so the scooter cannot be pushed can
only be driven. In freewheel the electromagnetic brake is not engaged, the scooter cannot be driven
because of this however you can push it.
6.4 Freewheel
Never put the scooter in freewheel setting when it is on an incline. This
way you prevent the scooter from rolling downwards unexpectedly.
Warning
Photo 8 Freewheel lever
© 2019 Travelux, part of Van Os Medical Ltd. | Excel House | Ashbrooke Park | Lincoln Way | Sherburn-in-Elmet | North Yorkshire | LS25 6PJ
T: [phone] | E: [email protected] | W: www.vanosmedical.co.uk

6.5 Battery
© 2019 Travelux, part of Van Os Medical Ltd. | Excel House | Ashbrooke Park | Lincoln Way | Sherburn in Elmet | North Yorkshire | LS25 6PJ
T: [phone] | E: [e-mail] | W: www.vanosmedical.co.uk
User Manual | Travelux Tiempo
17
6.5.1 Charging Batteries
The Travelux Tiempo is equipped with a removable battery pack with two closed maintenance free
batteries. which consists of two closed, maintenance free batteries. Van Os Medical recommends to
charge the batteries fully before rst use. We advise you to charge them for at least 12 continuous
hours. The Travelux Tiempo is equipped with an off-board charger of which you can either charge
the battery pack in its normal location on the scooter or away from the scooter. After each use we
also recommend to charge the batteries for 6 to 8 hours to extend the battery life.
Never turn the charger on before all plugs are plugged in
Warning
Tip
If you do not use the scooter for longer than a week you should always
disconnect the battery pack after fully charging, to avoid unnecessary
battery drainage.
Photo 9 Off-board charger
To increase battery life, you should charge the batteries as follows;
• Ensure the scooter is turned off
• Slide the battery cover off the charge
• Insert the charger plug into the socket
• The LED light will turn red, indicating the battery is charging
• When the batteries are fully charged the LED light will turn green
© 2019 Travelux, part of Van Os Medical Ltd. | Excel House | Ashbrooke Park | Lincoln Way | Sherburn-in-Elmet | North Yorkshire | LS25 6PJ
T: [phone] | E: [e-mail] | W: www.vanosmedical.co.uk
© 2019 Travelux, part of Van Os Medical Ltd. | Excel House | Ashbrooke Park | Lincoln Way | Sherburn-in-Elmet | North Yorkshire | LS25 6PJ
T: [phone] | E: [email protected] | W: www.vanosmedical.co.uk
