Majestic MS/9000 User manual

Comfy Go Mobility
Web:www.ComfyGoMobility.com, Email: [e-mail], Tel:[phone]
Folding Electric Scooter MS|9000
Operating Manual

Comfy Go Mobility
Web:www.ComfyGoMobility.com, Email: [e-mail], Tel:[phone]
Contents
Introduction..........................................................................................................................1
Specifications.................................................................. ....................................................2
Major Parts...........................................................................................................................3
Contents in Scooter Carton..................................................................................................4
Specification Diagram..........................................................................................................5
Main Operational Parts Function......................................................................................6-8
Folding and unfolding..........................................................................................................9
Battery and Charging....................................................................................................10-12
Battery Safety and Life Guide............................................................................................13
Instruction of Operation......................................................................................................14
Trouble shooting and maintenance...............................................................................15-16
Warranty.............................................................................................................................17
WarrantyCard....................................................................................................................18

Comfy Go Mobility
Web:www.ComfyGoMobility.com, Email: [e-mail], Tel:[phone]
1
Introduction
Dear User,
Thank you for choosing the MS|9000 Electric Scooter for your transportation needs. It is important to read
through this manual before operating your MS|9000 Electric Scooter to become familiar with its features
as well as its limitations and safety information.
You will find the operation and care of your MS|9000 Electric Scooter simple and easy.
Disclaimer: Comfy Go Mobility and partners cannot be held responsible for personal injury or property
damage resulting from the unsafe or improper operation or maintenance of MS|9000 Electric Scooter.
As part of our ongoing product improvement initiative, we reserve the right to change
specifications and design without notice. As a result, there may be minor differences between your
MS|9000 Electric Scooter and accessories and the photos, illustration and instruction in this manual.

Comfy Go Mobility
Web:www.ComfyGoMobility.com, Email: [e-mail], Tel:[phone]
2
Specifications
Model
MS|9000
Material
Aluminum alloy
unFolding size
L 940 W 470 H 920 mm
Folding size
L 720 W 470 H 365 mm
Packing size
L 550 W 440 H 820 mm
Color
Red , Orange , Blue
Motor
24 V 180 W
Battery charger
24 V 10 Ah
max speed
3.7 mph (0-6 km)
Driving range
18 km for single charging
Max load capacity
120kg
front wheels
6.5" ×2" PU wheel
rear wheels
7.5" ×2" PU wheel
climbing slope
6° ± 1°
seat height
550 mm from ground
turning radius
1200 mm
net weight without battery
20kg
net weight with batteries
22kg
Ground Clearance
40mm
Trench crossing ability
40mm
Drive system
S-drive 45 A, PG
braking system
Intelligent, Regenerative and Electromagnetic

Comfy Go Mobility
Web:www.ComfyGoMobility.com, Email: [e-mail], Tel:[phone]
3
Major Parts
1 Directional Control Lever 9 Transaxel 16 Side Seat Support Frame
2 Steering Post 10 Rear Wheel Cover 17 Rear frame
3 Tiller Angle Fixing Knob 11 Rear wheel 18 Middle Sliding Frame Cover
4 Front Wheel Cover 12 Batter Holder 19 Seat Cushion
5 Front wheel 13 Rear Bumper 20 Control Panel Cover
6 Front Bumper 14 Controller 21 Fixing Knob
7 Middle Sliding Outter Frame 15 Battery 22 Slide
8 Middle Slinding Inner Frame

Comfy Go Mobility
Web:www.ComfyGoMobility.com, Email: [e-mail], Tel:[phone]
4
Contents in Scooter Carton
Upon receipt of the scooter, please open carton packing and check if ther followings are
included:

Comfy Go Mobility
Web:www.ComfyGoMobility.com, Email: [e-mail], Tel:[phone]
5
Specification Diagram

Comfy Go Mobility
Web:www.ComfyGoMobility.com, Email: [e-mail], Tel:[phone]
6
Main Operational Parts Function
Handle Bar Set
The handle bar set including Control Panel
,Key Switch, Speed Setting Knob and Delta
Handle, Directional Control Lever. The major
operational functions are set.
Control Panel
Notice: Humidity of ambient environ
ment significantly affect on the opera
tional function main parts. Stay in low
moisture surrounding before operating
or during operating is strongly recom
mended.
Power Switch
Power is on after key switch turned clockwise,
scooter is ready to go.
Power is off if key is turned anti-clockwise,
scooter cannot be operated. Turn the power off
through key if drving is terminated.
Waring: Sudden immediately stop of scooter
occurs when power is switched off during operation
through eletromagnetic braking system control.
Speed Controller
The adjustment of driving speed through speed
control knob by finger range from 0 km/h to 6
km/h at your choice. Turn the knob to very left
for speed like turtle while turn very right rabbit
like speed.
Waring: Always keep lower speed level during
turning or backward for keeping safe.

Comfy Go Mobility
Web:www.ComfyGoMobility.com, Email: [e-mail], Tel:[phone]
7
Dispay
Battery Power is shown on display while power
is turned on.
Direction Control Lever
Forward and backward control is under Control
Lever.
a. Gently hold handle with both hands.
b. Scooter go forward by pulling lever on the
right with fingers.
c. Go backward by pulling lever on the left with
fingers.
d. Beef sound goes on during backward.
e. The Control Lever automatically to center
position while released and brake is on at the
same moment.
Steering Post
Tiller angle can be adjusted
by rotating the knob under the
post.

Comfy Go Mobility
Web:www.ComfyGoMobility.com, Email: [e-mail], Tel:[phone]
8
Controller
Located under rear cover which transfer the signal from control panel to motor, brake
and hub.
Notice: Keep controller under low moisture environment and make sure it is in dry
condition before operation.
Electric / Manual Mode Switch Lever
MAIN OPERATIONAL PARTS FUNCTION
Hand Brake on and off can be done by switching the lever for manual or electric control.
Electric Control Mode
Push down hand brake lever for electric control mode.
Pull up hand brake lever for manual push mode. trol
Manual Control Mode

Comfy Go Mobility
Web:www.ComfyGoMobility.com, Email: [e-mail], Tel:[phone]
9
Folding and unfolding
1. Folding and unfolding of the scooter is only applied through manual operationa.
2. First lift up and rotate the nob in the middle of frame for sliding in the frame to minimum length
through pushing the front post towards center with one hand, the other hand pushing from back of
scooter to center at the same time.
3. Unlock seat by pulling the lever under seat front till the locking lever ends reaches the top of fixing
holes on both side with a click sound, then push seat down slowy till it attaches bottom frame.
4. Rotating the locking knob at bottom of steering post for tilting down the post to the top of seat and
lock the knob again through rotating back.Scooter is fully folding to minimum Size.
5. To unfold the scooter mainly operate the reverse steps of folding scooter manually.

Comfy Go Mobility
Web:www.ComfyGoMobility.com, Email: [e-mail], Tel:[phone]
10
Battery and Charging
The scooter is designed for maintenance free with long usage of Lithium Ion Battery. It is suitable to be
Charged with 24 V 10 Ah charger.
1. Fully charge the battery 5 hours is good for battery usage. At least charge once in every 3 month.
2. Charge battery to full level and take apart battery from scooter if not going to use your scooter for long
period of time.
1. Power off the scooter. Open the cover of charger cap, then insert the charger plug in charge port of
scooter.
Warning: Make sure charger plug is fully plug in the charging port of scooter.
2. Connect the A/C power plug of charger to House power source. Check the light on charger, orange
color light means charging is in progress while green light shows power if full.
3. Turn off power charger when battery is fully charged. Disconnect AC power source before disconnect
the DC charging plug.
Warning: Disconnect AC power source after fully charge of battery will keep the life of Lithium Ion Battery
longer.
4. Charger red light is off while power source and power of charger is on. Please check if the power
connection is set properly.

Comfy Go Mobility
Web:www.ComfyGoMobility.com, Email: [e-mail], Tel:[phone]
11
5. Full charge time is around 5 hours duration.
The battery can be charged directly with house poer source,
simple connect the termial of battery with power source,
charging can be started.
1. Flip open the charger port protectoron the front of battery.
2. Use the secondary charger pigtail toadapt the battery
charger to plug into the battery directly.
Some knowledge on how charger charge battery
Large input of current from charge to battery at low voltage level, small current given from charger when
battery is close to full. Almost zero or little current given to battery, continuously charging would not cause
over charge, however, it is suggested charge duration not over 5 hours. The battery will continuous be
charged under charger connected situation.
The indication of charger lights
Two LED lights are on charger, red stands for power connection, the other is charging
status indication which shows charging with orange color and turns green on fully charged.
Red light may continue after power source disconnection, there maybe something wrong.

Comfy Go Mobility
Web:www.ComfyGoMobility.com, Email: [e-mail], Tel:[phone]
12
Normally red light will be off in a few seconds if disconnected to power source, it is normal
for red light to snuff out whille battery voltage is up to level.
Other type of charger
The charger is designed for battery of the scooter. Strongly suggest do not use other
type of charger from original manufacturer.
Frequency of Charging
The frequency of charging is based on the following conditions
A. All day long driving of scooter
B. Occasional driving scooter
Safe and reliable battery charging
A. Charge scooter after use if scooter is for daily use, it would full battery for next day. Fully charge is 5
hours depends on condition if battery is empty.
B. Charge scooter once a week when the use frequency is once in a week. Fully charge takes 5 hours.
C. Keep battery at full power.
How to reach maximum driving distance
A. Make sure full charge before driving
B. Keep away from go up hills, macadam and soft terrain.
C. Carry necessities, reduce load of scooter.
D. Drive smoothly without intermittent.
Suitable specification of battery
Lithium Ion battery with specification listed.
Warning
Do not take apart battery on your own. No need to add water for the battery.
Miss use of battery cause damage are excluded in warranty

Comfy Go Mobility
Web:www.ComfyGoMobility.com, Email: [e-mail], Tel:[phone]
13
Battery Safety and Life Guide
The reason of weak on new battery
The scooter use deep-cycle battery under special chemical technology that allow battery quick to be
charged with longer time use after full charge. Battery along with scooter packing is charged full, however,
the performance of initial power will be reduced in the process of transportation, such as temperature
variation.
High temperature causes battery power loss while low temperature lead to longer charging hours. It takes
a few days for adapting to ambient environment then turn to normal after transportation. It takes a few
days tor returning to stable perofmance after several charging and discharging cycles.
Steps of improving battery performance
A. Always charge to full when battery is new to ensure battery has 88% at least.
B. Always charge battery to full after use and keep on driving scooter is safe and familiar locations. Stay
low speed if you are first time user.
C. Charge battery to full after second time driving, it will increase the battery reach 90% capacity
performance.
D. After 4~5 times of driving with full charging, the performance of scooter will reach 100% level.
Ensure battery life
Full charge of battery keep good performance and life longer, while over charge and
seldom charge of battery damage.
Storage of scooter and Battery
Long time for not using scooter, please following the instruction for storage of scooter
A. Charge full battery
B. Disconnect battery
C. Keep scooter under dry and suitable temperature
D. Avoid dramatically temperature variation during storage
Warning
Keep in warm condition a few days when battery get frozened.
Long time storage of scooter is preferred lay a plate under foot rest panel for supporting and it will avoid
stain on tires after long time pressure to the ground.

Comfy Go Mobility
Web:www.ComfyGoMobility.com, Email: [e-mail], Tel:[phone]
14
Instruction of Operation
Before operating instruction
A. Make sure battery is fully charged.
B. Familiar with the route condition including crowd, animal and potential obstacles.
C. Always keep away from uneven and sloppy terrain.
D. Check if is fully inserted and the brake lever switch is pushed.
E. Steering with both hands rest on handle bar.
F. Sound the horn to check if it works.
Driving
Upon driving the scooter, please follow the following steps:
A. Unfold scooter fully.
B. Check if the seat at right position and adjust tiller to comfortable position.
C. Turn on power after making seat properly with hands on handle bar.
D. Gently push directional control lever with right thumb.
E. Brake release automatically and scooter move forward. Do not push control lever to much in a sudden
for the speed would be rapidly pick up.
F. Turn handle bar to left for turning left.
G. Right turning of handle bar to make right turn.
H. Scooter move straight forward by keeping handle in center position.
I. Brake is automatically on when control level in center position and once scooter stop going.
End of Driving
A. Make sure scooter is fully stopped.
B. Turn off Power with Key or turn the rocker switch to “O” position.
C. Carefully get off the scooter.
D. Fold scooter with 3 types of choice through Remote Controller, Electric Switch or by manual.

Comfy Go Mobility
Web:www.ComfyGoMobility.com, Email: [e-mail], Tel:[phone]
15
Trouble shooting and maintenance
The controller contains programs for identifying problem points and troubleshooting.
When the diagnostics detects problems and errors. The LED lights shine continuously in the form of a
flash until the fault is eliminated. Example: The number of flashes is “1-9” . Users can try to solve the
problem as follows.
If the problem persists, please contact us or our agent.
Number of
flashes
Fault description
Possible reason
1
Low battery voltage or
battery connection problem
Check the battery connection.
If there is no problem with the
connection, try charging the battery
2
There is a problem with the
motor connection
Check all connections between
the motor and the controller
7
Directional control
lever failure
Before turning on the power of the
scooter, make sure the directonal
control lvers is in the parking position.
9
Brake lever failure
Check the connection between the
brake lever and the motor to ensure
that the controller is securely connected.

Comfy Go Mobility
Web:www.ComfyGoMobility.com, Email: [e-mail], Tel:[phone]
16
Insufficient capacity of battery or dropped on performance
The decline issue of battery capacity or performance mostly can be sorted out as follows:
A.Inspect whether key is fully inserted and at ON position.
B.Make sure battery is fully charged.
C.Increase the charging cycle and time while battery capacity is dropped.
D.After going through above steps without any improvement, a capacity test on battery is required.
Though the scooter is designed service free, the followings have to be checked and
maintained.
Connection of Battery
A. Check if there is any corrosion and connection is sound.
B. Make sure battery is kept flat inside battery holder.
C. Any damage occurred of connections must be repaired or change new parts.
Plastic Cover
Never apply oil or chemical substances for cleaning plastic cover of scooter and wash
scooter with water avoid damaging electric components.
Bearing, Motor and Transmission
A.These component were lubricated and sealed during manufacturing process, not require for further
lubrication after purchasing.
B.Always keep electric component in dry condition, especially control panel, battery charger and all
electric components.
C.Dry any components which get moist before driving the scooter.

Comfy Go Mobility
Web:www.ComfyGoMobility.com, Email: [e-mail], Tel:[phone]
17
Warranty
The purchaser of this product is entitled to a limited warranty as offered by our
company, and its affiliates on the following components and timeframes:
※Scooter frame: 3 years
※Motors: 1 year
※Controller and CPU system: 1 year
※Battery: 6 months
※Wear parts: 3 months
Includes tires, seat and back rest, armrests, ans support straps.
This warranty is valid for the replacement of dysfunctional parts only. Any parts under warranty will be
replaced and shipped to your door. Any service and labor fees, if applicable, to replace parts under
warranty must be paid by the user.
Due to its straigtforward design, most parts can be easily exchanged by the end user without a
professional service tech required. However, it is always recommended you seek professional help for
maintenance and service, to make sure the work is down properly.
The warranty does not cover:
1. Products damaged by user negligence.
2. products damaged accidentally.
3. Products damaged intentionally.
4. Products that have been subjected to negligence.
5. Products that have been subjected to abuse.
6. Products that have been improperly stored.
7. Products that have been improperly handled.
8. Products that have been improperly operated.
9. Products that have experienced general misuse.
10. Products that have been modified in an unauthorized, unapproved way.
Warranty is non-transferable and only valid for the original scooter purchaser.

Comfy Go Mobility
Web:www.ComfyGoMobility.com, Email: [e-mail], Tel:[phone]
18
Warranty Card
User Name
ID No.
Address
Phone No.
Model
MS|9000
Product No.
Purchasing Date
(month) (day) (year)
Manufacturer
Distributor
(stamp or signature)
Distributor
(Phone,Address)
