Exit Light EB-LED User manual

EMERGE CY LED DRIVER |
170VDC | 8-20W OUTPUT
Code: EB-LED
FEATURES
UL Listed for factory and eld installation
Meets EC, IBC, and Life Safety Code Emergency Light
Requirements
High efciency performance meets CA Title 20
Ideal for many kinds of indoor LED lighting
Simple Wiring
Self-Testing (monthly/yearly)
Push to test button and AC Light
Single Flex
WARRA TY I FORMATIO
Any component that fails due to manufacturer’s defect is
guaranteed for 1 year. The warranty only covers products
installed and maintained in accordance with the instructions
provided by their respective manufacturer and no warranty is
made with respect to any of our products that are otherwise
installed or maintained. For full warranty details, visit our
Warranty Section.
Conformance to Codes and Standards
The EB-LED driver meets the following codes and listings:
EC, IBC, and Life Safety Code Emergency Lighting
Requirements. UL listed for factory and eld installations.
ORDERI G I FORMATIO
Series
Wattage
EB-LED
8W
20W

3170 Scott St, Vista, CA 92081
Phone: [phone] | Fax: [phone]
[e-mail]
CO STRUCTIO
The EB-LED emergency driver is constructed from durable
steel.
ELECTRICAL COMPO E TS
Model o. EB-LED-8W EB-LED-20W
Output Power 8W 20W
Output
Voltage 170V DC 170V DC
Input Voltage 100-347V AC,
50/60HZ 100-347V AC, 50/60HZ
Input Power 6W Max 12W Max
Input Current ≤ 100Ma ≤ 100Ma
Battery Type Lithium Lithium
Recharge
Time
≥ 24 Hours ≥ 24 Hours
Emergency
Time
≥ 90 Minutes ≥ 90 Minutes
Luminnare
Power 0-10V dimmable luminaire ≤ 60W
on-dimmable
luminaire ≤ 8W
0-10V dimmable
luminaire ≤ 100W
on-dimmable
luminaire ≤ 25W
EMERGE CY OPERATIO
The EB-LED emergency driver provides a minimum of 90
minutes of battery backup time
BATTERY - BATTERY BACKUP
The EB-LED emergency driver is designed with a
maintenance-free lithium battery that provides a minimum
emergency duration of 90 minutes. Recharge time of the
battery is 24 hours.
SELF-TESTI G OPTIO
The EB-LED emergency driver will perform an initial self-
diagnostic test for 3 seconds after the diver has been properly
installed followed by a second test after 120 minutes to
conrm the wiring and battery output. The driver will perform
monthly self-test every 30 days for 3 seconds; this will test for
wiring and battery output. *A blinking LED or completely off
means failed test.
OPERATIO AL TEMPERATURE
Temperature Ratings
Standard Option
41°F to 122°F
I STALLATIO
The EB-LED emergency driver can be installed in different
types of indoor troffers, strip xures, can lights, and LED
ceiling panels. We recommend conrming electrical specs to
make sure the LED Driver is fully compatible.
DIME SIO S
Weight : 5.00 lb
