Exmark Turf Ranger FMD524 Manual

FMD524/FMD604
SetupInstructions
ForSerialNos.720,000&Higher
LooseParts
Usethechartbelowtoverifythatallpartshavebeenshipped.
109-8511DealerPack
Part#DescriptionQty.Use
103-1309WarrantyRegistrationForm1Filloutwarrantyregistrationform.
109-8510LiteraturePack
Part#DescriptionQty.Use
—Manual,Operator’s1
—Manual,Parts1Readbeforeoperatingthemachine.
UncratetheUnit
Removethemowerdeckfromthecrate.
Note:Referencethetractorsetupinstructionsfor
componentsrequiredtocompletedeckinstallation.
InstallingtheMowerDecktoTurf
TracerUnits
1.Locatethedrivewheelreleasevalvesontherear
cornerofthehydrostaticpumps.
2.Witha5/8inchwrench,turnbothvalvesoneturn
counterclockwisetoreleasethedrivesystem.
3.Rollthetractortothemowerdeckassemblyand
allowthetractorassemblytotipbackwarduntilthe
rearoftheenginedeckcontactstheground.
4.Carefullyremovethetwohairpinsandspacersfrom
thefrontdecksupportpinsandlowerthefrontof
thedecktotheground.
5.Carefullyremovethetwohairpinsfromthereardeck
supportpinsandlowertherearofthedecktothe
ground.SeeFigure1.
6.Installthemowerdecksupportframetotractor
enginedeckandsecureusingeight3/8-16x11/4
inchscrews,eightspringdiscwashersandeight
whizlocknutsfromboltbag.SeeFigure1.
Note:Placespringdiscwasherconesideagainst
bolthead(cuppedsideawayfromhead)andinstall
tooutsideofsupportframeasshowninFigure1.
Installwithwhizlocknutstotheinsideofengine
deck.Tightenuntilspringwashersareat.
7.Positiontractorwithmowerdecksupportframein
place,overthemowerdeck.
Caution
Whenmowerdeckisnotinstalledorthetwo
frontsupportrodhairpinsareremovedfrom
themowerdeck,theunbalancedweightofthe
tractorortractorwithmountedmowerdeck
supportframemaycausethefrontoftheunitto
risesuddenly.Iftheunitrisessuddenly,injury
mayoccur.
Securelyholddownthefrontendoftheunit
whenthemowerdeckisnotinstalledorthe
supportrodhairpinsareremoved.
8.Alignandre-installthemowerdecksupportpins
intothesupportframe.Installthetwospacersand
hairpinsontothefrontsupportpinsandthetwo
hairpinsandspacersontotherearsupportpins.See
Figure1.
©1997–2007—ExmarkMfg.Co.,Inc.
P .O.Box808
Beatrice,NE68310
PartNo.4500-177Rev.A
PrintedintheUSA.
AllRightsReserved

Figure1
52inchdeckshownforreferenceonly.
1.Frontsupportpin4.Enginedeck
2.Mowerdecksupportframe5.Nutstoinside
3.Rearsupportpin
InstallingtheTurfTracerDecalon
theBeltShield
LocatetheTurfTracerdecal,peeloffbackingandplace
oncenterbeltshield.Smoothoutandremoveanyair
bubbles.
Note:DecalsuppliedwithTurfTracerunit.
InstallingtheStationaryIdlerand
DeckDriveBeltonTurfTracer
Units
1.Locatethetwoholesalongthebackcentersection
ofthedeckandinstallthestationaryidlerandrelated
parts(fromboltbag)intherighthandhole.Tighten
hardware.SeeFigure2.
Tightenhardware.
Note:Makesuretheconedendofthediscspring
washerisagainsttheheadofthebolt.
Figure2
1.Installidlerintherighthandhole.
2.Installthedeckdrivebeltaroundtheclutch.Refer
tobeltroutingdecallocatedontherearofthedeck.
Makesurebeltisintheclutchdrivesheavegroove.
3.PlacetheotherendofthebeltintotheV-grooveof
thestationaryidler,movethespringloadedidler
outwardandroutethebeltaroundtheinsideof
thespringloadedidler.Positionthebeltintothe
V-grooveofthemowerdeckdrivesheave.
4.Carefullyreleasethespringloadedidler.
5.Installthecenterbeltshield.
AdjustingtheCuttingHeight
Caution
Whenmowerdeckisnotinstalledorthetwo
frontsupportrodhairpinsareremovedfrom
themowerdeck,theunbalancedweightofthe
tractorortractorwithmountedmowerdeck
supportframemaycausethefrontoftheunitto
risesuddenly.Iftheunitrisessuddenly,injury
mayoccur.
Securelyholddownthefrontendoftheunit
whenthemowerdeckisnotinstalledorthe
supportrodhairpinsareremoved.
Installhairpinclipsintheholesforthedesiredcutting
height.SeeFigure3.
Important:Tomaintaincorrectcuttingheightand
rake,checkthefollowingforproperadjustment.
2

1.Thefrontandrearhairpinsareinthesameholeswith
theproperspacersunderthehairpins.SeeFigure3.
Figure3
1.Decksupportpin2.Cuttingheight
2.Thelengthofthereardecksupportlinkassemblies
average6.89inches(approximately67/8inches)
(175.01mm)fromthecenteroftheballjointtothe
centerofthefarthesthole.SeeFigure4.
Note:Allfourpinsmustequallysupporttheweight
ofthedeck.Adjustmentinthelengthoftherear
decksupportassembliesmaybenecessary.Ifone
sideislongerthan6.89inches(approximately67/8
inches)(175.01mm),thantheoppositesidemustbe
shorterbythesameamount.
Figure4
LeftHandSideShown
AdjustingtheAnti-ScalpRollers
Adjustanti-scalprollersforNormalOperating
Conditions.Placerollersinoneofthepositionsshown
inFigure5.Rollerswillmaintain3/4inches(19mm)
clearancetothegroundtominimizegougingandroller
wearordamage.
Note:ForMaximumDeckFlotation,placerollers
oneholepositionlower.Rollersshouldmaintain1/4
inch(6.4mm)clearancetoground.DoNotadjust
rollerstosupportthedeck.Besurerollerboltsandnuts
areinstalledwiththespringdiscwasherbetweenhead
oftheboltandmountingbracket.
Figure5
Forcuttingheightsabove3.5inches(38mm)usethe
bottomhole.Therollerswillstillbeeffectiveagainst
scalping.
1.Anti-scalprollermounting
bracket
2.Cuttingheight
1.Besuretherollerboltsareinstalledwiththespring
discwasherbetweentheheadoftheboltandthe
mountingbracket.Torquehardwareasspecied,or
lossofrollermayresult.
2.Torquethe3/8nylocnutto30–35ft-lb(41–47
N-m).
3.Torquethe3/8–24x2Gr8hexcapscrewto50–55
ft-lb(68–75N-m)(Figure6).
3

Figure6
1.Springdiscwasher(cone
towardsbolthead)
3.3/8nyloc-torqueto30-35
ft-lb(41-47N-m)
2.Frontrightanti-scalp
bracketshown
4.3/8-24x2GR8torqueto
50-55ft-lb(68-75N-m)
PositioningtheDischargeChute
Loosentwo5/16inchnylocnutsattachingdischarge
chute.Lowerthedischargechuteintoposition.
Retightennylocnutsuntilchuteissnugbutcanpivot
freely.
FillingOuttheWarranty
RegistrationForm
Filloutwarrantyregistrationform.
