Exodraft XTP150 User manual

Your energy. Optimized.
Accessory
XTP150
UK |Read and save these instructions!

Your energy. Optimized.
Accessory |XTP150
Content
Product information 7
Scope of supply 7
Technical specications 8
Construction and components 9
Installation 10
Fitting 10
Electrical wiring 11
Operation and conguration 12
UK Conformity Assessed 13
Declaration of Conformity 14

Disposal
Electrical and electronic equipment (EEE) often contain materials, components and substances
that may harm the environment or be hazardous to your health. Products (WEEE) marked with
the ‘crossed-out wheeled bin’ symbol should be disposed of separately from other waste at the
end of its life. Though legislation may differ from country to country we strongly advise that
electrical and electronic waste is separated from other waste and disposed of according to
national legislation to protect the environment and personnel that may come into contact with
waste.
How to use this manual
This manual has been prepared based on the specific product and
contains relevant technical information and installations guides.
Accessories and spare parts are not covered by this manual.
Please refer to the individual manuals of these components.
This installation manual does not contain any system design documentation.
Failure to observe instructions marked with a danger symbol
may result in personal injury and/or damage to the product.
Errors and omissions excepted.

Disposal
Electrical and electronic equipment (EEE) often contain materials, components and substances
that may harm the environment or be hazardous to your health. Products (WEEE) marked with
the ‘crossed-out wheeled bin’ symbol should be disposed of separately from other waste at the
end of its life. Though legislation may differ from country to country we strongly advise that
electrical and electronic waste is separated from other waste and disposed of according to
national legislation to protect the environment and personnel that may come into contact with
waste.
How to use this manual
This manual has been prepared based on the specific product and
contains relevant technical information and installations guides.
Accessories and spare parts are not covered by this manual.
Please refer to the individual manuals of these components.
This installation manual does not contain any system design documentation.
Failure to observe instructions marked with a danger symbol
may result in personal injury and/or damage to the product.
Errors and omissions excepted.
Symbols
The following symbols may be used in the manual
to draw attention to danger or risk of personal
injury or damage to the product.
General prohibition
Failure to observe instructions marked with the prohibited
symbol may result in extreme danger or serious personal injury.
General warning
Failure to observe instructions marked with a danger symbol
may result in personal injury and/or damage to the product.
General attention
Marks a dangerous situation that, in the worst-case scenario,
can cause serious personal injury or significant damage to the product.
Electricity hazard/High Voltage
Marks a situation in which caution is advised due to the risk of high voltage electric
shock which can cause serious personal injury or significant damage to the product.
Connect an earth terminal to the ground
Failure to observe instructions marked with a danger symbol
may result in personal injury and/or damage to the product.
Permitted and approved
Permitted and approved method of installation.
Prohibited and not approved
Prohibited and not approved method of installation.
UK |5

Warning
To minimise the risk of fire, electric shock, personal injury
and/or damage to the product please observe the following:
• Please read the manual before you start using the product and only use the product in
accordance with the manufacturer’s instructions. If in doubt, contact one of our specialized
dealers.
• All installations must be carried out by properly qualified personnel and in accordance
with national legislation and regulations.
• In order to avoid chimney fi res, ensure that the chimney has been swept before mounting
the fan.
• Prior to servicing the product, disconnect the power and ensure that it cannot accidentally
be reconnected.
• Exodraft always recommends the use of a smoke alarm when a solid fuel fireplace is
installed.
Your energy. Optimized.
6|UK

UK |7
3112029_XTP150_UK
Warning
To minimise the risk of fire, electric shock, personal injury
and/or damage to the product please observe the following:
• Please read the manual before you start using the product and only use the product in
accordance with the manufacturer’s instructions. If in doubt, contact one of our specialized
dealers.
• All installations must be carried out by properly qualified personnel and in accordance
with national legislation and regulations.
• In order to avoid chimney fi res, ensure that the chimney has been swept before mounting
the fan.
• Prior to servicing the product, disconnect the power and ensure that it cannot accidentally
be reconnected.
• Exodraft always recommends the use of a smoke alarm when a solid fuel fireplace is
installed.
Your energy. Optimized.
Product information
XTP150 is a high-precision pressure transducer specially developed for solid-fuel systems. The XTP sensor
constant pressure is monitored and maintained by regulating the speed of the chimney fan automaticly.
Incorrect use may result in problems with soot, chimney res, etc. which might damage the product.
Please check out this site for advice about the product:
www.exodraft.com
Scope of supply
• XTP150
• Silicone hose Ø 5 mm
• Installation manual and user instructions
Warranty
All Exodraft products are covered by a 2-year guarantee as per European consumer rights legislation. For
some countries an extended period of guarantee may apply depending on either national legislation or
other clearly stipulated conditions. Customer complaints must be handled by a specialised dealer or who-
lesaler (preferably where the Exodraft product has been bought originally). An updated list of Exodraft
specialised dealers can be found on our website for the country in question.
Exodraft products must always be installed by properly qualied personnel. Exodraft reserves the right to
change these guidelines without prior notice.
The warranty and liability does not cover instances regarding personal injury or damage to property or the
product that can be ascribed to one or more of the following causes:
• Failure to follow this installation and operation manual
• Incorrect installation, start-up, maintenance or servicing
• Improper repairs
• Unauthorised structural modications made to the product
• Installation of additional components that have not been tested/approved with the product
• Any damage resulting from continued use of the product despite an evident defect
• Failure to use original spareparts and accessories
• Failure to use the product as intended
• Exceeding or failure to meet the limit values in the technical data
• Force majeure

8|UK
Your energy. Optimized.
Technical specications
Technical data
Description XTP150
H x W x D [mm] 80 x 82 x 55
Weight 165 g
Material: Box: Leight grey polycarbonat
(PC)
Ingress Protection IP65
Pressure range 5 Pa - 150 Pa ( 5 Pa -250 Pa )
+/- 0,1 % Full scale
Ambient temperature -25 °C - +50 °C
Storage temperature: -25 °C - +50 °C
Connection terminals: Screw: max. 1.5 wire
Cable length Max. 100 m, min. 0.75 wire
Project:
Material:
Date:
Rev.:
Title:
Rev. No.: Ref.:
Format: A3
Weight:
Approved:
Draw. No.:
Sheet:
XTP150
19-11-2012
XTP150
PMN
DS/EN 22768 m
Unless otherwise specified tolerances are after
0,000 kg
1 of 4
108
55,1
55,1
80
80
28
14,2
Project:
Material:
Date:
Rev.:
Title:
Rev. No.: Ref.:
Format: A3
Weight:
Approved:
Draw. No.:
Sheet:
XTP150
19-11-2012
XTP150
PMN
DS/EN 22768 m
Unless otherwise specified tolerances are after
0,000 kg
1 of 4
108
55,1
55,1
80
80
28
14,2
Project:
Material: Date: Rev.:
Title:
Rev. No.: Ref.:
Format: A3 Weight: Approved:
Draw. No.:
Sheet:
XTP150
19-11-2012
XTP150
PMN
DS/EN 22768 m
Unless otherwise specified tolerances are after
0,000 kg
1 of 4
108
55,1
55,1
80
80
28
14,2
Description Inputs
Supply 24 VDC (+/- 15 %)
Power Consumption, abso-
lut max: 30 mA
Power Consumption,
nominel 20 mA
Description Outputs
Output 0-10 VDC, max. 10 mA
Description Miscellaneous
Tolerable overload 5000 Pa
Medium Air and exhaust gases
Responce time < 0,2 s
Resolution from digital
sensor 0,01 Pa
Repeatability +/- 0,1 % Full scale
Combined non-linearity
and hysteresis +/- 0,05 % Full scale
Offset longtime drift 1 year +/- 0,7 Pa max.
Temperature drift +/- 1,0 % Full scale
Transfer ratio 0,6 (250 Pa signal / 150 Pa
output)

UK |9
3112029_XTP150_UK
A DIP switch
B Power LED
C Zero-point calibration button
D Cable connector
E Mounting holes
F (-) Pressure connecter (P2)
G (+) Pressure connecter (P1)
H Status LED
I Connecting terminals
J Pressure transducer
Construction and components
A
G
F
H
J
D
CB
E
I
DIP switch (A) Setting Function Factory setting OFF ON
ON RSN
1234
1 0-150 / 0-250 Pa OFF 0-150 Pa 0-250 Pa
2 Calibration enabled OFF OFF Calibrate
Operating LED (B/H) Indication Function
PIC # 1
PIC # 2
Power LED Flashing YELLOW Power On
Status LED constant GREEN Unit is Ok
Status LED off Unit is not working
Zero-point
calibration button (C)
To activate Function
Press and hold for 5 s Calibration of zero point

10 |UK
Your energy. Optimized.
Installation
Fitting
The XTP150 must be tted with the hose connectors facing down.
For negative-pressure measurement, t the pressure hose to the ( - ) Pressure connecter.
For positive-pressure measurement, t the pressure hose to the ( + ) Pressure connecter.
Outdoor
If there is a risk of adverse effect from strong winds, the hose located inside the XTP150 can be removed
from the (+) valve. Interlter should be tted to the external (+) valve. The lter is not supplied by Exodraft.
Do not blow into the valves on the XTP150
