Exonic Exonic exd 6805 User manual

EXA 550 550W

•Monoblock subwoofer amplifier

•2ohm Stable

•160 Watts RMS x 1ch (4ohm)

•250 Watts RMS x 1ch (2ohm)

•Mosfet Power Supply

•Variable High-pass crossover 50~500Hz, 12dB/Octave

•Variable Low-pass crossover 50~500Hz, 12dB/Octave

•Frequency Response : 20 - 40KHz

•Short Protect / DC Protection / Thermal Protection /

Soft Turn On-Mute

•Damping Factor > 500

•Double Side FR4 PCB

•6.2" W x 2.0" H x 8.9" D

Model Max Power RMSPower 4 ohms RMSPower 2 ohms RMS Power 4 ohms Bridged Variable HPF X-over Variable LPF X-over Bass Boostat 45Hz Remote

EXA 600 600W x 4 50W x 4 70W x 4 150W x 2 50Hz~500Hz, 12dB 50Hz~500Hz, 12dB n/a -

EXA 550 550W x 4 160W x 1 270W x 2 - 50Hz~500Hz, 12dB 50Hz~500Hz, 12dB n/a -

EXA 10501050W x 1 350W x 1 500W x 1 - n/a 50Hz~250Hz, 12dB 0~12dB Gain

EXONIC Amplifiers

VARIABLY VERSATILE

Car audio has come a long way, and so have our

amplifiers. EXONIC amplifiers are variably versatile,

designed to adapt to the many different changes in

automotive design. The ultra compact size allows

installation of amplifiers in more locations. High

level inputs allow easier factory integration and vari-

able high and low pass filters are designed to elimi-

nate unwanted distortion.

DESIGNED TO DEFINE

Anew look, EXONIC amplifiers feature redesigned

awhole new chassis to accommodate our twin

board layout . The heat sink has been designed for

aoptimal cooling, allowing a larger mounting sur-

face for the output transistors, but overall smaller in

size. EXONIC’s new amplifiers are designed to

define the new generation of car audio amplifiers

on the market today.

MORE POWER PER SQUARE INCH

The ultra compact design, with double sided PCB

boards, and solid state technology gives EXONIC

amplifiers more power per square inch. Darlington

Transistors enable the amplifier to operate more

efficiently by more than 20% and also produce a full

bodied acoustic sound quality that rivals amplifiers 5

times the size.

EXA 600 600W

•4ch full-range amplifier

•2ohm Stable

•50 Watts RMS x 4ch (4ohm)

•70 Watts RMS x 4ch (2ohm)

•150 Watts RMS x 2ch (4ohm Bridged)

•Mosfet Power Supply

•Variable High-pass crossover 50~500Hz, 12dB/Octave

•Variable Low-pass crossover 50~500Hz, 12dB/Octave

•Frequency Response : 20 - 40KHz

•Short Protect / DC Protection / Thermal Protection /

Soft Turn On-Mute

•Damping Factor > 500

•Double Side FR4 PCB

•6.2" W x 2.0" H x 8.9" D

EXA 1050 1050W

•Monoblock subwoofer amplifier

•2ohm Stable

•350 Watts RMS x 1ch (4ohm)

•550 Watts RMS x 1ch (2ohm)

•Mosfet Power Supply

•Variable Subsonic Filter 10-60Hz, 12dB/Octave

•Lowpass Crossover 50~250Hz, 12dB/24dB switchable

Ultra Compact Size

•Variable Bass Booster 0-12dB at 45HZ

•Frequency Response : 10 - 250 Hz

•Remote Gain Control

•Short Protect / DC Protection / Thermal Protection /

Soft Turn On-Mute

•Damping Factor > 350

•8.8" W x 2.24" H x 13" D

EXONIC Speakers

The punishment that is delivered to car audio sub-

woofers is far greater than any other component in

an audio system. It is very easy to make a speaker

look good but it is a very tedious and time-consum-

ing task to make them perform well. Wetake

tremendous pride in each of our three subwoofer

series and quality from top to bottom is never com-

promised. The new EXONIC®Series Subwoofer with

flat progressive spider, flat tinsel woven wire and 2-

/2”4ohm dual voice coils will be able to get the

maximum power from your amplifiers

Model Size Power (RMS/Peak) Cone Voice Coil Impedance Freq. Response SPL

EXW 100 10” 200 / 400 Non-pressed kraft pulp 2’ 4-layer DVC DUAL 4 ohms 32 - 1KHz 85 dB

EXW 120 12” 250 / 500 Non-pressed kraft pulp 2’ 4-layer DVC DUAL 4 ohms 28 - 1KHz 88 dB

The EXONIC EXS Series Speakers are designed

to give you the same great sound quality experience

you are used to. Superior engineering and con-

struction, these speakers are built from the ground

up. They feature a new stamped steel basket design,

mounted magnet structures, and tweeters that are

designed for optimal efficiency. The new IMPP

Chrome Cone design allows structural rigidity pro-

ducing smooth bottom end, rich mid-ranges and

metal dome tweeters for that brilliantly crisp high.

EXONIC -Sound that you will enjoy for hours.

EXS 252 100W

• 5" 2-way • IMPP Chrome Cone

•4ohm • 80-22KHz

EXS 265 120W

•6.5" 2-way • IMPP Chrome Cone

•4ohm • 60-22KHz

EXS 268 120W

•6x8" 2-way • IMPP Chrome Cone

•4ohm • 60-22KHz

EXS 369 120W

•6x9" 3-way • IMPP Chrome Cone

•4ohm • 60-22KHz

Model Size Component Power (RMS / Peak) Cone Impedance Freq. Response Depth (inch) Depth (mm)

EXS 252 5” 2-Way 50 w / 100 w IMPP Chrome 4 ohm 80 - 22 KHz 1-7/8” 48 mm

EXS 265 6.5” 2-Way 60 w / 120 w IMPP Chrome 4 ohm 60 - 22 KHz 2-1/8” 53 mm

EXS 268 6” x 8” 2-Way 60 w / 120 w IMPP Chrome 4 ohm 60 - 22 KHz 2-1/8” 53 mm

EXS 369 6” x 9” 3-Way 100 w / 200 w IMPP Chrome 4 ohm 60 - 24 KHz 2-7/8” 72 mm

EXW 100 400W

EXW 120 500W

EXONIC Multimedia Player

EXD 7088

Double DIN 6.2” WVGA Digital TFT Multimedia Unit

•6.2" WVGA Digital TFT LCD (800x480 pixels)

•Touch Screen Control

•Rotary Volume Control

• Front SD / USB/AUX Input

•Built-in Bluetooth

•DVD / VCD / CD / MP3 / WMA / JPEG Playback

• DVD±R / DVD±RW / CD-R / RW Playback

•4Channels x 45W MAX Power Output

•3-Band EQ

•PLL Tuner with 18FM / 12AM Presets

•4.1 channels Line-Out : Front, Rear and Subwoofer

•PAL / NTSC / SECAM Compatible

•Dual Video Outputs

• Rearview Camera Input

•Telephone Mute

•Multi Function Remote Control

• ISO Cable Connector

• AV Input

•Steering Wheel Control ready

First we begin with an OEM quality fit and

finish, and then we add features like iPod

Integration, a high resolution WVGA screen

with stunning picture quality, a full featured

integrated Bluetooth system for hands free

operation, SD card and USB inputs, and even

an auxiliary input to connect more.

EXONIC’s EXD 7088 is an all-in-one multi-

media unit perfect to replace almost any bor-

ing factory double din unit. It’s highly intu-

itive Graphics User Interface makes it simple

tonavigate between menus and easy to set

up. Experience video in stunning detail with

its smooth WVGA screen, the internal 45x4

watt amplifier ensure crystal clear sound, and

with several types of media inputs, you are

sure to never run out of music or videos to

watch. Add a rearview camera and connect it

to the EXD 7088’s rearview camera input

and it is automatically selected when the

vehicle is put in reverse. It will even adapt to

most factory steering wheel controls with its

built-in Steering wheel control inputs and

setup–there is no need for additional

adapters or complicated wiring.

EXD 8090

Multimedia Disc Player with USB, SD / MMC

•DVD / VCD / MPEG4 / MP3 / WMA / CD / CD-R /

CD-RW Compatible

•Front USB / SD / MMC / AUX Input

•NTSC / PAL AUTO Compatible

•Anti-ShockMechanism

•ESP Electronic Shock Protection

•On Screen Display

•Audio & Video Output

•Multi Angle Mounting Capability

•Clock / Mute / Zoom / Loud Function

• Volume / Bass / Treble / Balance / Fader control

•DSP Sound Effect (Pop / Flat / Classic / Rock)

•Extension Remote IR

•Multi Function Remote Control

High Res WVGA Digital Panel

•6.2” WVGA DIGITAL TFT Panel

•800x480 Pixel Resolution

•The BEST in LCD Panel Technology

NEW Graphic Use Interface

•Easy to Navigate New Icons

•Accurate Calibrateable Touch Screen

•Highly Intuitive GUI

Steering Wheel Control Built-in

•Use factory steering wheel control

•Simple connection & on-screen setup

•Eliminates need for extra parts

OEMFactory Flush Mount Fit

•Slim Front Panel Design Sit Flush

•No need for major fabrication

•Sleeve and OEMMouting Included

USB and Aux-In on Front Panel

•Plays Music, Videos, Pictures

•Simple Plug, Search, and Play

• Front Panel RCA Aux Input

AM / FM Tuner

•PLL tuner with 18FM/12AM Presets

•4Ch x 45watt MAX Output

•4.1 Ch Line Out Front, Rear,Sub

SDCardMedia Slot

•Read Music, Videos, Pictures

•Simple Plug, Search, and Play

• MP3, WMA, JPEG, AVI

Bluetooth Function

•Bluetooth hands-free phone

•Incoming caller ID display on screen

•On-Screen Controls

Multimedia Player

• DVD/VCD/CD/MP3/WMA/JPEG

•DVD±R/DVD±RW/CD-R/RW

•Easy Media Search

Wiring and Setup

• 3 Band EQ with LPFSub Control

•2Video Outputs

•RCA Audio / Video Input

EXONIC Multimedia Player

Experience EXONIC’s EXD 7095, an all-in-one multimedia power house

all designed into a single din motorized touch screen unit. Watch as the dis-

play motorizes out, a stunningly clear 7inch WVGA monitor, intuitive touch

screen menus allow you to navigate through the limitless functions.

Multimedia functions allow playback of DVD, VCD, and CD playback as well

as a USB and SD card inputs, and even an auxiliary input so that you will

never run out of music or videos to watch. Crystal clear sound is produced

with its internal 45watt x 4 amplifier and Multiband EQ. Operate your cell

phone hands free with the integrated full featured Bluetooth system which

allows dialing, address book, search, and even voice recognition and dis-

plays right on the screen. Best of all never get lost with the built-in touch

screen navigation system , with millions of points of interest, you can get

where you want to go, when you want to go. Add a rear view camera to the

EXD 7095 and when the vehicle is shifted into reverse it will automatical-

ly display the video. It will even adapt to most factory steering wheel con-

trols with its built-in Steering wheel control inputs and setup-there is no

need for additional adapters or complicated wiring.

EXD 6805

7” Touch Screen In-Dash Multimedia Disc Player

•7” Wide TFT LCD Touch Screen

•Fully Motorized View Angle • Detachable Face

•DVD / MPEG4 / VCD / CD / MP3 Compatible

•Graphic OSD On Screen Display

•NTSC / PAL Compatible

•AM / FM Radio Tuner

•U.S.A. / European Frequency

•Built-in BLUETOOTH A2DP & AVRCP

•Integrated USB Port

•Integrated SD / MMC Card Slot

•Anti-Shock Mechanism

•ESP Electronic Shock Protection

•Rearview Camera Input

•Front AUX Input • RCA Line Out

•Dual Video Output • Subwoofer Output

•TA Traffic Announcement

•Multi Language Setup : OSD, Subtitle, Audio, Menu

Language (English / Spanish / French / Portuguese /

German / Italian / Russian)

•Auto Store / Preset Scan

•Clock, Title, Chapter, Subtitle & Angle

•Treble / Bass / Balance / Fader / Volume /

LO / DX & ST / MO

•Preset EQ – POP / ROCK / JAZZ / CLASSIC / FLAT

•Multi Function Remote Control

EXD 7095

Motorized 7” WVGA Digital In-Dash Multimedia Disc Player

Built-in GPS Navigation

•WVGA digital TFT LCD (800 x 480 pixels)

•WinCE based

•Touch Screen Dynamic Graphic User Interface

•Front USB / SD / AUX Input

•Built-in Navigation

•Built-in Bluetooth

•DVD / VCD / CD / MP3 / WMA / JPEG playback

• DVD+R/DVD+RW / CD-R / RW playback

•4channels x 45W MAX Power Output

•Multi-band EQ • Multi-Zone

•PLL Tuner with 18FM/12AM presets

•4.1 channels Line-Out : Front, Rear and Subwoofer

•PAL / NTSC / SECAM compatible

• Rearview Camera Input

•Steering Wheel Control ready

•Multi Function Remote Control

EXONIC Headunit

EXONIC 150

WMA / MP3, CD Receiver

•CD / MP3 / WMA / CD-R / CD-RW Compatible • Front AUX Input • Detachable Face

•MP3 File and Folder Search by Name • MP3 Track and MP3 Character Search

•MP3 ID3 TAG (Song / Album / Artist Title) Display • Multi-Color LCD Display

•DSP Sound Effect (Pop, Rock, Classic, Flat) • Volume / Bass / Treble / Balance / Fader control

•AM / FM Radio Tuner • 30 Preset Stations (18 FM / 12 AM) • Auto Memory Store

•MOSFET 45W x 4 Audio Output • 2 Channels x 2V Line-Out • Intro Scan

•Optional Multi Function Remote Control

EXONIC 250

WMA / MP3, CD Receiver with USB, SD / MMC

•CD / MP3 / WMA / CD-R / CD-RW Compatible • Integrated USB Port • Integrated SD / MMC Card Slot

•Front AUX Input • Detachable Face • iPod Ready • MP3 File and Folder Search by Name

• MP3 Track and MP3 Character Search • MP3 ID3 TAG (Song / Album / Artist Title) Display

• Volume / Bass / Treble / Balance / Fader control • DSP Sound Effect (Pop / Flat / Classic / Rock)

• Auto Memory Store • Repeat / Program / Random Play • AM / FM Radio Tuner

•30 Preset Stations (18 FM / 12 AM) • MOSFET 45W x 4 Audio Output

•4channels x 4V Line-Out • 4V Subwoofer Output • Multi Function Remote Control

EXONIC 500

Flip-Down WMA / MP3, CD Receiver with USB, SD / MMC

•CD / MP3 / WMA / CD-R / CD-RW Compatible • Integrated USB Port • Integrated SD / MMC Card Slot

• Front AUX Input • Flip-Down and Detachable Face • iPod Ready • MP3 File and Folder Searchby Name

•MP3 Track and MP3 Character Search • MP3 ID3 TAG (Song / Album / Artist Title) Display

•Volume / Bass / Treble / Balance / Fader control • DSP Sound Effect (Pop / Flat / Classic / Rock)

•Auto Memory Store • AM / FM Radio Tuner • 30 Preset Stations (18 FM / 12 AM)

•MOSFET 50W x 4 Audio Output • 4 channels x 4V Line-Out

•4V Subwoofer Output • Multi Function Remote Control

EXONIC Digital TV

EXDTV 100

ATSC Digital TV Tuner with Antenna

•High quality ATSC / QAM Demodulator

• Antenna Power Output

•Extension Remote Eye

•OSD On Screen Display

•Closed Captioning

•Favorite Channels

•Selectable A/V Input

•Compact Size (1” x 5” x 3”)

•High Gain Mini Magnet Mount Antenna Included

•12 VDCOperation

Upgrade your existing setup to receive digital TV channels with EXONIC’s

EXDTV 100 Digital TV tuner. The package comes complete to upgrade your soon

tobe obsolete analog TV tuner. Measuring only 1” x 5” x 3” this compact TV tuner

will fit just about anywhere in most vehicles and comes equipped with an exten-

sion IR, power cables, a remote control, and all necessary wiring. The unit fea-

tures a high quality ATSC / Qam demodulator, built-in antenna power supply for

amplified TV antennas, a complete OSD menu with favorite channels menu and

support for closed captioning. The EXDTV 100 also has an A/V input to use with

agame system or DVD player and is selectable through the remote. Included is

ahigh gain mini magnet mount antenna, measuring only 5.5” tall, that can easily

bemounted and removed for security purposes.

EXM 1100DTV

11” TFT LCD Ceiling Mount Digital TV

•Wide Screen 16:9 Ratio

• Low Reflection, High Resolution TFT LCD

•Swivel Display

•350:1 Contrast Ratio

• 400 cd/m2 Brightness Ratio

•On Screen Display

•NTSC / PAL Auto Switching

•Dual Audio & Video Input

•Built-in FM and IRtransmitter

•Built-in Dome Lighting

•Multi Function Remote Control

•Interchangeable Color Covers Included

•12 VDC Operation

The first 11” Ceilling Mount Monitor with built-in ATSC Digital TV tuner. This

unit not only is the first to have a built-in Digital TV Tuner but also it includes

three color interchangeable covers to match most vehicles factory color. Each

color does not have to be special ordered, instead it is included in the box.

These colors include Black, Grey, and Tan. The screen features a 16:9 ratio

wide screen, high contrast LCD display, which also swivels 180 degrees for

easy viewing. Built-right into the screen is an IR transmitter, FM transmitter,

dome lighting, and Digital TV Tuner, The EXM 1100DTV includes a high qual-

ity ATSC / QAM demodulator, built-in antenna power supply for amplified TV

antennas, a complete OSD menu with favorite channels menu and support for

closed captioning Also included is a high gain mini magnet mount antenna,

measuring only 5.5” tall, that can easily be mounted and removed for security

purposes

Interchangeable Color Cover (Black, Grey,Tan)

Matching your OEMinterior color is just a snap away.Select the color that best match-

es your interior and just snap it for a factory finish look. Best of all these snap on color

covers are included with each unit so there are no additional parts to buy or order.

Digital TV and DTV Tuner

11” Ceilling Mount Digital TV

EXONIC Monitors

EXM 920HP

9.2” TFT LCD Ceiling Mount Monitor

with Built-in DVD Player and Headphones

•9.2” TFT LCDCeiling Mount Monitor with Built-In DVD Player

•DVD, DiVX, MP4, MP3, VCD, SVCD, CD, CD-R, CD-RW, WMA Playback

•USB & SD Card Media Slot • Wide Screen 16 : 9 Ratio

• Low Reflection, High Resolution TFT LCD

•Swivel Display • 350 : 1 Contrast Ratio

•400 cd/m2 Brightness Ratio • On Screen Display

•NTSC / PAL Auto Switching • Dual Audio & Video Inputs

•Audio & Video Output • Built-in FM Transmitter

•Built-in IR Transmitter • Built-in Dome Lighting

•Multi Function Remote Control • 12V DCOperation

•Black Color only

EXM 1100

11” TFT LCD Ceiling Mount Monitor

• Wide Screen 16 : 9Ratio • Low Reflection, High Resolution TFT LCD

•Swivel Display • 350 : 1 Contrast Ratio • 400 cd/m2 Brightness Ratio

•On Screen Display • NTSC/PAL Auto Switching • Dual Audio & Video Input

•Built-in FM Transmitter • Built-in IR Transmitter • Built-in Dome Lighting

•Multi Function Remote Control • Interchangeable Color Cover Included

•Audio & Video Output • 12V DCOperation

EXM 110HP

11” TFT LCD Ceiling Mount Monitor with Built-In DVD Player

•DVD, DiVX, MP4, MP3, VCD, SVCD, CD, CD-R, CD-RW, WMA Playback

•Wide Screen 16 : 9 Ratio • Low Reflection, High Resolution TFT LCD

•Swivel Display • 350 : 1 Contrast Ratio • 400 cd/m2 Brightness Ratio

•On Screen Display • NTSC / PAL Auto Switching • Dual Audio & Video Input

•Audio & Video Output • Built-in FM Transmitter • Built-in IR Transmitter

•Built-in Dome Lighting • Multi Function Remote Control

•Interchangeable Color Cover Included

•12V DC Operation

Interchangeable Color Cover (Black, Grey, Tan)

Matching your OEM interior color is just a snap away with the EXONIC EXM

110HP & EXM 1100. Select the color that best matches your interior and just

snap it over the EXM 110HP & EXM 1100 for a factory finish look. Best of all

these snap on color covers are included with each unit so there are no addi-

tional parts to buy or order.

Monitor & DVD Player Combo

Wireless IRHeadphones Included

Monitor & DVD Player Combo

EXONIC Monitors

EXM 704

7" TFT LCD Dual Ch Headrest & Sunvisor Monitor

•Wide Screen 16 : 9 Ratio

•High Resolution (1440 x 234) TFT LCD

•350 : 1 Contrast Ratio • 400 cd/m2 Brightness

•On Screen Display • 3 Audio / Video Inputs

•Built-in IR Transmitter • NTSC / PAL Auto Switching

•Auto Picture Inverting • Front Panel AV Input

•Multi-Function • Remote Control

•Low Reflection TFT LCD • Low Power Consumption

•Headrest & Sunvisor Shroud Included

•12V DC Operation

Don't risk cutting into your factory headrests, replace them with the EXP 900. Designed to

replace most vehicle's headrests, the EXP 900 comes as a complete headrest with a built in

9" monitor. The high resolution screen has built-in on screen adjustments, built-in IR transmit-

ter, and will allow for up to 2 Video & 1 Audio inputs. Spacers are included to accommodate

the two standard sizes of the mounting posts. Unlike many competitors using spring loaded

post width adjustments, our monitors have heavy duty screw adjustments to adjust for mount-

ing post width and headrest mounting rigidity, making a superior headrest mounting system.

EXP 900B / 900T / 900G

9” TFT LED Headrest Monitor with Pillow

•Universal Headrest Mounting • Wide Screen 16 : 9 Ratio • High Resolution TFT LED

•350 : 1 Contrast Ratio • 400 cd/m2 Brightness Ratio • On Screen Display

•NTSC / PAL • Dual Video Input • Single Audio Input • Built-in IR Transmitter

• Aspect Control Mode • Screen Rotation • Dimmer Control

•Sleep Timer • Multi Function Remote Control • 12V DC Operation

Black EXP 900B

Tan EXP 900T

Grey EXP 900G

Heavy Duty Width Adjustment

EX2312LT

•23" High Definition Ready LCD TV • Wide-screen 16:9 Aspect Ratio

•High Resolution W-XGA (1366 x 768) LCD • 550 : 1 Contrast Ratio

•500 cd/m2 Brightness • 5 Audio & Video Inputs • DVI Input & PC Input

•12V DCOperation •Built-in IROutput

•Direct Speaker Output •Custom Mounting Bracket

•PIP(Picture-in-Picture) & Split Screen •176 Degree Viewing Angle •181 ch TV

•DVI Input • PC Input (RGB) • S-Video with Composit AV Inputs

•Dual Component Video with Composit AV Inputs • Cable Ready Input

•AV Output • 25Watts x 2 Audio Output • Graphic OSD • SRS WOW Surround

For any application EXONIC has the solution …

EXF 2030

Wireless FM Transmitter

•Hi-Gain Output for Cleanest Reception Possible

•Selectable 7 Channel Transmission

•RCA Type Inputs

•Easy Installation

•Low Power Consumption

EXH 12

Wireless IRHeadphones

EXH 44

Dual Channel Wireless IR Headphones

•Variable Volume Control • On / Off Switch

•Built-in Auto Mute with Auto Level Control

•Fully Adjustable Fit • Extremely Lightweight

•Excellent Sound Quality

EXV 40

Multi-Channel Video Amplifier

•Single Video Input with Four Video Outputs

•Individual Video Output Gain Controls

•Eliminates Video Signal Loss

•Clarifies Weak or Distorted Video Signals

•Low Power Consumption

RearView Camera

Compatible

Combine any of our rearview cameras with our OEM

Navigation Interfaces for a factory worthy setup. Clearly

display what is behind your vehicle direct to your factory

screen. Designed with safety in mind our cameras give

you a wide angle view to see what you normally may not

when using your rear view mirror.

Waterproof

Completely water proof design. No need to worry

about rain or dust, the camera is sealed from the ele-

ments inside its own case. Our extremely durable alu-

minum case housing with stands all water conditions

without corrosion or rust.

Night View

Our cameras are designed to adapt to low light situa-

tions. This can be extremely useful when parking at

night or in dark parking spaces. Our EXR 200 even

has built-in Night Vision for very low or no light sce-

narios.

Introducing OEM License Plate Rearview Camera

EXR 909NB

EXR 909NC / Chrome

EXR 909NB / Black

License Plate Rearview Camera Built-in Night Vision

•High Sensitive 1/3” Sony CCD • 250,000 Pixels

•420 TV Line Horizontal Resolution

•Moisture Free Waterproof • Reverse Image

•150 degree Wide Angle of View

• Remarkable True Color Reproduction

•Excellent Auto White Balance

•Super Sensitive Low Lux Image Capture

•Aluminum Die-Casting Frame • Waterproof (IP67)

•12V DC Operation • Remarkable Low Lux Performance of 0.8 Lux at F2.0

Bullet Type Rearview Camera

EXR 100

•Moisture Free Waterproof

•1Lux low Light Color Camera

• Wide Angle of View

•Reverse Image

•12 volt DC operation

EXR 909NC

Take A look Back

EXR 900C / Chrome

EXR 900B / Black

License Plate Rearview Camera

• High Sensitive 1/3” Sony CCD • 250,000 Pixels

• 420 TV Line Horizontal Resolution • Moisture Free Waterproof

• Reverse Image • 150 degree Wide Angle of View

• Remarkable True Color Reproduction • Excellent Auto White Balance

• Super Sensitive Low Lux Image Capture • Aluminum Die-Casting Frame

• 12V DC Operation • Remarkable Low Lux Performance of 0.8 Lux at F2.0

• Waterproof (IP67)

EXR 900B

EXR 900C

EXM 352R

3.5” Digital TFT LCD Rearview Monitor

• Adapts to any Rearview Camera • On Screen Display

• Dual Video Inputs • 300 cd/m2 Brightness

• Brightness, Contrast, Color & Tint Control

• Reverse Trigger Delay Time • Seperate Volume Up/Down

• Screen Mode : Mirror Image / Horizontal Flip / Vertical Flip

• Adjustable Suction Cup Mount included • 12V DC operation

US Patent Pending

Night Vision

EXR 200

• CCD built-in Night Vision

• Moisture Free Waterproof

• 1 Lux low Light Color Camera

• 150 degree Wide Angle of View

• 250,000 Pixels

• Reverse Image

• 12 volt DC operation

EXR 359B (Black)

EXR 359C (Chrome)

• EXR 900B / EXR 900C License Plate Rearview Camera

• EXM 352R 3.5” Digital TFT LCD Rearview Monitor

REARVIEW CAMERA PACKAGE

US Patent Pending

Night Vision

Rearview Camera

EXM 430RMG

OEM Rearview Mirror with integrated GPS Navigation &

Rearview Camera

•OEM Replacement Rearview Mirror with integrated GPS Navigation

• Samsung S3C244OA-400MHZ processor

• 64MB internal memory

• 2GB SD card for storing Maps, Pictures, and e-Books

•Built-in GPS reciever with highly sensitive (16 channels)

dual antenna design

•4.3” Touch Screen LCD Monitor (16:9 wide screen)

•Integrated speaker • 2 Video inputs w/rearview camera input

• Rearview Camera Included

GPS Navigation

• Navigation Mobile Navigator 6.5

• Millions of points of interest (POIs)

•Voice prompted turn-by-turn directions

•Intuitive menus and stunning 2D and 3D maps

•Spoken street names featuring Text to Speech Technology

• Easy to read map views that adapt to your needs

Bluetooth Function

• Bluetooth hands-free phone • Incoming caller ID display on screen

• Call history Log • Manual/Auto call answering

EXR 300

Dual Mount Rearview Camera

• Easy to Install Bracket or Flush-Mounting

• Low Profile High Resoulution Camera

• Selectable Display Mirror / Normal View

• Weather Resistant Moisture Proof Design

• Wide Viewing Angle • 640x480 pixels Resolution

• 1/4” CMOS Color Sensor • 300,000 Pixel Resolution

• Internal Sync System • 380 TVL Resolution

• 2 LUX / F1.2 Minimum Illumination • 45dB + S/N Ratio

• 0.45 Gamma Correction • Automatic Gain Control

• 1.0Vp-p Composite Video Out 75 ohm Load

• -20ºC - 60ºC Operation Temperature

• 12 volt DC Operation • Waterproof IP68

• View Angle : 170º D x128º H x 94º V

EXR 400

Rearview Camera with Virtual Overlay

Parking Guidelines

• Easy to install Multi-Angle Bracket Mount

• Low Profile High Resoulution Camera

• Selectable Distortion Corection

• Weather Resistant Moisture Proof design

• Wide Viewing Angle • Super Low Lux Performance

• 720x480 pixels Resolution • 1/4” CMOS Color Sensor

• 350,000 Pixel Resolution • Internal Sync System

• 380 TVL Resolution • 1 LUX Minimum Illumination

• 35dB S/N Ratio • 1.0 Gamma Correction

• Automatic Gain Control

• 1.0Vp-p Composite Video Out 75 ohm Load

• -40ºC - 85ºC Operation • Waterproof IP68

• View Angle : 160º D x 133º H x 109º V

• Distortion Correction

• Virtual Overlay Adjustable Parking Guidelines

• Bird’s Eye View Mode Compensates for High Mount

Low Profile Bracket Type Mount Shown

Selectable Normal or Mirror Image

Distortion Correction compensates for Lens

Distortion to give a true reverse image.

After Correction

Original image

Bird’s Eye View adjusts images from high mounted

cameras to display as if the camera were directly

above parking area.

Corrected Image

Bird’s Eye

Perspective

Virtual Overlay Adjustable Parking Guidelines to enhance parking safety and parking ability.

True Plug and Play Capability

No Splicing, Cutting, or Second Guessing. Only our systems

use factory type connectors that simply plug in-line to your

factory navigation system.

Multiple Input Capability

Connect your DVD player, Video Game Console, TV tuner,

IPOD, MP3 Player, and your rear view camera all to your

factory navigation system in a heartbeat. And itís easy to

select each source with your remote control.

Popular Car Receiver manuals by other brands

AMX

AMX DAS-AMFM installation guide

Panasonic

Panasonic CQ-C1120AN Service manual

Sanyo

Sanyo FT 200 F-4 operating instructions

Teac

Teac EX-M1 owner's manual

VIETA

VIETA HA3000BT user manual

Pioneer

Pioneer DEH-P300 Service manual

XZENT

XZENT xt7010 instruction manual

JVC

JVC EXAD KW-AVX826 instructions

Kenwood

Kenwood KVT-614 - Excelon 1-DIN In-dash DVD/CD... installation manual

JVC

JVC KD-SX990 instructions

Panasonic

Panasonic CQ-R155 Operating operating instructions

Bogen

Bogen TP30D Specifications

JVC

JVC KW-XC770J Installation & connection manual

Alpine

Alpine CDA-9855R Service manual

Panasonic

Panasonic CQ-DFX600N Service manual

JVC

JVC KD-S20 instructions

Convex

Convex CX-3500BS user manual

Clarion

Clarion ProAudio DXZ535 owner's manual

Exonic EXONIC EXD 6805 User manual

Popular Car Receiver manuals by other brands
