Delphi XpressRC SA10316 User manual

User Guide

2
TuneSelect favorite artists and songs . . . 38
GameSelect favorite sports and teams . . 42
Getstockquotes.......................44
How Else Can You Use
Your XpressRC?................47
Configuring your XpressRC ......49
Turn the FM modulator on/o . . . . . . . . . . 50
Find an FM frequency . . . . . . . . . . . . . . . . . . 51
Set the line out level . . . . . . . . . . . . . . . . . . . 53
Setthetone............................54
Aim antenna for best reception. . . . . . . . . 55
Displaysettings........................56
Display appearance . . . . . . . . . . . . . . . . . . . . 57
Settime ...............................58
Automaticpower ......................60
Delayedpower.........................61
Sleeptimer............................62
Factorydefaults........................63
Demomode...........................64
Troubleshooting . . . . . . . . . . . . . .65
Product Specifications. . . . . . . . .69
Patent Information. . . . . . . . . . . .71
Environmental Information. . . . .71
FCC Statement . . . . . . . . . . . . . . .72
Delphi Limited Consumer
Warranty....................73
Introduction ..................3
Features................................4
About XM Satellite Radio . . . . . . . . . . . . . . . . 5
AboutDelphi...........................5
Safety and Care information . . . . . . . . . . . . . 6
What’sinthebox?.......................8
XpressRC functions.......................9
Remote control functions . . . . . . . . . . . . . . 10
5-way navigation knob . . . . . . . . . . . . . . . . . .11
Vehicle Installation . . . . . . . . . . . 12
Step 1: Mount the XM Antenna . . . . . . . . . 13
Step 2: Install the vent or swivel mount . 16
Step 3: Connect your XpressRC ..........18
Step 4: Turning on your XpressRC.........20
Activation ...................21
Using your XpressRC ...........23
ListeningtoXM........................24
Viewacategory........................25
Direct channel entry . . . . . . . . . . . . . . . . . . . 25
Jump to the previous channel . . . . . . . . . . 26
Set your favorite channels . . . . . . . . . . . . . . 26
Skipachannel.........................28
Block xL (explicit language) channels . . . 29
Tune directly to a channel . . . . . . . . . . . . . . 31
Special Features. . . . . . . . . . . . . .33
Change the display mode . . . . . . . . . . . . . . 34
Save your favorite songs. . . . . . . . . . . . . . . . 35
60 minute pause and replay . . . . . . . . . . . . 37
Table of Contents

3
Table of Contents
Introduction

4
Introduction
Features
Congratulations, on your purchase of the XpressRC!
The XpressRC has these exciting features to enhance your listening experience:
• Large, customizable, color display – view the content you want; the way you want it.
• Multi Channel viewing-View the current channel and three other channels OR view
the current and the previous channels at the same time.
• Pause and Replay up to 60 minutes of live XM programming.
• SongSaver allows you to easily save up to 10 of your favorite songs
any time.
• TuneSelect nds your favorite artists or songs and alerts you when they’re playing
on an XM channel.
• GameSelect nds your favorite sports and team events and alerts you when
they’re playing on an XM channel.
• Sports and Stock Tickers so you are up to speed on the latest scores and stocks
while listening to your favorite XM programming.
• Quick and easy setup
Please read the entire user guide before using your XpressRC

5
About XM Satellite Radio
XM is America’s number one satellite radio company. Broadcasting live daily from
studios in Washington, DC, New York City, Chicago, the Country Music Hall of Fame in
Nashville, Toronto and Montreal, XM’s 2007 lineup includes more than 170 digital chan-
nels of choice from coast to coast: commercial-free music, premier sports, news, talk
radio, comedy, children’s and entertainment programming; and the most advanced
trac and weather information.
XM, the leader in satellite-delivered entertainment and data services for the auto-
mobile market through partnerships with General Motors, Honda, Hyundai, Nissan,
Porsche, Subaru, Suzuki and Toyota, is available in 140 dierent vehicle models for
2007. XM’s industry-leading products are available at consumer electronics retailers
nationwide. For more information about XM hardware, programming and partnerships,
please visit http://www.xmradio.com/.
About Delphi
Delphi is a world leader in mobile electronics, vehicle components, and audio technol-
ogy. Delphi created the rst in-dash radio in 1936 and continues its strong tradition
of innovation in the audio industry. Now Delphi technology has helped make satellite
radio a reality, and Delphi continues to expand its in-vehicle and consumer electron-
ics technologies. With its exciting line of satellite radio products, Delphi oers a broad
portfolio of products to answer a wide variety of information and entertainment needs
– in the vehicle, home, oce, or virtually anywhere.

6
Introduction
Safety and Care Information
IMPORTANT: Always read and understand all the instructions to avoid injury
to yourself and/or damage to your device. XM Satellite Radio claims no
responsibility for damage from data loss due to breakdown, repair, or other
causes.
• Do not expose to extreme temperatures (above 140°F or below -4°F,
or above 60°C or below -20°C).
• Do not expose to moisture. Do not use device near or in water.
• Do not let any foreign matter spill into device.
• Do not store in dusty areas.
• Do not expose to chemicals such as benzene and thinners. Do not use liquid
or aerosol cleaners. Clean with a soft damp cloth only.
• Do not expose to direct sunlight, re, ame or other heat sources for
a prolonged period.
• Do not try to disassemble and/or repair device yourself.
• Do not drop your device or subject it to severe impact.
• Do not place heavy objects on device.
• Do not subject device to excessive pressure.

7
WARNING
• Opening the case may result in electric shock.
• The uninsulated parts inside the power adapter and cradle may cause
electric shock or re. For your safety, please do not open these
components. Do not let metallic objects, such as necklaces or coins,
come into contact with the power adapter plugs.
• To avoid electric shock, use the power adapter only with an outlet that
matches the shape of the adapter’s plug.
• Make sure that you insert the adapter’s plug all the way into the outlet.
• Do not plug several devices into the same electrical outlet.
• Use the power adapter and cradle away from water sources to avoid re
or electric shock.
• Do not touch the device with wet hands.
When using this product it is always important to keep your eyes on the road and
hands on the wheel. Not doing so could result in personal injury, death, and/or damage
to your device, accessories, and/or to your vehicle or other property.
Your device should be placed in your vehicle where it will not interfere with the func-
tion of safety features, e.g., deployment of airbags. Failure to correctly place device may
result in injury to you or others if the unit becomes detached during an accident and/or
obstructs the deployment of an airbag.

8
Introduction
What’s in the Box?
8
5
2
7
4
1
9
6
3
mute
info menu display
0
jump fav
+
XpressRC
Car Cradle
Remote Control
XM Car Antenna
Cassette Adapter
Swivel Mount
Vent Mount
Swivel Mount
Preparation Kit
Car Power Adapter

9
XpressRC functions
60-Minute Replay Buttons
Pause and replay up to 60
minutes of live XM broadcast.
Power Button
Display
Customize the way you view
content on the display.
Left and Right Arrows
Search for channels by
category.
5-way Navigation
Knob
Previews channels; also selects
various menu options.
Menu
Access advanced features
and configuration options.
XM Button
Confirms selection for channel
and menu items, also press
and hold to GameSelect, to
TuneSelect or to save a song.
Fav
Choose among direct
channel entry, favorite
channels, and SongSaver
modes.
Jump
Switches between
current channel and
previous channel.
Info
Displays either your
personal stock or info
extras information.
Number Keys
Enter a channel
directly, select your
favorite channels, or
access songs saved
in SongSaver.

10
8
5
2
7
4
1
9
6
3
mute
info menu display
0
jump
+
fav
Introduction
Remote Control functions
60-Minute Replay Buttons
Pause and replay up to 60
minutes of live XM broadcast.
Power Button
Display
Customize the way you view
content on the display.
Arrow Buttons
Select menu entries,
change channels.
Menu
Access advanced features
and configuration options.
XM Button
Confirms selection for channel
and menu items, also press
and hold to GameSelect, to
TuneSelect or to save a song.
Fav
Choose among direct
channel entry, favorite
channels, and SongSaver
mode.
Jump
Switches between current
channel and previous channel.
Info
Displays either your personal
stock or info extras informa-
tion.
Number Keys
Enter a channel directly,
select your favorite channels,
or access songs saved in
SongSaver.
+ and -
Change channels or control
volume for audio system
(sold separately)
Mute
Silences live, saved songs,
and replayed XM content.
