Explo RX-WAV-Player User manual

Explo
Zündtechnik
Harald Kulterer
Völkermarkterstrasse 240
9020 Klagenfurt am Wörthersee
Austria
Tel: 43 (0) 463 / 32 2 45
Fax: 43 (0) 463 / 32 2 45 75
Mobil: 43 (0) 664 / 51 007 51
www.explo.at
[email protected]
Explo
Zündtechnik
RX-WAV-Player V1
Manual v0.1
As of Oktober 2013

2
Preamble
Dear Explo-Customer,
Please read through this set of instruction before operating your devices. Many of the informations
held within are crucial to learning about- and handling your system.
We ask of you to follow the mentioned safety and user guidelines closely.
Note: This Manual is a pre-version. If you have any questions, or should any vagueness appear, which
this manual cannot answer, please do not hesitate to contact us either by phone, or by E-Mail.
We wish you a lot of fun and success with your Explo-Ignition System!
~ The Team of Explo IGNsystems

3
1 Index
2 Overview/ Description of Components ........................................................................................... 4
2.1 Overview of Components ........................................................................................................ 4
2.2 Description of Components ..................................................................................................... 6
2.2.1 Buttons ............................................................................................................................ 6
2.2.2 SD-Card slot ..................................................................................................................... 6
2.2.3 Status-LEDs ...................................................................................................................... 6
2.2.4 Display ............................................................................................................................. 6
2.2.5 Antenna and Antenna socket .......................................................................................... 7
2.2.6 On and Off switch ............................................................................................................ 7
2.2.7 Charging socket ............................................................................................................... 7
2.2.8 Audio-output ................................................................................................................... 7
3 RX-WAV-Player – The menu ............................................................................................................ 8
3.1 Lock .......................................................................................................................................... 8
3.2 Delay ........................................................................................................................................ 8
3.3 Ch Settings ............................................................................................................................... 8
3.3.1 Main Box .......................................................................................................................... 8
3.3.2 Ch-Control ....................................................................................................................... 8
3.3.3 Ch-Track ........................................................................................................................... 9
3.4 Repeat ..................................................................................................................................... 9
3.5 Sys Settings .............................................................................................................................. 9
3.5.1 Sys Addr ........................................................................................................................... 9
3.5.2 Secure Key ....................................................................................................................... 9
3.6 Restore Default ........................................................................................................................ 9
3.7 Player ver ................................................................................................................................. 9
4 Using the RX-WAV-Players .............................................................................................................. 9
4.1 Switch on/off ........................................................................................................................... 9
4.2 Controling the receiver ............................................................................................................ 9
4.2.1 Audio-Files ....................................................................................................................... 9
4.2.2 Starting Audio-Files ......................................................................................................... 9
4.2.3 Channels with special functions .................................................................................... 10
4.2.4 Control in FSK- Mode .................................................................................................... 10
4.2.5 Positioning your devices: ............................................................................................... 10
5 Technical Data ............................................................................................................................... 10

4
2 Overview/ Description of Components
2.1 Overview of Components
Audio
-
output
Antenna socket
ON/OFF Switch
Status
-
LED
Button
Display
SD
-
Card slot
Charging socket

5

6
2.2 Description of Components
2.2.1 Buttons
The Buttons are used for manual control of the RX-WAV-Player. In all, 4 Buttons with different uses
are given. The function of every button is different in the menu and during use.
Designation Symbol Menu Function Function uring use
Play/Pause OK / Enter Play/Pause Track
Stop ESC / Back Stop Track (Time is reset to 0)
Minus Minus Previous track(Skip backward)
Plus Plus Next track (Skip forward)
2.2.2 SD-Card slot
SDHC-Memory cards containing Audiofiles can be insertes into the SD-Card slot.Please remove the
card from the slot during transport, since mechanic stress onto a connected SD card may damage the
card slot.
2.2.3 Status- EDs
To the left and right of the Buttons are two red LEDs. These can give you a visual output when
receiving signals.
2.2.4 Display
The lit display shows all important informations about the WAV-Player and tracks, as well as show
you the menu.
Re LED uring use
1x long flash Start-, Pause- or Stop-Signal received
3x short flashing Testsignal has been received

7
2.2.5 Antenna and Antenna socket
The antenna is used to receive data. During use it is connected to the antenna socket (BNC-socket) of
the WAV-Player. You should prevent jamming the antenna or damaging it in any other way, even
when not in use and just storing the device.
During use, make sure the antenna is firmly mounted and upright.
You may also use a magnetic antenna, which should be placed on a metallic surface.
2.2.6 On and Off switch
By use of this Wip switch, the Player can be turned on or off. "O" = OFF, "I" = ON. Do not forget to
turn the device off after use, since the battery may deep discharge otherwise.
2.2.7 Charging socket
The 3 pole female socket is used to charge the device with a fitting charger. The device itself must
not be switched on during charging.
Furthermore, the device can be supplied with an external power supply hooked up to this socket. The
external supply uses Pin 2 (Plus) and Pin (1). The source should not exceed 12VDC, since the device
may be damaged otherwise.
2.2.8 Audio-output
Symmetrical Audio output. XLR 3 pole L and R, can be bridged to asymmetrical.

8
3 RX-WAV-Player – The menu
The menu can be accessed by pressing Stop and Play at the same time.
3.1 ock
Allows you to lock (Lock:ON) all play function of the WAV-Player. (This is unlocked by accessing the
menu again)
3.2 Delay
Allows you to set a starting delay. It is made in steps of 5meters. Furthermore, the delay will be
shown in milliseconds (ms).
3.3 Ch Settings
Allows you to set the channel and boxnumbers.
3.3.1 Main Box
Allows you to set the Box number of the RX-WAV-Player from 1 - 50 (Default is 50).
3.3.2 Ch-Control
Allows you to set the channelnumbers of the special functions, like "Play", "Pause", or "Skip
forward". ( A table with the special functions and the standard channelnumbers can be found in
chapter 4.2.3)
Menu
Lock: OFF/ON
Delay: >0m<
Ch Settings
Main Box: 50
Ch-Control
Ch-Track
Repeat
Sys Settings
Sys Addr xxx
Secure Key xxx
Restore Default
Player ver. : 21

9
3.3.3 Ch-Track
Allows you to set the Channelnumber that should play an audio track directly. (Standard: Channel 1 =
Track 001, Channel 2 = Track002, etc...)
3.4 Repeat
If this function is active, the next track will start automatically, after one track has finished. If the last
track has finished, the first one will be started again.
3.5 Sys Settings
3.5.1 Sys Addr
Allows you to change the system adress of the WAV-Player.
3.5.2 Secure Key
Allows you to set a radio encryption. All devices used must feature the same secure key.
3.6 Restore Default
Allows you to reset all settings, except the secure key.
3.7 Player ver
Displays the Software version of the RX-WAV-Player.
4 Using the RX-WAV-Players
4.1 Switch on/off
By use of the Wip switch, the Player can be turned on or off. "O" = OFF, "I" = ON. Do not forget to
turn the device off after use, since the battery may deep discharge otherwise.
4.2 Controling the receiver
Controlling is done by use of an Explo-transmitter, and Box and channelnumber. By default, the
player is set to box 50. The Boxnumber can be changed in the menu of the player.
4.2.1 Audio-Files
Only WAV-files may be used. (PCM 16bit, 44.1kHz; 32Bit and 32Bit floating does not work!)
Up to 60 different tracks can be used by the Player. The name of the first audiofile on the Memory
card must start with "01", all others are not important (eg.: "01 - Eye of the tiger" or "01 Eye of the
tiger").
4.2.2 Starting Audio-Files
Audiofiles can be started using their Box and channelnumber. Box number must be the one of the
Player. The channelnumber is the same as the tracknumber. For example, channel 1 starts track "01"
or channel 12 starts track "12".
The first 60 files can be accessed directly by their channelnumbers. All others can only be accessed by
using the "Skip forward" function.

10
4.2.3 Channels with special functions
Some channelnumbers control important WAV-Payer functions. The following ignition channels are
set by default:
4.2.4 Control in FSK- Mode
If the transmitter is in FSK- Armed Mode, the RX-WAV can be started and paused by used of the "Z"
button. By pushing "-" and "z" at the same time (but "-" before), a stop is made. Repeating this action
will result in a reset on the receiver ( the first Track will be played at the next Play command).
4.2.5 Positioning your devices:
If possible, position the transmitter and receiver in a way, that no objects stand between them.
Avoid objects made of metal especially (eg.: Steelconcrete buildings, metal fences, Tanks, Ships,...) as
well as mountains.
Theoretically, it is possible for a receiver to receive a signal behind such objects, since radiowaves
break or reflect on objects, and thusly an indirect contact can be made, however the full range can
only be used by a direct line.Under no circumstance should Transmitter or receiver be covered by
metals, since this materials could shield them from radio waves.
Ideally, all devices should be on a heightened position. (eg. Transmitter on a table)Because of the
radiance, all antennas shoudl stand up straight (vertical). If possible we recommend using magnetic
antennas.
5 Technical Data
Standby: 16 hours
Range: min. 800 Meters
Temperature range: -20°C to 65°C (protect from direct sun lighting)
Outputs: 2x XLR (left and right, symmetrical / asymmetrical)
1x 3,5mm Cinch (only asymmetrical)
Output level: 2Vpp
Signal-static distance: 87dB
Channel distance: 70dB
Channel WAV-Player-Function
61 Play/Pause Track
62 Stop Track (Time is reset to 0)
63 Previous Track (Skip backward)
64 Next Track (Skip forward)
65 Reset (Time is reset to 0, and Player will be set to Track number 001)
66 Timer is started and shown on the display.
