Pinnacle SoundBridge Wireless Network Music Player User manual

User Guide | Software v2.5
SoundBridge
Wireless Network Music Player

1
Welcome
Thanks for purchasing SoundBridge! We hope you enjoy using it as much as we’ve
enjoyed creating it.
SoundBridge is a network music player that connects to your stereo or powered speakers
to play your Mac or PC digital music library in any room of the house. You can even play
thousands of free Internet radio stations on SoundBridge without the computer on.
SoundBridge works with your Wi-Fi or Ethernet home network and is compatible with
popular music servers such as Windows Media Connect Musicmatch and more. Enjoy!
Run the Latest Software!
We are always working on improving the software for our products. Your SoundBridge will
let you know when a software update is available. We recommend you accept new software
updates when they are offered. The update just takes two minutes, and enhances the
features of your SoundBridge. All you need is an active Internet connection. See “Options for
System Configuration” on page 45 for easy instructions.
Register Your SoundBridge!
It’s quick, easy and ensures that you are notified of the latest software updates for
SoundBridge. Of course, we won’t share your personal information with anyone else. Visit
www.pinnaclesys.com/support.
Download the Latest User Guide!
When our software changes, so does our
user guide. Visit www.rokulabs.com/pinnacle
to download the latest version as a PDF
document and learn about the latest features.
Visit www.pinnaclesys.com/support
to register your SoundBridge.

3
TABLE OF CONTENTS
SECTION 1: GETTING STARTED
I. Music Server Software Requirements..4
II. Enabling Music Sharing ..........................7
III. Hooking Up Your Home Network
Hardware (Wired Ethernet or Wireless)...........9
IV. Connect Your Speakers
or Stereo System.......................................9
V. Connecting SoundBridge
to AC Power................................................10
VI. Using Your Remote Control....................11
VII. Establishing a Network Connection.....11
VIII. Setting Display Preferences ...................12
IX. Checking for the Latest Software .........13
X. Wall or Under-Cabinet
Mounting (optional).................................13
SECTION 2: BROWSING MUSIC........................14
Choosing Your Music Library............................14
Remote Control Quick Reference....................15
The Home Menu..................................................15
Browsing Your Music by Album.......................16
Browsing by Artist or Composer.....................18
Browsing by Song...............................................19
Browsing by Genre..............................................19
SECTION 3: THE SONG QUEUE........................20
Building a Song Queue......................................20
Reviewing a Song Queue..................................21
Erasing a Song Queue .......................................21
SECTION 4:
ADDITIONAL PLAYBACK OPTIONS................22
Playing a Playlist..................................................22
Repeat and Shuffle.............................................22
Search Options....................................................22
SECTION 5: PRESETS..........................................24
Recalling Presets.................................................24
Editing Presets Using the Web Interface.......24
SECTION 6: INTERNET RADIO..........................26
Browsing Internet Radio Stations...................26
Customizing Favorites and Presets for
Internet Radio............................................27
Playing Stations Saved as “My Favorites”
or “Presets”.................................................29
Playback Limitations of Internet
Radio Streams............................................30
Discovering More Internet
Radio Stations............................................30
SECTION 7:
SOUNDBRIDGE WEB INTERFACE...................31
Launching the Roku Web Interface...............31
Now Playing ........................................................34
Presets ...................................................................35
Configuration ......................................................37
Status ....................................................................38
SECTION 8: WHEN YOU ARE FINISHED
USING SOUNDBRIDGE .....................................39
SECTION 9: ADVANCED FEATURES ...............40
Brightness, Contrast, Font,
and Text Display........................................40
Brightness & Time Format While
in Standby...................................................40
Settings..................................................................40
Music Visualizer Settings...................................40
Clock Settings.......................................................41
Language Setup .................................................43
Standby and Reboot Options..........................44
WMA Lossless Transcoding...............................44
FLAC and Ogg-Vorbis Transcoding................44
Programming a Universal
Remote Control.........................................44
SECTION 10: OPTIONS FOR
SYSTEM CONFIGURATION ..............................45
Software Version & Updates............................45
Select Wi-Fi SSID & Password...........................45
Show Wired Ethernet Status............................45
Show Wi-Fi Status...............................................45
Network Control.................................................45
Reset to Factory Defaults.................................45
Restart SoundBridge..........................................45
Safe Mode.............................................................45
Roku Control Protocol (RCP)............................46
Geeks — Read This.............................................46
SECTION 11: Appendices..................................47
1A: MENUS OVERVIEW........................................47
1B: SCREEN ICONS QUICK REFERENCE...........49
2: WI-FI SETUP HELP............................................50
3: END USER SOFTWARE LICENSE
AGREEMENT................................................62
4: REGULATIONS AND SAFELY..........................63
2

4 5
SECTION 1: GETTING STARTED
To use SoundBridge you will need to do the following (detailed explanations follow):
I. Make sure you have a compatible music server installed. Compatible music servers include
Microsoft® Windows® Media Connect, Firefly Media Server,™ Rhapsody,™ Musicmatch,®
and others. (Note: If you plan only to listen to Internet radio, you can skip this step because
no music server is needed.)
II. Connect SoundBridge to your Ethernet or Wi-Fi home network.
III. Connect SoundBridge to powered speakers or your home stereo system’s receiver or
amplifier.
IV. Plug in SoundBridge to AC power (there is no “on/off” switch).
V. Put batteries into your SoundBridge remote control.
VI. Establish a network connection. If you are using Wi-Fi and have WEP security enabled, you
will need to enter your security key with SoundBridge’s remote control.
VII. Enable any music sharing options required by your music server:
a. Windows Media Connect: authorize SoundBridge as a recognized device.
b. Firefly Media Server: always enabled.
c. Musicmatch: enable Music Sharing feature and UPnP option in Options menu.
VIII. Select and connect to your music library.
IX. Play music: Using your remote control, find a song you want to play, then press Play to play
it immediately or Add [+] to add it to the Song Queue.
I. Music Server Software Requirements
SoundBridge is designed to act as a remote client for several kinds of music libraries, including
Windows Media Connect, Firefly Media Server, Rhapsody, Musicmatch and TwonkyVision
MusicServer. You can also play WMA and DRM WMA files purchased from popular online music
stores such as Napster.™(Apple’s policy does not allow SoundBridge to support playback of
protected AAC files purchased from the iTunes Music Store.)
What Is a “Music Server”?
SoundBridge is a network music player. That is, it doesn’t store any music, but plays files that
you have stored on a computer connected to your home network. (It can also play Internet
radio without connecting to your computer, using a direct connection to the Internet.) To play
the music files stored on your computer, SoundBridge needs to receive data from software
installed on the computer that “serves” the music. This “music server” is responsible for
streaming the music to SoundBridge. It is also responsible for sending the list of music you
have available to SoundBridge (when asked), and performing searches of the music library at
SoundBridge’s request.
The most common music servers are Windows Media Connect and Musicmatch. Roku
also offers a customized server (Firefly Media Server) available as a free download from
www.fireflymediaserver.com. If you want to use a Microsoft PlaysForSure™ music service,
you must use Windows Media Connect. If you want to listen to the music you have in your
iTunes library, you must use Firefly Media Server.
Note: For playing back Internet radio using SoundBridge’s “Radio Favorites” library, you don’t
need a music server, because SoundBridge receives the radio stream directly from the Internet.
SoundBridge Has Two UI Modes
Each music server has different capabilities. To experience the full SoundBridge user interface,
which includes searching and robust browsing modes, you must use a server that supports
these functions, such as the Firefly Media Server or Windows Media Connect. Some other
servers don’t have the functionality required to deliver the full SoundBridge feature set. For
example, you won’t be able to search, and the browse modes will vary by server.
1
Section 1: Getting Started Section 1: Getting Started

6 7
You have several options for connecting your music library to SoundBridge:
Music Server Recommended for Users
of . . .
Notes
Windows Media Connect
(UPnP Windows Media DRM
10 protocols)
Windows XP with SP2 A free media server from Microsoft. Works with any music
jukebox, but optimized for Windows Media Player v.10. Supports
SoundBridge’s full Browse, Search and Display feature set. Plays:
WMA, DRM WMA*, WMA Lossless, MP3, WAV, playlists created in
jukebox software such as Windows Media Player 10.
Firefly Media Server (support for
Roku Server Protocol)
PC/Mac This high quality “open source” media server will serve music
in many formats (WMA, MP3, AAC, FLAC, Apple Lossless). It
integrates directly with iTunes and can share your iTunes music
library, or any music library. As with all non-apple products,
it does NOT support Protected AAC files. It does not support
protected WMA files. It does support SoundBridge’s full Browse,
Search and Display feature set as well as playlists and Smart
Playlists created in iTunes.
Musicmatch Jukebox
(UPnP AV protocol)
Windows 98 SE/Me/XP/2000
(SP3 or above)
Popular jukebox software and music service. Has a built-in UPnP
AV server supported by SoundBridge. You can also use Windows
Media Connect with Musicmatch, which is more feature-rich.
Plays: WMA, MP3, WAV (DRM WMA and Musicmatch playlists
supported only if using Windows Media Connect Server).
SlimServer
(SlimServer protocol)
PC/Mac Compatible with SoundBridge, but not supported by Roku.
Requires download of SlimServer software. Uses its own (very
different) user interface.
1
Section 1: Getting StartedSection 1: Getting Started
Installing a Compatible Music Server
To access network music sharing, make sure you have a compatible music server installed.
Compatible music servers are listed on the previous page. To install one of these, follow the
instructions below.
Installing Windows Media Connect
1. If not already installed, install Windows XP Service Pack 2, a free download from Microsoft or
via Windows Update Installer.
2.Download the latest version of Windows Media Player, v.10, a free download from Microsoft
or via Windows Update Installer.
3.Download Windows Media Connect, a free download from Microsoft, or via Windows
Update Installer.
4.Continue to “Enabling Windows Media Connect.”
Installing Firefly Media Server
1. Download and install Firefly Media Server from www.fireflymediaserver.com.
2.Continue to “Enabling Firefly Media Server.”
Installing Musicmatch Jukebox
1. If not already installed, download a free version of Musicmatch Jukebox 9.0 on your PC from
www.musicmatch.com.
2.Continue to “Enabling Musicmatch Jukebox.”
II. Enabling Music Sharing
After installing a music server, you need to enable your music server to share data with your
SoundBridge.
Enabling Sharing in Windows Media Connect
To authorize SoundBridge as a permitted client for Windows Media Connect, follow these
steps:
1. Click the Windows Media Connect tray icon or open Windows Media Connect through the

8 9
Enabling Sharing in Musicmatch
1. Select Options/Settings.
2.Click the CD Lookup/Connectivity tab.
3.Select Enable Music Server and then select Universal Plug and Play. You can close
Musicmatch if you like — the UPnP server will keep running in the background.
III. Hooking Up Your Home Network Hardware (Wired Ethernet or Wireless)
Ethernet Connection: Plug your cable into the jack provided on the right side of the rear
of the unit. Connect your Ethernet cable to a hub, switch or router on your home network.
Alternatively, you can connect SoundBridge directly to your computer (and bypass a hub/
switch/router), but only with a “crossover” cable (sold separately). Connect the other end of the
cable to your network.
Wireless Connection: No need to install any additional hardware into SoundBridge
Please note that most, but not all, wireless access points are compatible with SoundBridge.You
can find a list of supported wireless hardware at www.rokulabs.com/support.
IV. Connect Your Speakers or Stereo System
Connect your audio cable into the left side of the rear of the SoundBridge unit. Your
SoundBridge has several audio connection options:
a.Connect your SoundBridge to a set of powered speakers, using the RCA-to-mini (1/8”) Y-
audio cable included with your SoundBridge (M500), or by plugging your powered speaker
1/8” cable directly into the SoundBridge (M1000).
1
Section 1: Getting StartedSection 1: Getting Started
Windows Control Panel. The SoundBridge device appears in the notification area in the
bottom-right corner of the window.
2.Open the Wizard window, click the SoundBridge device and then click Allow. Windows
Media Connect will now authorize SoundBridge.
3.Click Close.
Enabling Sharing in Firefly Media Server
You do not need to enable the Firefly Media Server to share music. However, the program must
be running in order to play music on your SoundBridge.

10 11
Speaker Base
PC or Mac with
music files
Power Cable
Wireless Router/Switch
(or wired Ethernet)
Connecting to powered speakers (M1000)
b.Connect your SoundBridge to your stereo system’s Aux or other “Line Input,” using one of
the RCA (red/white) audio cables included with your SoundBridge.
Note: If your speakers have a male connector, you will need a female-to-female coupler
available from your local electronics accessory store.
PC or Mac with
music files
Connect 1 of the following:
(1) Optical “Toslink” SPDIF from
SoundBridge to receiver
(2) Black SPDIF Coax (RCA) to “Coax Digital
In” on your receiver
(3) Analog RCA cable (white/red) to AUX
on your receiver
Power Cable
Connecting to a stereo
Wireless Router/Switch
(or wired Ethernet)
c. Connect to your stereo system using either coaxial SPDIF digital or optical SPDIF digital (the
SoundBridge has connectors for both) — cables sold separately.
V. Connecting SoundBridge to AC Power
If you plan to use an Ethernet connection, be sure the cable is plugged in to the unit. Plug the
power cord into the SoundBridge unit, and plug the other end into to a wall outlet.
There is no power switch to turn on SoundBridge. As soon as you plug in the power, you should
quickly see the welcome message “Roku SoundBridge.” If not, please stop and ensure that your
power cable is connected properly on both ends.
VI. Using Your Remote Control
The SoundBridge remote control is an infrared remote, so it needs “line of sight” to
SoundBridge in order to operate. Point the remote in the direction of your SoundBridge,
and make sure that the IR receiver window is not blocked by another object.
VII. Establishing a Network Connection
Wired Ethernet Network: After you have connected SoundBridge to your computer via a
switch/hub/router (or directly to your computer via crossover cable) and powered up the unit,
SoundBridge will auto-configure its network settings (using DHCP or AutoIP). There is nothing
you need to do. If for some reason you have trouble connecting to your network, select the
“System Configuration” option, then select “Show Wired Ethernet Status.”
Note: Do not plug in an Ethernet cable if you plan to use your Wi-Fi network to avoid confusion
in the setup of the device. Also, if you plan to use an Ethernet connection, make sure the cable
is connected before powering up the device.
Wireless Network: If you have an open and visible Wi-Fi network in your home (one which
broadcasts its name, and which has no security keys set) then SoundBridge will auto-connect
to your wireless network. However, you will be asked to enter your network’s name (SSID) if:
- SoundBridge detects more than one Wi-Fi network (as some advanced users have in their
home, or if your neighbor’s signal is leaking over), or
- Your Wi-Fi network does not broadcast its name (for security reasons)
In these cases, enter the SSID using the remote control. Use the Left/Right [◁▷]arrows to
choose letters, and use the Up/Down [△▽]arrows to change to Uppercase and to other
character sets (numbers, international characters) and to enter “Space”, “Delete” and “OK”
when you’re done.
SoundBridge supports networks with WEP security. WPA is not yet supported. If you have a
WEP security key, you will need to enter your WEP key manually into SoundBridge. This is the
1
Section 1: Getting StartedSection 1: Getting Started

12 13
same key you have entered into your Access Point and your computer. Your screen will look
something like this:
No Music Libraries Found (Why?)
System Configuration
Scroll down using your remote control’s Down arrow until the option “System Configuration” is
highlighted, and press Select on your remote control. You will see a screen that looks like this:
Software Version & Updates
Select Wi-Fi SSID & Password
Show Wired Ethernet Status
Show Wi-Fi Status
Navigate down to “Select Wi-Fi SSID & Password” and enter your wireless network name
and password.
For additional help connecting to your network, including password help, see the Wi-Fi setup
section in the appendix of this guide.
Personal Firewall
If you are having trouble connecting, your computer may have a firewall installed that is not set
correctly. Make sure your firewall is configured to allow music sharing from your music server:
For help with firewall troubleshooting, please visit the troubleshooting section of our support
area at www.rokulabs.com/support or visit our user forums at www.rokulabs.com/forums.
VIII. Setting Display Preferences
The brightness of your display can be adjusted by pressing the Bright []button.
Text size and fonts can also be controlled for the SoundBridge M1000’s VFD display by pressing
the Bright button.
Also, from the Home Menu, you can navigate down to the “Settings” option to change certain
options, such as the style of music visualizer, whether the music visualizer appears full screen
during playback, and what kind of information is displayed when a song is playing.
For a complete list of SoundBridge settings, please see the “Advanced Features” section of this
user guide.
IX. Checking for the Latest Software
When a software update is available,your SoundBridge will automatically offer you the choice
to upgrade.Please take a minute to do so.You’ll just need SoundBridge connected to a network
with a high-speed Internet connection.
Note: You will be offered the chance to upgrade after accessing your “source” menu (which
lists your available music libraries and Internet radio). If for some reason you never access this
menu, like you always stay connected to the same library, we recommend checking for new
software manually.
See Options for System Configuration section for instructions on how to check for new
software manually. Roku will release a revised user guide in PDF format periodically to explain
new features or functions that have been added to the SoundBridge software. Please visit
www.rokulabs.com/support to download the latest manual.
X. Wall or Under-Cabinet Mounting (optional)
SoundBridge ships with a portable black rubber table stand which looks great on your shelf or
nightstand. An optional wall mounting kit is available for sale at www.soundbridge.co.uk.This
allows SoundBridge to be mounted to the wall or under a cabinet using a sleek, hidden bracket
which screws into your wall.
1
Section 1: Getting StartedSection 1: Getting Started

14 15
SECTION 2: BROWSING MUSIC
Choosing Your Music Library
Once SoundBridge is successfully connected to your network and your server’s music sharing
options are enabled, SoundBridge will automatically find any supported music libraries on the
network. You will be prompted to choose the library you would like to access from a screen that
looks something like the one on the left:
“Change Library or Configuration” Menu
Play Dan’s Music
Ë Play Joe’s Music
Play AM Radio
Play FM Radio
Play Internet Radio
System Configuration
Playlist
Browse
Search
Show Song Queue
Play Preset
Now Playing
Settings
Change Library or Configuration
Navigate to your preferred library (in this example, “Joe’s Music”) and press Select. You will
then see the “Home Menu” (see above at right), where you can begin browsing and playing
your music.
To change to a different library, or to play Internet radio, select the “Change Library or
Configuration” option located at the bottom of SoundBridge’s Home Menu (accessible by
pressing the Home Menu [ ].
Hint: SoundBridge will automatically connect to the last library you were connected
to when awakened from Standby. Use the “Change Library or Configuration” option to
select a different library.
Remote Control Quick Reference
Use these commands on your remote control to select and play music:
• Use the Up and Down [△▽] arrow buttons to take you through a list item by item. Use
the Select []button to take you one level down into the highlighted item (think of it as
double-clicking a selected item).
• Use the Left and Right [◁▷]arrow buttons to “fast browse” a list of music options
by skipping to the next or previous letter of the alphabet, or if your list is not arranged
alphabetically, by about 5% of your list at a time. Then use the Select []button to choose
an item to play.
• Use the Back []button to go one step backward while browsing, much like the Back
button on your Internet browser. (Pressing Back repeatedly displays the “Now Playing”
screen, with information about the song currently playing.)
• The Search []button takes you to your text-based search options (if supported by your
music server).
• When you find a selection you want to play, you can use the Play []button to play it, or the
Add [+] button to add your current selection to the end of your Song Queue.
• The Pause[ ;]button pauses playback of audio currently playing; pressing again resumes
playback.
• The Next Track and Previous Track[ :9] buttons advance or retreat playback of your
Song Queue (or Internet Radio menu) one song at a time.
• Press the Home Menu [ ]button at any point to return to the beginning menu.
The Home Menu
To begin navigating through your music, start on your “Home” menu, by pressing the Home
Menu [ ]button. The display on SoundBridge should look something like this:
2
Section 2: Browsing Music Section 2: Browsing Music

16 17
Home Menu Overview
ËPlaylists
Browse
Only the first two lines of the Home Menu are displayed at once (or one line if you are using an
M1000 with the largest font size),but you can use the Down ▽arrow on your remote control to
scroll through all these options:
Playlists [Displays all the playlists available for the selected
music library from your network. ]
Browse [Browse the music library by artist, album, song,
genre, and composer]
Search [Enter text for song title, album, artist, composer, and
keyword.]
Play Preset [Select one of 18 different preset stations or
playlists.]
Show Song Queue [Shows past and upcoming songs selected playback ]
Show Now Playing [Shows song now playing. Press Select to get more
info about the selection.]
Settings [Set options for the music visualizer and memorizing radio playlists.]
Change Library [Exit the current music library and connect to another one, or
or Configuration change your network or system configuration.]
The Ëarrow to the left of a menu item denotes the current item. You can also refer to the
scroll bar (at the right of your display) to see your position in the list.
Browsing Your Music by Album
From the Home Menu, press the Down button until you see the “Browse” option highlighted
and press Select. You will see a list of options:
ËBrowse Artists
Browse Albums
If you scroll down, you will see these browsing options:
Browse Songs
Browse Genres
Browse Composers
Now, if you navigate to the “Browse Albums”option and press Select, you
will see an alphabetical listing of Albums found in your music library. The
screen will look something like this:
ËParachutes
Paul’s Boutique
Navigate to the album that you want to hear using the Up/Down [△▽]
arrow buttons — in our example,“Parachutes.”Or, for faster browsing,press
the right arrow to skip ahead in the album list to the next letter of the
alphabet.When the album you want is selected, press the Select button for
a listing of songs found on this album.
Ë Don’t Panic
Shiver
The music note next to each song name indicates the selection is an
individual track (and not a playlist, album or other collection of songs).
Note: Songs purchased from the Apple Music Store will be displayed with a
padlock œicon. SoundBridge is not able to play back these “locked” files — they will simply be
skipped during playback.
Use the Up/Down arrows again to highlight the song you want to play. Press the Play button
(or press the Select button twice) to start that song playing. When the song begins playback,
the display will switch to the “Now Playing” screen, which looks something like this:
Don’t Panic 0:10/2:17 4
Coldplay - Parachutes (2000) (|||------)
Please note that the artist and album information may be abbreviated, or appear one line
at a time, if the total number of characters exceeds what can be displayed at once. See the
“Settings” chapter at the end of this manual for more information on display options.
Hint: If you would like to go back to the above “Now Playing” screen at any time in order to see
what’s playing, press Back several times until you see this screen. Alternatively, press Home
Menu [ ], then scroll down to the “Show Now Playing” option and press Select. This screen
Section 2: Browsing Music Section 2: Browsing Music

18 19
also appears by default after a few minutes of inactivity on the remote control.
If you press Play on an album track, that track will play, followed by each track remaining on the
album. For example, if you press Play on track #5 on an album containing 10 tracks, then tracks
#5–#10 will play. (For continuous playback of the entire album, press Repeat [ ]on your
remote control — the album will play until the end, then start again at the beginning.)
You can also browse to an album, artist or genre selection and press Play to start playing the
entire contents of the selected category.
If you are not sure what you have selected to play, simply press the Down arrow from your
“Now Playing” screen (the screen that displays the currently playing song). This is a shortcut to
the Song Queue, which shows your upcoming songs (see upcoming section, “Building a Song
Queue”).
Hint: If you navigate to a new song and press Play while your original selection is
playing, you will overwrite the old selection (called the “Song Queue”) and begin playing
your new selection. Therefore you should only press Play when you want to clear your
previous music selections. Use the Add [+] button to add your new selection to the end
of your Song Queue.
Browsing by Artist or Composer
Browsing by artist or composer works similarly to browsing by Album, as described above.
After entering your desired artist or album, you will see a screen that lists the albums available
by that artist:
Ë<Show all matching songs>
Medusa
You can add all songs by this artist to your existing Song Queue by pressing Add [+] while the
first menu item <Show all matching songs> is active. Or, press Play to play all songs by this
artist and replace your existing Song Queue. (Songs will play in the order they appear on each
album, with each album played in alphabetical order).
Hint: Artist names starting with “the,” such as The Beatles, will be found under the first
letter of the word following “the” — in this case, “B” for “Beatles”.
You can choose specific albums or songs to play by navigating down to your desired album and
pressing Add [+] to add to an existing Song Queue, or Play to replace an existing Song Queue.
Hint: if your selected album contains songs by different artists, such as compilation
albums or movie soundtracks, only the song(s) by your selected artist will be played.
Browse by Album instead to play all the tracks.)
Browsing by Song
Browsing by song displays a list of all the songs in your music library, listed in alphabetical
order. Use the Left/Right [◁▷]arrows to “fast browse” through the list, or Up/Down [△▽]to
move through the list one item at a time.
Browsing by Genre
Browsing by genre displays an alphabetical listing of genres that describe the artists in your
music library. To add all songs within a genre to your Song Queue, highlight that genre and
press Add.
To browse within a genre, such as Hip Hop/Rap, press Select on your desired genre. You will
see a list of artists in that genre, with the option to see a list of all albums in that genre. Or you
can navigate to an artist and press Select to view albums of the selected genre by that artist.
Hint: Information about your music, including Song Name, Artist, Album, and Genre is
usually created automatically by the software you used to save your audio CD files on
your computer’s hard drive (aka “ripping”). This process creates data called “ID3 tags”
to describe each track. If this data is missing from your audio files, they will not appear
when you browse by that data category. If you need to edit your ID3 tags, or if you are
not satisfied with the description of genres (or other data) assigned to your music file, it
is possible to edit that data in Windows Media Player or other supported music jukebox
programs.
2
Section 2: Browsing MusicSection 2: Browsing Music

20 21
SECTION 3: THE SONG QUEUE
SoundBridge automatically builds a song queue every time you select a song or album to play.
This section will tell you how to build a Song Queue, review a Song Queue and erase a Song
Queue.
Building a Song Queue
Let’s say you would now like to choose several different songs or selections to play in a row.
This is called building a “Song Queue.” SoundBridge automatically builds a new Song Queue
every time you select a song or album to play. You can add to that list by navigating to your
preferred music and pressing Add [+]. The selection will be added to the end of the current
Song Queue.
You may add a single song, an entire album, all songs by an artist, all songs in a genre, or any
search result — just browse to the selection you prefer and press Add [+]. For example, if
you would like to play all songs by Coldplay, select Home menu > Browse > Browse artists.
Navigate to Coldplay in your artist list and press Add [+]. All songs on all albums by Coldplay
will be played in the order they appear on each album. See “Browse” and “Search” for more
information.
You have several other options for building a Song Queue. After you press Select while
browsing on a song, a “Song” menu appears with the following options:
Play Songs, Starting With selected song name (and clear previous Song Queue)
Get Song Info
Play Song (and clear previous Song Queue)
Add Song to Song Queue (same as pressing the Add [+] button)
The first, “Play Songs” option is described in the section above — it starts playing your album
(or other browsed list), beginning with the current track.
If you choose “Play Song” on any track in your selection, the entire list is added to the Song
Queue, but playback starts on the chosen track. If you have the Repeat [ ]option selected,
the earlier tracks in the queue will play after the last song. If you have the Shuffle [ ]option
selected, then the chosen track will play first, followed by all the other tracks in the list in
random order.
The “Add song to Song Queue” option behaves similarly to the Add [+] button it places the
current song at the end of your playlist.
You can add an almost unlimited number of songs to your Song Queue. Each selection will be
played in the order it was entered (unless you have chosen to Shuffle your Song Queue).
Hint: After you have selected multiple songs to be played in turn, you can use the Next
Track [9]and Previous Track [:] buttons to skip from song to song in your Song
Queue.
Reviewing a Song Queue
At any point, you can review what’s in your Song Queue by pressing the Down [▽]arrow from
the Now Playing screen, which is the default screen that appears while SoundBridge is playing.
The Now Playing screen looks something like this:
Don’t Panic 0:10/2:17 4
Coldplay Parachutes (2000) (|||------)
Alternatively, you can press Home Menu [ ], then select the “Show Song Queue” option. You
will see the entire list of songs in your song queue; refer to the scroll bar on the right side of
the screen to determine where in the list you are located. Press the Up/Down arrows to see the
entire list of selections in your Song Queue. The currently playing selection is indicated by a
speaker X)).
You cannot save a Song Queue that you have created — it’s only held in memory temporarily
until you build your next Song Queue. If you would like to build a Song Queue that you can
save, please build a Playlist in your music jukebox software (see “Playing a Saved Playlist”
below).
When the Song Queue has played all the way through, it will stop (unless repeat has been
selected). You will see the Stop icon <on the right side of your display. To start playing your
Song Queue again at the beginning, press the Play button.
Erasing a Song Queue
If you decide you don’t want to play the Song Queue you’ve just created, simply select
something else to play. Navigate to another selection (song, playlist, etc.) and press Select or
Play (not Add [+]). This selection immediately replaces your old Song Queue.
3
Section 3: The Song Queue Section 3: The Song Queue

22 23
SECTION 4: ADDITIONAL PLAYBACK OPTIONS
Playing a Playlist
To play a playlist that you have created in your music jukebox software such as Windows Media
Player, select the Playlist option from the Home Menu [ ]. Use your Up/Down [△▽]arrows
to browse your playlists one by one, find the one you want to play, then press Play to play all
songs on the playlist immediately or Add [+] to add the playlist to your Song Queue. Playlists
can include audio tracks and Internet radio streams. If your playlist was created in Windows
Media Player or other software using Windows Media Connect, be sure to save your playlist in
the My Music/My Playlist folder on your hard drive, or configure Windows Media Connect to
share the directory on your hard drive containing the playlist.
Repeat and Shuffle
Pressing Repeat [ ]once makes your Song Queue play continuously. You will see the Repeat
icon qdisplayed on the right side of your “Now Playing” screen below the Play icon. Pressing
Repeat again makes the current song play over and over; you will see another Repeat icon,
a circle with just one arrow . Press Repeat a third time and you will remove the repeat
command altogether.
Pressing Shuffle [ ]while playing a Song Queue will give you the following options:
Shuffle On — will play everything in your Song Queue in random order. (The shuffled order
of songs will be displayed in the Song Queue.) An icon with two crossing arrows will be
displayed on your Now Playing screen.
Shuffle Off — will play everything in your Song Queue in the original order.
You can execute the Repeat and Shuffle command from any menu in SoundBridge. Even
though you can only see the mode change on the Now Playing screen, the command is taking
effect.
Search Options
To search for a specific selection by spelling it out, you can press the Search []button on
your remote control, or navigate down to the “Search” option from the Home Menu.
Note: Unfortunately Musicmatch does not support searching on SoundBridge at this time. If
searching is not available, the Search menu item will not appear, and pressing the Search key
on the remote will display a message.
Whether you use the Search menu or the remote button, you will see the following options:
Search for Titles
Search for Albums
Search for Artists
Search for Composers
Search Keywords
Press Select on the option you would like to search with. Then, use your Left/Right arrows
on the remote control to enter characters for spelling your selection and then pressing Select.
When you are done spelling, use the Down button to go to the OK option and press Select. (If
you make a mistake, use the Down button to go to the Delete option and press Select.)
Hint: Partial spelling is OK — the Search function searches for letters anywhere in the
word, as opposed to just at the beginning. For example, to search for Radiohead, you
can enter any combination of letters found in the word (“RA,” “DI,” “HE,” etc.), and the
results will return all Artists containing those letters (e.g., if you enter “DI” you may get
Radiohead, India Arie, and Diana Krall).
When you find the music you like, use the Add [+] button to add it to your Song Queue. If
searching for albums or artists, you can press Select to navigate down to individual tracks.
4
Section 4: Additional Playback Options Section 4: Additional Playback Options

24 25
SECTION 5: PRESETS
Your SoundBridge includes 18 positions in its internal memory, which can store a variety of
selections for your quick and easy recall. You can save just about anything to Presets that you
can play on the SoundBridge by highlighting it and pressing the Play key. For example, you can
save all tracks by a single artist, a Playlist, an Internet Radio Station, or a set of search results.
Simply navigate to your selection and press the Play button to begin playing it. Then press
Select []and scroll down to the option “Save Preset: [Name of selection]”. Each position is
numbered: A1-A6, B1-B6, and C1-C6. Choose which preset you would like to replace, and your
preset will be saved.
For example, let’s say you want to save all tracks by the artist Coldplay as one preset. Select the
Browse/Browse Artists options and scroll down to the listing “Coldplay”. Press Play, and then
press Select. Scroll down to the option “Save Preset: Tracks by Coldplay” and press Select.
Note: You cannot make a preset out of a Song Queue that was created using the Add key or
menu command. The selection must be playable simply by hitting the Play key on the remote.
Individual tracks cannot be saved as Presets. When an Internet radio station is playing, even if it
was part of a larger list, only the individual station is saved.
Recalling Presets
You can access your Presets in several ways:
From the Home Menu of any music library, scroll down to “Play Preset” and press Select. Scroll
down to the preset you would like to play and press Select [].
While listening to any selection (music, Internet radio, etc.) press Select from the Now Playing
menu and scroll down to the “Play Preset…” option.
Editing Presets Using the Web Interface
You can also edit your presets in the SoundBridge web interface. See page 35 for instructions
on connecting to your web interface. Click on the link to the “Presets” page. Here, you can:
- Re-name a Preset by typing a new name into the web form.
- Reorder the selections in the list by pressing and dragging the “Move” button.
- Play back the selection by pressing the “Play” button next to the selection. (If your
SoundBridge is in Standby mode when you press Play, it will power up and start playing.)
- Enter a stream URL for an Internet radio station from an external source. (For help with
locating and importing stream URL’s, see the link on the top of the web page. For more
information about playing Internet radio streams, see the “Internet Radio” section of this
user guide.)
When you are finished editing your Presets, click on the “Update Presets” button at the bottom
of the page.
Presets commands can also be programmed into a universal remote control. For more
information, see the “Programming a Universal Remote Control” section in the Advanced
Features chapter of this document.
5
Section 5: Presets Section 5: Presets

26 27
SECTION 6: INTERNET RADIO
You can listen to Internet radio in one of two ways. First, you can listen to SoundBridge’s built-in
set of radio stations located in the “Internet Radio” Library. Your computer does not need to be
on - all you need is an active Internet connection on your home network. Second, you can enter
a URL of a radio station playlist on the Internet Radio tab of the SoundBridge web page. (This
feature is described more in the “Web Page Control” chapter of this user guide.)
The easiest way to play Internet radio on SoundBridge is through the “Internet Radio” Library,
where you can access a large and growing number of Internet radio stations, browseable by
Name, Genre, Language, and Location. To navigate to the “Internet Radio” Library, follow these
steps:
1. Press Home Menu [ ]. Navigate down to ”Change Library or Configuration” and press
Select [].
2. Your available music libraries will be displayed, including the one named “Internet Radio.”
Select that library and you will see a list of Internet radio stations. These are your Presets,
and they are pre-loaded when your SoundBridge is first set up. See below for more
information on how to edit these Presets.
3. Scroll to the station you want to play and press Play. (Alternatively, you can press Select
[]and choose “Get Station Info” to view the genre/format of the station, its language and
location.)
When the station is playing, the “Now Playing” screen looks similar to this:
Michelle Shocked — Black Widow
http://www.radioparadise.com
RadioParadise.com
The song and artist information is provided by each Internet radio station. Therefore, it may not
be available for every Internet radio station, or it may look slightly different.
Browsing Internet Radio Stations
You can browse SoundBridge’s built-in stations by Name, Genre, Language or Location. From
anywhere in the Internet Radio Library, press Home Menu [ ]. You will see the following
options:
My Favorites
Browse
Play Preset
Show Now Playing
Select “Browse” and choose the method of browsing that you prefer:
Browse Names
Browse Genres
Browse Locations (by country of origin)
Browse Languages
Hint: You can “Fast Browse” a list of results by pressing the Left/Right [◁▷]arrows on
your remote; your results will skip to the next letter of the alphabet.
Choose your desired browse option and press Select. Scroll down to the station you would like
to hear and press Play (or Select twice) to begin playback.
Customizing Favorites and Presets for Internet Radio
There are two ways to save Internet radio stations for easy playback.
The first way has already been discussed, and that is to save the station as a Preset. Whether the
station was found by browsing SoundBridge’s built-in Internet Radio Library, by playing it from
music server on your computer, or by entering it manually on the web page, it can be stored in
a Preset slot and played back easily via the “Play Preset” command.
The second way is to mark a station from the built-in Internet Radio Library as a favorite. When
a station is marked as a favorite, it appears in the “My Favorites” list in the Internet Radio library,
but does not use up one of the 18 Preset slots.
Note: If a station is saved as a Preset, then it is assumed to also be a “favorite”, and will
always appear at the front of the “My Favorites” list.
There are several important differences between Presets and My Favorites:
ËPresets are accessible from any Library, while My Favorites only appear in the Internet
Radio Library.
6
Section 6: Internet Radio Section 6: Internet Radio

28 29
ËMy Favorites may only contain stations found by browsing the Internet Radio Library.
Presets may contain stations from the built-in library or entered via the web page.
ËPresets can recall content other than Internet radio stations, like playlists or
selections that you have browsed to from SoundBridge (such as all songs by a
particular artist, etc). My Favorites include only Internet radio stations.
ËWhen displaying My Favorites, Internet radio station Presets are also included at the
beginning of the list.
ËPresets can be programmed and played from the preset web page (see page 25 for
more information.)
ËPresets can be programmed as discrete commands on a custom remote control. (For
more information about customizing your remote for SoundBridge control and a
pronto CCF file, please visit the Support section of our web site.)
To save an Internet radio station to My Favorites:
1. From the “Internet Radio” Library, Scroll down to the “Browse” menu item. Navigate to the
station you would like to save.
2.Press Select, then press the Down arrow to display these options:
Play [Station name]
Get Station Info
Add Station to My Favorites
3.Scroll down to the option “Add Station to My Favorites” and press Select. You will see the
message “Station added to your favorites”. Next time you view My Favorites, you will see
that station displayed in the list.
You can also save a station to My Favorites while it is playing. Simply press Select to display
these options:
Get info for “[Station name]”
Play Preset…
Save Preset: [Station name]
Add Station to My Favorites
Stop
Select the option “Add Station to My Favorites” and press Select.
Note: Only stations that you have accessed via the browse feature in the Internet Radio Library
can be saved to your Favorites. Stations that are played from a URL manually entered as a Preset
cannot be saved to your Favorites.
To save an Internet radio station to your Presets:
Play a radio station and press Select. You will see the following list of options:
Get info for “[Station name]”
Play Preset… (this displays a list of your 18 presets)
Save Preset: [Station name]
Add Station to My Favorites
Stop
Select the option “Save Preset: [Station name]” and press Select. Scroll down to the position
you want to replace and press Select. Next time you view Presets, you will see that station
displayed in the position you have chosen. You will also see Presets displayed first in the list of
My Favorites.
Playing Stations Saved as “My Favorites” or “Presets”
From anywhere in the Internet Radio Library, press the Home Menu [ ]. Choose the “My
Favorites” option. You will see a list of your Internet radio Presets followed by your Favorites.
Navigate to the station you would like to play and press Select []. You will have the option to
play it, get station info, or “Remove station from My Favorites”.
You can also just press the Down arrow on the Now Playing screen of an Internet radio station.
Since there is no Song Queue when listening to Internet radio, this shortcut takes you directly
to My Favorites. If the currently-playing station appears in My Favorites, it will be marked with
the speaker icon [X].
To play your Presets, you can also choose the Play Preset option from the Home Menu of any
music library (not just the Internet Radio Library). Choose the station you would like to play,
then press Select.
6
Section 6: Internet Radio Section 6: Internet Radio

30 31
Playback Limitations of Internet Radio Streams
SoundBridge currently supports MP3 and WMA Internet radio stations. RealAudio and AACplus
stations are not supported at this time. However, stay tuned for additional formats that may be
supported in future software releases.
Unfortunately, there are few standards in Internet radio (especially for MP3 stations), and
sometimes a station will do something out of the ordinary that will prevent SoundBridge from
being able to play it. See our online document at www.rokulabs.com/support/internetradio.
php for more information.
Discovering More Internet Radio Stations
Our online user forums have an active discussion dedicated to helping SoundBridge users find
good Internet radio stations in a variety of genres. Visit our Forums (accessible from www.
rokulabs.com/support) and look for the discussion topics related to Internet radio stations if
you would like to find more stations in a particular genre or would like to suggest a station or
offer help to others on this topic.
SECTION 7: SOUNDBRIDGE WEB INTERFACE
Use SoundBridge’s web page to control SoundBridge playback remotely, configure your
SoundBridge or reconfigure your preset Internet radio stations by entering the stream URL
directly into the web page. There are several ways to access the web page:
Launching the Roku Web Interface
PC/Windows users:
You can configure your computer to display UPnP devices including SoundBridge in your My
Network Places window.
Windows XP Service Pack 2 (SP2) users:
1. Open My Network Places
2. Click on Show icons for networked UPnP devices in the Common Task panel on the left
side of the My Network Places window. If the Common Task panel is not visible
a.Select Tools>Folder Options in the My Network Places window
b.Under the Tasks section, choose Show Common Tasks in Folders and click OK.
3. Choose OK when asked to open the UPnP firewall ports.
Windows XP Service Pack 1 (SP1) users:
From the Control Panel, click Add or Remove Program.
1. Click Add/Remove Windows Components.
2. From the Windows Component list, select Network Services and then click Details.
7
Section 7: SoundBridge Web InterfaceSection 6: Internet Radio

32 33
3. Select the UPnP Interface check box.
4. Click OK and then Next. The Configuring Window appears.
5. When the configuration is completed, click Finish.
6. Navigate to My Network Places and double-click the SoundBridge icon. You are now ready
to access SoundBridge’s web interface.
Apple/OSX users:
Follow these steps to access the web page:
1. Launch the Safari web browser. Because SoundBridge uses the Bonjour protocol (formerly
known as Rendezvous), the device automatically announces itself.
2.In Safari, be sure you have your bookmark list showing. If it is not showing, go to the
Bookmark menu and select Show All Bookmarks.
3.Click on the Bonjour option in the bookmark list to reveal your SoundBridge. If more than
one device is connected, they will be named SoundBridge, SoundBridge (2), and so on.
4.Double-click the name of your device to open the SoundBridge web page.
7
Section 7: SoundBridge Web InterfaceSection 7: SoundBridge Web Interface

34 35
The web page includes four tabs:
Now Playing
Allows for control of playback of current music selection, including Pause, Play, Next/Previous
Track, Stop, Repeat and Shuffle. You can also change the volume level.
Presets
On this page, you can:
- Specify up to eighteen of your favorite music selections, such as Internet radio streams,
search results, or Playlists, to be stored in your Presets. (See p 26 for more info about
Presets.)
- Change the name of a Preset.
- Click and drag the “Move” button to change the order of items in your Preset list.
- Press the “Play” button to play a preset item on your SoundBridge.
Why eighteen presets? Roku’s new Wi-Fi Radio includes eighteen preset buttons on the top of
the unit– which makes playing and changing presets quick and easy.
If you experience problems with playback of an Internet radio stream you copied from a web
browser, make sure that copied the correct URL. Usually, an MP3 stream URL ends with the
“.pls,” or “.m3u” extension, and a WMA stream ends with “.asx”. Currently, SoundBridge can
stream MP3 and WMA formats. RealAudio streams (ending in .ram or .rm) are currently not
supported. AACplus stations may use the same extensions as MP3 stations, but will not be able
to be played. Usually, an Internet radio station’s web site will say which format is being used.
Stay tuned for additional format support in future software updates. 7
Section 7: SoundBridge Web InterfaceSection 7: SoundBridge Web Interface

36 37
You may wish to use fewer than the 18 available Preset slots. If you want to leave a slot empty,
ensure that the menu below the “Name” label reads “URL”, and then ensure that both the name
and location boxes are empty. When you save changes, the Preset will be marked as empty.
When you are finished editing your presets, click on the “Update Presets” button at the bottom
of the page.
Hint: If for some reason you insert a URL that is too long to fit inside the text field
(longer than 250 characters), SoundBridge will automatically revert to the previous
URL that was in your list before.
Please see the “Internet Radio” section for information about accessing and playing your stored
stations from your presets..
Configuration
Use this page to enter a unique name for your SoundBridge unit, choose a language other
than English, or set options for displaying the time and date on your SoundBridge when it is
in Standby mode. See the “Clock Settings” and “Language Setup” sections of the Advanced
Features chapter at the end of this manual for more information.
7
Section 7: SoundBridge Web Interface Section 7: SoundBridge Web Interface
