Expobar MONROC Guide

U / GB
Rev. 090123
...............................................................................
...............................................................................
Instruction manual and maintenance
MONROC

1. Contents Page 2
2. Identification of external components Page 3
3. Characteristics Page 3
4. Equipment provided Page 4
5. Installation of the coffee machine Page 4
6. Filling water in the boiler Page 5
7. Pressure gauge Page 5
8. Start up Page 5
9. Fitting the filter holder into the brew group Page 6
10. Dispensing of coffee MONROC Page 6-7
11. Control panel
11.1 Programming the electronic control panel Page 8
11.2 Electronic control panel alarms Page 9
12. Heating of liquids Page 9
13. Extraction of water for infusions (teas) Page 9
14. Cleaning the coffee machine Page 10
15. Cleaning the brew group Page 10
16. We recommend Page 11
17. Possible dysfunctions Page 12
18. Precautions Page 12
1. Contents MONROC
2.
READ THIS INSTRUCTION AND MAINTENANCE MANUAL CAREFULLY
BEFORE INSTALLATION AND BEFORE USING THE COFFEE MACHINE

3.
1. Steam tap
2. Boiler pressure gauge
3. Water tap
5. Electronic control
panel
6. Indication lamp
7. Adjustable leg
8. General switch
9. Filter holder
10. Brew group
11. Hot water exit
12. Exit steam spout
Model Unit Measurements in mm. Boiler Power (W) Voltage Weight
Number Width depth height Litres Resistance Total Vac Kg.
2 Units 2 650 530 480 11.5 3050 3235 230 60
3. Characteristics
2. Identification of external components MONROC
FIG. 1

4.
For models: Units 2, 3 and 4.
2 complete filter holders for two cups
+ 1 filter holder for 1 cup.
+ 1 1/2 meter hose.
+ 1 clean unit filter.
When the machine is installed in its case, the latter must be as near horizontal as possible (use the
adjustable legs) so that the coffee issuing from the machine is evenly distributed between the cups.
- Electrical installation:
Electrical installation of the coffee machine must be performed by qualified personnel, who must
follow closely the following safety instructions:
a) Check that the electrical information on the data plaque fits with the installation on your site
or at your home.
b) The coffee machine must be connected to a socket with current provided with an earth
which complies with current regulations in your country.
c) The electric cable on the installation site must be protected with a magneto-thermic fuse
which should be adequate for the power of the current used by the coffee machine, as
indicated on the data-plaque.
d) There must also be a differential relay adequate for the type of installation.
e) Make sure that the thickness of the installation cables is suitable for the energy
consumption of the coffee machine. Do not use extensions, adapters or multiple sockets
when connecting the coffee machine to the electricity supply.
- Hydraulic installation:
Using the pipe connected to the machine, connect it to a male 3/8” water tap
with a screw-down valve. It is obligatory to fit a softener between the
valve and the machine (in the equipment provided there is a 50 cm pipe for making this
connection). In a later chapter we will explain how to regenerate the resins in the softener so
that they continue capturing the lime particles.
The manufacturer is not responsible for any injuries or damage to health, whether of animals or
human beings, nor for any material damage caused by incorrect installation of the coffee machine.
4. Equipment provided MONROC
5. Installation of the coffee machine MONROC

5.
Water is refilled automatically.
Indicates pressure in the interior of the boiler
Pressure-Temperature Relationship
6. Refilling water in the boiler MONROC
7. Pressure gauge MONROC
8. Start up MONROC
Temperature (ºC)
125
120
115
110 0,6 0,7 0,8 0,9 1 1,1
Pressure bars
1. Open the water screw valve external to the machine.
2. Connect the general switch, see (8) Fig. 1-.
3. Open the steam tap until steam is emitted.
”The red pilot light, see (6) Fig.1,- shows that the machine is heating up.
When it goes out, the machine has reached its ideal temperature”.
4. Connect the dispensing button, see (4) Fig. 1, or the control panel, see (5) Fig. 1 ,until
the water is issuing continuously for each dispensing unit, see (10) Fig. 1.

6.
Water is refilled automatically.
9. Fitting the filter holder into the dispensing unit MONROC
10. Coffee dispensing MONROC
CORRECT POSITION OF THE HOLDER IN THE UNIT
CORRECT THE RUBBERS ARE WORN
FIG. 2
PULSER MODEL
a) Pull the filter holder away from the machine.
b) Place the amount of coffee you need for coffee of your choice in the filter.
Preferably, the coffee should have been recently ground. Use the appropriate filter holder
See Fig. 4-.
c) Push the coffee down with the coffee press.
d) Position the filter holder into the unit and make sure that it is really tight,
see Fig.3-, place the cup below the filter holder’s outlet, and activate the dispensing
switch, - see (4) Fig. 1-.
FIG. 3
FITTING THE FILTER HOLDER INTO THE
DISPENSING UNIT
The filter holder has two projections on the sides which
must be fitted into the unit’s slots. When that has been
done, turn from left to right until the handle of the holder
is at a perfect right angle to the coffee machine.

7.
10. Dispensing coffee MONROC
CONTROL MODEL
a) Pull the filter holder away from the machine.
b) Place the amount of coffee you need for coffee of your choice in the filter.
Preferably, the coffee should have been recently ground. Use the appropriate filter holder
See Fig. 3-.
c) Push the coffee down with the coffee press.
d) Select the desired option from the electronic control panel.
The panel is pre-programmed with 4 standard doses (which can be programmed to your taste,
see programming) and a continuous dispensing option. The first four buttons
(1 small coffee - 1 large coffee - 2 small coffees - 2 large coffees) are automatically
disconnected, and the fifth is for continuous coffee, to disconnect it push it again
ALWAYS LEAVE THE FILTER HOLDER ENGAGED IN THE UNIT.
It is very important to keep it at the ideal temperature, so that you can get
a good expresso coffee.
.
Filter holder for two
doses of coffee Filter holder for one dose of coffee
Filter for two doses of
coffee Filter for one dose of
coffee
FIG. 4

8.
11. Electronic control panel MONROC
11.1. Programming the electronic control panel
Keep pressing the continuous button, on either of the two control panels, for 8 seconds. The
continuous coffee lights will blink on and off.
Press the coffee dose you want to reprogramme (1 espresso - 1 large coffee - 2 espresso -
2 large coffees). It will then begin to dispense coffee. When you have reach the desired dose,
push the dose you selected once more to end the process, and the dose will be remembered.
Repeat the process for the other buttons.
Very important: When you reprogramme a dose in the left hand control panel (looking at the
machine from the front), the dose will be remembered in both control panels.
Example: If we re-programme the dose of the small coffee button on the left control panel, the
new dose which we have placed in the memory is remembered by the small coffee button on the
other control panels.
This only happens with the left control panel, if we re-programme another panel only that panel is
modified.
When reprogramming the coffee dose, fresh coffee must be used in the filter.
FIG. 5
2. ESPRESSO
1. ESPRESSO
1. LARGE
COFFEE 2. LARGE COFFEES
CONTINUOUS
COFFEE

9.
11. Electronic control panel MONROC
11.2. Electronic control panel alarms
When the electronic control panel detects a lack of water in the boiler, the five lights on the control
panel will blink.
When the volume meter on the electronic control panel detects a problem, the light for the dose
which we have pressed blinks.
Maximum security period. All doses have a maximum coffee dispensing time of five minutes.
Heating of liquids
a) Fit the steam pipe, which is above the tray, and open the steam tap, see (1) Fig. 1-, so
that any condensed water in the pipe escapes.
b) Close the steam tap.
c) Place the steam pipe in the liquid to be heated.
d) Open the tap. It will begin to heat (never take the steam pipe out of the liquid to be
heated because it could spray out hot liquid which could cause scalding).
e) When the process is finished, place the vaporiser on the tray, open the steam tap so
that the inside of the pipe is clear of remains of milk or other liquids, close the tap and
clean the outside of the pipe with a damp cloth.
Extraction of water for infusions (teas)
Place the receptacle in which you wish to put the hot water beneath the water pipe.
Open the water tap, see (3) Fig. 1, until enough water has been obtained.
Close the tap.
12. Heating of liquids MONROC
13. Extraction of water for infusions (teas) MONROC

10.
14. Cleaning the coffee machine MONROC
Cleaning the coffee machine
Disconnect the machine for cleaning. The entire surface of the coffee machine can be cleaned with
a damp cloth. Use NON-aggressive detergents.
Do not use solvents or degreasing agents.
Cleaning the dispensing unit
a) Pull the filter holder away from the machine.
b) Place the filter membrane inside the filter holder, -see Fig. 6-.
c) Place a sachet of detergent inside the filter holder. Special detergents
must be used for cleaning the dispenser unit.
d) Place the filter holder in the coffee machine and press the dispensing button, - see (4)
Fig. 1, for about 10 seconds.
Repeat the operation at least five times.
Important: When the cleaning cycle with detergent is finished, dismount the filter and wash it
out. For complete elimination of any leftovers, repeat the cleaning but this time without using any
detergent.
”DO NOT HANDLE THE FILTER HOLDER DURING THE SELF-CLEANSING PHASE”
The unit must be cleaned every day without using detergent, only with the membrane and water.
The unit must be cleaned with detergent once a week. Filter
15. Cleaning the dispensing unit MONROC
Filter
Filter membrane
Filter membrane
Detergent
FIG. 6

11.
We recommend
·The unit must be cleaned every day without using detergent, only with the membrane
and water.
·The unit must be cleaned with detergent once a week.
Depending on the hardness of the lime, decalcify.
Use freshly ground coffee to preserve the aroma and taste of the coffee.
To prepare good coffee, do not forget that the dispensing unit as well as the filter
holder must be warm and at a constant temperature, which is why the filter holder must
always be fitted into the unit.
16. We recommend MONROC

Possible dysfunctions
These malfunctions are caused by lime:
The coffee does not emerge at the right temperature:
- The exit tubes of the exchangers are obstructed by lime.
Water fails to issue from the brew groups:
17. Possible dysfunctions MONROC
12.
Precautions
When brewing a coffee, never take the filter holder out. Hot water under pressure can
cause serious scalding.
Never handle anything inside the machine. Only qualified authorised personnel may
do so.
Never push anything into the ventilation slots
Periodically check the drainage tray.
Do not let children play with the machine. They could be burnt.
Do not use the machine with wet hands or when feet are wet or unshod.
When disconnecting the coffee machine from the electricity supply, never pull the cable.
Always use the pin.
If in any doubt, contact qualified and authorised support.
The manufacturer reserves the right to modify the machine without prior warning, in the
interest of improving the product.
18. Precautions MONROC

Art. nr/Art. no. 1730041
FOR SERVICE
Your retail dealer
...............................................................................
...............................................................................
...............................................................................
CREM International AB
Box 960, 671 29 ARVIKA, Sweden
Tel:[phone], Fax: [phone]
E-mail: [email protected] www.creminternational.com
