Exputt RG EX500D User manual

GOLF PUTTING SIMULATOR
User’s Manual
EX500D
Please read the ‘Safety Notes’carefully before using the product in order to use it safely and prevent
damage. This manual includes a product warranty. Please read this User’s Manual carefully and keep it safe
for future reference. The product images in the manual are included for explanatory purposes and may
differ slightly from the actual product.

2

3
Table of Contents
1. SETTING UP 5
Components 5
Product specifications 6
Name of each component of the EXPUTT camera 6
Connecting cables 7
Installation of EXPUTT camera 7
The putting mat and control keys 9
Putter sticker and control key input 9
2. GETTING STARTED 10
Remote control 10
Login 11
WiFi setting 11
Creating profile 12
Searching for the putting mat 12
Connecting to a mobile device 13
3. USING EXPUTT 14
Main menu 14
Personal setting 14
Classic 15
Multi 16
Explorer 17
4. TROUBLESHOOTING 19

4
Safety Notes
Warning
Be sure to follow the Precautions as failure to do so may result in death or severe
injury due to fire/electrocution.
Precautions
Make sure to correctly connect the AC adaptor to the rated voltage before use.
Do not use the AC adaptor or power cord if it is damaged or if the sheath is torn.
Make sure to use the correct AC adaptor
When changing the location of installation of the EXPUTT camera, make sure to
separate the AC adaptor plug from the power. When unplugging the power cord,
make sure to correctly hold and unplug the main body of the AC adaptor.
In the event of overheating or abnormal operation of the product, stop using it
immediately and contact the Customer Center.
Do not try to disassemble or remodel this product.
Keep this product away from infants and children at all times.
Use this product in a well-ventilated place. Do not install the product near a
heating machine or a place full of moisture or dust.
As a golf ball could be knocked off the mat due to an abnormal putting stroke, be
sure to install the product in a safe place where it can cause no injury or damage.

5
1. SETTING UP
Components
The package consists of the following components. Make sure to check them.
The images in the user’s manual are included for explanatory purposes only and
may differ slightly from the actual components.
The design and specifications of the product may be changed without notice to improve
the quality.
Golf balls are not included with the components. We recommend the use of clear, white
golf balls.
01 02
04 05 07
06
10
09
03
08
01 EXPUTT camera 06 Putter sticker
02 AC adoptor 07 User manual
03 HDMI cable 08 Tripod
04 TV attatching holder 09 Connecting rod
05 Remote control 10 Putting mat

6
Product specifications
Name of each component of the EXPUTT camera
0102 03 04 09 07 10 06 05 08
01 Camera lens 06 Power terminal (micro-C type)
02 Dial for camera rotation 07 HDMI terminal
03 Indicating LED 08 micro SD card slot
04 Remote control receiver 09 USB port (WiFi dongle)
05 Power button 10 Female tripod mount (0.25 inch)
Power DC 5V AC input: 110V ~ 220V
Current consumption 800mA
Camera resolution VGA@60Hz
Signal output HDMI 1.2 Video resolution: 1280x720
Network WiFi 802.11b/g/n(2.4GHz)
Operating temperature
0 C ~ 35 °C
Size 13.4 inch x 44.1 inch including ball stopper
Stopper material Aluminum
EXPUTT
camera
Putting
mat

7
Connecting cables
Please connect the video output of the EXPUTT to a display device with a built-in speaker
using the HDMI cable. The EXPUTT camera does not have a speaker.
Installation of EXPUTT camera
The EXPUTT camera, after taking
into account the length of the
HDMI and power cables and the
installation location of the display
device, can either be
attached to the display device
itself or used with a stand.
Please choose the method that
best suits your circumstances.
The length of the tripod
connection rod is adjustable.
2
AC 110V ~ 220V
HDMI
1 2

8
To ensure accurate analysis of
the video image, it is
recommended to install the
EXPUTT camera between 2.3ft
(70cm) and 5.6ft (170cm) from
the floor.
After installing the camera,
check the image and then
position the mat so that the
entire putting mat is included
within the image.
The higher the camera is
installed, the farther the
putting mat should be placed
from the camera (no more
than 5.9ft or 180cm).
The recommended distance from the EXPUTT camera to the beginning of the putting mat
depends on the height at which the body is installed. Please refer to the table below and
place the mat in the appropriate location.
Minimum Maximum
2.3 ~ 3.0 2.0 4.3
3.0 ~ 4.6 2.6 5.9
4.6 ~ 5.6 4.3 5.9
Height of camera (ft)
Horizontal distance available to place mat (ft)
Max. height: 5’6’’
Min. height: 2’3’’
Max. horizontal distance: 5’9’’

9
The putting mat and control keys
Control keys 02, 04, 06 in the Fig. shown above are for right-handed golfers, while control
keys 03, 05, 07 are for left-handed golfers.
Putter sticker and control key input
Stickers need to be attached to the putter face for control key input and accurate detection
of the putter path when putting. Make sure to attach stickers on each end of the putter face
(heel and toe) as shown in the picture below. If no stickers are included in the EXPUTT
package, make sure to use white stickers of a similar size (sticker diameter: 15mm).
If you locate the putter on the printed control key (for 1~2 seconds), the relevant function will
be performed. The control keys are only recognized when the ball is in the Ready zone.
010402 04 06
0503 05 07
Sticker
Sticker
Number Name Description Note
01 Ball ready zone
Area where the ball is placed for putting
02, 03 Hint key
Shows recommended ball speed, angle to hole, &
directional aim distance to hole.
04, 05 Direction key
Used to adjust the putting direction from side to
side.
06, 07
Viewing angle
key
The user's perspective is lowered while the key is
pressed.
Only functions
when the ball is
in the ready zone

10
2. GETTING STARTED
Remote control
01
03
05
08
02
04
07
09
06
Num.
Button
Name
Function
01 Power
Turning the power on or off
02 Mobile
Connecting to the mobile device
03 OK
Selecting the current menu and
function
04 Direction
Navigating the menu or
adjusting the putting direction
05 Explore
Locating ball and hole potion in
green explore mode
06 Mute
Turing the sound off
07 Hint
Seeing a recommended ball speed,
angle to hole & direction aim
distance to hole
08 Menu
Summoning the menu during
practice or game
09 Back
Returning to the menu or
closing the in-game menu

11
Login
You need to log in to the device
to use EXPUTT. Exercise data are
saved and managed for each
logged-in ID, so please use them
after creating an ID through
online membership.
To sign up for membership and
login using ID, WiFi setup must
be completed. Please set up your
WiFi network by selecting the
WiFi icon on the login screen.
WiFi setting
The Fig. on the left shows an
image of the WIFI setup screen.
Select the network you want to
connect to and enter the
password to complete network
setup.
Once connected, the network is
saved and will be automatically
connected the next time it runs.
01
Gray profile Inactive profile, password entry required to log in.
02
Green profile Active profile, no password entry required to log in.
03
Guest Exercise history will not be saved and online features will not available.
04
Create ID Creating a new profile by registering ID and password
05
Delete ID Leaving membership, deleting ID
06
Login Log in by entering ID and password
07
WiFi WiFi setting and status
01 03 04 05 0602 07

12
Creating profile
Left Fig. is the image of the
screen on which a new profile can
be created. Please create a new
profile by entering your ID,
password, nickname, email, etc.
You can also create a profile at
the EXPUTT website.
( www.exputtgolf.com ).
Searching for the putting mat
When you log in to EXPUTT and enter the main menu, the putting mat search is carried out
automatically. Please proceed with the mat search in the following order.
1. Position the mat so that it can
be fully viewed on the image
output screen, as shown in
the picture.
2. If the putting mat is
recognized normally, the mat
area is displayed as green.
3. Press the OK button on the
remote control to finish
setting the putting mat.
When searching for the putting mat, make sure not to place a golf ball, putter, or other
objects on the putting mat.
Make sure to install the putting mat so that it is facing towards the camera.
Do not install the putting mat in places where the lights are too dark or where the mat is
in shadow or in direct sunlight.
If the putting mat is hidden from the camera or the mat is moved while using the
program, the mat search screen is activated automatically. In this case, please search
again according to the above mat search procedure.

13
Connecting to a mobile device
You can use EXPUTT by connecting it with your mobile device (cell phone, tablet, etc.). Please
proceed for the connection with the mobile device in the order shown below.
If the LED on the front flashes red during step 03, it means that the EXPUTT has failed to
connect to the WIFI network. Please connect the main body to the TV and set up the WIFI
first. The configured WIFI network is stored on the machine and automatically connected on
the next run.
Please search and install the EXPUTT mobile app as 'EXPUTT RG' on Play Store (Google)
or App Store (Apple).
The Mobile Connection mode requires EXPUTT and mobile devices to be connected to
the same WIFI network. Please check that the mobile device is connected to the same
WIFI network.
When connected to a mobile device, only the PRACTICE mode in the Classic menu is
enabled.
02
03
05
04
01
green
blue
blue
01
After booting of the EXPUTT, the
LED on the front turns green.
02
With the LED green, press the
mobile button on the remote for 3
seconds.
03
When the EXPUTT enters mobile
mode, the LED on the front flashes
blue.
04
Launch the 'EXPUTTRG' app on
your mobile device
05
When the connection is complete,
the LED on the front stops flashing
and displays blue.

14
3. USING EXPUTT
Main menu
If you shut down the power without logging off, you will remain logged on and will be able
to log in the next time without entering your password.
Personal setting
01
Configuring WIFI network
02
Setting the operating
environment of the profile.
03
Log off. Exiting the main menu
and returning to the login
scene.
04
Classic menu containing
Practice, Challenge and Play9
05
Exploring the green by
choosing a golf course/green
and placing the hole and ball at
the desired position
06
Online multiplay
07
checking announcements,
events, and more.
01
To modify user's password,
email, and more.
02
To delete/initialize exercise
data.
03
Terms and conditions of
online game.
04
Privacy policy
05
To set preferences - size of
hall, distance unit, etc.
04 07 05 01 02 06 03
01 0502 03 04

15
Classic
The Practice mode settings are as
follows:
The Play9 mode settings are as
follows:
The course is the background scene that forms the fields of a golf course. The selected green
is automatically synthesized with the course to create the golf course. You can play games by
selecting carious greens from the golf course scenery you want.
01 02 03
01
Practice: you can practice
your sense of distance on the
flat green.
02
Challenge: you can practice
reading slope and putting
direction depending on the
slope of the green.
03
Play9: up to four players can
play putting game by
selecting a course.
Green speed 7 levels: 8 ~ 14
Practice green Selecting green
Distance mode Fixed, increasing, …
Max. distance 5ft ~ 50ft
Min. distance 5ft ~ 50ft
Slope up/down: -2° ~ 2°
Slant left/right: -2° ~ 2°
Camera mode Fixed, Tracking
Ball trajectory On, Off
Tempo Off, 0.7s ~ 1.4s
Num. of players Max. 4 players (1~4)
Green speed 7 levels: 8 ~ 14
Green Selecting green
Course Selecting course

16
The Challenge mode settings are as
follows:
The Challenge mode proceeds as follows:
(1) Check the slope of the field and putt towards the hole.
(2) In the case of hole-in or concede, the ball moves to the next position on the same
green. If failing on hole-in or concede, try to putt again in the same position.
(3) If succeeding to hole-in or concede three times on the same green, you will move on
to the next green.
(4) Upon completing nine holes on the selected course, the practice session is over.
Multi
The Multi-mode allows you to play putting games with other users online. Please check that
the Expert device is connected to the WIFI network to proceed with the Multi-mode.
Green speed 7 levels: 8 ~ 14
Green Selecting green
Course Selecting course
Camera mode Fixed, Tracking, …
Ball trajectory On, Off
01
Create game: openning a
new game. The user who
opened the game will be the
host of the game.
02
Game list: list of games
currently open. You can
participate by selecting the
game you want.
03
Filter: displayin only the type
of games you want in the list.
04
Refresh: redisplaying the
game list.
05
Server: selecting game server.
01 02 03 04 05

17
If you select the game you want from the list, you can participate in the game. If the game
you want is not on the list, you can be the host and create the game. The options for
creating a game are as follows:
The figure on the left shows the
waiting screen after opening the
game. The participating users
appear on the list.
Once the Start button has been
activated, you can start the game.
Explorer
In the Explorer mode, you can set the locations of the holes and balls on the green of a
selected course.
The Explorer mode settings are as
follows:
Num. of players Max. 4 players (2~4)
Green speed 7 levels: 8 ~ 14
Green Selecting green
Course Selecting course
Password None or 4 digits
Green speed 7 levels: 8 ~ 14
Green Selecting green
Course Selecting course
Camera mode Fixed, Tracking, …
Ball trajectory On, Off

18
The Explorer mode proceeds as
follows:
(1) Choose the green you want to
explore among the nine greens
of the selected course.
(2) The selected green is shown as
a top view. Use the direction
buttons on the remote control
to determine the location of the
ball and press the OK button.
(3) Move the ball to the desired
position and proceed with the
putting.
(4) You can specify new positions
of the hole and the ball by
pressing the Explorer button of
the remote control on the
putting screen.
(5) To re-select the green, press the
Explorer button of the remote
control once again at the top
view scene.
Direction button
Move hall and ball position Explorer button
Reset the position of
holes and balls (at putting scene),
Green re-select (at top-view scene)

19
4. TROUBLESHOOTING
Symptom Cause
The power might be
off
(1) Please check that the adaptor has been
plugged into the socket correctly.
(2) Please check that the adaptor's Micro C-
type plug is connected to the terminal in
EXPUTT camera correctly.
(3)The power supply might have been
switched off. Please check.
Cable may have been
connected incorrectly.
Please connect EXPUTT camera and display
device using HDMI cable correctly.
Power button might
have been pressed
too transiently.
Press the power button until the LED on the
side of EXPUTT camera lights up.
TV's input selection
might be incorrect.
Press input (or external input) button of the
TV/monitor, so that HDMI connected to
EXPUTT is selected.
The ends of the
screen are truncated.
TV's input mode may
have been set to
video.
Please set the screen mode of relevant HDMI
to PC or graphic (name of the setting may
differ depending on different manufacturers).
The edges of the
screen is black/the
screen looks fat.
TV's mode may have
been set to 4:3 or
wide screen.
Adjust TV's menus so that the screen is set to
16:9. Or, set the screen mode to PC/graphic.
EXPUTT might have
been connected to
monitor.
Some monitors might not have speakers.
Please use EXPUTT after connecting it to a
display device with speakers.
The volume might
have been turned off
or is too small.
EXPUTT does not have volume control.
Please check the volume of TV device.
The resolution may
not be correct.
EXPUTT's resolution output is HD (1280x720).
In some TVs, resolution might be
compromised in video scaling process.
The color might not
be what you want.
Adjust the color output of the TV by looking
at the grass and trees in the graphics of
practice/game.
The screen is not
working.
There is no sound.
The quality of the
image is bad.
Solution

20
