USERMANUAL


PM120–PowerMonitor










Introduction
ThankyouforselectingtheExtechPM120PowerMeter.ThePM120
monitorsandrecordspowerusageofhomeandworkappliancesfor
energyconservationandcostreductionanalysis.Thepowermeter
measuresthevoltage,current,power,andpowerfactoraswellastotal
time,cost,andenergy.ThePM120isequippedwithahigh‐precision
currentsensorgivingreal‐timemonitoringofACpowersupplyunits.It
featuresanalarmandpowercut‐offforsafety.
Thisdeviceisshippedfullytestedandcalibratedand,withproperuse,
willprovideyearsofreliableservice.Pleasevisitourwebsite
(www.extech.com)tocheckforthelatestversionandtranslationsofthis
UserManual,ProductUpdates,ProductRegistration,andCustomer
Support.
Features

LargedualLCDmanuallydisplayselectrical,cost,andmetering
functionsinreal‐time.
Electricalsafetytransferfunctionwhenconnectingthisproductto
asocketandthenpluggingtheelectricalapplianceintothis
product.
Over‐currentwarningfunction.
PrimaryLCDshowsvoltage,current,power,powerfactor,or
frequency.
Secondarydisplayshowstotaltime,cost,set,orenergy.
Enterelectriccharge(costsetting)tocalculateanddisplaykWh.
Displaycostofoperationinminute,hour,day,andweek.
Batterybackupstoresdatawhenremovedfromoutlet.
ThreeprongstandardUSplugandfrontsocketforeasyconnection.

SafetyInformation
Toensurethesafeoperationandserviceofthemeter,followthese
instructionsclosely.Failuretoobservewarningscanresultinsevere
injury.
WARNINGS
WARNINGSidentifyhazardousconditionsandactionsthatcould
causeBODILYHARMorDEATH.
Checkthehousingforcracksormissingplasticespecially
surroundingtheplug.Donotuseifanypartofthemeteris
damaged.
Verifythemeter’soperation.Donotuseifthemeterresponds
abnormallyastheinternalstructuremaybedamaged.
UsethemeteronlyasspecifiedinthisUserGuideor
accompanyingQuickStarttoavoidcompromisingtheprotections
providedbythemeter.
Donotexceedtheratedpowerorcurrentofthismeter.
Donotexposethemetertoextremesintemperatureortohigh
humidity.
Keepthismeterawayfromchildren.
Donotusethemeterinthepresenceofexplosivegas,vaporor
dust.
Toreduceriskoffireorelectricshock,donotusethemeterifitis
wetanddonotexposethemetertomoisture.
MeterDescription
1. PrimaryDisplay:See↑M
forfunctions.
2. SecondaryDisplay:See↓M
forfunctions
3. ↓M:Cyclesthrough
secondarydisplayfunctions:
TotalTime,Cost,Energyand
thecorrespondingvaluesof
eachselection.
4. ↑M:Cyclesthrough
primarydisplayfunctions:
Voltage,Current,Power,
PowerFactor,Frequency
andthecorresponding
valuesofeachselection.
5. Applianceoutlet
6. SET:Longpresstosetthe
costin$/kWh
7. +/RESET:Shortpresstoincreasethedigits.Longpressto
resettheEnergyorCostfunctions.Shortpresstowakethe
powermonitorfromsleepmode.
Operation
Measurement
PlugthePM120intoahouseholdsockettobeingmeasuring.The
displaywillpoweronandenterdefaultmeasurementdisplay
(VoltageandTotalTime).

SelecttheMode
Shortpressthe↑Mbuttontoscrollthroughprimarydisplay
functions.ThemeterwillcyclethroughVoltage,Current,
Power,PowerFactorandFrequency.Longpress↑Mtoreturn
todefault‘Voltage’mode.
Shortpressthe↓Mbuttontoscrollthroughsecondary
displayfunctions.ThemeterwillcyclethroughTotalTime,
Cost,andEnergy.Longpress↓Mtoreturntodefault‘Total
Time’mode.
TotalTime
Checkthetimebypressingthe+/RESETbutton.Ifthe
accumulatedtimeislessthan1day,onlyHourandMinwill
display.Iftheaccumulatedtimeexceeds1day,theLCDwillonly
display‘Day’.Toviewthehourandminutedisplay,shortpress
the+/RESETbutton.


TotalTimeinDaysTotalTimeinHour:MinTotalTimesincepowerON

Note:Ifthemeterisabovetheratedcurrent,thedisplaywill
showawarningintheprimarydisplayandOLinthesecondary
display.Bothdisplaysandthepowerlightwillflash.


WarningIconandOverload PowerOFF


1
2
3
4
5
6
7

 2  PM120‐en‐US_V1.08/17
CostSetting
Thepowermonitorcanbeusedtocalculatethecostofelectrical
appliances.
1. Shortpressthe↓Mbuttontoenterthecostmode.
2. LongpresstheSETbuttontosetthe$/kWhpriceofthe
electriccharge.
3. Pressthe+/RESETbuttontoadjusttheamount.
4. PresstheSETbuttontoadvancetothenextdigit.
5. LongpressSETtosavethedataandreturntonormal
operatingmode.
Themetercanbeadjustedfrom0to99.99$/kWhwiththe
defaultconditionbeing1.00$/kWh.

StandbyMode
ThePM120comeswitha3Vbuttoncellbatterytoensuredatais
notlostwhenremovingthemeterfromthepowersource.The
meterwillenterstandbymodeafterapproximately10seconds
ofinactivityafterdisconnectingfromthepowersource.Tobegin
readingdatawhileunpluggedfromasource,pressthe+/RESET
buttontowakethemeter.ReplacethebatteryiftheLCDbegins
flickeringorthereadingsarenolongerstable.
Maintenance
WARNING:Toavoidelectricalshock,disconnectthe
meterfromanycircuitandturnOFFthemeterbefore
openingthecase.Donotoperatewithanopencase.
BatteryReplacement
1. RemovetheonePhillipsheadscrewsthatsecurethe
batterycompartmentatthebackofthemeter.
2. Openthebatterycompartmentandreplacethe3V
buttoncellbatteryobservingcorrectpolarity.Re‐
assemblethemeterbeforeuse.
Safety:Pleasedisposeofbatteriesresponsibly;neverdispose
ofbatteriesinafire,batteriesmayexplodeorleak.Ifthe
meterisnottobeusedfor60daysormore,removethe
batteryandstoreseparately.
Neverdisposeofusedbatteriesorrechargeablebatteriesin
householdwaste.
Specifications
LCD:  50x36mm(1.97x1.41”)
Voltage: 100~150VAC@60Hz
Current:  0~15AAC
Power: 0~1800W
PowerFactor:0~1.00
Energy: 0~9999kWh
TotalCost:0~9999USD($)
Cost/kWh:0~99.99USD($)
TotalTime:0Min~9999Days
Frequency:45Hz~65Hz
Over‐currentWarning: >16.5A
OperatingTemp./Humidity:
0°Cto45°C(32°Fto113°F)/<95%RH
StorageTemp./Humidity:
‐10°Cto60°C(14°Fto140°F)/<95%RH
Dimensions:130x65x37mm(5.1x2.6x1.5)
Weight:155g(5.47oz.)
Altitude:Max2000meters(abovesealevel)
PowerSupply:one(1)3Vbuttoncellbattery(CR2032)
Safety:CE,ETL,CATII150V

