signAl Processors
ASA 304
Quad Active ASA - Audio Summing Amplifier with Captive
Screw Inputs
unique feAtures
•Inputs: Captive screw connectors
ASA 204
Quad Active ASA - Audio Summing Amplifier with RCA Inputs
unique feAtures
•Inputs: Female RCA connectors
common feAtures
• Four, independent active audio summing amplifiers in a single enclosure
• Converts stereo audio to balanced or unbalanced mono audio
• Mono outputs on captive screw connectors
• ± 6 dB output gain switch
• Rack-mountable 1U, quarter rack width metal enclosure
• External universal power supply included, part # 70-055-01 — Provides worldwide
power compatibility.
model Version descriPtion PArt #
ASA 204 RCA Input................................................................................................. 60-552-30
ASA 304 Captive Screw Input..................................................................................... 60-552-20
descriPtion
The Extron ASA 204 and ASA 304 are high performance Audio Summing Amplifiers that
convert two-channel stereo audio signals to balanced/unbalanced mono audio signals. They are
ideal for summing stereo signals for use in mono multi-speaker PA systems in churches, halls,
arenas, stadiums, and other environments where stereo signals would result in cancellation.
The ASA 204 and ASA 304 offer four independent, active audio summing amplifiers in a single
enclosure. They convert stereo audio signals from four different sources into mono audio
signals and include switch-selectable gain to achieve different output gain levels. While the
ASA 204 and ASA 304 offer different input connector configurations to meet specific integration
needs, both provide balanced/unbalanced outputs on captive screw connectors. These high
performance summing amplifiers enable long cable runs and immunity from interference
and noise normally associated with the use of unbalanced audio equipment in professional
integration projects.
Part of the VersaTools®line of products, the ASA 204 and ASA 304 are housed in 1U, quarter
rack width metal enclosures, are easy to install in small spaces, and are rack and under-desk
mountable. They can also be mounted at the projector using Extron's series of PMK - Projector
Mounting Kit products.
oPtionAl Accessories model descriPtion PAGe PArt #
RSU 129 1U 9.5" Deep Universal Rack Shelf Kit .............................................page 819 60-190-01
RSF 123 1U 3.5" Deep VersaTools®Rack Shelf Kit ..........................................page 818 60-190-20
RSB 129 1U 9.5" Deep Basic Rack Shelf .....................................................page 820 60-604-01
RSB 123 1U 3.5" Deep Basic Rack Shelf .....................................................page 818 60-604-20
MBU 123 VersaTools®Mini Under-Desk Mount Kit............................................page 815 70-212-01
PMK 100 One VersaTools®, 1/4 Rack Width Mini Projector Mounting Kit ...................page 813 70-217-01
PMK 300 Multi-Product Projector Mount Kit ..................................................page 813 70-374-01
