Extron electronics UTR 104 FRP User manual

1
IMPORTANT:
IMPORTANT:
Go to www.extron.com for the
complete user guide, installation
instructions, and specifications.
IMPORTANT:
IMPORTANT:
Go to www.extron.com for the
product specifications.
UTR 104 FRP • Installation Guide
The UTR 104 Front and Rear panels provide extra security for the Under
Table Rack by preventing unwanted contact with system products and
cabling. The front panel features a smoked acrylic window to allow visibility
of products for troubleshooting. These panels are also easily removable,
allowing for service access.
NOTE: The UTR 104 FRP can be installed either before or after the main
UTR installation.
Installing the UTR 104 Front and Rear Panels
Side View
1
2
3
4
UTR 104
Front Panel
UTR 104
Rear Panel
1
4
Latch each panel onto its respective
top mounting pegs.
Swing down each panel
onto the bottom mounting pegs.
Insert the eight included #10-32 x 0.25 inch Phillips
truss-head screws into the eight mounting pegs,
located on the vertical rack rails of the UTR 104.
Lock each panel in place with two of the included
#10-32 x 0.25 inch Phillips truss-head screws.
3
2
UTR 104
Front Panel
1
4
Figure 1. Installing the UTR 104 FRP
UTR 108
UTR 104

2
68-3757-51 Rev. A
1 23
For information on safety guidelines, regulatory compliances, EMI/EMF compatibility, accessibility, and related topics, see the
Extron Safety and Regulatory Compliance Guide on the Extron website.
© 2023 Extron — All rights reserved. www.extron.com
All trademarks mentioned are the property of their respective owners.
Worldwide Headquarters: Extron USA West, 1025 E. Ball Road, Anaheim, CA 92805, 800.633.9876
Side View
1
2
3
4
UTR 104
Front Panel
UTR 104
Rear Panel
1
4
Latch each panel onto its respective
top mounting pegs.
Swing down each panel
onto the bottom mounting pegs.
Insert the eight included #10-32 x 0.25 inch Phillips
truss-head screws into the eight mounting pegs,
located on the vertical rack rails of the UTR 104.
Lock each panel in place with two of the included
#10-32 x 0.25 inch Phillips truss-head screws.
3
2
UTR 104
Front Panel
1
4
Figure 2. Securing the UTR FRP
