UTR 104 SP • Installation Guide
The UTR 104 Side Panels provide extra security for the Under Table Rack
by preventing unwanted contact with system products and cabling. These
panels help keep noise at a suitable level for meetings while also providing
a clean and subtle aesthetic.
NOTE: The UTR 104 SP can be installed either before or after the
main UTR installation.
Installing the UTR 104 Side Panels
1
3
4
3
1
1
2
3
4
UTR 104
Side Panel
4
Secure the panels in place with four additional
mounting screws at the top.
Insert four included #10-32 x 0.25 inch Phillips truss-head
screws part way into the base of the UTR 104 frame.
4
Slide each side panel onto the mounting screws
and secure.
Align the top edge of each panel against the UTR 104 frame.
3
3
2
Slide the base panel into the base slot
on the front end of the UTR 104.
Make sure the base panel slides
beneath the six securing screws.
Lock in place with the captive thumb
screw.
Insert the six included #6-32 x 1 inch
Phillips pan-head screws into the base
of the UTR 104 frame.
2
UTR Base Panel
2
Figure 1. Installing the UTR 104 SP
UTR 108
UTR 104

2
68-3757-52 Rev. A
1 23
For information on safety guidelines, regulatory compliances, EMI/EMF compatibility, accessibility, and related topics, see the
Extron Safety and Regulatory Compliance Guide on the Extron website.
© 2023 Extron — All rights reserved. www.extron.com
All trademarks mentioned are the property of their respective owners.
Worldwide Headquarters: Extron USA West, 1025 E. Ball Road, Anaheim, CA 92805, 800.633.9876
1
3
4
3
1
1
2
3
4
UTR 104
Side Panel
4
Secure the panels in place with four additional
mounting screws at the top.
Insert four included #10-32 x 0.25 inch Phillips truss-head
screws part way into the base of the UTR 104 frame.
4
Slide each side panel onto the mounting screws
and secure.
Align the top edge of each panel against the UTR 104 frame.
3
3
2
Slide the base panel into the base slot
on the front end of the UTR 104.
Make sure the base panel slides
beneath the six securing screws.
Lock in place with the captive thumb
screw.
Insert the six included #6-32 x 1 inch
Phillips pan-head screws into the base
of the UTR 104 frame.
2
UTR Base Panel
2
Figure 2. Securing the UTR 104 SP
