Eyecar M1 User manual

User Manual
(Ver 1.0 EG)
CAR Black Box System
M1
This manual should be read before the product is activated.
For Safety purposes, users are advised to correctly operate
the product according to this manual

16
Notice for safety
04
Package contents
06
Name of each Part
07
Specification
08
Installing Instructions
09
• Button, LED, Voice guide
• Operation Function
• Preparation Recording
• Video Recording and Playing
• Using SD CARD
• Format in the condition of SD Card Error
• Update lnstruction
• Voice Recording Setting
• Manual Event Recording
Function of each part
11
Product overview
03
Explanation of player
22
Q&A
24
World Time Zone
25
Warranty Card
• Full screen of player
• play data
• Original Size image
• Link with MAP
• Analysis for G-SENSOR Data
• Print and storing of screen, verification of Version
• Conversion of Speedometer
• Setting
Contents


Product overview
This product is auxiliary system which helps to analyze the cause of vehicle accident with video and
voice recording, GPS location information while driving.

│Continuous Recording│
The product constantly stores video and audio data in driving on a SD CARD. When the amount of
recorded data exceeds the capacity of the SD MEMORY, the oldest files get overwritten.
│Event Recording│
If the impluse sensed by the G-sensor exceeds a specific limit or the user presses the emergency recording
button△,2 minutes video file which is recorded 30 seconds before and after event stored and transferred to
the EVENT folder automatically.
The User can play recorded video data and information with using the software provided with the product and
analyze velocity, coordinates, time and GPS location easily.
Recorded video file can be played at 640 X 480 (VGA) resolution.
│Video and Voice data Playing and Analyzing│
It is possible to set voice recording On/Off for protection of user privacy.
│Voice recording control│

Notice for safety

This chapter contains the information on preventing property damage and inconvenience. It should be read
before product activation, and users should be correctly operate the product based on the instructions stated below.
1. Do not use water or volatile chemicals when cleaning the inside of the car or the product.
This increases the risk of product damage, fire, and electric shock.
2. Avoid causing the product severe impact and immersing it in a foreign substance. This increases the risk of
product damage, fire and electric shock.
3. Refer all servicing to qualified service personnel. We take no responsibility for any damage or problems caused
by arbitrarily repairing or modifying the product.
4. Only in normal conditions can the user obtain proper video image. If the user is in a tunnel or is driving
at night video recording cannot work properly. Intense backlights also affect the image quality of the video.
5. Window tinting can also affect video quality. Users should check the recorded imagery before operating
the product, if their cars have tinted windows.
6. Do not relocate the product arbitrarily. This may cause GPS communication error.

Notice for safety
7. Do not manipulate or stare at the product while driving. This increases the risk of automobile accidents.
8. Secure clear vision for camera. Contact with foreign materials or covering of the lens may cause abnormal
video recording.
9. Only use the cable provided and automobile electric power, as instructed.
If not, this may cause product damage, fire, and electric shock.
10. Do not cover the product when using other electric devices. This may cause GPS communication failure.
11. When the cable is damaged by an accident, replace the electric power cable with a new one.
When the product malfunctions or smoke is detected, stop using the product immediately and consult service
personnel through the agency.
12. Remove dust in the cigar lighter socket periodically, for it may result in a fire hazard.
Check frequently whether the productis installed firmly.



This manual should be read before the product is activated.
For Safety purposes, users are advised to correctly operate
the product according to this manual
User Manual
(Ver1.0EG)
CAR Black Box System
M1
Package contents
│Optional Accessories (Sold separately)│
1. External Monitor connecting cable
2. Connecting cable for constant power supply
3. Subsidiary Battery for constant power supply
(4,000mA, 8000mA)
Basic Components
Cradle SD CARDInstalling
Supplements
PDF Manual
- Please contact sales representative or dealer for purchasing
the optional accessories.
- The optional accessories can be changed by the situation
of company.
Body Power Cable

Name of each Part








Video out port
Front View Camera
Power
connector
port
Inner speaker
SD Card
Slot
Cradle socket

3 Colors LED
Operating Buttons
ObserveR

ITEM SPECIFICATION
Camera
Resolution
Event
Recording
Video
Quality
Driving Mode
Auto
1.3M Pixel
Voice Recording
GPS

- “SanDisk” is the most compatible SD CARD for the product.
SD CARD compatible with the product can be allowed,
but using different SD CARD may result in product malfuction.
In such cases, the user responsible for the problems
- There can be error of saving time according to external
environmental and the image condition which is stored.
SD Card Capacity
2GB
4GB
8GB
16GB
32GB
Constant Recording
90min.
180min.
360min.
720min.
1440min.
Event Recording
30 min.
60 min.
120 min.
240 min.
480 min.

│Specification│ │Saving Time│
640 x 480
High
LowParking Mode
Video
Voice Guiding
Manual
Storage
Power
Internal Mic
Internal Speaker
G-Sensor (3 Axis)
EMR Buttion (△)
SIRF-III
SD CARD (1~32GB)
DC12V~DC24V
MAX 20fps

Install after turning the engine off. Locate the product where GPS signals are received well.
Secure a clear vision for the front camera, where it is not covered by the hood.
Adjust the angle of the body to secure horizontal and vertical positioning.
1. Avoid installing the product on a heating line.
It may cause damage to the heating line when
demounted.
2. Remove foreign substances from the attaching
area and dust cleary with a dried cloth before
attaching the product
Installing Instructions

│Install as instructed│
- Please be prudent to control angle of mount cradle. If you inflict
a unresonable force, cradle can be damaged

Installing Instructions
Remove all foreign materials
on the window where the
product will be attached to.

Connect the power cable plug
to the cigarette lighter socket.

Mounted on holder like
a drawing to the body.

Power cable to the passenger
(or driver) in the direction of
put cleaned.

After connecting the cable to
the body’s right side with the
power cable, pull out the cable
upward.

After in order for the holder’s
direction does toward a down,
securely attach the product with
adhering closely to the glass
window.

Be sure the power light is ON. When starting
up the eigine. If power light does not light
up, check the connection between parts.
Remove dust or foreign substances near the
cigarette lighter socket.
│Check installation│


Function of each part

Front Camera
Front view camera should be fixed horizontally. Periodically clean the lens for clear video image.
Use a soft cloth to clean the lens in order to avoid lens damage
SD CARD
Disconnect the power cable or turn off the engine, before inserting or removing the SD CARD.
When using an SD CARD that was not supplied with the product, the user should format it as FAT32,
download and copy the provided program on it, and set the TIME ZONE in PLAYER setting menu
Indicate LED
• Violet LED Light : The first Power Supplying, Shut off Power Supplying
• Blue LED Light : Constant recording in the condition of receving stable GPS signals
• Blue LED Blinking : Constant recording in the condition of receving instable GPS signals
• RED LED Light : Emergency recording • RED LED Blinking : Error
UP(+) / DOWN(-) / EMERGENCY (△) Button
Use these buttons for setting each function.
POWER Connection and A/V OUT Port
- A/V OUT : It is possble to check real time image by connecting product with external monitor.
- Power input : By connecting the provided power cable to the cigarette lighter socket, the product is supplied
with electric power
* When the provided power cable is lost or damaged, do not use unqualified power cables.
Make sure to immediately contact the service agency. Using unqualified cables may cause fatal damage to the product.
│Button, LED, Voice guide│

│Operation Function│
Function of each part
 Operation Function can be changed by updated specification

POWER ON
Before receiving GPS signal
After receiving GPS signal
POWER OFF
SD CARD MISSING
SD CARD ERROR
User format
SD CARD
Voice Recording OFF
Voice Recording ON
F/W upgrade
Volume control
Emergency recording
N/A
N/A
N/A
N/A
N/A
N/A
Pressing (△) button for more than 3 seconds when turn on product
 Button
(+) Button
Pressing a (+) Button for more than 3 seconds
Pressing a (+) Button for more than 3 seconds
If SD CARD has a New update file
(bsac.bin, mcode.bin)
upgrade is proceeded automatically
UP(+), DOWN(-) Button 3 step (1second)
N/A( G-sensor working)
Pressing
(△) Button for 1 second
Starting CAR DVR
N/A
GPS data is succefully transmitted
Stoping the CAR DVR
Please insert SD memory card
Unable to read SD memory card
Do you want to format SD memory card?
SD memory card will be formatted
SD memory card will not be formatted
Voice recording stopped (After beep sound twice)
Voice recording started (After beep sound twice)
Update mode
(Beep sound once)
N/A
N/A
Violet LED Lighting
Blue LED Light Blinking(Recording Mode)
Blue LED Lighting (Recording Mode)
Violet LED Lighting
RED LED LightingAlert status
RED LED LightingAlert status
RED LED LightingAlert status
RED LED LightingReboot
RED LED LightingReboot
Violet LED BlinkingRecording mode
Violet LED BlinkingRecordinf mode
RED LED BlinkingReboot
Recording Mode
RED LED BlinkingRecording Mode
RED LED BlinkingRecording Mode
STATUS BUTTON Voice Guide (One Tone Guide)LED

1. If the power cable is connected, after inserting SD CARD in the body, the violet LED lights.
2. Video Recording starts with “Starting CAR DVR” voice guide after connecting the power cable.
3. GPS receiving starts after blue LED Lights ON with “GPS data is successfully transmitted” voice guide.
Function of each part

│Preparation Recording│
1. When the amount of recorded data exceeds the capacity of the SD memory during constant and
event recording, the oldest files get overwritten.
2. If the impluse sensed by G-Sensor exceeds a specific limit or the user presses the emergency button(△),
the 2 minutes video file which is recorded 30 seconds before and after event stored and the tranferred to
the EVENT folder.
3. When the user turns off the engine or disconnects the power cable from the cigarette lighter socket, violet LED
lights and product is off. After the Violet LED is out, remove the SD card from the body. Unless the instructions
above are not observed, the problem on storing video image may happen
4.Connect the SD card to a PC, using the memory card reader. The user can then play the stored video file
with the normal muti-media program or exclusive program embedded in the SD card.
The user can check not only image data but find impact and location information through exclusive viewer
program.
│Video Recording and Playing│
 We recommend to use a USB reader that supports SDHC2.0

Do not use the SD CARD supplied with the product for any other purpose. If the SD CARD is used for another purpose
or other files are stored on it, fatal errors may be caused. SD CARDs compatible with the product can be allowed,
but using different SD CARD may result in product malfunction. In such cases, the user is responsible for the problems.
“SanDISK” is the most compatible SD CARD for the product.
Function of each part
│Using SD CARD│
1. When hear voice guiding “Unable to read SD memory card”with RED LED blinking, Format SD Card with
pressing (△) button. After format is completed, rebooting will be occured.
2. Inspection for the SD Card is needed when errors occur even after rebooting.
3. If hear voice guiding “Unable to read SD memory card”, Please check hold key (Lock button) of SD CARD , too.
1. If SDHC 2.0 is not compatible with the PC, use a separate USB reader that supports SDHC 2.0
2. Periodically format the SD CARD in order to prevent errors and to use it for a ling time.(Recommendation : 1 time per 15days)
3. Configure SD card after formating, or else the initial loading may take a long time, and the time on the stored
video file and the actual time zone may differ.
4. When user turn on the product with pressing (△) button for more than 3 seconds, user can get voice guiding
“Do you want to foramt SD Card ?” In this case.
- Press (-) button : Format SD Card with voice guiding “SD memory card will be formatted”
- Press (+) button : Do not format SD Card with voice guiding “SD Card will not be formatted”
5. In the condition of formatting SD Card, All data which is stored will be deleted. So, Please back up data definately which user need.
│Format in the condition of SD Card Error│


1. Firmware Update
- Store bsac.bin , mcode.bin (New version) at the top-level directory of SD CARD.
After inserting SD CARD and turn on the product, RED LED will be light.
And then, product will reboot after voice guiding “Update mode”and putting out LED light.
2. PC player Update
- Store new version of player (player.exe, config.sys) at the top-level directory of SD CARD. Insert SD CARD
into the product, turn on the product by pressing (+) Button. Update will be proceeded with voice guiding
“update mode” and RED LED light.After finishing Update, product will be reboot with putting out LED light.
Function of each part

│Update Instructions│
1. Voice recording ON : In the condition of Voice recording OFF, Press (+) Button for more than 3 seconds,
Voice recording start with voice guiding after beep sound twice
2. Voice recording OFF : In the condition of Voice recording ON, Press (+) Button for more than 3 seconds,
Voice recording stop with voice guiding after beep sound twice.
│Voice Recording Setting│- Default setting is Voice recording OFF mode
If user press EMR buttion for 1 second, the 2 minutes data which is storing will be transfered & stored to the
EVENT folder automatically
│Manual Event Recoding│
- Do not remove the power cable and do not turn the engine Off. Power Off during the update process may cause fatal error.







1.Connect SD card with PC using memory card reader.
2.Select the removable disk that is recognized as SD memory.
3.Double click PLAYER.EXE, then the screen below will appear on the monitor screen.
Explanation of Player
│Full screen of player│

Camera Display

GPS MAP

Function Icon

Volume, Play speed control

File list

G-sensor Impulse Graph

Speed, Direction


File Open : Open file which user want to check.
Select Dir : Open folder which user want to check.
Delete All : Delete all files list on the Play List
Type : Type of recorded data.
( Constant Recording, Event Recording, Recorded data by pressing △ Button,
Parking Mode Recording)
Date : Indicate Date and Time of recorded data
File Name : File name of recorded data.
Division
of Data
File order Year/Month/Date Hour/Minute/Second
Double click data which is played on Player,
Original Size(640 X 480) will be showed
  


더블클릭
1. Select the folder by click [Select Dir] button of the middle of player.
Data is stored on Movie folder of applicable SD CARD
2. Double click the file, Image will be played
Explanation of Player

│Play data│
│Original Size image│
Double
Click

It is possible to be linked with MAP in the time
of being conntected internet.
It is impossible to be linked with MAP for DATA
which was recorded not getting GPS receiving.
The linking time with MAP can be delayed by
speed of internet condition.
[G-sensor Graph]
Click button, MAP will be showed and User can check driving routes with GPS location information.
Explanation of Player
│Link with MAP)│
G-sensor check 3-Axis data (X,Y,Z axis) and indicate those data as
graphing at Player. It is possible to analyze driving conditions and
habits of driver. The changing of graph curve can be differ by type
of vehicle and situation of the road surface.
│Analysis for G-SENSOR Data │


Double click Speedometer in the down part of right side of player,
two type of speed unit is available.
1. Click button in the middle of player,
It is possible to print or store screen image.
2. Click buttion in the middle of player,
It is possible to verify the version of player.
Explanation of Player

│Print and storing of screen, verification of Version│
│Conversion of Speedometer│
Double
Click

Pressing button in the middle of player, User can print or store data which is playing.
 


Explanation of Player
│Setting│


