Ez one shot Bar code scanner User manual

Default

CHECK VERSION

Version: MAR20041021

DEFAULT

BAR CODE

SCANNER

USER'S

MANUAL

Ez One Shot

CONTENTS

GENERAL

Table of contents

-------

Introduction, Ez Troubleshooting

-------

2-3

Cloning Mode

-------

4-5

Getting Started

How to fix the scanner to the terminal

-------

6-9

How to change a cable

-------

How to set up the parameter

-------

SETTING GROUP

1 Interfaces selection, Computer type, Default

-------

2 Reading Mode

-------

3Check Version, Beep tone, Caplock Mode

-------

4Preamble and postamble

-------

5Accuracy adjustment

-------

6Enable and Disable Code ID

-------

7 Symbologies Code Identifier,

-------

8~9 Set Code ID, Customer Configuration

-------

18-

10 Delay between block and character

-------

11 Terminator & keyboard layout

-------

12 RS232: Baud rate, Data bits & parity

-------

13 RS232: Stop bit, handshaking, ACK/NAK,

Flow Control

-------

14 Wand Emulation parameter setting

-------

SYMBOLOGY

FORMATTING

( GROUP 15~31)

15 Enable Barcode Symbology

-------

16 Disable Barcode Symbology

-------

17 China post code ( Toshiba code), Code 32

-------

18 UK Plessy code, MSI code

-------

19 Code IATA, Code93, Telepen

-------

20 Interleaved 2 of 5, Code 11

-------

21 Codabar

-------

22 ABC Codabar, CX Codabar,

-------

23 Codabar Coupling

-------

24 Code 128, Standard Code 39, Full ASCII code

-------

25 Industrial 2 of 5, Matrix 2 of 5

-------

26 UPC-E

-------

27 UPC-E(0) &(1), UPC-E&UPC-A Expand

-------

28 UPC-A

-------

29 EAN-8

-------

30 EAN-13

-------

31 EAN/UCC 128, ISSN, ISBN

-------

FULL ASCII (CODE 39 ) TABLE,

FUNCTION CODE TABLE

32~39Full ASCII table ( Code 39)

-------

50-57

40 Numeric table

-------

41~42Function code table (Code 39) for PC- AT

-------

59-60

43~46Trouble Shooting

-------

61-63

APPENDIX- A

Default

-------

Cable pinout

-------

67-68

GENERAL

INTRODUCTION

This scanner apply with Ez one shot easy programming decoder, It is

specially designed to deliver high-end bar code reading performance

at the lowest possible price. The scanner utilizes exceptional decoding

technology. One-time settings are easily made by scanning set-up bar

codes in this handy user's manual. This bar code scanner uses CCD or

optical diode technology which does not have moving part, provide

ragged reliable quality, enables it suit for any harsh environment

conditions. Furthermore, the LED illumination light source of scanner

provides less harmful beam to human eyes, and more longer product

lifetime.

Notes: ( Please contact your distributor for the detail model number.)

The Ez One shot decoder are mainly apply to the following

categories bar code scanner for your reference:

1. Short Range- The reading distance is about from contact to 100mm,

2. Mid Range- The reading distance is about from contact to180mm,

3. Long Range - The reading distance is about from 5mm to 300mm,

4. Wand or Pen bar code scanner.

5. Scan Engine and Fixed Mount scanner .

This scanner has many settings that can be used to conform the

unit to the requirements of a particular application. For most usages,

however,the default settings programmed into the unit at the factory

are appropriate.It is not recommended that the default settings be

changed unless thereis a specific need to alter the characteristics of

the scanner's performance.

The scanner is easy to install and use. Many problems encountered

can be attributed to a wrong setting that has been programmed into

the scanner. Before troubleshooting the problem, try this:

1. Unplug the cable from the host computer.

2. Plug the cable back into the host computer.

3. Reset the scanner settings to DEFAULT (Group 1).

If these steps do not resolve the problem, please refer to the

troubleshooting table on the next page. If this fails to correct the

problem, please consult the troubleshooting section beginning on

page 61~63 for further assistance.

EZ TROUBLESHOOTING

. A001$

CLONING MODE

.A018$( Cloning Mode on PC/AT) - you can clone the settings to a PC/AT

regardless what kind of device has been chosen on the scanner

. A016$

CLONING MODE

. A018$

CLONING MODE ON- PC/AT

Figure 1

* Format of Cloning :

1st rows >>> ".A017$" ( never edit any data of the first row )

2nd rows >>> "....XXXX" you can adjust the String's Length starting

from the dots"...." forward. The length of the string should

be in 4, 8,12,16 or 20 ( MAX )digits.

3rd rows~ so on >>> XXXX

End rows- A dot "." Is an ending of cloning.

XXXX Stand for any String

FORMAT OF CLONINGFORMAT OF CLONING

NOTES:

WHAT IS CLONING MODE?

HOW SHOULD CLONING WORK?

CLONING duplicates a wand's settings in other wands. It can save time

when a number of wands must be programmed to the same settings.

1. Using this guide, make all the necessary settings for one wand.

2. Scan the CLONING MODE bar code shown below.

3. When CLONING MODE is scanned, all setup parameters will be

converted to alphanumeric characters and shown on the monitor.

4. Using a bar code printer, print out all the setup parameters as

Code 39 bar code labels.

5. Scan the printed labels sequentially with each wand to be

programmed.

1. All cloning strings are upper case.

2. All cloning strings printed on labels should be the same as those on

the monitor sequentially from first to last.

3. Cloning mode works in Word Note Pad only.

4. Never edit the data on the first row (.A017$). It is an entry gate for

cloning.

5. The cloning string's length can be adjusted by combining multiple

strings into one, or by breaking one string to multiple strings starting

from the second row after "....". Length must be in sequences of four,

such as 4,8,12,16,20 (MAX).

6. Be sure to print the dots exactly where they are shown on the monitor.

HOW TO CHANGE A CABLE

The CCD scanner are designed to switch easily between interface options.

To switch from one interface to another, the appropriate cable must be

installed. To change a cable, simply follow these steps:

1.To release the cable, insert a pin or straightened paper clip into the

hole at the base of the scanner where the cable is connected.

2. Remove the cable from the scanner.

3. Plug in the new cable.

After changing to a new cable, be sure to resetthe interface setting as

appropriate (including parameter settings for the RS-232 interface).

New Cable

Present cable

New Cable

Present cable

USB INTERFACES

The USB Interface supported is compatible with the Apple MAC series,

later PCs and Windows 98, 2000, Me, and XP.

1. Connect the USB cable between the scanner and the computer.

2. The scanner will beep.

3. The Scanner will detect the USB driver automatically. (The first time

the scanner is connected via the USB port, follow the appropriate

instructions for the host computer.)

4. Set the scanner to KEYBOARD/USB interface by referring to

GROUP-1 (Interface Selections).

5. Scanner will beep to confirm the setting.

6. Scan a bar code to confirm that data shows on the monitor.

How do you program a scanner with this user's

guide?

RESET

. P023$

HOW TO SET PARAMETERS

1. Use the scanner to scan at the bar code representing the function/

parameter you want to set.

2. When you hear two beeps, the new setting will have been defined

or updated into the memory processor.

Default parameters are indicated in bold type and underlined

characters. The character font is ARIAL BLACK. CD = Check Digit.

CDV = Check Digit Verification.

Most settings require only a single bar code, but a few need several

different bar codes to be scanned in order to completely define a

setting. They are:

Preamble / Postamble (maximum 16 digits)

MinLength/MaxLength

Accuracy Adjustment

Customer Configuration ID ( Example: Code 39 )

Set A Data - ( CX-Codabar, ABC Codabar, Codabar Coupling).

Step 1: Scan CLR PRE/POSTAMBLE.

Step 2: Scan PREAMBLE or POSTAMBLE..

Step 3: Scan any alphanumeric from Full ASCII Table in Groups 32 - 40.

Step 4: Scan PREAMBLE or POSTAMBLE.

Step 1: Scan MIN LENGTH or MAX LENGTH.

Step 2: Scan two digits from Appendix 1.

Step 3: Scan MIN LENGTH or MAX LENGTH

Step1: Scan ACCURACY ADJUSTMENT.

Scan one digit from Appendix 1.

Scan ACCURACY ADJUSTMENT.

Scan CODE 39 SET ID from Group 8.

Scan either one digits or two digits alphanumeric (maximum 2 digits)

from Full ASCII table In Groups 32 - 40.

Scan CODE 39 SET ID from Group 8.

Scan SET A DATA.

Scan one digits any alphanumeric character from Full ASCII Table in

Groups 32 - 40.

Scan SET A DATA.

Step 2:

Step 3:

Step 1:

Step 2:

Step 3:

Step1:

Step 2:

Step 3:

NOTES:

1. The scanner will beep three times as a reminder that a setting is

not yet complete.

2. If you make a mistake, forget a step, etc., scan CLEAR to start

again.

SETTING BAR CODE

. A001$

COMPUTER TYPE

. C007$

NOTEBOOK*

MAC ADB

PC- AT

GROUP-1

INTERFACES SELECTION, COMPUTER TYPE, DEFAULT.

. C001$

KEYBOARD& USB

. C003$

WAND

. C008$

RS485

. C002$

RS232

INTERFACES SELECTION

DEFAULT

Caution: This scanner is designed to switch easily between interface

options. To switch from one interface to another, the appropriate

cable must be installed. After changing to a new cable, be sure

to reset the interface setting as appropriate.

. C006$

. C004$

SYMPTOMS SOLUTION

Scanner seems to be

performing as usual,

but no data is being

output.

1. Unplug the cable from the host computer.

2. Plug the cable back into the host computer.

3. Set the scanner to the exact computer type

immediately.

SOLUTION

SYMPTOM

Thewanddoesnot

scan/ The scanner

does not scan when

the trigger is

depressed.

1. Unplug the cable from the host computer.

2. Plug the cable back into the host computer.

3. Set the wand to the correct interface. The

cable needs to match the interface.

Caution:Please ensure the correct computer type is set when the

scanner is attached to a new host computer. If set to Notebook, the

scanner will operate with no external keyboard.

. A012$

. A013$

. A011$

. A010$

. P023$

RESET

. A014$

. A008$

. A015$

. A009$

4 563987 123453 11421

145287

Preamble

145287

CODE ID

AIM ID : ]E0

BARCODE / DATA

EAN 13 +5

]E0

OUTPUT : 145287]E0456398712345312411

SYMBOLOGIES Factory

AIM

ID SYMBOLOGIES Factory

AIM

SYMBOLOGIES CODE ID IDENTIFIER, SET ID

SYMBOLOGIES CODE ID IDENTIFIER

GROUP-7
