Ezetai E9-4K User manual

Model:E9-4K
User's manual

IF YOU HAVE ANY QUESTIONS OR PROBLEMS.
Please contact us by
[e-mail]
we will offer prompt and authoritave reply within
24hrs,and try our best to resolve your problem
asap as soon as possible.
lf you are not sasfied with product.Please tell us
about your thought. That will be much appreciated.
AMZ store:EZETAI Security services
Company website:hps://ezetai.vip
Facebook:Ezetai Trail & Game Camera
EN

PACKAGE LISTING ...............................1
PRODUCT DIAGRAM..............................2
CAMERA PARAMETER...........................3
QUICK START GUIDE.............................4
BUTTON FUNCTIONS.............................5
SETTING FUNCTIONS.............................7
IINSTALL ATIO.........................................11
IMPORTANT INSTRUCTIONS.................14
QUESTIONS & ANSWERS...................... 15
WARRANTY AND SERVICE.....................17
CONTENTS EN

4K trail camera *1
Installaon Belt *1
Micro USB Cable *1
Stand Mount *1
Bolts & Stoppers *3
User Manual*1
PACKAGE LISTING
32GB TF card *1
1
EN

PRODUCT DIAGRAM
1. Lens 2. Infrared LEDs
3. PIR moon sensor 4. LCD screen
5. Menu buon 6. Replay buon
7. Navigaon buons 8. Shot buon
9. OK buon 10. TF card slot
11. USB slot 12. Mode switch
13. Fixaon port 14.Power supply port
15. Baery cover
1
2
7
4
5 8
9
15
10 11 12
14 13
6
3
2
EN

CAMERA PARAMETER
PhotoResoluon 5MP/8MP/12MP /16MP /20MP /32MP
VideoResoluon 480P /720P /1080P /1520P /2160P(4K
DeteconAngle Upto120°
FillLightLEDWavelength940nm(No Glow)
FillLightLEDQuanty 40PCS
TriggerTime0.2s- 0.5s
Waterproof Level IP66
WorkingTemperature -4°F- 160°F
Memory Card Type Upto256G TF Card (Class 10)
PowerSupply Type Baery /Externalpowersupply
Baery Type AABaery(4or8)
WorkingVoltage6V
ExternalPowerSupply DC6V 1.5A,3.5*1.35mm
Standby TimeUpto6Months(Only beachievedif the
power
Photo Format JPEG
）
3
EN

QUICK START GUIDE
Please refer to the instrucons below for a quick start .
We hope you can know the mode below before trying to use .
Power switch mode
OFF-TEST-ON
15
4
Aer inserng the baery and Micro SD card, the camera is
ready to work! All you need to do is select one of its posions
and switch it "ON" to ON by seng the operang mode, then
the display will show a "15s" countdown.
4/8*AA
Baery
Open the baery compartment waterproof cover and insert
4/8 AA alkaline dry baeries.
Open
15
AALR6 AALR6
AALR6
AALR6
AALR6
AALR6 AALR6
AALR6
EN

BUTTON FUNCTIONS
①【MENU】Press to open or close the setup menu / replay menu.
In Replay mode (video): Stop video
②【REPLAY】
Press to preview photos and videos on the LCD screen.
③【↑】 Cursor moves to previous item.
(In TEST mode) Switch current tests funcon to video funcon.
(In REPLAY mode) View next photo or video.
④【↓】 Cursor moves to the next item.
(In TEST mode) Switch current tests funcon to photo funcon.
(In REPLAY mode) View previous photo or video.
⑤【←】
Oen used to move to the le when zooming in on a photo.
⑥【→】 Oen used to move to the right when zooming in on a photo.
⑦【SHOT】:
In TEST mode: Take a photo or record a video manually.
In REPLAY mode (photo): Press and hold to zoom in.
⑧【OK】:
In Menu: Confirm/Enter
In Replay mode (photo): Press and hold to zoom out.
In Replay mode (video): Start or pause to replay.
5
EN

Image / Data Output
Connect to your computer to download photos/videos
●Aer the camera is connected to the computer and enters the
removable disk mode, a removable disk will be added in the "My
Computer" window.
Taken photos or videos will be stored in the "DCIM\100MEDIA"
directory on the removable disk. You can enter this directory to copy
files to your computer hard disk.
6
EN

Mode
Photo resolution
Photo series
Video resolution
TL video resolution
Video length
Mode
Photo resolution
Photo series
Video resolution
TL video resolution
Video length
SETTING FUNCTIONS
7
Setting
Mode
Photo resolution
Photo series
Video resolution
TL video resolution
Video length
Setting
【Mode】 You can specify one of three operang modes for E9-4K.
Photos (Default): E9-4K only take photos, not record videos.
Videos: E9-4K only record videos, not take photos.
Photos & Videos: E9-4K will take a photo, record a video, take
a photo,record a video, and so on.
Setting Setting
32MP(7680*4320P)
20MP(6144*3456P)
16MP(5376*3024P)
12MP(4608*2592P)
8MP(3840*2160P)
5MP(3072*1728P)
【Photo Resoluon】 You can choose different photo resoluons.
32MP/20MP/16MP12MP/8MP/ 5MP (Default)
Setting
Mode
Photo resolution
Photo series
Video resolution
TL video resolution
Video length
【Photo Series】How many photos you want to take in one shoong.
1 photo (Default)/2/3/10 photos in series.
Setting
Mode
Photo resolution
Photo series
Video resolution
TL video resolution
Video length
1 photo (default)
2 photos in series
3 photos in series
10 photos in series
Video
Photo & Video
Mode
Photo resolution
Photo series
Video resolution
TL video resolution
Video length

8
Mode
Photo resolution
Photo series
Video resolution
TL video resolution
Video length
Mode
Photo resolution
Photo series
Video resolution
TL video resolution
Video length
3840*2160P
2688*1520P 20FPS
1920*1080P
1280*720P
720*480P
【Video Resoluon】 You can choose different video resoluons.
3840*2160P/2688*1520P/1920* 1080P/1280*720P (Default) /
720* 480P/640*480P
Mode
Photo resolution
Photo series
Video resolution
TL video resolution
Video length
Mode
Photo resolution
Photo series
Video resolution
TL video resolution
Video length
8MP(3840*2160P)
5MP(3072*1728P)
3MP(2304*1296P)
【TL Video Resoluon】You can choose different Time-Lapse video
resoluons.
8MP (3840* 2160P)/5MP (3072*1728P)/3MP (2304* 1296P)
Mode
Photo resolution
Photo series
Video resolution
TL video resolution
Video length
Mode
Photo resolution
Photo series
Video resolution
TL video resolution
Video length
10 second
【Video Length】 Adjust individual video lengths.
3 seconds (Min.)/10 seconds (Default)/10 minutes (Max.)
Setting
Setting
Setting Setting
Setting
Setting

Setting
Audio recoding
Shot lag
Sensitivity motion sensor
Target recording time
Time lapse
Setting
Audio recoding
Shot lag
Sensitivity motion sensor
Target recording time
Time lapse
【Shot Lag】The interval between each trigger
2 seconds (Min) | 30 seconds (Default) | 60 minutes (Max)
Setting
Audio recoding
Shot lag
Sensitivity motion sensor
Target recording time
Time lapse
Setting
Audio recoding
Shot lag
Sensitivity motion sensor
Target recording time
Time lapse
Low
Middle
Hight
【Sensivity Moon Sensors】Adjust the sensivity of moon sensor.
Low /Middle (Default)/High
Audio recoding
Shot lag
Sensitivity motion sensor
Target recording time
Time lapse
Setting
Audio recoding
Shot lag
Sensitivity motion sensor
Target recording time
Time lapse
Set
target recording time
start stop
Hr:Min Hr:Min
00 00 00 00
Setting
【Target Recording Time】Want to set E9-4K to work in a certain period?
Off (Default)
On >E9-4K will ask you to set the work me period.
(Requires entry of military me)
Sample: Start:2100 / Stop: 0600. E9-4K only work from PM 9:00 to AM 6:00.
9
30 second

10
Audio recoding
Shot lag
Sensitivity motion sensor
Target recording time
Time lapse
Audio recoding
Shot lag
Sensitivity motion sensor
Target recording time
Time lapse
Normal
TL video
Off
Audio recoding
Shot lag
Sensitivity motion sensor
Target recording time
Time lapse
Set time lapse
Hr：Min：Sec
00 00 30
Notification:Motion
sensors deactivated
Audio recoding
Shot lag
Sensitivity motion sensor
Target recording time
Time lapse
Normal
TL video
Off
Audio recoding
Shot lag
Sensitivity motion sensor
Target recording time
Time lapse
Normal
TL video
Off
Audio recoding
Shot lag
Sensitivity motion sensor
Target recording time
Time lapse
Set time lapse
Hr：Min：Sec
00 00 30
Notification:Motion
sensors deactivated
Setting Setting
【Time Lapse】Change the camera from moon detecon mode to
interval photo mode.
Off. (Default)/Normal/TL video
Setting Setting
Normal→E9-4K will ask you to set the Interval me.
Sample: 20 seconds.
E9-4K will be take photo or record video per 20 seconds
Setting Setting
TL video→E9-4K will ask you to set the Interval me.
Similar with TL normal mode, but will automacally stch the photos
taken per 20 seconds into a video.
Note: IR will stop working when Time Lapse is turned on. You can also
bring E9-4K back into moon detecon mode by turning off Time Lapse.

INSTALLATION
If you walnt to put the camera on the wall, the Fixaon Kit is
ready for you:
1. Mark the installaon posion with the help of the metal plate
and make holes in the wall;
2. Put the green components in the holes;
11
EN

3. Fix the Fixaon Kit by following the picture.
4. Put the camera at the posion you have chosen and fix the
camera with screws.
If you want to put the camera on a tree.
1. Pass the Installaon Belt through the support on the back of the
camera. If the Belt is too long for the tree which you choose,
there are 3 holes on each side the support, you could pass the
Installaon Belt through several holes to shorten the belt.
12
EN

2. Put the camera on the boom of the tree;
3. Go to the other side of the tree, pass the belt through the buckles
by following the picture;
4. Adjust the posion of the camera then ghten the belt
5. If you afraid that the camera would fall, you could also use the
Fixaon Kit and the Installaon Belt together to make sure that
the camera is sturdily fixed on the right posion.
Install the Camera in the field.
The TEST mode is advantageous for determining the best possible
detecon angle and range of the movement sensor.
For this purpose, aach the camera at approx.1m-2m height to a tree
and align the camera to the desired direcon.
At 1 meter height above the ground, place the camera parallel to the
ground. At 2 meters height above the ground, Tlt the camera down
five degrees to the ground.
13
EN

IMPORTANT INSTRUCTIONS
①The E9-4K uses a Micro SD card (TF class 10,U3) instead of a
standard SD card.
②The E9-4K is compable with Micro SD cards up to 256GB.
③Format the Micro SD card when you find that the camera does
not recognize the memory card properly. Please ensure that the
memory card is formaed successfully, if it is successful the
upper right hand corner will show the current capacity for the
duraon of the recording. if not, the number shown in the upper
right corner will be 00:00:00.( Format memory card→YES→OK )
④When you don't know what happened to E9-4K, try to reset
camera.( MENU→Reset sengs→YES→OK )
⑤Don't take out Micro SD card or disconnect the camera from
USB port while formang the Micro SD card or transferring
photo/video onto your computer,otherwise, photo/video in
the memory card will be lost, even corrupt the Micro SD card.
⑥Camera must be turned off before inserng or taking out the
Micro SD card.
⑦E9-4K supports 6V/1.5A external power supplies. The size is
3.5mm x 1.35mm.
⑧For your reference - use keyword”6v dc 3. 5mmx1.35mm" to
search items on Amazon, look for which power adapter is the
most suitable for you.
⑨Please remove the baery to prevent damage to the baery
or the camera when you are using an external power supply.
⑩Remove the baery from the camera when it will not be used
for a long period of me.
⑪Do not dip the camera in the water.
⑫Alkaline baeries are strongly recommended because alkaline
baeries were able to provide stable power to the camera.
⑬Do not use dead baeries together with fresh baeries.
14
EN

QUESTIONS & ANSWERS
1. Q: Why can't I open photos taken by E9-4K on my Windows
computer?
A: Videos created by E9-4K may not be supported by Windows
Player.We recommend using VLC or Interview player.
2. Q: Why my photos appear with strange color blocks or lines?
A: This could be a problem with the memory card.
Try formang the memory card or replacing it and test again.
If the same problem sll occur.
Send your order info and problem to our customer service team.
3. Q: My camera is frozen and I can't do anything with it.
A: This could be a malfuncon in the camera's system.
4.Q: How do I get the camera to work for the specified me.
A: Please refer to "Target Recording Time" in SETTING FUNCTIONS.
5. Q: How to remove Micro SD card.
A: Just gently push in the memory card and it will pop out automacally.
6. Q: Why does E9-4K has a white screen and cannot enter the system.
A: please replace the baery, the current baeries are just about dead.
7. Q: Why does my camera take a photo/Video every few second?
A: please check if the Time Lapse funcon is turned on, it will
automacally turn off the sensor. Please check "Time lapse"
in SETTING FUNCTIONS.
8. Q: E9-4K does not work at night or does not record at the set length.
A: If the baery is low (1/3 of a charge), Night Vision funcon will
be turn off automacally. Please replace the baery and then the
Night Vision funcon.
15
EN

9. Q: Why 4 baeries can work but have 8 baery slots.
A: E9-4K power module is divided into two groups (upper and lower).
Max supports to 8. This design makes it easy about some
customers with rechargeable baeries to alternate with the four
baeries to use E9-4K.
10. Q: E9-4K does not respond when connected to the computer.
A: Make sure photos can be previewed directly through the
camera's LCD screen before connecng to a computer. Try
another Micro USB Cable or USB port (Motherboard USB port)
Send your order info and problem to our customer service team.
11. Q:What kind of memory card should I buy for E9-4K.
A: E9-4K uses Micro SD card Size: 0.04 x 0.59 x 0.43 inches.
Type: CLASS 10, Less than 256 GB.
Most Micro SD cards below 256GB can be used on the E9-4K.
12. Q: How to determine whether the camera sensor is working
properly.
A: Please fallow the guidance sengs in the QUICK START GUIDE
chapter to set up E9-4K. Aer configuraon, switch the power
switch to TEST mode.About 15 seconds later, please walk in
front of the camera.If the red light flashes, the camera's in-
frared moon sensor is working properly. This method can
also help you adjust E9-4K's direcon and angle,determine
whether the current locaon is within the camera's monitor-
ing range.
If these Q.A. don't cover your problems. Please describe the
problem in detail and send your order number to our customer
service team. We will solve the problem with you ASAP. No
maer what quesons or suggesons you have, you can
email us without hesitaon.
16
EN

WARRANTY AND SERVICE
Authorized Service Centers for E9-4K
Whether you use the E9-4K for hunng or wildlife monitoring or
farm monitoring, a reliable camera repair service is key in ensuring
that you connue to enjoy your photographing experience. If your
E9-4K isn't performing as it should, making a strange noise, doing
strange things, or if you're just unsure. Please describe the problem
you are experiencing in as much detailing as possible and send your
order informaon along to our customer service team. Our
customer service team will get back to you as soon as possible. If
you do not hear back from us within 24 hours, please send us a
nother email, which may have been undelivered.
Warranty for E9-4K
EZETAI offers a 30-day free replace/refund and an one-year warranty.
Please remember or write down your order number or keep your
other proof of purchase. We will use these documents to verify your
order informaon and provide you with efficient and convenient aer
-sales service.
EZETAI are responsible for all quality issues of the product itself.
Corrosion and arficial damage are not covered under warranty.
Customer service team will carry out relevant verificaon based on
the photos provided by the customers. EZETAI will either repair or
replace due to non-conformies or manufacture defect.
17
EN
