F-Pedals TREMELON User manual
F-Pedals - PULSE OF REBELLION SERIESTremelon - User’s Guide
TREMELON
USER’S GUIDE
PULSE OF REBELLION
F-PEDALS
F-Vision LLC © All Rights Reserved.
The Design of Tremelon is inspired by and based on
an original artwork created by Italian artist
MELO
F-Vision LLC © All Rights Reserved.
F-Pedals - PULSE OF REBELLION SERIESTremelon - User’s Guide
Congratulations on your new F-Pedal !
I know you are ready to rock but Please Read
through this guide before you start.
You will find important information about this pedal
and useful tips.
Please don’t be shy to share photos, videos or
stories of your epic moments rockin’ out F-pedals!
Stay connected with us and many other cool artists
on our social medias and be part of our F-amily.
I truly hope our pedals will inspire you to create
amazing music.
TREMELON is a Classic Tremolo featuring two completely
independent engines.
The control panel is divided in two sections: "TURBO" and
“SLOWMO" to allow user to control separately the Volume,
Depth and Speed of each Tremolo engine.
Use the TURBO mode for a faster frequency and slightly
more triangle square wave sound.
SLOWMO as instead a slower speed range and is more of a
sine wave.
It also features custom black chrome bolts and diffuse LED
lights potentiometers with indicators.
By keeping the volume of one of the two tremolos at 0,
Tremelon will work as a single tremolo and when combining
the two engines together the user creates a unique pattern
never heard before in such a compact unit.The volume
control as a boost from 50% (Control at 12 O’clock) and up to
avoid the loss of signal or for simply giving a more driven
sound to the signal.
Another great feature is the ability to control the speed of
each tremolo engine by foot, using the optional FXP™
external expression pedal sold separately.!The expression
control can be used on TURBO and SLOWMO simultaneously
by using two expression pedals.!
F-Pedals - PULSE OF REBELLION SERIESTremelon - User’s Guide F-Vision LLC © All Rights Reserved.
STEP 1 Plug in audio and power cables
STEP 2 Stomp on the foot switch and turn on the Tremelon
STEP 3 Figure it out yourself….!
End of this User’s Guide. LOL !
STEP 4 If STEP 3 Failed…
…keep reading !!
A tremendous amount of time and
brain power has been dumped into
this User’s Guide.
You’d be better off reading it !
FRONT PANEL CONTROLS
SPEED CONTROL TURBO
Sets the frequency (speed) of the Tremolo TURBO
has a built-in LED light to show the on/off status of the pedal.
•Set to minimum (counter clockwise) BPM= 108
•Set in the middle (12 o’clock) BPM= 130
•Set to maximum (clockwise) BPM= 180
DEPTH!
Use this control to set the balance between
direct input sound and effect
TRUE BYPASS FOOT SWITCH!
Turns the pedal ON/OFF. F-Pedals - PULSE OF REBELLION SERIESTremelon User’s Guide F-Vision LLC © All Rights Reserved.
SLOWMOTURBO
SPEED CONTROL SLOWMO
Sets the frequency (speed) of the Tremolo SLOWMO
has a built-in LED light to show the on/off status of the pedal.
•Set to minimum (counter clockwise) BPM= 56
•Set in the middle (12 o’clock) BPM= 80
•Set to maximum (clockwise) BPM= 180
DEPTH!
Use this control to set the balance between
direct input sound and effect
VOLUME!
•Use this control to adjust the desired amount of
volume for the Turbo Section Tremolo.
•From Middle (12 O’clock) to maximum adds extra
boost to the output volume
VOLUME!
•Use this control to adjust the desired amount
of volume for the Slowmo Section Tremolo.
•From Middle (12 O’clock) to maximum adds
extra boost to the output volume
BPM RANGE : 108-180 BPM RANGE : 56-180
RIGHT PANEL CONNECTIONS
A.C. Adapter !
(Not included) Use a standard Center Negative 9V Power Supply.
You can use a power supply up to 18V (make sure it’s regulated)
There is No Battery Slot inside this pedal.
Input Jack 1/4 Inches
This is where you plug your guitar (or any
other instrument of your choice) using
a standard 1/4 Inch Jack cable.
F-Pedals - PULSE OF REBELLION SERIESTremelon - User’s Guide F-Vision LLC © All Rights Reserved.
FXP SLOWMO!
Here you can connect an F-Pedals FXP™
External Pedal Control (optional)!
to control the SPEED of the SLOMO section
Tremolo by foot.
FXP TURBO!
Here you can connect an F-Pedals FXP™
External Pedal Control (optional)!
to control the SPEED of the of the TURBO
section Tremolo by foot..
Output Jack 1/4 Inches
Connect here the 1/4 inch Jack that goes to
your Amplifier or other system of your choice.
LEFT PANEL CONNECTIONS
F-Pedals - PULSE OF REBELLION SERIESTremelon - User’s Guide F-Vision LLC © All Rights Reserved.
SPEED CONTROL!
The 2 LED Lights are actually the controllers
of the Tremolo Frequency (Speed).
Warranty !
If you experience a malfunction of the pedal, depending on the country and region
you are!in,!you may either contact the dealer where you purchased the pedal from, or
you can reach us directly!at Support@F-Pedals.com.
We will ask you to ship your pedals to us ONLY IF!we find it necessary to perform a
factory repair or replacement. Our!warranty is effective for 1 year (from the date of
purchase of a new unit) and only for issues caused by our manufacturing defects.!The
warranty will be voided if the unit has been misused, abused, modified by any
unauthorized parties, or if any seal sticker on the bottom screws is removed or
broken.!
Although you don’t need to register your product, we will ask for your original
receipt in order to process your request.
F-Pedals reserves the right to make changes or improvements on this
product!without incurring any obligation to install the same on!products previously
manufactured. F-Pedals is not responsible for injuries and/or damages related to the
use of our products.!
F-Pedals - PULSE OF REBELLION SERIES
Tremelon - User’s Guide F-Vision LLC © All Rights Reserved.
Please do not try to open
the pedal! Keep in mind
that if the stickers on the
screws are removed or
damaged you will lose
your Warranty.
