Dear user1
Congratulations on purchasing your Faber product,
a quality product that will provide you with the
warmth and atmosphere for many years. Please
read the user manual before using the fire. Should,
despite the careful final checks, a malfunction
occur, please contact your Faber dealer.
Please note:
The data of your fire is available in the user
manual.
Introduction1.1
Only have the appliance installed by a qualified
installer according to the gas safety regulations.
Read this installation manual properly.
Please check1.2
Check the fire for transport damage and report any
damage immediately to your dealer.
Check that the following parts are included:
1. Decoration material
2. Cover Ionisation plug .(fig.3.1 a)
3. Suction Cups
4. warranty card
5. User’s manual
6. Installation manual
7. Instruction card for decoration material
8. Remote controller
9. ranges of restrictors (fig.4.2)
10. Set long legs (fig.1.2 c )
11. Decorative solid cover trims (method 1
and 2) and integrated cover trim Q
(Method 3) (fig. 2.1a tm 2.1 c)
12. magnet snapper (fig.2.1R)
CE Declaration1.3
Glen Dimplex Benelux certifies that this Faber fire
complies with the essential requirements of the
gas appliances directive.
Product: gas room heater
Model: Triple Premium XXL
Applicable EC directives: 90/396/EEC
Harmonised standards applied: NEN-EN-613
NEN-EN-613/A1
This Declaration is invalid, if without the written
permission of Glen Dimplex Benelux:
Changes are made to the appliance.
The fire is connected to other exhaust
materials than specified.
Safety instructions2
The unit must be installed and subsequently
serviced every year and maintained in
accordance with these instructions and the
applicable national and local regulations.
Ensure that the data on the type label matches
the local gas type and pressure.
The settings and the construction of the fire
must not be changed!
The 230V electric cable may be only replaced
by a qualified person.
Ensure that the log layout (if applicable)
exactly matches the relevant photographs in
the instruction leaflet and never add extra
decorative material that was not supplied with
the fire.
The pilot flame must never be obstructed and
particular care must be taken when placing
the logs, pebbles or stones which are supplied
with the fire.
The unit is for atmosphere and heating
purposes. This means that all surfaces,
including the glass, can be very hot (over
100°C); exceptions to this are the bottom of
the fire and the control elements.
Do not place any combustible materials within
0.5m of the radiation area of the fire.
Before use, remove all stickers, protective film
and any protective rubber strips from the
glass.
Ensure adequate ventilation of the room when
using the fire for the first time. Run the fire at
the highest setting for several hours so that
the paint will have the chance to harden and
any possible vapours can be released safely.
Keep children and pets out of the room during
this process.
Please note
Through the natural air circulation of the fire
moisture and uncured volatile components
from paint, building materials and carpeted
floors, etc. are attracted. These parts can
settle as soot on cold surfaces. Therefore do
not light the fire shortly after installation.

Installatie handleiding
8 < <<<
Installation requirements3
Attention points for the fire3.1
This device can be built into an existing or new
chimney.
To prevent damage in transit, the flexible pipes are
fixed with tie-wraps which must always be removed
during the installation!
Attention points for the Installation3.2
box and Control unit (fig.1.7)
The gas valve and control unit are pre mounted in
an installation box, which is sealed with a cover
plate and removable door. (fig. 1.4)
The installation box can be placed as required to
the left or right, fixed or loosen of the appliance.
Before the falls chimney breast can be placed, the
installation box (on the same way the like the fire)
is placed level and in the correct position.
Note that the front of the system box is flush with
the finished wall.
After finishing the falls chimney breast the frame
and door of the installation box can be mounted.
Make sure that both the service plug (fig.1.7B) and
the gas tap remain accessible once the installation
is complete.
If positioned under the appliance or in the false
chimney breast, an extra service hatch or a
removable grille may be used.
For installation and service purposes the control
unit can be slid out of the installation box by
unscrewing the mounting nut. (fig. 1.5)
Attention points for the Power3.3
connection
To isolate the appliance and its control unit
(fig.1.7B) from the electricity supply, disconnect the
service plug (Fig. 1.7C) behind the plastic cover in
the installation box (fig.1.7A).
For the power supply a socket 230VAC/50Hz must
be installed.
Gas connection3.3.1
The gas connection must comply with the
applicable local standards.
Provide a flexible gas connection pipe with at
least ½ meter extra length to allow for installation
and service of the control unit (fig. 1.7)
False chimney breast or other3.4
structure
The False chimney should be made entirely of
non-combustible material.
The space above the fire should always be
ventilated using grids with minimal free
passage of 200cm² per grid.
Never build directly onto the built-in frame of
the appliance as this is not a weight-bearing
structure.
Fluepipe and terminal requirements
3.5
Supply of combustion air and the discharge of
exhaust gases must always be achieved using
flue materials specified by Faber. Only when
using these materials can Faber guarantee the
safe and proper operation of the appliance.
The outside of the concentric flue pipes can
heat up to +/-150°C so particular care must be
taken when penetrating a flammable wall or
ceiling to safeguard the construction with
proper insulation and protection. A minimum
distance of 50mm from the flue pipe to
combustible materials must be maintained.
Long lengths of flue pipe must be supported
every metre so that the weight of the flue is
not supported by the fire.
A piece of cut-down pipe material must never
be used as the first flue part of the flue system
connected directly to the fire as is could result
in the closure of the air supply.
Terminals3.6
The balanced flue pipe for combined air supply
and discharge can use a wall terminal or a roof
terminal, exiting either through the roof or
through an existing chimney.
Verify that the position of the terminal meets
the local regulations, e.g. regarding ventilation
openings, which may be greater than the
dimensions specified by Faber for safe and
effective functioning of the appliance.
For proper functioning, the air supply and
combustion gas discharge must not be
obstructed.
The minimum distances for safe operation are
specified in Chapter 15

Installatie handleiding
9 < <<<
C11, Wall terminal.3.6.1
For a facade or wall outlet use a wall terminal.
(fig.4.1 C11)
Depending on the calculation this can be a
diameter of 130/200mm or 100/150mm.
C31, Roof terminal.3.6.2
For a flat or pitched roof outlet use a long roof
outlet with a diameter of 100/150mm (fig.4.1 C31)
C91, Existing chimney.3.6.3
For an existing chimney use the short chimney
outlet with a diameter of 100/150mm (fig.4.1C91).
In this case the existing chimney acts as air inlet an
inserted flexible stainless steel pipe discharges the
flue gases. The top and the bottom should be
airtight.
Depending on the calculated outlet diameter, use a
flexible stainless steel tube of Ø 100mm or Ø
130mm with CE marking for 600°C.
Please note:
The minimum chimney diameter for a 130mm
flexible stainless steel pipe must 200 x 200mm.
And for a 100mm flexible stainless steel pipe
150x150mm.
Preparation and installation4
instructions
Gas connection4.1
See also chapter 3 Installation requirements.
Calculate/Size the pipe so that no pressure drop
occur in the gas pipe.
Please note
Provide a flexible gas connection with at least ½
meter extra length to allow for installation and
service of the control unit (fig. 1.7)
Preparing the fire4.2
Remove the fire from its packaging!
Please note:
Ensure that the gas supply pipes under the
appliance are not damaged.
Remove frame and glass and take the packaged
parts from the fire.
Store the frame and glass in a safe place.
Prepare the gas connection on the gas valve
Positioning of the fire4.3
Take the installation requirements into account see
Chapter 3.
Place the unit in the desired position and set the
height and level of the fire with the adjustable legs
supplied (Fig. 1.2c).
Rough height adjustment can be achieved with the
extendable leg or with the long legs supplied.
Fine adjustment can be achieved with the
adjustable feet..
Suspended from the wall4.3.1
The appliance can be mounted suspended from
the wall with the use of the suspension bracket
(Fig.1.3).
Installing the flue materials4.4
When penetrating a wall or ceiling the opening
must be at least 5mm larger than the diameter
of the flue pipe.
Horizontal sections should be installed with a
slope of 3 degrees towards the fire.
Build the system from the fire. If this is not
possible you can make use of an extendable
adapter section.
Where an adjustable section cannot be used, a
1/2 meter cut down pipe, which can be
shortened as required, can be used instead.
When shortening this type of pipe, ensure that
the inner pipe is 2cm longer than the outer
pipe.
Pipes that have been shortened must be
secured to the next pipe with self-tapping
screws.
The tail end of wall and roof terminals can also
be shortened as required, leaving a minimum
of 150mm of twin-wall pipe, i.e. the 150mm
measurement does not include the outdoor
part of the terminal.
When enclosing flue material within any sort
of structure, the pipes must not be insulated
but ventilated instead (approx. 100cm2).
Constructing the false chimney
4.5
If possible, carry out a performance test on the fire
before finally finishing the installation.
Chapter 7 “checking the technical parts of
installation”

Installatie handleiding
10 < <<<
Minimum false chimney size and4.5.1
distance to combustible materials
Construct the false chimney of non-combustible
material in combination with metal profiles or of
masonry/concrete blocks.
Always use a lintel or reinforcing bars while
bricking the outlet.
No part of the construction should rest on the fire
itself as it is not designed to be weight-bearing.
When selecting a finishing method(fig. 2.1a, 2.1b
and 2.1c) please take into account the surrounding
temperatures! (fig. 2.1 d)
Temperature surroundings zone A = +/- 120 °
Temperatures surroundings zone B = +/- 60 °
Ventilation4.5.2
The ventilation must comply with the applicable
local standards.
Correct ventilation prevents damaging overheating
of the gas regulator block and its electronics and
also limits the temperature of the convection air.
When planning the design of the false chimney
breast, you must allow for two ventilation
openings with a minimum free passage of 200cm2
per opening in the space above the fire. Faber
supply grilles of the correct dimensions or a similar
alternative may be used. Within the chimney
breast, a horizontal screen plate made of non-
combustible material must be installed just above
the ventilation openings. (fig. 1.2A)
The door of the control unit is designed and
constructed (fig.1.7 A and B ) with a ventilating
effect for the electronics and the gas valve,
Any impediment will have adverse effects on the
operation of the fire. (fig.1.4)
Building-in and finishing4.5.3
For installation and finishing the following points
are of interest::
A = installation reverent points (fig. 2.2 A)
S, T and Q = covers (fig. 2.7 to 2.9)
C = spacer(fig.2.2 B and C )
F(fig. 2.3)
D (fig. 2.2)
H (fig. 2.5)
Please note:
Ensure that the fire is not load-bearing with
regard to the false chimney breast or other
structural elements.
Pay special attention to the following points:
1. Check during work that the glass can be
inserted and removed easily.
2. Check during work that the covers T (fig.
2.7 and 2.8) or Q (fig.2.9) fit correctly.
(See the dimensional drawing Chapter 16.1).
Method 1 (fig. 2.1a)4.5.4
Build the false chimney breast against the
reverence points A, the mouldings B and the build-
in frame D (Fig. 2.2).
please note:
The installation must always allow for installing
and removing the glass!
Take into account the thickness of your chosen
finishing material!
Bracket Bhas to be in line (F Fig. 2.3) with the top
of the glass slot H.(Fig. 2.5)
ensure that the finishing material does not project
above bracket B. see dotted line F (fig.2.3)
Remove the reverence points (A) on the side wall
before applying the final finish to the wall! (Fig.
2.4).
If the reference points are not removed, the cover
strips will not fit.
Method 2 (fig. 2.1b)4.5.5
Process see Chapter 4.6.4
Method 3 (fig.2.1c)4.5.6
Please note:
Remove the bracket B(fig. 2.2). To ensure the air-
tightness of the fire the screws must be replaced.
The base X(fig. 2.5) must be 2mm clear of the
spacer C(fig. 2.5) and 4mm above the glass slot H
of the unit (Fig. 2.5). This will allow the Strip Q (Fig.
3.3) to be on the same level as the base.
Mounting the Solid cover strips4.5.7
(fig.2.7, 2.8 and2.9)
First, place the bottom strip Tor Q
Then place the left and right strips S(these are
fixed by the adjustable magnetic snappers)
To Remove the bottom strip Quse the supplied
magnetic knob R(fig. 2.9).
Removing the front glass5
Remove the solid covers trips see section 4.5.7
above.

Installatie handleiding
11 < <<<
Place the suction cups on the glass.
Draw the sealing cord and the glass clip out
the slot. (fig.5.1 a).
Slide the glass to the top so that the bottom is
released from the slot. Now pull the glass out
and gradually down. (fig. 5.1 b ).
Removing the side glass5.1
It is not necessary to take out the glass on the
side for placing the log set or for maintenance.
Remove the solid covers trips see section 4.5.7
First remove the front glass
Remove logs ore other decorative material
and the burner cover plate (fig 5.1 c)
Place the suction cups on the glass.
Remove the glass-bracket from the inside of
the burner chamber (Fig. 5.1 d)
Draw the sealing cord out the slot. (Fig.5.1a)
Slide the top of the glass up and
simultaneously tilt the top of the glass inwards
into the burner chamber (Fig. 5.1 e)
Replace the glass in reverse order.
Clean all fingerprints from the glass, otherwise they
will burn in once the fire is used.
Placing the decorative material6
Never add extra decorative material that was not
supplied with the fire.
Ensure that the ignition and ionisation plugs are
kept free from decorative material (fig.3.1 a b c d)
Distribute the decorative material evenly and
carefully on the burner in stages; if the material is
placed too thickly it can block the burner openings!
Log set6.1
Place some of the chips on the burner and
on the burner cover plate .
Place the logs as specified. (fig.3.1 or the
included log set card)
Divide the rest of the chips on the burner
and on the cover plate. Prevent a thick layer
on the burner; this adversely affects the
flame pattern.
Glow wire6.1.1
The “glow wire” gives a decorative glow effect.
Pull the wire well apart and place tufts in different
places on the burner.
Please note:
Do not use the glow wire near the ignition and
ionisation plugs as this can cause a short circuit in
the ignition system.
Pebbles or Grey stone6.2
Install the ionisation cover(fig.3.1a and 3.1 b)
Place the pebbles or grey stones on the
burner and on the burner cover plate(fig.
3.1b/3.1c or the included log set card).
Prevent a double layer; this adversely affects
the flame pattern.
Control and first use.7
Control of the technical parts7.1
Purge the gas pipe if necessary.
Remove the front glass from the unit if necessary.
For correct functioning of the appliance :
Check if the ignition and ionisation plugs are free
from all decorative material.
Check that the ignition and ionisation cables are
not constricted but hang freely under the
appliance.
Remove all the tie-wraps on cables and pipes!
Control of the main burner ignition7.1.1
and flame pattern.
Start the ignition process as described in the user
manual.
Please note:
if, after a first ignition time (1x 15sec.) the
burner does not start, the electronics will have
to be reset.
Wait 5 minutes before you start the ignition
process again.
Reset can only be done via the remote control;
first using a combination of buttons 1 and 2,
then a combination of 2 and 5.
After a third time of reset, a 15 minutes delay
period will automatically start.
The main burner will automatically start on full-
burn mode in the centre part to the burner.

Installatie handleiding
12 < <<<
Check that ignition of the main burner goes
smoothly and quietly
With the remote you can control the fire to the
desired position.
Let the fire burn in wide and full position to
assess the flame distribution.
TIP: If necessary, rearrange some decorative
material and glow-wire to give an enhanced flame
pattern.
Checking the flame image.7.2
Replace glass, sealing cord and clip, let the fire run
for 20min. on wide full section and Rate if the flame
pattern is oke!
Check the flame pattern for:
1. Flame distribution
2. Colour of the flames
If the flame distribution or the colour are not
acceptable then check:
The log set layout and/or the amount of chips
on the burner.
The pipe connections for leaks (in case of blue
flames).
Whether the correct Restrictor is fitted.
The roof/wall terminal:.
oWall terminal right side up?
oRoof terminal on the correct
Position? see chapter 14
oIf the maximum horizontal flue
lengths has not been exceeded?
Checking for gas leaks7.3
Check all connections and pipes for gas leakage
with a gas leak finder or spray.
Checking the burner and inlet7.4
pressure.
Check that the burner pressure and inlet pressure
match the information listed in this manual,
Chapter 14 Technical specifications.
The burner pressure is set at the factory; if the
value does not match that shown in chapter 14 of
this manual, contact the service department
How to check inlet pressure :
Close the gas tap/isolator.
Loosen the measuring point B (see fig. 1.7) a
few turns and connect a pressure gauge hose to
the test point.
Connect your meter on the measure point
B(see fig. 1.7)
Open the gas tap/isolator
The pressure must match the value specified in
the technical data of this manual
When the inlet pressure is 5mb higher or
lower, do not connect the appliance and get
in contact with the gas supply company.
How to check burner pressure:
This test can only be performed if the inlet
pressure is correct!
Loosen the measuring point A (see fig. 1.7) a
few turns and connect a pressure gauge hose to
the test point.
Start the fire and set with remote control to
wide and full flame picture.
The burner pressure must match the value
specified in the technical data of this manual
Please note:
Close all pressure measuring nipples and check for
gas leakage.
Flue gas analyzer7.5
By using a CO/CO2 flue gas analyzer, it is possible
to check the supply air and the combustion gases.
two measuring pipes at the front of the fire
between the mounting frame and the glass (Fig.
1.7 A and B).
The ratio of CO2 and CO must not be greater than
1:100
Example:
CO2 is 4% and CO is 400ppm, measured at the
highest point
If the ratio is greater than 1:100 or exhaust gases
are detected in the supply air, then all points in
sections 6 and 7 above must be re-checked.
Instructions for client8
Advise that the fire must be serviced, cleaned
and checked for correct operation annually by a
qualified specialist to ensure the continuing
safe operation and to guarantee a long service
life.
Give advice and instructions on the care and
cleaning of the glass. Highlight the danger of
burnt-in fingerprints
Instruct the customer on the operation of the
unit and the remote control, including replacing

Installatie handleiding
13 < <<<
the batteries and how to “pair” the remote
control and ITC.
Handing over to the customer8.1
Installation instruction.
User manual.
ITC operation instruction.
Warranty card.
log layout instruction card.
Remote control handset.
Suction cups.
Magnetic snapper.
Annual maintenance9
Checking and cleaning:
9.1
Check and where necessary, clean
oIgnition to the main burner.
oIonisation.
oThe burner.
oThe combustion chamber.
oThe glass.
oThe ceramic logs for breakages.
oThe terminal.
Replace, if necessary:
oDecoration material / Glow-wire.
Cleaning the glass9.1.1
Most deposits can be removed with a dry cloth but
if necessary a ceramic hob cleaner. Can be used.
Please note:
Avoid fingerprints on the glass. These may be
burnt on by the heat and then no longer be
removable
Conversion to another gas type10
The conversion to a different gas type may only be
performed by a qualified installer/dealer.
Conversion from natural gas to10.1
propane (or vice versa)
This can only be done by replacing the burner. To
do so, please contact your dealer.
Specify with your order always the type and serial
number of the device.
Flue calculation11
The quickest and simplest way to calculate
whether your chosen flue configuration is possible
in combination with your fire, is to use the free
“Faber Flue App” which can be download from:
INTERNET:
BlackBerry, Android, PC (with Google Chrome
browser)
APP store:
iPhone, iPad and Mac.
Google Play:
Android smartphones and Android tablets.
Alternatively use the flue calculation table (see
tables below and sections 12 and 13).
The alternatives of outlet lengths and any
restrictors are set out in the restrictor table. In the
table we work with Start Length (STL) Total Vertical
Height (TVH) and Total Horizontal Length (THL).
Start Length (STL)
This is the first pipework component that is placed
on the fire and is shown as length in metres (Fig.
12.1, 12.2 and 12.3 A, N, F).This value is in the top
row of the table (see table).
Total Vertical Height (TVH)
TVH is the difference in height measured from the
top of the fire to the end of the outlet; it can be
measured or determined from the building plan.
For clarification see the TVH indication in the
drawings. (Fig. 12.1, 12.2 and 12.3: TVH)
Total Horizontal Length (THL)
THL is the Total Horizontal Length and consists of
elbows and pipes used entirely in the horizontal
plane. Elbows I, K and Q and the elements H, J, L,
M, P and R (Fig. 12.2 and 12.3).
Horizontal length
The horizontal length consists of the elements H, J,
L, M, P and R (Fig. 12.2 and 12.3).
bends 90° in the horizontal plane
Bends used entirely in the horizontal plane (Fig.
12.1, 12.2 and 12.3 I, K and Q).
Bends 45° or 30° in the horizontal plane
Bends used entirely in the horizontal plane
90° Bends

Installatie handleiding
14 < <<<
90° bends which are used to switch from vertical to
horizontal or vice versa (Fig. 12.2 and 12.3 G, O and
S)
Bends 45° or 30 ° vertical to horizontal
plane
These are 30° or 45° bends used within the vertical
plane (Fig.12.1 B and D).
Pipes running upwards at an angle:
These are pipes which are ascending at an angle of
30° or 45° from the horizontal. (Fig. 12.1 C). Fill in
only in combination with at least 2 x 30 or 45°
bends in the vertical part.
Table:
Select from the table the correct vertical (TVH) and
horizontal length (THL).
If the result is “x” or if the values are outside the
table, then the combination is not allowed. The
TVH or THL can be adjusted to achieve a viable
system.
If a value is indicated, check that the calculated STL
value is not lower than indicated in the table. In
this case STL must be adjusted.
The resulting value indicates the width of the flue
restrictor (“0” means no restrictor) required
30mm restrictor is installed as standard by the
factory and each fire is supplied with a full set of
restrictors. (fig.4.2)

Installatie handleiding
15 < <<<
Table for pipe diameter 100/150mm11.1
Start length (STL) total Vertical height (TVH) and total Horizontal length(THL)
STL
0,1
TVH
0
1
2
3
4
5
6
7
8
9
10
THL
0
x
x
x
x
x
x
x
x
x
x
x
0,5
x
x
x
x
x
x
x
x
x
x
x
1
x
x
x
x
x
x
x
x
x
x
x
1,5
x
x
x
x
x
x
x
x
x
x
x
2
0.2
x
x
x
x
x
x
x
x
x
x
3
0.2
x
x
x
x
x
x
x
x
x
x
4
0.2
x
x
x
x
x
x
x
x
x
x
5
0.2
x
x
x
x
x
x
x
x
x
x
6
0.2
x
x
x
x
x
x
x
x
x
x
7
0.2
x
x
x
x
x
x
x
x
x
x
8
0.2
x
x
x
x
x
x
x
x
x
x
9
0.2
x
x
x
x
x
x
x
x
x
x
10
0.2
x
x
x
x
x
x
x
x
x
x
11
30.2
x
x
x
x
x
x
x
x
x
x
12
30.2
x
x
x
x
x
x
x
x
x
x
13
30.2
x
x
x
x
x
x
x
x
x
x
14
30.2
x
x
x
x
x
x
x
x
x
x
15
30.2
x
x
x
x
x
x
x
x
x
x
16
40.2
x
x
x
x
x
x
x
x
x
x
17
40.2
x
x
x
x
x
x
x
x
x
x
18
40.2
x
x
x
x
x
x
x
x
x
x
19
40.2
x
x
x
x
x
x
x
x
x
x
20
40.2
x
x
x
x
x
x
x
x
x
x
21
50.2
x
x
x
x
x
x
x
x
x
x
22
50.2
x
x
x
x
x
x
x
x
x
x
23
50.2
x
x
x
x
x
x
x
x
x
x
24
50.2
x
x
x
x
x
x
x
x
x
x
25
50.2
x
x
x
x
x
x
x
x
x
x
26
50.2
x
x
x
x
x
x
x
x
x
x
27
60.2
x
x
x
x
x
x
x
x
x
x
28
60.2
x
x
x
x
x
x
x
x
x
x
29
60.2
x
x
x
x
x
x
x
x
x
x
30
60.2
x
x
x
x
x
x
x
x
x
x
THL
TVH
STL

Installatie handleiding
16 < <<<
Table for pipe diameter 200/130mm11.2
Start length (STL) total Vertical height (TVH) and total Horizontal length(THL)
STL
0,1
0,2
0,5
0,5
1
1
1
1
1
1
1
TVH
0
1
2
3
4
5
6
7
8
9
10
THL
0
x
x
x
x
x
x
x
x
x
x
x
0,5
x
0.4
x
x
x
x
x
x
x
x
x
1
x
30.4
0.4
0.4
x
x
x
x
x
x
x
1,5
0.4
30.4
30.4
0.4
0.4
0.4
0.4
x
x
x
x
2
30.4
40.4
30.4
30.4
0.4
0.4
0.4
x
x
x
x
3
40.4
40.4
40.4
30.4
30.4
0.4
0.4
x
x
x
x
4
40.4
40.4
40.4
40.4
30.4
30.4
0.4
x
x
x
x
5
50.4
50.4
40.4
40.4
40.4
30.4
30.4
x
x
x
x
6
50.4
50.4
50.4
40.4
40.4
40.4
30.4
x
x
x
x
7
60.4
60.4
50.4
50.4
40.4
40.4
40.4
x
x
x
x
8
60.4
60.4
60.4
50.4
50.4
40.4
40.4
x
x
x
x
9
60.4
60.4
60.4
60.4
50.4
50.4
40.4
x
x
x
x
10
70.4
70.4
60.4
60.4
60.4
50.4
50.4
x
x
x
x
11
70.4
70.4
70.4
60.4
60.4
60.4
50.4
x
x
x
x
12
70.4
70.4
70.4
70.4
60.4
60.4
60.4
x
x
x
x
13
80.4
80.4
70.4
70.4
70.4
60.4
60.4
x
x
x
x
14
80.4
80.4
80.4
70.4
70.4
70.4
60.4
x
x
x
x
15
80.4
80.4
80.4
80.4
70.4
70.4
70.4
x
x
x
x
16
80.4
80.4
80.4
80.4
80.4
70.4
70.4
x
x
x
x
17
80.4
80.4
80.4
80.4
80.4
80.4
70.4
x
x
x
x
18
80.4
80.4
80.4
80.4
80.4
80.4
80.4
x
x
x
x
19
80.4
80.4
80.4
80.4
80.4
80.4
80.4
x
x
x
x
20
80.4
80.4
80.4
80.4
80.4
80.4
80.4
x
x
x
x
21
85.4
85.4
80.4
80.4
80.4
80.4
80.4
x
x
x
x
22
85.4
85.4
80.4
80.4
80.4
80.4
80.4
x
x
x
x
23
85.4
85.4
85.4
80.4
80.4
80.4
80.4
x
x
x
x
24
85.4
85.4
85.4
85.4
80.4
80.4
80.4
x
x
x
x
25
85.4
85.4
85.4
85.4
85.4
80.4
x
x
x
x
x
26
85.4
85.4
85.4
85.4
85.4
x
x
x
x
x
x
27
85.4
85.4
85.4
85.4
x
x
x
x
x
x
x
28
85.4
85.4
85.4
x
x
x
x
x
x
x
x
29
85.4
85.4
X
x
x
x
x
x
x
x
x
30
85.4
X
X
x
x
x
x
x
x
x
x
STL
THL
TVH

Installatie handleiding
17 < <<<
Example12
fig. 12.1 fig.1 2.2
fig 12.3
TVH
TVH
TVH

Installatie handleiding
18 < <<<
flue calculation table13
Starter Length (STL)
first pipework component that is placed on the fire
value
completed
Flue length from 0,1 - 0,45 m
0,2
Flue length from 0,5 - 0,90 m
0,5
Flue length from 1,0 - 1,40 m
1
Flue length from 1,5 - 2,00 m
1.5
Flue length from 2,00 m und mehr
2
Bends 90°
0,1
Bends 45° oder 30°
0,2
Roof terminal
1
Wall terminal
0
Total

Installatie handleiding
19 < <<<
Total Vertical height (TVH)
Measured height
Rounded value
Meter
Meter
Total Horizontal length (THL)
Calculate
Part
number
value
result
Rounded value
The total flue length
of ½ m and 1 m pipes
in meters
x
1
90° bends in the
horizontal flue length
x
1,5
45° bends in the
horizontal flue length
x
1
90° bends from
Vertical to horizontal
Vice versa
x
0,4
45° bends from
Vertical to horizontal
Vice versa
x
0,2
Pipes running
upwards at an angle
In meters
x
0,7
total
_______+
Meter
Search in the table at TVH and THL and enter the value that is found
Found value
If the detected value is a number,
check whether the completed STL is higher or equal to the value in the table.

Installatie handleiding
20 < <<<
Is the found value “X” then the flue run is not possible
Solution: change the TVH or THL
If the STL value is less than as specified in the top row of the table , the flue run is not possible .
Solution: starter length to low! see for the minimum length in the top row of the table
Result
Restrictor size = found value before the comma
mm
Ectra information = found value behind the comma
Mark which is applied
Install the air reducer plate! See the installation manual!
0,1
Install the adapter 200/130 to 150/100mm direct on top of the fire
0,2
In case of wall terminal:
Install the adapter 200/130 to 150/100mm before the last bend.
In case of roof terminal:
Install the adapter 200/130 to 150/100mm before the terminal.
0,3
In case of roof terminal (Always size 100/150mm):
install the adapter 200/130 to 150/100mm just before the terminal.
In case wall terminal:
Use the 200/130mm wall terminal
0,4
