Faber PEBBLES Series User manual

INSTRUCTION MANUAL
PEBBLES SERIES
PEBBLES 106WH
PEBBLES 107BK

Thank you for purchasing FABER Instant Water Heater.
Please read this manual thoroughly and understand the content before use.
1. Do not install reverse INLET & OUTLET and Stop Valve of heater.
2. Do not install the heater at where there is consistent spray directly over the unit.
3. Do not connect the OUTLET to any tap or fitting that is not recommended by the manufacturer.
4. Do not block the heater OUTLET in any way.
5. Do not attempt to repair the heater without qualified technician.
6. This appliance is not intended for use by person (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
supervised or instructed concerning use of the appliance by a person responsible for their safety.
7. Children should be supervised to ensure that they do not play with the appliance.
8. Engage qualified electrician for installation.
9. Test water temperature with hand before using the shower.
10. Check the ELCB once a month (please refer to the Test Run of Heater) and consult professional
for repair if there is any malfunction.
11. Metallic / chrome flexible hose and conductive control valve shall not be used.
12. Use only new hoses to connect the appliance to the water supply. The old hoseshould not be
reused.
13. This appliance is not to be used for portable water supply.
14. The water inlet of this appliance shall not be connected to inlet water obtained from any other
water heating system.
15. Do not leave the hand shower idle in the pail. (refer below)
SAFETY PRECAUTION
LANGKAH–LANGKAH KESELAMATAN
2

3
EXTERNAL PARTS IDENTIFICATION
ABS Heater Base
Temperature Control Knob
Power LED (Green) Heater LED (Red)
Stop Valve (Inlet)
Test & Reset
Button
Flow Sensor Assembly
Water INLET Connection
ABS Heater Base
ELCB Control Board
LED Display Board
Thermal Cut Out
Heater Tank
Triac
Water OUTLET Connection
1. WATER HEATER PARTS IDENTIFICATION
INTERNAL PARTS IDENTIFICATION
Electric cable
Recommended conductor
size: 4.0mm2(not included)
Cabel Entry
Terminal Block
Test & Reset
PCB
Heater
Control Unit

4
INSTALLATION
2. GENERAL INFORMATION
CAUTION:
AWAS:
THIS APPLIANCE MUST BE EARTHED
PERKAKAS INI MESTI DIBUMIKAN
1. All plumbing work should be completed before proceeding to electrical wiring connection. (Table 1)
2. Installation must be carried out by qualified electrician with close reference to this manual and in
compliance with the local regulations.
3. The unit works at minimum water flow rate of 2 liter/min, which would trigger the built-in pump
(only for pump model), boostering a stronger shower spray.
4. The built-in electronic Earth Leakage Circuit Breaker (ELCB) would cut-off the power supply to heater
in the event of current leakage of as low as 15mA.
5. The Thermal Cut-Off would automatically shut off the power supply shall there is any abnormal rise
of showering temperature.
6. The unit only operates when there is sufficient water flow to trigger the flow switch.
7. Electrical loading Table 1:
Recommended Conductor Size (csa)
mm2
3.5 16.0 2.5 7/0.67mm 50/0.25 20 20
4.5 20.5 2.5 7/0.67mm 56/0.30 25 25
5.5 25.0 4.0 7/0.85mm 56/0.30 32 32
6.0 27.3 4.0 7/0.85mm 56/0.30 32 32
6.5 29.6 4.0 7/0.85mm 84/0.30 32 32
7.5 34.1 6.0 7/1.04mm 84/0.30 40 40
8.0 36.4 6.0 7/1.04mm 84/0.30 40 40
3.5 15.2 2.5 7/0.67mm 50/0.25 20 20
5.5 24.0 4.0 7/0.85mm 56/0.30 32 32
6.6 28.7 4.0 7/0.85mm 56/0.30 32 32
8.8 28.3 6.0 7/1.04mm 84/0.30 40 40
3.6 15.0 4.0 7/0.67mm 50/0.25 32 20
3.8 16.3 4.0 7/0.67mm 50/0.25 32 20
4.2 17.5 4.0 7/0.67mm 50/0.25 32 20
7.7 32.1 6.0 7/1.04mm 84/0.30 40 40
9.0 37.5 6.0 7/1.04mm 84/0.30 40 40
Voltage
(Vac)
Power
(kW)
Amperes
(A)
Fuse/MCB
(A)
ON/OFF
Switch (A)
220 –
50/60Hz
230 –
50/60Hz
240 –
50/60Hz
Conduit
Cable
Flexible
Cable
8. Instantaneous water heater shall be equipped with a 2-pole control switch and own residual current
device.
9. Water heaters exceeding 3kW shall be permanently connected to a 20A/30A rated circuit breaker/
fuse with an isolator switch and residual current device.

5
1. All the plumbing works should be completed before proceeding
to electrical wiring connection.
2. INLET and OUTLET connection of the heater unit should not be
reversed, with stop valve installed on INLET. (Diagram 1)
3. It is recommended to mount the unit at 1.5mm above the
floor to bottom of the hater.
4. Mounting position (Refer Diagram 2)
• Remove screw from the bottom of the heater
• Lift the plastic cover upward
• Mark mounting position on the wall for all
4 screws
• Drill the holes with 5.0mm diameter drill bit
(Refer Diagram 3)
• Install the unit to the wall with plug
5 Installation of Heater INLET and OUTLET connection.
a) Connect the stop valve to INLET, and be sure to put a
gasket to prevent water leakage.
b) Connect the pipe from the stop valve to incoming
water supply. If necessary make use of sealing tape
for the connection to prevent water leakage.
c) Connect flexible hose to heater OUTLET. Turn on
the water mains to drain out all the plumbing dirt
and fill up the heater tank. Then, connect the
flexible hose to the hand shower.
(Note: This step will prevent damage to the heating element).
3. INSTALLATION PROCEDURES
Floor
Stop Valve
1.5m
Diagram 1
Diagram 2
Diagram 3
SAFETY PRECAUTION
Do not install reverse INLET and OUTLET of heater
INLET
OUTLET
OUTLET
OUTLET
correct installation inlet - outlet reverse
(wrong installation)
stop valve reverse
(wrong installation)
INLET
Lift upward

6. Electrical Connection
a) Insert electrical cable through the rubber grommet as shown.
b) Connect the cable to the terminal block and fully tighten them
as the following:-
• Red or Brown ……………………………….……… Live (L)
• Black or Blue.…………………………………… Neutral (N)
• Green or Green/Yellow……………………………Earth
c) Restore the cover and secure screw at the bottom. ( Diagram 4)
d) Align the knob from ‘ON’ position in clockwise direction to ‘MAX’
and return to ‘OFF’ mark as shown. (Diagram 5)
Test Run of Heater
a) Turn on the stop valve and water should spray out from the head.
b) Switch on the main power supply (‘POWER’ LED would light up).
c) Turn on the Temperature Control and ‘HEATER’ LED would light up.
d)Test the ELCB by pressing ‘TEST’ switch. The unit should be tripped. ‘POWER’ and ‘HEATER’ LEDs
would go out.
e)Press ‘RESET’ switch. The unit should resume to normal condition.
f)The heater is now ready for use.
6
Diagram 5
Diagram 4
Restore cover

DO NOT USE THINNER, ALCHOHOL OR PETROL
You may clean the heater with a damp cloth and mild detergent but do not use thinner, alcohol,
petrol or any other organic solution.
CLEAN FILTER REGULARLY (DIAGRAM 6)
a) Remove the filter mesh from the stop valve (for filter type only) by turning the knob filter
counter clockwise and pulling out the knob (Diagram 6). Flush it with water to remove any
trapped sediments. Install the knob filter back to its original position.
7
1. Switch on the main power supply, the ‘POWER’ LED would light up.
2. Turn on the water supply at the stop valve.
3. Turn on the Temperature Control Knob. The ‘HEATER’ LED would light up and the water
temperature will be increased accordingly as the knob is turned clockwise from ‘ON’ to ‘MAX’.
4. For normal cold shower, just turn the Temperature Control Knob to ‘OFF’ position.
5. Switch off the power supply when not in use.
4. OPERATION PROCEDURES
5. GENERAL MAINTENANCE
CLEAN FILTER
MESH REGULARLY
Filter Mesh
stop valve

6. TECHNICAL SPECIFICATION
7. SCHEMATIC WIRING DIAGRAM
Electrical loading 3.8kW 240V 50/60Hz
Other loading Please refer Electrical loading table
ELCB sensitivity 15 mA
Operating condition Open system (Open outlet)
Water connection 15mm (1/2” BSP)
Degree of protection IP25
Min water flow rate 2 litre/ min
Min water pressure 0.2 bar ( 20kPa / 2.9psi )
Max water pressure 4 bar ( 400kPa / 58psi )
Heater dimension (mm) 251 (H) x 231 (W) x 87 (D)
Heater nett weight Non pump: 1.2kg
Notes: The specification of product design and accessories shown are correct at the time of printing
and subject to change without prior notices.
NON-PUMP (PEBBLES 106WH/PEBBLES 107BK)
Live L L
Neutral NN
Earth
Test / Reset
ELCB
15mA
Thermal Cut Out
Flow Sensor
Relay Triac
T2 T1
G
LED
Temperature
Control
Heating Element
8
