Operation & Maintenance Manual
CAMDEN bench

Introduction
Design
Design, shop drawings and development by Factory Furniture Ltd.
Manufacture
Factory Furniture manufactured components. Products are assembled in Factory workshops, checked and
dispatched ready for installation. Replacement products or components thereof should be ordered direct from
Factory Furniture Ltd.
Copyright
The design copyright for the product and drawing copyright remains the sole property of Factory Furniture Ltd.
General Specifications
Bench
Metric length 2700mm | width 550mm | height 650mm
Imperial length 8’ 10½” | width 1’ 9½” | height 2’ 1½”
Approx Weight 1765kg
Detailed Material & Finish Specifications
Bench
• Bench material - Exposed aggregate concrete (white or black concrete (both smooth finish); limestone, yellow
granite, blue granite and black granite (all shot peened) effects available). Surface is sealed to make it water
repellant
• Internal reinforcement - Galvanised steel frame
• 4 no. lifting sockets (RD20 knuckle thread Din 405) **Lifting eyes not supplied**
General Maintenance (Recommended Schedule & Guidelines)
Daily/Weekly/Monthly (or as adopted)
Visual checks of bench - check for superficial or physical damage.
Three Monthly
Clean bench as detailed below
Six Monthly
Full clean as detailed below; check that bench is firmly secured to the ground
Specific Maintenance Details
Concrete
Clean with a stiff brush once per year, especially in more exposed locations, in order to prevent a verdigris type
build up on the surface. Ideally, this should be completed in early spring.
Repairs
Heavy Damage
In the event of serious damage please contact Factory Furniture for detailed technical advice.
Reordering / Spares
There are no spare parts for this model of bench
AutoCAD Drawing List
FF1031 / 01 CAMDEN BENCH OVERVIEW DRAWING
FF1031 / 02 CAMDEN BENCH SETTING OUT DRAWING
Contacts
Factory Furniture Ltd Tel [phone]
5 Pioneer Road Email [e-mail]
Faringdon, Oxon Web www.factoryfurniture.co.uk
SN7 7BU UK
2CAMDEN bench specification

Foundation 1 no. pad
2900x750x400mm in
C20 concrete
(recommendation only)
Foundation 1 no. pad
2900x750x400mm in
C20 concrete
(recommendation only)
2700
650
550
410
Ground Level
Installation Instructions
ALL INSTALLATION WORKS TO BE CARRIED OUT BY COMPETENT PERSONNEL - INSTALL AS COMPLETE UNIT
Surface fix
Camden Bench (surface fix only)
1. Install suitable foundation pad (see illustration) with top face at ground level
2. Position bench in correct orientation with base centrally on foundation pad. 4 no. lifting sockets included to
aid lifting and positioning (RD20 knuckle thread Din 405) **Lifting eyes not supplied**
3
CAMDEN bench installation
