User Guide for
FEBFAN302HL_CH442v1
Evaluation Board
FAN302HL 5V / 1A PSR Mobile Phone
Battery Charger
Featured Fairchild Product:
FAN302HL
Direct questions or comments
about this Evaluation Board to:
“Worldwide Direct Support”
Fairchild Semiconductor.com

© 2011 Fairchild Semiconductor Corporation 2 FEBFAN302HL_CH442v1 • Rev. 1.0.0
Table of Contents
1.General Introduction ................................................................................................................. 3
1.1.General Specification...................................................................................................... 3
2.Function Check Report ............................................................................................................. 3
2.1.Input Current................................................................................................................... 4
2.2.Input Wattage at No-load Condition............................................................................... 4
2.3.Startup Time.................................................................................................................... 6
2.4.DC Output Rising Time.................................................................................................. 7
2.5.Line and Load Regulation............................................................................................... 9
2.6.Efficiency........................................................................................................................ 9
2.7.Output Ripple and Noise............................................................................................... 10
2.8.Step Response ............................................................................................................... 12
2.9.Over-Power Protection.................................................................................................. 13
2.10.Hold-up Time................................................................................................................ 13
2.11.Short-Circuit Protection ................................................................................................ 15
2.12.Brownout Test............................................................................................................... 16
2.13.VDD Voltage Level ........................................................................................................ 16
2.14.Voltage Stress on MOSFET and Rectifiers .................................................................. 20
2.15.Constant Voltage (CV) and Constant Current (CC) Curves......................................... 21
2.16.VSOVP Test ................................................................................................................. 22
2.17.Over-Temperature Protection Test (OTP) .................................................................... 23
2.18.EMI Test ....................................................................................................................... 24
2.19.Surge Test ..................................................................................................................... 25
2.20.ESD Test ....................................................................................................................... 25
3.Photographs............................................................................................................................. 26
4.Schematic................................................................................................................................ 27
5.PCB Layout............................................................................................................................. 28
6.Bill of Materials ...................................................................................................................... 29
7.Transformer Specification ...................................................................................................... 30
7.1.Specification Approval ................................................................................................. 30
8.Revision History ..................................................................................................................... 34

© 2011 Fairchild Semiconductor Corporation 3 FEBFAN302HL_CH442v1 • Rev. 1.0.0
1. General Introduction
This document describes a 5W power supply using a FAN302HL device. This power
supply is targeted for mobile phone battery chargers with a 10mW solution and requiring
high efficiency.
To get the standby power consumption lower than 10mW at 230VAC, the FAN302HL has
functions to enhance the standby power consumption, including proprietary Burst Mode
with lower operation current under light-load conditions and built-in HV startup circuitry
in the IC side to reduce startup resistor power loss.
Using FAN302HL, a charger can be implemented with the few external components and
minimized cost.
1.1. General Specification
Specification Min. Normal Max. Units
Input
Voltage 90 264 VRMS
Frequency 47 63 Hz
Output
Output Voltage 1 4.75 5.00 5.25 V
Output Current 1 1.0 1.2 1.4 A
Total Output Power
Full-Load Output Power 4.75 6.00 7.35 W
2. Function Check Report
Test Model FEBFAN302HL_CH442v1
Test Date March 2011
Test Temperature Ambient
Test Equipment
AC source: 6800 AC POWER SOURCE
Electronic Load: Chroma 63030 and 63102
Power Meter: WT210
Oscilloscope: LeCory 24Xs-A
Test Items
1. Input current
2. Input wattage at no-load condition
3. Startup time
4. DC-output rising time
5. Line and load regulation
6. Efficiency
7. Output ripple and noise
8. Step response
9. Over power protection
10. Hold-up time
11. Short-circuit protection
12. Brownout test
13. VDD voltage level

© 2011 Fairchild Semiconductor Corporation 4 FEBFAN302HL_CH442v1 • Rev. 1.0.0
14. Voltage stress on MOSFET and rectifiers
15. Constant voltage (CV) and constant current (CC) curve
16. VS OVP test
17. OTP test
18. EMI test
19. Surge test
20. ESD test
2.1. Input Current
2.1.1. Test Condition
Measure the AC input current at maximum loading.
2.1.2. Test Result
Input Voltage Input Current (mA) Specification
90V / 60Hz 120.20
264V / 50Hz 51.57
2.2. Input Wattage at No-load Condition
2.2.1. Test Condition
Measure the input wattage and output voltage at no load.
2.2.2. Test Result
Input Voltage Input Wattage (mW) Output Voltage (V) Specification
90V / 60Hz 6.3 5.116
<10mW
115V / 60Hz 6.5 5.116
230V / 50Hz 7.3 5.116
264V / 50Hz 9.0 5.116

© 2011 Fairchild Semiconductor Corporation 5 FEBFAN302HL_CH442v1 • Rev. 1.0.0
2.2.3. Measured Waveforms
Ch1: VFB
Ch2: VVS
Ch3: VDD
Figure 1. 90V / 60Hz at No Load
Ch1: VFB
Ch2: VVS
Ch3: VDD
Figure 2. 264V / 50Hz at No Load

© 2011 Fairchild Semiconductor Corporation 6 FEBFAN302HL_CH442v1 • Rev. 1.0.0
2.3. Startup Time
2.3.1. Test Condition
Set output at maximum loading. Measure the interval between AC plug-in and stable output.
2.3.2. Test Result
Input Voltage Startup Time (ms) Specification
90V / 60Hz 249 <3s
264V / 50Hz 236
2.3.3. Measured Waveforms
Ch1: VAC
Ch4: VO
Figure 3. 90V / 60Hz at Maximum Load
Ch1: VAC
Ch4: VO
Figure 4. 264V / 50Hz at Maximum Load

© 2011 Fairchild Semiconductor Corporation 7 FEBFAN302HL_CH442v1 • Rev. 1.0.0
2.4. DC Output Rising Time
2.4.1. Test Condition
Set output at maximum loading and no loading. Measure the time interval between 10%
and 90% output during startup.
2.4.2. Test Result
Input Voltage Maximum Load (ms) No Load (ms) Specification
90V / 60Hz 4.841 3.185 <20ms
264V / 50Hz 4.882 3.229
2.4.3. Measured Waveforms
Ch4: VO
Figure 5. 90V / 60Hz at Maximum Load
Ch4: VO
Figure 6. 90V / 60Hz at No Load

© 2011 Fairchild Semiconductor Corporation 8 FEBFAN302HL_CH442v1 • Rev. 1.0.0
Ch4: VO
Figure 7. 264V / 50Hz at Maximum Load
Ch4: VO
Figure 8. 264V / 50Hz at No Load

© 2011 Fairchild Semiconductor Corporation 9 FEBFAN302HL_CH442v1 • Rev. 1.0.0
2.5. Line and Load Regulation
2.5.1. Test Condition
Measure line and load regulation as shown in the table below.
2.5.2. Test Result
Input Voltage Output V at Max. Load (V) Output V at Min. Load (V) Load Regulation (%) Specification
90V / 60Hz 4.990 5.116 2.46
115V / 60Hz 4.994 5.116 2.38
132V / 60Hz 4.998 5.116 2.31
180V / 50Hz 5.006 5.112 2.07
230V / 50Hz 5.018 5.112 1.84
264V / 50Hz 5.022 5.112 1.76
Line Regulation(%) 0.64 0.078
2.6. Efficiency
2.6.1. Test Condition
Measure input wattage and output wattage at maximum load.
2.6.2. Test Result
Input Voltage Input Wattage (W) Output Wattage (W) Efficiency (%) Specification
90V / 60Hz 6.938 4.980 71.78
115V / 60Hz 6.808 4.990 73.30
132V / 60Hz 6.748 4.994 74.01
180V / 50Hz 6.719 5.006 74.51
230V / 50Hz 6.743 5.016 74.39
264V / 50Hz 6.797 5.024 73.91
2.6.3. Average Efficiency Test Result
Efficiency(%)
Input
Voltage 25% Load 50% Load 75% Load 100% Load Avg. Spec.
115V / 60Hz 76.06% 75.34% 75.45% 73.30% 74.79%
Avg>68.17%
230V / 50Hz 72.91% 73.52% 74.28% 74.39% 73.78%

© 2011 Fairchild Semiconductor Corporation 10 FEBFAN302HL_CH442v1 • Rev. 1.0.0
Figure 9. Efficiency Chart
2.7. Output Ripple and Noise
2.7.1. Test Condition
Ripple and noise are measured using a 20MHz bandwidth-limited oscilloscope with a
10μF capacitor paralleled with a high-frequency 0.1μF capacitor across each output.
2.7.2. Test Result
Input Voltage Max. Load (mV) Before Leaving Burst Mode (mV) Min. Load (mV) Spec.
90V / 60Hz 38 56 15
<150mV
115V / 60Hz 34 52 16
230V / 50Hz 33 57 25
264V / 50Hz 32 65 22

© 2011 Fairchild Semiconductor Corporation 11 FEBFAN302HL_CH442v1 • Rev. 1.0.0
2.7.3. Measured Waveforms
Ch4: VO
Figure 10. 90V / 60Hz at Maximum Load AC and Burst Ripple
Ch4: VO
Figure 11. 264V / 50Hz at Maximum Load AC and Burst Ripple

© 2011 Fairchild Semiconductor Corporation 12 FEBFAN302HL_CH442v1 • Rev. 1.0.0
2.8. Step Response
2.8.1. Test Condition
Dynamic loading (20%–80%) of the full load, 5ms duty cycle, 2.5A/μs rise/fall time).
2.8.2. Test Result
Input Voltage Overshoot (mV) Undershoot (mV) Specification
115V / 60Hz 105.6 112.0
230V / 50Hz 93.6 86.4
2.8.3. Measured Waveforms
Ch4: VO
Figure 12. 115V / 60Hz at Step Response
Ch4: VO
Figure 13. 230V / 50Hz at Step Response

© 2011 Fairchild Semiconductor Corporation 13 FEBFAN302HL_CH442v1 • Rev. 1.0.0
2.9. Over-Power Protection
2.9.1. Test Condition
Increase output loading gradually. Measure the output maximum power.
2.9.2. Test Result
Input Voltage Output Power (W) Specification
90V / 60Hz 6.00 (4.932V / 1.216A)
115V / 60Hz 6.05 (4.952V / 1.224A)
230V / 50Hz 6.38 (4.958V / 1.290A)
264V / 50Hz 6.40 (4.976V / 1.293A)
2.10. Hold-up Time
2.10.1. Test Condition
Set output at maximum load. Measure the time interval between AC off and output
voltage falling to the lower limit of the rated value. The AC waveform should be off at
zero degrees.
2.10.2. Test Result
Input Voltage Hold-up Time (ms) Specification
90V / 60Hz 11.84
115V / 60Hz 26.06
230V / 50Hz 108.7
264V / 50Hz 149.5

© 2011 Fairchild Semiconductor Corporation 14 FEBFAN302HL_CH442v1 • Rev. 1.0.0
2.10.3. Measured Waveforms
Ch1: VAC
Ch4: VO
Figure 14. 90V / 60Hz at Maximum Load
Ch1: VAC
Ch4: VO
Figure 15. 264V / 50Hz at Maximum Load

© 2011 Fairchild Semiconductor Corporation 15 FEBFAN302HL_CH442v1 • Rev. 1.0.0
2.11. Short-Circuit Protection
2.11.1. Test Condition
Short the output of the power supply. The power supply should enter “Hiccup” Mode
protection with less than 2W input voltage.
2.11.2. Test Result
Input Voltage Input Wattage at
Maximum Loading (W) Input Wattage at Minimum Loading (W) Specification
90V / 60Hz 0.468 0.465 <2W
264V / 50Hz 0.93 0.95
2.11.3. Measured Waveforms
Ch2: Vsense
Ch3: VDD
Ch4: VO
Figure 16. 90V / 60Hz at Maximum Load Short
Ch1: Vsense
Ch3: VDD
Ch4: VO
Figure 17. 264V / 60Hz at Maximum Load

© 2011 Fairchild Semiconductor Corporation 16 FEBFAN302HL_CH442v1 • Rev. 1.0.0
2.12. Brownout Test
2.12.1. Test Condition
Set output at maximum loading. Decrease input voltage with 5VAC step. Record input
wattage and output voltage. After the output is off, increase the AC voltage gradually and
record the recovery voltage.
2.12.2. Test Result
Input Voltage Input Wattage (W) Output Voltage (V)
90V / 60Hz 6.936 4.988
85V / 60Hz 6.962 4.978
80V / 60Hz 7.015 4.976
75V / 60Hz 7.076 4.972
70V / 60Hz 7.174 4.970
65V / 60Hz 7.290 4.966
60V / 60Hz 7.476 4.956
55V / 60Hz 7.413 4.870
50V / 60Hz 7.027 4.666
45V / 60Hz 6.501 4.420
40V / 60Hz 5.793 4.112
35V / 60Hz 4.677 3.642
30V / 60Hz 3.744 3.172
25V / 60Hz 0 0
Recovery Voltage Input Wattage (W) Output Voltage (V)
53V / 60Hz 7.331 4.822 / 0.967A
70V / 60Hz 7.162 4.974 / 1.00A
2.13. VDD Voltage Level
2.13.1. Test Result
Min. Load (V) Max. Load (V) Near OPP (V) Output SC
(Max. Value) (V) Spec.
90V / 60Hz 7.110 8.819 8.829 16.30 <24V
264V / 50Hz 7.830 8.772 8.826 16.10

© 2011 Fairchild Semiconductor Corporation 17 FEBFAN302HL_CH442v1 • Rev. 1.0.0
2.13.2. Measured Waveforms
Ch2: VCS
Ch3: VDD
Figure 18. 90V / 60Hz at No Load
Ch2: VCS
Ch3: VDD
Figure 19. 90V / 60Hz at Maximum Load

© 2011 Fairchild Semiconductor Corporation 18 FEBFAN302HL_CH442v1 • Rev. 1.0.0
Ch2: VCS
Ch3: VDD
Figure 20. 90V / 60Hz at Short Circuit
Ch2: VCS
Ch3: VDD
Figure 21. 264V / 50Hz at No Load

© 2011 Fairchild Semiconductor Corporation 19 FEBFAN302HL_CH442v1 • Rev. 1.0.0
Ch2: VCS
Ch3: VDD
Figure 22. 264V / 50Hz at Maximum Load
Ch2: VCS
Ch3: VDD
Figure 23. 264V / 50Hz at Short Circuit

© 2011 Fairchild Semiconductor Corporation 20 FEBFAN302HL_CH442v1 • Rev. 1.0.0
2.14. Voltage Stress on MOSFET and Rectifiers
2.14.1. Test Condition
Measure the voltage stress on MOSFET and secondary rectifiers under conditions
specified in Table 2.
2.14.2. Test Result
Condition Stress on MOSFET Rating Stress on Output Rectifier Rating
90V / 60Hz, Max. Load 378V
650V
16.2V
40V
90V / 60Hz, Max. Load, Startup 390V 17.1V
90V / 60Hz, Max. Load, Output Short 384V 16.5V
264V / 50Hz, Max. Load 614V 37.2V
264V / 50Hz, Max. Load, Startup 634V 39.1V
264V / 50Hz, Max. Load, Output Short 627V 37.8V
264V / 50Hz, Max. Load Turns Off 621V 37.8V
2.14.3. Measured Waveforms
Ch1: Vdrain
Ch4: Vdiode
Figure 24. 264V / 50Hz at Maximum Load
