Falconeyes VRG-S1 User manual

3
D)
VRG-S1多功能防滑摄像托架
DSLR SHOULDER MOUNTED RIGS
FM1310_VRG-S1_chinese_ENG
使用功能 Function
E) Precaution
E-mail:[email protected]
Websit:www.falconyes.com.hk
Thank you for purchasing FalconEyes’ products.
For further details of our related products, please contact your local
distributor or visit our
webpage at www.falconeyes.com.hk
Please read this manual carefully before using this product.
①.可调挡光板高度
②.无段对焦
③.可调式快拆板及底板
④. 防滑手柄
⑤.护肩负重
⑥.连接零件
⑦.18" 杆, 9"杆, 5" 杆
①.Height-adjustable matte box without filter tray
②.Gearless mini follow focus
③.Quick-release and height-adjustable baseplate
④.Anti-slip and comfortable handle
⑤.Ergonomic shoulder pad with counterweight
⑥.CNC-made connecting parts
⑦.18" rods,9" rods,5" rods
1、使用产品时，请详细阅读产品说明书。
2、购买产品时，请注意查看配件是否齐全。
3、请保持摄像托架干净勿刮伤以免影响使用效果。
4、使用环境应保持干燥、通风注意防潮防水。
1、Please read this user manual carefully before using the product.
2、Please check if all accessories are well attached when purchasing the product.
3、Please keep the rig in good condition, avoid damages in order to get it functioned
properly.
4、Store the product in dry and cool area. Avoid high humidity and direct water on the
product.

1 2 1 2
A)
B) 配件示意图Parts and accessories
C) 安装 Installation
产品概述 product description
VRG-S1 单反相机摄录架采用了多项专业摄影机的元素 , 令使用单反相机摄录可以拍
出专业的水平。摄录架设有一个可调高低的挡光板及可调高低的快装底板 , 可方便调
较相机画面至视线水平 . 快装底板的旁边更设有一个手动对焦滚轮 , 令拍摄时对焦更
准确方便 . 摄录架前端设有两支舒适防滑手柄 , 令稳定性大大提高 . 后面设有连接负重
的护肩 , 令重量得以平衡分布 , 提升稳定性 , 更可令用户减少体力上的负荷。
VRG-S1 DSLR shoulder mounted system has applied many professional cam-
corder factor which can enable DSLR video recording can reach a profes-
sional camcorder standard.
The DSLR shoulder mounted system has a quick release base plate and a
matte box. Both of the quick release base plate and matte box are height adjustable
so it can adjust to eye level. There is a gearless mini follow focus located next to
the base plate. The gearless mini follow focus enable accurate and convenience
focus for shooting. Two comfortable anti-slip handles located at the front which
can improve the stability of the whole system. A shoulder pack with counter weight
is located at the back which improve the balance of weight of the whole system
and improve stability. It can even reduce the physically workload of user.
组合示意图 complete figure
安装分解示意图 installation figure
挡光板 对焦仪 底板
护肩负重 防滑手柄 連接2A
連接2B 5吋连接杆 9吋连接杆 18吋连接杆
松开
旋紧
