Falconeyes TF-L Series User manual

Thank you for purchasing FalconEyes’ products.
For further details of our related products, please contact your
local distributor or visit our webpage at www.falconeyes.com.hk
Thank you.
Please read this manual carefully before using this product.
FM1301_TF-L_eng
D) Technical Data
E) Attention:
TF-L Series LCD Professional Studio Flash
Instruction Manual
3
(Optional: RC-2L - Wireless Remote Control)
Press the key "Channel" to select the desire channel. (Set from C0 to C9)
Test button "Test":
Click test button "Test" to check if the flash unit is in a normal working status.
Power adjustment knob "Power":
- Turning the power knob can adjust the power of the flash or modeling lamp.
- Press down the "POWER" knob can bring the flash unit into hibernation.
TF-400L
400Ws 600Ws 900Ws 1200Ws
150W
1/32-Full,Remote Control Compable
1/700-1/1700
>55°
5500K±200K
AC110-120 60Hz/AC220-240 50Hz
15m
250Ws 250Ws 250Ws
64
1-2sec. 1-4sec.
70 90 100
TF-600L TF-900L TF-1200L
TF-400L(FT) TF-600L(FT) TF-900L(FT) TF-1200L(FT)
Model:
Power:
Modeling
Power Control
GN.(ISO100/m)
Recycle Time
Flash Duraon(t:0.5s)
Angle Of Illuminaon
Color Temperature
Operang Voltage
Remote Distance
Sync Cord / Photo Sensor / Test Buonl / Remotel Control
Power Cord,sync cord,modeling lamp ,standard reflector
Sobox , Barndoor , (Honeycomb & Color Filter Set),Snoot , Light Stand , Umbrella etc.
Triggering
Accessories Included
Oponal Accessories
1. Do not unplug the cable while power is still supplying.
2. Avoid crashing or any types of impact to the flash unit otherwise it would harm
the flash tube as well as decreasing its life span, especiallywhen it is in a working state.
Please find a professional technician for maintenance. Do not dismantle the
flash unit if it’s not necessary.
3. The product is suitable for dry, clean environment, and should not be used
under moisturized and dusty areas. Keep the flash unit away from inflammable,
explosive, and corrosive gas.
4. Emitting heat is a normal phenomenon when the flash unit is working; please
do not touch it with bare hands.
5. Do not flash directly to the photo sensor to avoid the reduction of its sensitivity.

A) Product Feature:
Control Panel
B)
C) Instruction
TF-L is equipped with accurate power regulator and LCD digital display as well
as 2.4GHz anti-interference wireless function. Every TF-L flash provides 10
channels, each channel can individually control 100 units of other TF-L flashes
while set in different IDs (each channel provides selection of 100 different IDs),
allowing the control of 1000 pieces (10 channels x 100 IDs) of TF-L flash in total.
This is a very useful feature when light synchronization is not suitable to use.
With the help of the channels, flashes in the same channels will be trigged while
flashes in other channels will not be interfered. This significantly solves the
problems when working in a large studio where the photographers will always
have to worry about triggering with the unexpected flashes. As long as the
channels are set correctly (same channel and same ID) on both the remote and
flash unit, everything will become a lot easier and efficient.
*Remote working distance is up to 15 meters.
Channel and ID settings
Each flash unit has 10 channels, each channel has 100 IDs, channel and ID are
the identification of the flash unit. Channel and ID must be set through the flash
unit; other functions can be set via the remote control.
Channel: Set C0-C9 (same channel can be triggered with remote control)
ID: set 00-99 (each channel can be set from 00 to 99)
- To trigger one or more flash units: simply set the same channel on the flash unit
and remote.
- To adjust the setting of one or more flash units: simply set the same channel and
ID code on the flash unit and remote.
1 2
Photo Sensor
Menu
Enter
Channel
Sync Cord Socket
LCD Display
Test Button
Sleep &
Power Adjustment
Fuse
Power Socket
Modeling Lamp
Reflector Lock
Handle
Power Switch
Reflector Knob
Lock Knob
Lock Handle
Reflector
Studio Flash LCD Display
Main menu "Menu":
2
REMOTE
BEEPER/OFF
1
BEEPER/ON
3
FREE PROP OFF
FLASH
VARI.
MODEL
..
..
MENU
R
Modeling Lamp and Flash tube work proportionality
Power Output
Menu
Modeling Lamp Off
Flash Power Output
Modeling Lamp Power
ID code
Channel
Beeper Switch
Photo Sensor Off
Pre-flashes mode
Modeling Lamp works
Independently
• When you click the main menu key "Menu",the flash functions "FLASH" blinking.
• Double-click the main menu key "Menu" modeling lamp function blinking, then
press enter key "Enter" to select function. Features choice of three types (1, "FREE"
the monotonous modeling lamp power, "PROP" Modeling lamp synchronized
with the flash power adjustment, "OFF" turn off modeling lamp).
• Consecutively triple-click the main menu key "Menu" beeper function blinking,
then press the Enter key "Enter" to choose the "BEEPER / ON" to turn on the
beeper or select "BEEPER / OFF" to turn off the beeper.
•Consecutively press the menu key "Menu" four times, REMOTE feature blinking,
then press the Enter key "Enter" to select the REMOTE synchronization func-
tion ("REMOTE" turn off the light synchronization, "REMOTE 1" as normal trigger,
"REMOTE 2" is pre-flash trigger function , "REMOTE 3" simply means to pre-flash 2 times.
•Consecutively press the menu key "Menu" five times, ID code first digit blinking,
press the Enter key "Enter" to adjust the parameters.
•Consecutively press the menu key "Menu" six times, ID code second digit blinking,
press the Enter key "Enter" to adjust the parameters. (Or done setting up the first
ID code, click the main menu key "Menu" if it’s still blinking, select the second
ID code).
Adjust the flash and modeling lamp power
By pressing the key "Enter", you can select flash or modeling lamp, then simply
turning the power knob to adjust.
